Kuppersberg NSFF 195752 Installation and maintenance instructions

TECHNICAL PASSPORT
ПАСПОРТ ТЕХНИЧЕСКОГО ИЗДЕЛИЯ
REFRIGERATORS
ХОЛОДИЛЬНИКИ
NSFF 195752

2
TECHNICAL PASSPORT ENGLISH
Refrigerator NSFF 195752
SAFETY PRECAUTION............................................................................................................ 4
PARTS.............................................................................................................................................. 5
PLACEMENT................................................................................................................................. 6
OPERATION CHECK................................................................................................................. 7
FOOD STORAGER ..................................................................................................................... 10
MAINTENANCE.......................................................................................................................... 11
TROUBLE SHOOTING............................................................................................................. 12
ENERGRY SAVING TIPS......................................................................................................... 15
CONTENTS

3
ENGLISH TECHNICAL PASSPORT
Refrigerator NSFF 195752
WARNING
1) The appliance has to be
unplugged after use and before carrying
out user maintenance on the appliance.
2) This appliance is not intended
for use by persons(including children)
with reduced physical ,sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use
of the appliance by a person responsible
for their safety.
3) Children should be supervised
to ensure that they do not play with the
appliance.
4) If the supply cord is damaged,
it must be replaced by manufacturer,
its service agent or similarly quali ed
persons in order to avoid a hazard.
5) Save these instructions and be
sure that they remain with the appliance
if it is moved or sold,so that anyone, using
it throughout its life, will be properly
informed on usage and safety notices.
6) Do not use mechanical devices or
other means to accelerate the defrosting
process, other than those recommend by
the manufacturer.
7) Do not damage the refrigerant
circuit.
8) Do not use electrical appliances
inside the food storage compartments of
the appliance, unless they are of the type
recommended by the manufacturer.
9) please abandon the refrigerator
according to local regulators for it use
 ammable blowing gas.
10) Keep ventilation openings, in the
appliance enclosure or in the built-in
structure, clear of obstruction.
11) Do not store explosive substances
such as aerosol cans with a  ammable
propellant in this appliance.
12) This appliance is intended
to be used in household and similar
applications such as
staff kitchen areas in shops,
of ces and other working environments;
farm houses and by clients in
hotels, motels and other residential type
environments;
bed and breakfast type
environments;
catering and similar non-retail
applications.
13) When fresh food are introduced
into food freezer compartment, the
appliance should be set in operation in
the fast freezing condition.
14) This appliance can be used by
children aged from 8 years and above and
persons with reduced physical,sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved.Children
shall not play with the appliance.Cleaning
and user maintenance shall not be made
by children without supervision.
by children without supervision.
WARNING: When positioning the
appliance, ensure the supply cord is not
trapped or damaged.
trapped or damaged.
WARNING: Do not locate multiple
portable socket-outlets or portable power
supplies at the rear of the appliance.
REFRIGERATOR
If the refrigerant circuit should be
damaged:
Avoid opening  ames and sources of
ignition.
Thoroughly ventilate the room in
which the appliance is situated.
It is dangerous to modify this produce
in any way.

4
TECHNICAL PASSPORT ENGLISH
Refrigerator NSFF 195752
SAFETY PRECAUTION
Please always follow the safety
hint listed below:
The power supply for the unit should
be exactly the same as described on the
data sheet, and use the standard triprong
socket.
The unit should be operated in the
absence of  ammable or explosive fumes.
It is prohibited to put the  ammable, acid
or volatile goods in cabinet.
Please unplug the unit first when
you replace the light bulb or repair the
refrigerator.
Please unplug the unit immediately
if you  nd any abnormal smell or smoke,
and contact your local service center.
Hanging or sitting on the door is
very dangerous, it may overturn the unit
and subvert the goods in (oron) the
refrigerator.

