KROHNE BATCHFLUX 3100 User manual

Electromagnetic flowmeter for volumetric filling
machines
BATCHFLUX 3100 C
BATCHFLUX 3100 CBATCHFLUX 3100 C
BATCHFLUX 3100 C Quick Start
Quick StartQuick Start
Quick Start
© KROHNE 09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en

CONTENTS
2
www.krohne.com 09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
BATCHFLUX 3100 C
1 Safety instructions 3
2 Installation 4
2.1 Scope of delivery............................................................................................................... 4
2.2 Device description ............................................................................................................ 5
2.3 Nameplate (example) ....................................................................................................... 5
2.4 Storage ............................................................................................................................. 6
2.5 Pre-installation requirements ......................................................................................... 6
2.6 General requirements ...................................................................................................... 7
2.6.1 Vibration .................................................................................................................................. 7
2.6.2 Magnetic field.......................................................................................................................... 7
2.7 Installation conditions ...................................................................................................... 8
2.7.1 Inlet and outlet ........................................................................................................................ 8
2.7.2 Bends in 2 or 3 dimensions..................................................................................................... 9
2.7.3 T-section ................................................................................................................................. 9
2.7.4 Open feed or discharge........................................................................................................... 9
2.7.5 Pump ..................................................................................................................................... 10
2.7.6 Control valve ......................................................................................................................... 10
2.7.7 Flange deviation.................................................................................................................... 11
2.7.8 Mounting ............................................................................................................................... 12
2.7.9 Installation location .............................................................................................................. 12
2.7.10 Adjustment after installation.............................................................................................. 12
2.7.11 Mounting position................................................................................................................ 13
2.7.12 Torques and pressures....................................................................................................... 14
2.7.13 Temperatures ..................................................................................................................... 15
3 Electrical connections 16
3.1 Safety instructions.......................................................................................................... 16
3.2 EMC regulation............................................................................................................... 16
3.3 Grounding ....................................................................................................................... 17
3.4 Electrical connection......................................................................................................18
3.4.1 Cable connector M12 - 5 pin................................................................................................. 18
4 Technical data 19
4.1 Dimensions and weights ................................................................................................ 19
4.2 Counter flanges .............................................................................................................. 20
5 Notes 21

SAFETY INSTRUCTIONS 1
3
BATCHFLUX 3100 C
www.krohne.com09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
Warnings and symbols used
HANDLING
• This symbol designates all instructions for actions to be carried out by the operator in the
specified sequence.
i RESULT
RESULTRESULT
RESULT
This symbol refers to all important consequences of the previous actions.
Safety instructions for the operator
DANGER!
This information refers to the immediate danger when working with electricity.
DANGER!
These warnings must be observed without fail. Even partial disregard of this warning can lead to
serious health problems and even death. There is also the risk of seriously damaging the device
or parts of the operator's plant.
WARNING!
Disregarding this safety warning, even if only in part, poses the risk of serious health problems.
There is also the risk of damaging the device or parts of the operator's plant.
CAUTION!
Disregarding these instructions can result in damage to the device or to parts of the operator's
plant.
INFORMATION!
These instructions contain important information for the handling of the device.
CAUTION!
Installation, assembly, start-up and maintenance may only be performed by appropriately
trained personnel. The regional occupational health and safety directives must always be
observed.
LEGAL NOTICE!
The responsibility as to the suitability and intended use of this device rests solely with the user.
The supplier assumes no responsibility in the event of improper use by the customer. Improper
installation and operation may lead to loss of warranty. In addition, the "Terms and Conditions of
Sale" apply which form the basis of the purchase contract.
INFORMATION!
• Further information can be found in the manual, on the data sheet, in special manuals,
certificates and on the manufacturer's website.
• If you need to return the device to the manufacturer or supplier, please fill out the form
contained in the manual and send it with the device. Unfortunately, the manufacturer cannot
repair or inspect the device without the completed form.

