KVM-TEC Ultraline UVX1 User manual

4K ULTRALINE UVX1/UVX1-F KVM EXTENDER
INSTRUCTION
MANUAL
Part.No: 6901
Ultraline UVX1
Part No: 6902
UltralineUVX1-F

2 | kvm-tec
TABLE OF CONTENTS
1. Introduction 4
1.1 Intended Use 4
1.2 Safety Instructions 5
1.3 Technical Specications 7
1.4 Product Elements 8
1.5 Meaning of LED indicators 10
2. Installation of the extender 11
2.1 Unpacking and checking the contents 11
2.2 Mounting options 12
2.2.1 Mounting pads and rubber feet 12
2.2.2 Mounting kits (optional) 12
2.3 Installing the extender 13
2.4 Startup 17
2.5 Replacing the SFP module 17
2.6 Removing a CAT7 cable 18
2.7 Removing a ber cable 18
3. Extender Settings 19
3.1 Access Main Menu 19
TABLE OF CONTENTS

kvm-tec | 3
3.1.1 Status Menu 20
3.1.2 Denition DDC/EDID Settings 21
3.1.3 Display Update Menu 21
3.1.4 Firmware Update with USB Stick 22
3.1.5 Upgrade Menu 24
3.1.6 Menu Features 25
3.1.7 Select keyboard layout 26
4. Maintenance and care 27
5. Troubleshooting 28
6. Disposal 28
7. Warranty 29
8. Support 29
9. Declaration of Conformity 30
10. Requirements for cables 32
10.2.1 Requirements for CAT7 cable 33
10.2.2.Requirements ber cables 32
11. Notes 33
TABLE OF CONTENTS

4 | kvm-tec
1. INTRODUCTION
Congratulations on the purchase of your new Ultralineline UVX1/UVX1-F KVM Extender.
You have bought a high quality extender. These instructions are part of this product.
They contain important information regarding safety, use and disposal for every user
of the Ultraline UVX1 and UVX1-F KVM Extender. Please familiarise yourself with the
information within prior to using your product. Use the product only in the manner as
described and for the areas of application as stated. When passing the product to a third
party be sure to also supply all instructions and other relevant documentation. Following
proper use and maintenance, your Ultraline UVX1/UVX1-F KVM Extender will bring you
joy for many years to come.
1.1 INTENDED USE
This product is intended to be used as a device to increase the distance that a keyboard,
monitor and mouse can be placed from a computer. This product is intended for professional
use. The product should not be used in potentially explosive environments.
The product may only be used according to the instructions as described in this manual. All
use, other than that described in this manual, is seen as unintended use. Modications in the
course of technological progress are reserved. In these user instructions the Ultraline
UVX1/UVX1-F KVM Extender is referred to as ‘product’ or ‘extender‘. The UVX1/PC is referred to
as the ‘local unit’ - CPU and the UVX1/Monitor is referred to as the ‘remote unit‘ - CON.
WARNING
The device may not be opened by an authorized technician.
Danger of electric shock!

kvm-tec | 5
1. introduction
1.2 SAFETY INSTRUCTIONS
WARNING! Read and understand all safety instructions.
• Follow all the instructions. This will avoid accidents, re, explosions, electric shocks or
other hazards that may result in damage to property and/or severe or fatal injuries.
Please ensure that everyone who uses the product has read and followed these warnings
and instructions.
• Keep all safety information and instructions for future reference and pass them on to
subsequent users of the product.
• The manufacturer is not liable for cases of material damage or personal injury caused
by incorrect handling or non-compliance with the safety instructions. In such cases, the
warranty will be voided.
• This product is not intended for use by persons (including children) with restricted
physical, sensory or intellectual capability or lack of experience and/or knowledge, unless
they are supervised by a person who is responsible for their safety or provides them with
instructions on how to use the product.
• DANGER! Not for use in potentially explosive environments.
• DANGER! Be vigilant at all times, and always take care around this product. Do not use
electrical equipment if you are lacking in concentration or awareness, or are under the
inuence of drugs, alcohol or medication. Even a moment of inattentiveness can lead to
serious accidents and injuries when using electrical equipment. Check the product and
the cables for any damage before use. If there is any visible damage, a strong odour, or
excessive overheating of components unplug all the connections immediately and stop
using the product.
• DANGER! The UVX1-F KVM Extender is a Class 1 Laser Product 1 according to
DIN 40008/EN and VDE 0837.
• If the product is not installed and used in accordance with this manual, it may cause
disruptive interference with radio or television reception or affect other electronic
products in residential areas.
• Use shielded cables only to connect the components in order to avoid such interference.
Non-compliance invalidates the permission to operate this product.
• Only the mains adapter included with the product should be used as the power supply.
Do not use other adapters.
• Prior to connecting to the mains, make sure your local mains voltage matches the rating
indicated on the product.
• The product must be connected to a permanent and earthed AC wall socket.
1

