Preface
The illustrated manual will help you understand and be familiar with the meter
function, guiding you on how to operate the meter, how to set the project parameters, how
to achieve the best match of the three as motor, controller and meter to improve electronic
control performance of the electric motor. This manual covers installation, operation,
parameter setting of the meter and how to use it properly, which help you resolve the
problems appeared in practical use.
Outlook and Size
○Meter Dimension
Meter Dimension
Dual Bracket Mounting Dimension
○Main Material and Color

ELECTRIC BICYCLE METER KT—LCD10YN Product User Manual
- 5 -
PC material is mainly used for KT-LCD10YN meter and button box housing, and the
housing color is black.
○Wiring Schematic
Installation Instruction
The meter body and button box are mounted on the handlebars of the electric vehicle,
adjusting perspective. In the case that the vehicle is power off, the meter connectors are in
plug connection to corresponding controller connectors. Turn on the power, electric
vehicle and meter will be under normal operation, the meter installation is finished. The
protection film on meter display panel should be torn.
○Physical installation icon
Function Overview
KT-LCD10YN meter provide you with a variety of functions such as vehicle controls
and vehicle status digitized displays to meet the trip demands.
◇Trip time display (with displays of a single trip time (TIM) and total trip time (TTM));
◇Trip speed display (with displays of real-time speed (Km/H or MPH) and a single
maximum speed (MXS) and a single average speed (AVS));
◇Trip distance display (with displays of a single trip distance (DST) and total trip distance
(ODO));

ELECTRIC BICYCLE METER KT—LCD10YN Product User Manual
- 6 -
◇Display of turned on handlebar;
◇Display of power-assist startup;
◇Power assistant ratio (or handlebar) gear (PAS) switch;
◇6Km/H power assistant push ( ) function;
◇Cruise function (CRUISE);
◇Battery capacity indicator ( );
◇Real-time battery voltage (VOL) display;
◇Motor power and temperature (MOTOR W) and (MOTO ℃) display;
◇Brake display ( );
◇Turn on backlighting and lights ( );
◇Environment temperature (℃ or ℉) display;
◇Data clearing;
◇Fault code display;
◇User parameter setting
◇24V, 36V, 48V supply voltage can automatic identification and be compatible
Display Content
The display content is shown as follow.
Button Definition
KT-LCD10YN meter adopts the structural form with part design buttons.

ELECTRIC BICYCLE METER KT—LCD10YN Product User Manual
- 7 -
There are three keys on the operating panel of button box, which are icons of
button (alt text UP), button (alt text SW) and (alt text DOWN).
Normal Operation
○On/Off
Hold button (SW) long, the meter is powered on and into normal operation, and
it provides the controller with power supply. Under normal operating status, hold
button (SW) long, the meter is powered off, meanwhile to shutdown the power supply of
controllers. When the vehicle is stopped and without any button operation on the
meter for five minutes, the meter will automatically shut down, and the power supply
of the electric vehicle will be powered off. In power off mode, the power consumption of
the meter and controller is zero.
○Display Interface
Display 1：
The meter is startup to enter display 1.
Display 1
The followings are shown on display 1.

ELECTRIC BICYCLE METER KT—LCD10YN Product User Manual
- 8 -
Battery Capacity Indicator Single Trip Time (TM) Display
Power Assist Ratio Gear (ASSIST) Real-time Trip Speed (Km/H)
Single Trip Distance 6Km/H Power Assist Function
Motor Operation Power Environment Temperature
Backlights and Headlights Status Brake Status
Cruise Function (CRUISE) Motor Running Temperature
Display 2：
In display 1, press button (SW) to enter display 2.

ELECTRIC BICYCLE METER KT—LCD10YN Product User Manual
- 9 -
Display 2
The followings are shown on display 2:
Total Trip Time (TTM) Total Trip Distance (ODO)
Single Average Speed (AVS) Motor Operating Temperature
In the riding mode within 5 seconds, display 2 automatically returns to display 1.
In display 1, the original motor power is replaced by motor running temperature as is
shown in Figure.
Display 3：
In display 2, press button (SW) to enter display 3.