5
ENGLISH TECHNICAL PASSPORT
Refrigerator NSFF 195752
PARTS
Due to the production’s improvement, the unit you purchased maybe different
from below sketch.
1) Lamp
2) Upper Balcony on Fridge Door
3) Fridge Door
4) FreshRoom
5) Lower Balcony on Freezer Door
6) Galss Shelf
7) Crisper Cover
8) Crisper
9) Freezer Compartment Drawe
10) Adjustable Feet
1. Display screen
2. Lamp
3. Upper shelf of refrigerating chamber
4. Lower shelf of refrigerating chamber
5. Glass shelf

6
TECHNICAL PASSPORT ENGLISH
Refrigerator NSFF 195752
PLACEMENT
1) The unit should be placed in a ventilated and dry environment. Do not put
the unit in direct sunshine, and keep it as far as possible from heat sources.
2) The unit should be placed on  at and steady ground. Keep the unit level by
adjusting the front leg levelers.
3) Don’t put the unit in cold area.
4) There should be enough spare space around the unit as shown, to allow
proper ventilation.

7
ENGLISH TECHNICAL PASSPORT
Refrigerator NSFF 195752
OPERATION CHECK
It may not work properly if being left at a temperature above or below the
indicated rang for a long period.
Climate class Ambient temperature
SN +10°C to +32°C
N +16°C to +32°C
ST +16°C to +38°C
T +16°C to +43°C
Make sure the unit has been placed
properly and all instructions have been
observed.
Adjust the control knob to the
middle position, and then plug in the
unit. After closing the door for several
minutes, both side of cabinet becomes
warm.
30 minutes later, open the freezer
compartment door, feel the cold air,
that means the unit works properly.
After a period of time the thermostat
will switch off & on automatically and
set the compartments at the desired
temperature.

8
TECHNICAL PASSPORT ENGLISH
Refrigerator NSFF 195752
CONTROL PANEL
Use your appliance according to
the following control regulations,
your appliance has the corresponding
functions as the control panels showed
in the pictures below.
OPERATION DISCRIPTION
Keep long press «unlock» button
for 3 seconds, then you can press other
buttons for operating.
Touch the «room» button,the current
room will  ash, and then press the
«room» button again, you can choose
between the fridge rooms and freezer
romms. If there is no operation for more
than 5S,the default will be con rmed,
then the settings take effect.
Touch the «Temperature» button,
the temperature of compartment will
increase and cycle.
Short press «function» button to
select the different mode.
FRIDGE TEMPERATURE SETTING
Press the «room» button, select the
fridge compartment, indicator  ash;
Each time of press «temperature»
key, the temperature rise and cycle
as 23 ... ...  8OF2
3 ... ...  8OF, no operation for
5S, display  ash stopped, the settings
take effect. OF means stopping cooling.
FREEZER TEMPERATURE
SETTING
Press the «room» button, select the
freezer compartment, indicator  ash;
Each time of press «temperature»
key, the temperature rise and cycle as
-25... ... -16-15-25... ... 
-16-15,
no operation for 5S, display  ash
stopped, the settings take effect.

9
ENGLISH TECHNICAL PASSPORT
Refrigerator NSFF 195752
MODE DESCRIPTION
MODE SETTING
Press the «function» button, the
current mode will ash; you can choose
beteen smart, quick cooling, quick
freeze, holiday and other four modes
by pressing the «function» button; If
there is no operation for more than
5S,the default will be conrmed, then
the settings take effect; when you’re
setting the temperature , you’ll exit this
function freeze and the light indicator
off.
SMART MODE
The refrigerator will adjust the
temperature automatically according
to the ambient temperature and the
temperature inside the refrigerator, you
don’t have to choose the temperature
by yourself, save your time and effort.
QUICK COOLING MODE
In thhis mode,the temperature of
fridge comparment will reach setted
temperature quickly ,which will help to
keep the food fresh. If you want to put
much food in the refrigerator at once,
please choose this mode.
QUICK FREEZE MODE
The food will be frozen in a short
time. Note: This mode has a duration of
6 hours and a duration of 48 hours for
both time modes to be chosed. When
entering the quick freeze function
normally, it defaults to a 6 hour quick
time mode. If you need to enter the 48
hour quick-freezing function you also
need to do the following: in the quick-
freeze function has been effective,
continue to hold the «function» key and
«temperature» button for 5 seconds,
enter the set frozen time selection,
frozen temperature display area display
the current freezing time (unit: hours),
the remaining icons are not displayed;
then press the «temperature» key to
set the quick-freezing time, set the
order of 48 ^ 6 ^ 48 ... ^ 6 cycles; 5s
no key operation after the automatic
lock conrmation or press the «unlock»
button for 3 seconds, the settings take
effect, and return to the normal state.
Frozen mode takes effect immediately
after you have nished setting, and
automatically exits and returns to
normal control when the quick freeze
time is set.
HOLIDAY MODE
When you and your family intend to
go on holiday, and no one at home, you
can choose this mode. The fridge and
freezer compartment will automatch
the appropriate temperature in this
mode.
FRAPPE MODE
There is a special drawer for drinks
in the fridge compartment. You can
choose the mode to quick cool the drink
and have a better feeling.
Long press 3 seconds «unlock»
button, then long press 3 seconds
«function» button to choose this
function; when the drink area achieving
the setteled temperature, the light off
and function stopped.
When you need to start the function
again, you can repeat the operation.