6 | kvm-tec
1. introduction
• Protect cables from being strained, pinched or buckled and place them in a way to
prevent people from tripping over the cord.
• In particular, ensure to avoid damage to the mains adapter.
• Use the product with a suitable, properly installed and easily accessible mains power
socket. Make sure the product can be disconnected from the power socket at all times.
• Unplug the product during electrical storms or when not in use.
• DANGER! Never touch the adapter with wet hands.
• Use the product within the specied performance limits.
• Keep the product away from ammable materials such as curtains and drapes.
• Protect the mains adapter from use by third parties (particularly children). Keep the
unused mains adapter in a dry, elevated or locked location away from children.
• Do not place the product near heaters.
• Do not drop or hit the product.
• Unplug all connections before cleaning the product. Do not use wipes or chemicals
as these could damage the surface. Wipe the housing with a damp cloth. Electrical/
electronic parts must not be cleaned.
• Alterations to the product and technical modications are not permitted.

kvm-tec | 7
1. introduction
1.3 TECHNICAL SPECIFICATIONS
Type: KVM Extender (local unit-CPU and remote unit-CON)
Model: 4K Ultraline UVX1/UVX1-F KVM Extender
Power supply input voltage: 90 - 240 V; 50/60 Hz AC
Power supply IN: 12V; 2A (external power supply - redundant)
Power requirement: 15 W per extender (excluding attached USB devices)
Operating temperature range: 0 ºC to 45 ºC / 32 °F to 113 °F
Storage temperature range: −25 ºC to 80 ºC / −13 °F to 176 °F
Relative humidity: max. 80% (non-condensing)
Storage humidity: max. 80% (non-condensing)
Casing Material: Anodized aluminium
Dimensions: approx. 218 x 43 x 105 mm/ 8.58 x1.69 x 4.13 “
Weight: approx. 1383 g / 48.78 oz. per set
Expected product life: 82 820 hours / 10 years
Laser MVX1-F: Class 1 Laser Product 1 according to DIN 40008/EN and
VDE 0837
Manual Version 0.01/14
1

8 | kvm-tec
1. INTRODUCTION
1.4 PRODUCT ELEMENTS
Local Extender (CPU)
Nr. Name Function
1 audio in Audio in from PC
2 audio out Audio Out to PC
3 RS232 RS232
4 ON/OFF Power Switch ON/OFF
5 grounding grounding screw
6 power Connection for 220 V power supply
7 kvm-link Connection for CAT 7 cable or  bre cable
8 dc Connection für 12V power supply
9 dpout 2 Displayport Output to Monitor 2
10 dpout 1 Displayport Output to Monitor 1
11 dpin DP Input from PC
12 AUX Auxilary Gigabit Network Connector
13 USB 2.0 USB 2.0 to PC
14 POWER/LED status Displays the status of the extender

kvm-tec | 9
1. INTRODUCTION
Remote Extender (CON)
Nr. Name Function
15 audio in Audio In from microphone etc.
16 audio out Audio Out to speakers etc.
17 RS232 RS232
18 power Power Switch ON/OFF
19 grounding grounding screw
20 Power Power Connector AC90-240V
21 kvm-link Connection for CAT 7 cable or  bre cable
22 DC Connection für 12V power supply
23 dp out 2 Displayport Output to Monitor 2
24 dpout 1 Displayport Output to Monitor 1
25 AUX Auxilary Gigabit Network Connector
26 USB USB 2.0 to keyboard /Muse
27 POWER/ LED Displays the status of the extender
1

10 | kvm-tec
1. introduction
Normal Operation
1.5 MEANING OF LED INDICATORS
The Status LED (8/15) can light red, orange or green. Table 1 shows the meaning of each colour.
Also see chapter Troubleshooting.
* UVX only ** Rem. Only
Table 1: Meaning of LED indicators
Colour Blinking Physical
Link
Active
Connection
Video
Extended
USB
Initialisation
UBS Data
Received
Identify
Command
Autoupdate
Mode
Red - Yes No No Update Failed
Red Slow No No No
Orange -Yes Yes No
Orange Fast Update in Progress
Green - Yes Yes Yes Update Succedded
Green V. fast Yes**
Red/Green V. fast Yes
Yellow - No
Yellow Slow Yes
Green - Yes
Green V. fast Yes
Main LED
RJ45 Socket LEDs *