2INSTALLATION
4
BATCHFLUX 3100 C
www.krohne.com 09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
2.1 Scope of delivery
INFORMATION!
Inspect the packaging carefully for damages or signs of rough handling. Report damage to the
carrier and to the local office of the manufacturer.
INFORMATION!
Do a check of the packing list to make sure that you have all the elements given in the order.
INFORMATION!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
Figure 2-1: Scope of delivery
1 Flowmeter in ordered size
2 Product documentation (on request)
3 Calibration report (on request)
INFORMATION!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.

INSTALLATION 2
5
BATCHFLUX 3100 C
www.krohne.com09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
2.2 Device description
Your measuring device is supplied ready for operation. The factory settings for the operating
data have been made in accordance with your order specifications.
The following compact versions are available:
•Only available in size DN 15
INFORMATION!
Product specific information and extensive product specification is available using PICK, the
Product Information Center KROHNE web-tool.
PICK can be found via the service menu button on the KROHNE.com website.
Figure 2-2: Device version
2.3 Nameplate (example)
Figure 2-3: Example of nameplate
1 Name and address of the manufacturer
2 Type designation, S/N number, software revision number and year of manufacturing
3 Device data, temperature and pressure limits, electrical values and protection category
4 Calibration data, size and wetted materials
5 Tag number
6 Manufacturer website, marking (e.g. CE and environmental marking)
7 Data matrix

2INSTALLATION
6
BATCHFLUX 3100 C
www.krohne.com 09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
2.4 Storage
•Store the device in a dry and dust-free location
•Avoid lasting direct exposure to the sun
•Store the device in its original packaging
•Storage temperature: -20 ...+70°C / -4...+158°F
2.5 Pre-installation requirements
Make sure that you have all necessary tools available:
•Torque wrench for installing flowmeter in pipeline.
Always tighten the bolts uniformely and in diagonally opposite sequence!
Accessories necessary for the correct installation are available on request at the manufacturer.
Make sure that these accesoires are available before starting installation:
•O-rings
•Special pipe flanges
•Stud bolts with lockwasher, plain washer and nut
INFORMATION!
To facilitate servicing and/or exchanging of the device, please note that:
• it must be possible to shut off the flow through the pipeline (control valve upstream in
pipeline).
• Drain the pipeline before removing device (provide drain valve).

INSTALLATION 2
7
BATCHFLUX 3100 C
www.krohne.com09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
2.6 General requirements
2.6.1 Vibration
2.6.2 Magnetic field
INFORMATION!
The following precautions must be taken to ensure a reliable installation.
• Make sure that there is adequate space to the sides.
• Protect the signal converter from direct sunlight and install a sun shade if necessary.
• Support the pipeline on both side of the flowmeter.
• Do not expose the flowmeter to intense vibration. The flowmeters are tested for a vibration
level in accordance with IEC 61298-3
Figure 2-4: Avoid vibrations
Figure 2-5: Avoid strong magnetic fileds

2INSTALLATION
8
BATCHFLUX 3100 C
www.krohne.com 09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
2.7 Installation conditions
2.7.1 Inlet and outlet
D > 25°
Figure 2-6: Horizontal piperun
CAUTION!
Install in a slightly descending pipe section , to prevent air from collecting and to avoid faulty
measurements (meter can drain).
INFORMATION!
Support the pipeline on both side of the flowmeter. Make sure the M12 connector is on the flow
inlet side.
Figure 2-7: Inlet and outlet section
1 Refer to chapter "Bends in 2 or 3 dimensions"
2 t2 DN
3 Drain valve (to empty pipeline)
3

INSTALLATION 2
9
BATCHFLUX 3100 C
www.krohne.com09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
2.7.2 Bends in 2 or 3 dimensions
2.7.3 T-section
2.7.4 Open feed or discharge
D > 25°
1Drain valve (to empty pipeline)
Figure 2-8: 2 and/or 3 dimensional bends upstream of the flowmeter
1 2 dimensions = X/Y
2 3 dimensions = X/Y/Z
Inlet length: using bends in 2 dimensions: t5 DN; when having bends in 3 dimensions: t10 DN
INFORMATION!
2 dimensional bends occur in a vertical or
oror
or horizontal plane (X/Y) only, while 3 dimensional bends
occur in both vertical and
andand
and horizontal plane (X/Y/Z).
Figure 2-9: Distance behind a T-section
1 t10 DN
Figure 2-10: Installation in front of an open discharge