10
TECHNICAL PASSPORT ENGLISH
Refrigerator NSFF 195752
FOOD STORAGE
The temperature in the fresh
compartment is between 0~10°C,
although this lower temperature can
limit the bacteria propagation, it is
not suitable for a long period of food
storage.
FRESH FOOD STORAGE
Cooked food should be cooled down
to room temperature before putting
into the refrigerator. It is better to put
the food in a sealed bag before placing
into the refrigerator.
In order to keep vegetables fresh
in the crisper, any water should be
removed  rst, otherwise the vegetables
may spoil. If you put the vegetables in
the bag. they may be stored for a longer
period.
period.
CONTROL KNOB
Is used to adjust the temperature of
different compartment. User can adjust
for desired temperature.
User can adjust the temperature of
cooling by turn-control knob located at
the back of the cooling zone cabinet.
According to the above picture. the knob
is used for controlling temperature of
cooling. Temperature shall get lower if
turning the knobs by clockwise sense
while I get higher if anticlockwise.
FROZEN FOOD STORAGE
The temperature of the freezer is
colder than -18°C. It is to store food to
be kept for a long period.
After buying frozen food, please put
it into the freezer compartment as soon
as possible.

11
ENGLISH TECHNICAL PASSPORT
Refrigerator NSFF 195752
Any hot food must be cooled down
to room temperature before it is put
into the freezer.
Please don’t put glass containers
 led with liquid into the freezer
compartment as the glass may break.
It is better to presort the foods
before putting them into the freezer.
Put the same kinds of food together to
help to minimize the time to the freezer
door opening when you take the food
out,and helps to save energy.
The food should be put too close to
the outlet or inlet of the air ow. It may
affect the air circulation.
When it stops working, users
should remove the food inside freezer
compartment to check if all is ok.
MAINTENANCE
CLEANING
Always unplug the unit before
cleaning.
The unit should be cleaning
frequently both inside and outside using
water and a little neutral detergent.
Never use boiling water, harsh
cleaning agents, acid, alkali or benzene
etc.
This product must be serviced by
an authorized service center, and only
genuine spare parts must be used.
1) If the appliance is frost free.
2) If the appliance contains freezer
compartment.

12
TECHNICAL PASSPORT ENGLISH
Refrigerator NSFF 195752
WATER PAN CLEANING
The water pan is located in the back
of cabinet. Its function is to collect and
evaporate the defrost water. Usually
it doesn’t need special care, but if you
 nd some water over ow or odd smell,
it may need to be checked and cleaned.
Pull out the power cord  rst. Lift the
water pan up a little, and then pull it
straight out carefully.(Caution: make
sure the discharge pipe is not too hot).
After cleaning, re x the water pan into
the original position. Make sure that
the pipe is on the top of the water pan
before you push it into the original.
LEAVING THE NUIT
SWITCHED OFF
If the unit will be switched off for a
long time, the plug should be pulled out,
the clean the unit thoroughly. Ensure
that the door cannot be fully closed
(leaved a suitable gap), and place the
unit in a well-ventilated area to avoid
any odor.
REPLACING THE LED LIGHT
Warning: The LED light must not be
replaced by the user! if the LED light is
damaged, contact the customer helping
for assistance. To replace the LED light,
the below steps can be followed:
3) Unplug your appliance.
4) Remove light cover by pushing
up and out.
5) Hold the LED cover with one
hand while pressing the connector
latch.
TROUBLE SHOOTING:
If you experience a problem with
your appliance or are concerned
that the appliance is not functioning
correctly, you can carry out some easy
checks before calling for service,please
see below.
Warning! Don’t try to repair the
appliance yourself. If theproblem
persists after you have made the checks
mentioned below, contact a quali ed
electrician, authorized service engineer
or the shop where you purchased the
product.

