kvm-tec
First Aid
MX
Video error
(stripes in the
picture)
USB is not
working
No Power
(No LED)
Check the
powerplug
Is the power
supply ok? Try
another Unit.
Try reprogramming
the Unit by using a
JTAG programmer
Contact kvm-tec
support
Are the USB
Devices plugged
in correctly?
Is the USB cable
on the Local side
plugged into the
PC?
Are the USB
Devices working
directly on the
PC?
Check if local
and remote Unit
have the same
fi rmware
Replace the USB
cable from PC to
the Local
Extender
Check if the local
or the remote
Unit is causing
the problem by
swaping fi rst the
local and than the
remote Unit to
another Unit
Contact kvm-tec
support
Check if all
cables are plug-
ged in correctly
Check if the PC is
sending a Image by
plugging in a
monitor on the
local out of the
local Unit
Check if the DDC is
set correctly (in menu
under point „O“)
Check if both
Units have the
correct fi rmware
No Video
Contact kvm-tec
support
Check if all
cables are plug-
ged in correctly
Check if the PC is
sending a Image
by plugging in a
monitor on the
local out of the
local Unit
Check if local and re-
mote Unit have the
correct fi rmware
Check if the DDC
is set correctly (in
the menu under
point „o“)
Check if the
network switch
is setup correctly
and has enough
bandwidth
Contact kvm-tec
support
Check if other units
have the same
behaviour
We are here for you to answer
your questions about installation?
Manual download www.kvm-tec.com
or
kvm-tec Installationchannel on our homepage
personally +43 2253 81912
kvm-tec Support
[email protected]
Phone: +43 2253 81912 - 30
Check out
our Installation Channel:
www.kvm-tec.com
line
line
line
matrix
matrix
kvm-tec
Quick
Instruction
Matrixline
MX
6711 SET
6711L CPU/LOCAL
6711R CON/REMOTE
connect collaborate communicate control
kvm-tec = C 4
Power plug
12V 1A
DVI in
from PC
USB to PC
DVI out
to Monitor
Audio
from PC
Audio to PC
USB from
Keyboard and mouse
Audio from
Microphone
Audio to
Speaker
Network cable CAT5e/6 up to 150m/492ft
matrixline
RS232
matrixline
RS232
DVI to Monitor
Quick Installation MX2000 MATRIXLINE local / CPU – remote / CON
1. Connect the CON / Remote and the CPU / Local Unit to the included 12V 1A power supply.
2. Now connect the USB cable to a USB port on your PC and connect the other end of the USB cable to the CPU /
Local Unit. Connect keyboard and mouse to the CON / Remote Unit.
3. Connect the CPU / Local and the CON / Remote Unit with a network cable.
4. Now connect the DVI cable to the DVI socket of the PC and the other end to the DVI socket of the CPU Local
Unit (PC-in). Then connect the monitor with the DVI cable to the CON / Remote Unit.
5. Then connect PC audio/out with the audio cable to Local audio/in. Then connect audio/out via the audio cable
6. Almost done! Now connect the audio cable Local audio/out to the PC audio/in and Remote audio/out with the
audio cable to the microphone
HAVE FUN - your kvm-tec Extender is now in use for many years (MTBF approx 10 years)
