Kraus KEU12 User manual

www.kraususa.com I Toll Free: 1.800.775.0703 I © 2020 Kraus USA Inc. I REV. March 24, 2020
KEU12 / KEU14/ KE1US21
Porcelain Enameled Steel
Undermount Kitchen Sinks
R
INSTALLATION MANUAL

Congratulations on the purchase of your new
Kraus plumbing fixture!
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance or have any problems with your product:
2
Please contact our Customer Service Team
1-800-775-0703 / [email protected]
Have the model number available and retain a copy of your receipt
with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE
STOP

Prior to Installation:
·Make sure that you have all necessary parts by checking the parts list.
If any part is missing or damaged, please contact Kraus Customer
Service at 800-775-0703 for a replacement.
·Inspect the sink prior to installation to make sure that it has not been
damaged during shipping.
·Use the cut-out template provided by Kraus.
·Observe all plumbing and building codes according to your state
requirements.
·Not recommended to be installed with laminate countertop.
3
For technical assistance or replacement parts, please contact Kraus
Customer Service and one of our representatives will be happy to help:
Toll-Free: 800-775-0703 or [email protected]
The step-by-step guidelines in the installation instructions are a general reference for installing a
Kraus Sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to
install all Kraus products by hiring a licensed professional.

4
Parts List
·Cut-out Template
·Mounting Hardware
Tools you will need:
4
NOTE: Specialized tools may be necessary to install Kraus Porcelain Enameled
Steel Undermount sinks with countertop materials other than wood, marble or
granite.
Safety Goggles Silicone Adhesive Jig Saw
Phillips Screwdriver Tape Measure Pencil
Drill Scissors
Screwdriver Putty Knife

55
Dimensions
19 3/4" (500mm)
21 1/4" (540mm)
15 3/4" (400mm)
17 3/8" (440mm)
7 3/4"
(195mm)
KE1US21
21 1/4” x 17 3/8” x 7 3/4”
Min Cabinet Size: 24”
R3/4"
(20mm)
R1 5/8"
(40mm)
7 1/2"
(190mm)
R3/4"
(20mm)
KEU12
23" x 17 1/2" x 9"
Min Cabinet Size: 27"
KEU14
31 1/2" x 18 3/8" x 10"
Min Cabinet Size: 36"
17 1/2"
(445mm)
15 7/8"
(403mm)
21" (534mm)
23" (584mm)
9"
(230mm)
10"
(255mm)
18 3/8"
(467mm)
16 1/4"
(413mm)
29 1/2" (750mm)
31 1/2" (800mm)
R3 1/2"
(90mm) R3 1/2"
(90mm)

6
1. Determine Reveal Type
Use scissors to cut along the line of the paper template for your desired
reveal type (Negative, Positive or Flushed Reveal).
6
3/8“ Positive Reveal
Flushed/Zero Reveal
1/8“ Negative Reveal
KRAUS Recommended Installation Type
3/8”POSITIVE
1/8”NEGATIVE
FLUSHED/ZERO
Centerline

7
2. Position Template
·Check the cut-out template against the actual sink to ensure a proper
sized cut-out.
·Place the cut-out template in the desired location on the countertop.
NOTE: Make sure clearance is suitable for backsplash, faucet and plumbing for the sink.
3. Trace Template
·Trace template on countertop with a pencil.

8
4. Cut Countertop
·Cut the opening in the countertop by carefully following the traced line.
NOTE: Please use the appropriate saw that best fits your countertop material.

9
5. Set up Mounting Brackets
·Turn countertop over and align sink with countertop. Decide location for
mounting brackets.
·Mounting holes should be 1/2" from edge of sink.
6. Drill Hole in Countertop
·Drill 3/8" diameter x 1/2" deep hole in countertop.
1/2"
(13mm)
3/8 1/2

10
7. Install Anchors
·Insert anchors into drilled holes and lightly tap with a hammer until flush.
8. Secure Sink to Countertop
·Use a bead of silicone (or preferred adhesive) around the rim of the sink.
Check the alignment of the sink to the cutout in the countertop. Place sink
over cutout hole and press firmly.