13
ENGLISH TECHNICAL PASSPORT
Refrigerator NSFF 195752
Problem Possible cause & Solution
Appliance is
not working
correctly
Check whether the power cord is plugged into the power outlet
properly.
Check the fuse or circuit of your power supply, replace if
necessary.
The ambient temperature is too low. Try setting the chamber
temperature to a colder level to solve this problem.
It is normal that the freezer is not operating during the
automatic defrost cycle, or for a short time after the appliance is
switched on to protect the compressor.
Odours
from the
compartments
The interior may need to be cleaned
Some food, containers or wrapping cause odours.
Noise from the
appliance
The sounds below are quite normal:
•Compressor running noises.
•Air movement noise from the small fan motor in the freezer
compartment or other compartments.
•Gurgling sound similar to water boiling.
•Popping noise during automatic defrosting.
•Clicking noise before the compressor starts.
Other unusual noises are due to the reasons below and may
need you to check and take action:
The cabinet is not level.
The back of appliance touches the wall.
Bottles or containers fallen or
The motor
runs
continuously
It is normal to frequently hear the sound of the motor, it will
need to run more when in following circumstances:
Temperature setting is set colder than necessary
Large quantity of warm food has recently been stored within the
appliance.
•The temperature outside the appliance is too high.
•Doors are kept open too long or too often.
•After your installing the appliance or it has been switched off
for a long time.

14
TECHNICAL PASSPORT ENGLISH
Refrigerator NSFF 195752
Problem Possible cause & Solution
A layer of frost
occurs in the
compartment
Check that the air outlets are not blocked by food and
ensure food is placed within the appliance to allow
sufcient ventilation. Ensure that door is fully closed. To
remove the frost, please refer to cleaning and care chapter.
Temperature inside
is too warm
You may have left the doors open too long or too
frequently; or the doors are kept open by some obstacle; or
the appliance is located with insufcient clearance at the
sides, back and top
Temperature inside
is too cold
Increase the temperature by following the "Display
controls” chapter.
Doors cant be
closed easily
Check whether the top of the refrigerator is tilted back by
10-15mm to allow the doors to self close, or if something
inside is preventing the doors from closing.
Water drips on the
oor
The water pan (located at the rear bottom of the cabinet)
may not be properly leveled, or the draining spout (located
underneath the top of the compressor depot) may not
be properly positioned to direct water into this pan, or
the water spout is blocked. You may need to pull the
refrigerator away from the wall to check the pan and spout.
The light is not
working
•The LED light may be damaged. Refer to replace LED
lights in cleaning and care chapter.
•The control system has disabled the lights due to the door
being kept open too long, close and reopens the door to
reactivate the lights.
FAULT DISPLAY
Fault display shows as following under Fault mode:
ERROR CODE ERROR TYPE
UC Communication failure or model mismatch
RS Sensor failure (refrigerating chamber)
CS Sensore failure (Drinks box)
FS Sensor failure (freezing chamber)
Fd Defrosting sensor failure
FF Fan failure
FH Defrosting failure

