These instructions explain how to install or replace a gyro PCB in a TracVision M5/M7 antenna.
Installation/Replacement Steps
Tools Required
This procedure requires the following tools:
Technical Support
If you need technical assistance, please contact KVH Technical Support:
1. Remove the Radome, 2
2. Remove the Main PCB Cover, 2
3. Install/Replace the Gyro PCB, 3
4. Reinstall the Main PCB Cover and Radome, 7
5. Calibrate the Gyros, 7
• #1 Phillips screwdriver
• #2 Phillips screwdriver
•Cuttingpliers
• PC with the latest version of the Flash Update Wizard installed
TIP: The Flash Update Wizard is available to KVH-authorized dealers through the KVH Partner
Portal at www.kvh.com/partners.
N. America, S. America, Australia:
Phone: [phone]
E-mail: [email protected]
Europe, Middle East, Asia:
Phone: [phone]
E-mail: [email protected]
Gyro PCB Installation/Replacement
Instructions for TracVision®M5/M7

2
Step 1 - Remove the Radome
Follow the steps below to remove the radome.
a. Disconnect power from the TracVision
system and any connected receivers and/or
multiswitch.
b. TracVision M5 – Remove the four Phillips
screws securing the radome. Then carefully
remove the radome and set it aside in a safe
place (see Figure 1).
c. TracVision M7 – Remove the six Phillips
screws securing the radome. Then carefully
remove the radome and set it aside in a safe
place (see Figure 2).
Step 2 - Remove the Main PCB Cover
Follow the instructions below to remove the
main PCB cover. Be sure to remove the cover
carefully to avoid damage to the PCBs or cables.
a. TracVision M5 – Remove the six Phillips
screws securing the main PCB (see Figure 1).
Then remove the cover and set it aside in a
safe place.
b. TracVision M7 – Remove the seven Phillips
screws securing the main PCB (see Figure 2).
Then remove the cover and set it aside in a
safe place.
NOTE: If the TracVision M7 includes an inverter
PCB, do not disconnect any of its cables. Simply
lay the main PCB cover down to allow the
required access.
CAUTION
For your own safety, be sure to disconnect
power from all wired components before
performing this procedure.
Figure 1 TracVision M5 Radome/Main PCB Cover Screws
Figure 2 TracVision M7 Radome/Main PCB Cover Screws
Radome
Baseplate
123
46
5
Main PCB
Cover
PCB Cover
Radome
Baseplate
1234
6
57
Inverter PCB
(included on
some antennas)

3
Step 3 - Install/Replace the Gyro PCB
Refer to Figure 3 to determine if your TracVision
system includes a gyro PCB. If a gyro PCB is
currently installed, proceed to Option A. If a gyro
PCB is not currently installed, proceed to
Option B.
Option A - Replace an Installed Gyro PCB
Follow the instructions below to replace the gyro
PCB.
a. Place labels on the elevation and azimuth
gyro cables as needed to ensure proper
connection to the new PCB later (see
Figure 3).
b. Using cutting pliers, cut and remove the tie-
wrap securing the jumper cable connector to
the gyro PCB (see Figure 3).
c. Disconnect the jumper cable and gyro cables
from the gyro PCB (see Figure 3).
d. Remove the four Phillips screws securing the
gyro PCB (see Figure 4).
If the gyro connections are reversed, the
TracVision system will not operate properly.
IMPORTANT!
Figure 3 Gyro PCB Location/Connections
Figure 4 Gyro PCB Screws
Main PCB
Gyro PCB
Jumper
Cable
Tie-wrap
Azimuth
Gyro
Elevation
Gyro
Screw (x4)

4
e. Reverse these instructions to install the new
gyro PCB.
NOTE: Be sure to install the jumper cable
supplied in the kit with its ferrite coil installed
(see Figure 5), and secure the jumper cable’s
connector to the gyro PCB, using a supplied tie-
wrap (see Figure 6).
Figure 5 Ferrite Coil Installed
Figure 6 Tie-wrap Installation
Ferrite Coil
Tie-wrap

5
Option B - Install a Gyro PCB
Depending on the serial number, some
TracVision M5/M7 systems require installing a
gyro PCB and modifying connections. The
following instructions apply only to the serial
numbers specified below.
a. Using four supplied Phillips screws, secure
the gyro PCB to the standoffs (Figure 7).
b. Place labels on the elevation and azimuth
gyro cables as needed to ensure proper
connection to the gyro PCB (see Figure 8).
Model Serial Numbers
M5 081100140 - 090500206
M7 081100749 - 090500117
Figure 7 Gyro PCB Standoffs
Figure 8 Gyro PCB Screws/Labels
1
3
2
4
Elevation
Azimuth
Main PCB
Gyro PCB

6
c. Disconnect the gyros from the main PCB.
Then connect them to the gyro PCB
connectors, as shown in Figure 9.
d. Install the ferrite coil onto the supplied
jumper cable, as shown in Figure 10.
e. Connect one end of the supplied jumper cable
to the gyro PCB. Then connect the other end
to the main PCB (see Figure 11).
Figure 9 Gyro Connections
Figure 10 Ferrite Coil Installed
Figure 11 Jumper Cable Connections
Elevation Azimuth
Main PCB
Az
Gyro PCB
Ferrite Coil
Jumper
Cable
Jumper
Cable
Elevation
Gyro
Azimuth
Gyro

7
Step 4 - Reinstall the Main PCB Cover and
Radome
Follow the instructions below to reinstall the
main PCB cover and radome. Be sure to position
the cover carefully to avoid damage to the PCBs
or cables.
a. TracVision M5 – Secure the main PCB cover
using the six Phillips screws you removed in
“Step 2 - Remove the Main PCB Cover” on
page 2 (see Figure 1 on page 2).
b. TracVision M7 – Secure the main PCB cover
using the seven Phillips screws you removed
in “Step 2 - Remove the Main PCB Cover” on
page 2 (see Figure 2 on page 2).
c. Reinstall the radome. Then restore power to
the TracVision system and any connected
receivers and/or multiswitch.
Step 5 - Calibrate the Gyros
Follow the steps below to calibrate the gyros for
use with the new gyro PCB.
a. Follow the instructions in the TracVision
M5/M7 User’s Guide to connect a PC to the
TracVision system.
b. Double-click the KVH Flash Update Wizard
shortcut on your PC’s desktop to start the
Flash Update Wizard.
NOTE: You do not need to flash the antenna; you will
simply type commands in the Flash Update Wizard’s
“TracVision Antenna Comms” window. Be sure to
click the “TracVision Antenna Comms” window to
select it before typing.
c. Type HALT then press Enter.
d. Type DEBUGON then press Enter.
e. Type =CALGYRO then press Enter.
f. Type ZAP then press Enter.
The procedure is complete!