2INSTALLATION
10
BATCHFLUX 3100 C
www.krohne.com 09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
2.7.5 Pump
D > 25°
1Drain valve (to empty pipeline)
2.7.6 Control valve
D > 25°
1Drain valve (to empty pipeline)
Figure 2-11: Installation behind a pump
Figure 2-12: Installation in front of a control valve

INSTALLATION 2
11
BATCHFLUX 3100 C
www.krohne.com09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
2.7.7 Flange deviation
Figure 2-13: Mounting position and flange deviation
1 L
max
2 L
min
CAUTION!
Max. permissible deviation of pipe flange faces:
L
max
- L
min
d0.5 mm / 0.02"
CAUTION!
Install the device always with the 4 rods or bushes supplied. Non compliance will lead to
damaging of the tube or leaking.

2INSTALLATION
12
BATCHFLUX 3100 C
www.krohne.com 09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
2.7.8 Mounting
2.7.9 Installation location
2.7.10 Adjustment after installation
It is not allowed to use any force (turning or rotating) on the device after installation between
flanges and with the bolts already tightened.
Figure 2-14: Horizontal installation
CAUTION!
Mount the flow sensor in such a way that the electrode axis
(X--------X) is approximately in a horizontal pipe run.
Figure 2-15: No force on device after installing
1 After installation between flanges
2 No turning or twisting of device
CAUTION!
Do not use a rotation force on the device once mounted between flanges. The device will be
damaged!
CAUTION!
The (counter) flanges are installed with M6 studs and nuts, positioned and fastened through the
four bushing rods. Do not exceed the specified torque!

INSTALLATION 2
13
BATCHFLUX 3100 C
www.krohne.com09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
2.7.11 Mounting position
The flowmeter can be installed in every position.
D > 25°
1Drain valve (to empty pipeline)
Figure 2-16: Installation in bending pipes
CAUTION!
Install in a slightly descending pipe section (of 25 degrees or larger), to prevent air from
collecting and to avoid faulty measurements (meter can drain).
CAUTION!
To ensure a correct measurement, avoid draining or partial filling of the flow sensor during
operation.
INFORMATION!
Vertical down position only in conjunction with a control valve.

2INSTALLATION
14
BATCHFLUX 3100 C
www.krohne.com 09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
2.7.12 Torques and pressures
The maximum pressure and torques values for the flowmeter are theoretical and calculated for
optimum conditions and use with steel counter flanges.
Tightening of bolts
• Always tighten the bolts uniformly and in diagonally opposite sequence.
• Do not exceed the maximum torque value.
• Step 1: Apply approx. 50% of max. torque given in table.
• Step 2: Apply approx. 80% of max. torque given in table.
• Step 3: Apply 100% of max. torque given in table.
Figure 2-17: Tightening of bolts
Nominal
size
Counter flanges Max.
operating
pressure
Bolts Bush /
spacer
Max. torque
[Nm]
Flange
size
Flange
class
DN15 15 [mm] PN16 d8 [bar] 4 x M8 solid spacer 22
4 x M6 open bush 9
½"½[inch] 150 [lb] d116 [psi] 4 x M8 solid spacer 22
4 x M6 open bush 9

INSTALLATION 2
15
BATCHFLUX 3100 C
www.krohne.com09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
2.7.13 Temperatures
Process temperature vs ambient temperature
1 Ambient temperature
2 Process temperature
3 Temperature area for continuous process
4 Temperature area for cleaning, up to 1 hour
INFORMATION!
For more information on temperatures, refer to the relevant Manual or the Technical
specifications.