15
ENGLISH TECHNICAL PASSPORT
Refrigerator NSFF 195752
ENERGRY SAVING TIPS
1) The internal temperatures
could be affected by such factors as the
location of the refrigerating appliance,
ambient temperature and the frequency
of door opening, and, if appropriate,
a warning that the setting of any
temperature control device might have
to be varied to allow for these factors;
2) The food to be frozen is not to
be placed in direct contact with food in
storage and, if appropriate,that it could
be necessary to reduce the quantity
to be frozen if freezing every day is
anticipated,)
3) The placing of ice-tray(s) in
order to achieve optimal ice-freezing;
4) The fact that effervescent drinks
should not be stored in food freezer
compartments or cabinets or in low-
temperature compartments or cabinets,
and that some products such as water
ices should not be consumed too cold;
5) The need to not exceed the
storage time(s) recommended by the
food manufacturers for any kind of food
and particularly for commercially quick-
frozen food in food-freezer and frozen-
food storage compartments or cabinets;
6) The precautions necessary
to prevent an undue rise in the
temperature of the frozen food while
defrosting the refrigerating appliance,
such as wrapping the frozen food in
several layers of newspaper;
7) The fact that a rise in
temperature of the frozen food during
manual defrosting, maintenance or
cleaning could shorten the storage life;
8) Make sure the refrigerator is
located away from any heat source
(including ovens) and direct sunlight.
9) Before storing hot foods, cool
them to room temperature.
10) Keep the door closed, reduce
the opening frequency, and keep the
opening time to a mimimum.
11) When defrosting frozen foods,
you can put them into the fridge
compartment, which will assist in
refrigeration helping to reduce the
energy used.
12) Make sure the temperature
sensor is not covered or blocked by
food, an keep a good distance between
foods.
Insurance
Any warranty provided with this product
does not cover loss of fridge/freezer
content
Any claim for loss, damage, costs or
expenses of an indirect or consequential
nature including any economic loss or
damage to foodstuffs or any other goods
is excluded. We recommend that you
inspect your fridge/freezer regularly to
check that itis working correctly, losses
can result from deterioration following
breakdown or accidental failure of
the appliance, fuses, plugs or public
electricity supply, these can be covered
by your standard home insurance or
might require extra cover. Check with
your insurance provider.

16
TECHNICAL PASSPORT ENGLISH
Refrigerator NSFF 195752
Important Note:
This appliance is marked according
to the European directive 2002/96/
EC on Waste Electrical and Electronic
Equipment (WEEE). By ensuring this
product is disposed of correctly, you
will help prevent potential negative
consequences for the environment and
human health, which could otherwise
be caused by inappropriate waste
handling of this product.
The symbol on the product, or on the
documents accompanying the product,
the Crossed Out Wheelie Bin, indicates
that this appliance may not be treated
as household waste. Instead it shall be
handed over to the applicable collection
point for the recycling of electrical and
electronic equipment.
Disposal must be carried out in
accordance with local environmental
regulations for waste disposal. For more
detailed information about treatment,
recovery and recycling of this product,
please contact your local authority, your
household waste disposal service or
the retailer where you purchased the
product.
We continuously try to improve
our products for the bene t of our
customers.
For this reason we reserve the right
to make changes to any product at any
time, without notice.

17
ENGLISH TECHNICAL PASSPORT
Refrigerator NSFF 195752
Year
Serial number
Month
XX XX XXXX
Manufacturer:
«M&G Hausgerate GmbH»
Manufacturer Factory: Nanjing Chuangwei Household Electronic Appliances Limited
Skyworth (Nanjing) industrial park, Lishui, Nanjing, Jiangsu, P.R. China
Importer:
LLC «MG Rusland», Russia, 141400 Himki, Butakovo str. 4
DETERMINATION OF THE PRODUCTION DATE BY SERIAL NUMBER

18
ПАСПОРТ ТЕХНИЧЕСКОГО ИЗДЕЛИЯ РУССКИЙ
Холодильник NSFF 195752
МЕРЫ ПРЕДОСТОРОЖНОСТИ......................................................................................... 20
СОСТАВ.......................................................................................................................................... 22
МЕСТО РАЗМЕЩЕНИЯ ......................................................................................................... 23
ПРОВЕРКИ ВО ВРЕМЯ РАБОТЫ ПРИБОРА.............................................................. 24
ХРАНЕНИЕ ПРОДУКТОВ..................................................................................................... 28
ОБСЛУЖИВАНИЕ..................................................................................................................... 30
УСТРАНЕНИЕ НЕИСПРАВНОСТЕЙ................................................................................ 31
СОВЕТЫ ПО ЭКОНОМИИ ЭНЕРГИИ И ДРУГИЕ РЕКОМЕНДАЦИИ........... 34