11
9. Attach Mounting Hardware
·Attach mounting hardware to secure bowl. Remove excess sealant
from inside lip.
·Allow sealant to set for 30 - 60 minutes.
NOTE: Use acetone or rubbing alcohol to remove any excess sealant.

12
10. Install Plumbing Fixtures
·Connect drain to sink. Connect trap to drain. Connect water supply
connections to faucet according to manufacturer's instructions.
·Run water into sink and check for leaks.

13
Codes/Standards Applicable:
Kitchen Sink Warranty
Kraus products are manufactured and tested to the highest quality standards by Kraus USA Inc. (“Kraus”).
Kraus extends this warranty to the original purchaser for personal household use of the “Kitchen Sink” in its original location.
The warranty is non-transferable.
Kraus warrants the structure and finish of the product to be free from defects in material and workmanship under normal
usage for the lifetime of the product. The warranty commences from the initial date of purchase by the owner or trade
professional, from an authorized Kraus dealer, through the lifetime of the original owner or end-user.
Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or
replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is
not transferable to a subsequent owner.
Restrictions
This warranty does not cover antediluvian, discontinued, or display products, whether such items are purchased at discount
outlets, unauthorized dealers, and/or sold on clearance.
This warranty does not cover instances of negligence, misuse, abuse, improper installation, carelessness, accident, hard water
or mineral deposits, exposure to corrosive materials, misapplication, damages caused by improper maintenance, alteration
of the product, or failure to follow care or installation instructions enclosed with your product. Avoid using abrasive cleaners
such as powders, bleach, ammonia, alcohol, or chlorine. Avoid using abrasive pads, steel wool, or wire brushes, as these will
damage and wear down the finish.
This warranty does not apply to Products that have not been installed or operated in accordance with instructions supplied
by Kraus and all applicable rules, regulations, and legislation pertaining to such installations.
This warranty does not apply unless the Kraus product is installed by a fully insured and licensed trade professional. Kraus
insists that such professionals have experience in the installation of bathroom and kitchen manufactured goods.
This warranty does not cover labor charges or costs of removal and reinstallation of said product. This warranty does not
allow
recovery of incidental or consequential damages, such as loss of use, delay, property damage, or other consequential
damages, and Kraus accepts no liability for such damages.
This warranty does not cover Marine or Outdoor Installation.
This warranty does not cover any free gifts included with purchase.
Except as otherwise provided above, Kraus makes no warranties, expressed or implied, including warranties of
merchantability
and fitness for a particular purpose, or compliance with any code.
Shipping charges will be covered for the first (1) year of the warranted replacement part or product (HI, AK, and Puerto Rico
shipping charges may apply). International shipping fees are not included.
UPC
CR

14
Commercial Warranty
Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial,
commercial,
and business use.
All incidental or consequential damages are specifically excluded. No additional warranties, express or implied,
are given, including but not limited to any implied warranty of merchantability or fitness for a particular purpose.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on
how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
KRAUS USA has the right to change, modify, and/or update the warranty policy at any time. For the latest, most
up to date comprehensive warranty, go to www.kraususa.com/warranty
If you are a homeowner, please contact a Kraus Customer Service Representative at:
Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
Toll-Free : 800-775-0703
[email protected]
If you are a plumbing contractor or trade professional, please contact a Kraus Pro
Representative at:
Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8955
[email protected]
If you are an authorized partner, please contact a Partner Support Representative
at:
Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8954
[email protected]
In requesting warranty service, please be ready to provide:
1. Proof of purchase.
2. A description of the problem.
Download the Kraus Care & Maintenance Guide at:
http://www.kraususa.com/maintenance

Register Your Kraus Product
Activate Your Warranty
Access Premium Customer Support
Get Product Information
REGISTER TODAY
http://www.kraususa.com/registration