3ELECTRICAL CONNECTIONS
16
BATCHFLUX 3100 C
www.krohne.com 09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
3.1 Safety instructions
3.2 EMC regulation
EMC radiation limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment
DANGER!
All work on the electrical connections may only be carried out with the power disconnected.
Take note of the voltage data on the nameplate!
DANGER!
Observe the national regulations for electrical installations!
WARNING!
Observe without fail the local occupational health and safety regulations.
Any work done on the electrical components of the measuring device may only be carried out by
properly trained specialists.
INFORMATION!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
CAUTION!
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio
communications.
CAUTION!
The device shall not be used with long-distance lines longer than 30 meters, or which leave the
building (including lines of outdoor installations).
CAUTION!
This equipment is not intended for use in residential environments and may not provide
adequate protection to radio reception in such environments.

ELECTRICAL CONNECTIONS 3
17
BATCHFLUX 3100 C
www.krohne.com09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
3.3 Grounding
Figure 3-1: Grounding
1 Metal grounding strip
2 Grounding of the installation
CAUTION!
The groundingstrip should not transmit any interference voltage. Therefore do not ground any
other electrical device at the same conductor.
CAUTION!
When connecting to functional extra-low voltages (24VDC), ensure that you use protective
separation (PELV) according to IEC 60364/IEC 61140 or VDE 0100/VDE 0106.
CAUTION!
The installation requires metal piping and flanges on both sides of the process connections to
ensure galvanic connection to the liquid.
CAUTION!
Do not use excessive force to tighten the M12 nut, when connecting the metal ground strip
(maximum torque allowed d4 Nm).

3ELECTRICAL CONNECTIONS
18
BATCHFLUX 3100 C
www.krohne.com 09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
3.4 Electrical connection
3.4.1 Cable connector M12 - 5 pin
All the operating data are preset at the factory. For changing the parameters and diagnostic
purposes BATCHMon plus operation software can be used.
Note; the switch circuits are polarity sensitive and have a resistance of approximately 76 Ohm.
Use one of the following attachment plug types to connect the flowmeter to a third
party system:
•moulded plug, straight or angle-entry form
•integrally extruded plug with cable in various lengths
•moulded plug, straight form, especially suitable for high-interference environments
1 +24 VDC
2 Frequency output
3 Frequency output (ground)
4 Ground
5 To be connected for servicing only
Figure 3-2: Connection diagram
INFORMATION!
Cables for electrical installation are available at request, please contact the supplier.
When purchasing cables, make sure the material and protection class are suitable for the
installation conditions. Contact the manufacturer support office, for suitable cables options.

TECHNICAL DATA 4
19
BATCHFLUX 3100 C
www.krohne.com09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
4.1 Dimensions and weights
Weight: 0.24 kg - 0.53 lbs
Weight: 0.18 kg - 0.39 lbs
DN15 version with solid spacer
1 M12; 5 pins connector (Grounding)
2 Grounding strip - R (radius mounting hole) = 4.3 mm / 0.17 inch)
DN15 version with spacer bush
1 M12; 5 pins connector (Grounding)
2 Grounding strip - R (radius mounting hole) = 3.1 mm / 0.1 inch
Dimensions [mm - inches] ±½mm - 0.1
a b c d e f g h i j k l m n o p q
DN15 41 7136 22 15 20 853 75 36 31 53 34 50 54 83 18
1/2" 1.6 0.3 5.5 0.9 0.6 0.8 0.3 2.1 3.0 1.4 1.2 2.1 1.3 2.0 2.1 3.3 0.7

4TECHNICAL DATA
20
BATCHFLUX 3100 C
www.krohne.com 09/2020 - 4008472601 - QS BATCHFLUX 3100 - R01 en
4.2 Counter flanges
The BATCHFLUX 3100 C must be mounted between counter flanges (as shown in the following
drawing), to ensure that the device works correctly.
Dimensions:
Figure 4-1: Flange according DIN 11850 row 2 / DIN 11866 row / EN 10357 Serie A
Figure 4-2: Flange according DIN 11850 row 2 / DIN 11866 row / EN 10357 Serie A
Øa b c d O-ring
[mm] 14 19 26.2 30.4 15.5 x 3.5
inch 0.5 0.75 1.03 1.2 0.61 x 0.14
INFORMATION!
Detailed construction drawings of the above sketches are available from the manufacturer
website.