19
РУССКИЙ ПАСПОРТ ТЕХНИЧЕСКОГО ИЗДЕЛИЯ
Холодильник NSFF 195752

1) После окончания использова-
ния, атакже перед проведением пред-
усмотренных для пользователя работ
по обслуживанию прибор следует от-
ключить от источника питания путем
извлечения сетевой вилки из розетки.
2) Данный прибор не предназна-
чен для использования детьми, атакже
лицами сограниченными физическими,
сенсорными или умственными способ-
ностями или отсутствием опыта изна-
ний, за исключением тех случаев, когда
они находятся под присмотром лица,
отвечающего за их безопасность, или
инструктируются им относительно по-
рядка использования прибора.
3) Необходимо следить за детьми,
не допуская, чтобы они играли спри-
бором.
4) Чтобы предотвратить возник-
новение опасной ситуации, повреж-
денный кабель питания должен быть
заменен специалистом компании-из-
готовителя, ее официального сервис-
ного центра или другим техническим
лицом, обладающим соответствующей
квалификацией.
5) Сохраните данное руководство
по эксплуатации, авслучае продажи
прибора или передачи его впользо-
вание другому лицу передавайте вме-
сте сним иданное руководство, что-
бы новый пользователь мог получить
информацию опорядке эксплуатации
иправилах техники безопасности.
6) Не используйте сцелью ускоре-
ния процесса размораживания механи-
ческие устройства или иные средства,
если только они не рекомендованы
компанией-изготовителем.
7) Не допускайте повреждения
холодильного контура.
8) Не используйте никакие элек-
трические приборы вотделениях для
хранения продуктов, за исключением
тех, которые рекомендованы компа-
нией-изготовителем холодильника.
9) Утилизацию холодильника по
окончании его срока службы следует
проводить всоответствии стребовани-
ями местного законодательства, дей-
ствующего вотношении оборудования,
содержащего легковоспламеняющиеся
ивзрывоопасные газообразные веще-
ства.
10) Не допускайте перекрытия вен-
тиляционных отверстий вкорпусе при-
бора или кухонном модуле, вкоторый
он встраивается.
11) Запрещается хранить вданном
приборе взрывоопасные вещества, на-
пример, аэрозольные баллоны слегко-
воспламеняющимися жидкостями.
12) Данный прибор предназначен
для бытового или аналогичного ис-
пользования, например, взонах для
приема пищи сотрудниками магазинов,
офисов идругих подобных учрежде-
ний;

20
ПАСПОРТ ТЕХНИЧЕСКОГО ИЗДЕЛИЯ РУССКИЙ
Холодильник NSFF 195752
 вжилых загородных домах,
клиентами вгостиницах, мотелях идру-
гих учреждениях, предназначенных
для проживания людей;
 вхостелах ичастных гости-
ницах;
 на предприятиях, занимаю-
щихся приготовлением идоставкой
пищи, атакже предоставлением других
аналогичных услуг.
13) При помещении свежих про-
дуктов вморозильное отделение при-
бор должен быть переключен врежим
быстрого замораживания.
14) Данный прибор может ис-
пользоваться детьми ввозрасте 8лет
истарше, атакже лицами сограничен-
ными физическими, сенсорными или
умственными способностями или отсут-
ствием необходимых для работы сним
опыта изнаний, если они находятся
под присмотром или были проинструк-
тированы по вопросам безопасного
использования прибора, атакже если
им понятны возможные опасности. Не
разрешайте детям играть сприбором.
Чистка иобслуживание прибора
могут выполняться детьми только под
присмотром взрослого.
 При перемеще-
нии прибора вместо установки следите
за тем, чтобы кабель питания не был
пережат или иным образом поврежден.
Запрещается
размещать узадней стенки прибора
многоместные розетки или портатив-
ные источники питания.

Вслучае повреждения холодильного
контура:
Не используйте приборы соткрытым
пламенем идругие устройства, которые
могут приводить квоспламенению.
Обеспечьте эффективную вентиля-
цию помещения, вкотором находится
прибор.
Внесение изменений вданный при-
бор может приводить квозникновению
опасных ситуаций.




Параметры источника питания долж-
ны соответствовать данным, указанным
втехническом описании. Для подклю-
чения используйте стандартную розетку
стремя контактами.
При работе прибора ввоздухе
должны отсутствовать пары легковос-
пламеняющихся или взрывоопасных
веществ. Запрещается помещать внутрь
холодильника легковоспламеняющиеся
