Kuat Transfer2 User manual

TRANSFER2
USER GUIDE

2
(1) Hitch Washer
(1) Hitch Lock Washer
PARTS INCLUDEDHARDWARE INCLUDED
PARTS LIST
TOOLS INCLUDED
8mm
19mm
(1) Pivot Bolt
(2) Front Tire Cradle
(2) Rear Tire Cradle
(2) Arm Puck
(2) Arm Ratchet Tube
(2) Rear Tire Strap
(2) Arm Knuckle
(2) Ratchet Handle
(1) Hitch Stinger
(2) End Cap
(1) Pivot Nut
(1) Pivot Washer
(2) Plate
(2) Spacer
(4) M6 Nut
(2) M5 Nut
(2) Locator Tab Bolt
(4) M6 x 90
(4) M6 x 60
(4) M6 x 60 Low Prole
(2) M5 x 30
(1) Hitch Bolt (1) Cotter Pin
5mm
4mm

3
x1 x1
ASSEMBLY INSTRUCTIONS
Slide front tire cradle
into position.
Front Tire Cradle Locator Tab Bolt
Install bolt with locator
tab as shown.
Reference page 18 for
information on locator tab
functionality.

4
x1 x1 x1
Slide rear tire cradle
into position.
Secure with bolt and spacer.
Rear Tire Cradle SpacerM6 x 90

5
x1 x2
Slide arm puck into position with
the pre-installed nuts facing out.
Install screws.
Arm Puck M6 x 60

6
x2
x2
x1
x1 x1
Assemble tire hook arm.
NOTE: Use arm without Küat logo.
Arm Ratchet Tube
Arm Knuckle
Ratchet Handle
M6 x 60 Low Prole
M6 Nut

7
x1
x1 x1
Slide tire hook arm
onto puck.
Install arm tensioner
plate and bolt.
PlateM6 x 90Assembled Arm

8
x1 x1
Slide front tire cradle
into position.
Install bolt with locator
tab as shown.
Front Tire Cradle Locator Tab Bolt
Reference page 18 for
information on locator tab
functionality.

9
x1 x1 x1
Slide rear tire cradle
into position.
Secure with bolt
and spacer.
Rear Tire Cradle SpacerM6 x 90

10
x1 x2
Slide arm puck into position with the
pre-installed nuts facing out.
Install screws.
Arm Puck M6 x 60

11
x2
x2
x1
x1 x1
Assemble tire hook arm.
NOTE: Use arm with Küat logo.
Arm Ratchet Tube
Arm Knuckle
Ratchet Handle
M6 x 60 Low Prole
M6 Nut

12
x1 x1
Slide tire hook arm
onto puck.
Install arm tensioner
plate and bolt.
Plate
M6 x 90

13
x2 x2
x2
Place nuts into caps, insert
caps, attach with screws.
M5 x 30
M5 Nut
Cap

14
x2
x1 x1
x1
x1
Thread tire strap through both ratchets.
Open side should face end caps.
Install hitch shank with
pivot bolt, washer and nut.
Remove stretch wrap.
DO NOT TIGHTEN PEDAL BOLTS
Pivot Nut
Pivot Bolt
Pivot Washer
Hitch Shank
Tire strap

15
Thread the hitch bolt with washers into the hitch, secure bolt
with cotter pin. Tigthen with 8mm allen or 9mm box wrench.
Insert rack into hitch.
x1 x1
x1 x1
For 1-1/4” hitches remove 2”
hitch adapter by removing
6mm socket bolt.
Lock Washer
Hitch Bolt
Washer
Cotter Pin

16
USING THE RACK
STEP 2
BEFORE ATTEMPTING TO LOAD A BICYCLE CHECK:
• The rack is secured to the hitch.
• The pivot lever is fully engaged in position.
Adjust rear tire cradle position to t
bicycle. Tighten tire strap evenly.

17
STEP 1
Place tire hook as close as possible
to fork and then ratchet the tire hook
down tightly to the tire.

18
The Transfer rack pivots upward for travel and pivots down to
allow trunk or hatch access.
CAUTION
PINCH
POINT
!
The front tire cradle bolts locator tab can be ipped upside-
down to adjust the pitch of the bike for a better t or to eliminate
interference between multiple bikes.

19
ACCESSORIES
Phat Bike Kit
Product #APBK
kuatparts.com/transfer
Lock Kit
Product #ATSCLK12 TRANSFER2Kit
Product #ATSCLK13 TRANSFER3Kit
• For use with 2.75-4.25” width tires
• Compatible with the Transfer and NV racks
• Kit includes hitch lock and cable locks

KUATRACKS.COM
1.877.822.5828
[email protected]
