Kygo A6-500 User manual

Headphones
Kygo A6-500
USER GUIDE

2

3
I am known for my music. It is my passion. Behind it
is a craftsmanship - the drive to keep on improving,
perfecting every little step of the process.
This philosophy is now passed on to Kygo Life. It is built
upon Scandinavian design with sophisticated items that
have enough backbone to become classics. I hope you
will enjoy them for years to come.
Kyrre Gørvell-Dahll
Creative Director, Kygo Life

ENGLISH
4
Congratulations on purchasing your new KYGO A6-500 Bluetooth
stereo headphones. Before using them, please read through
this manual carefully to learn how to cooperate the Bluetooth
headphones with your mobile phone or other devices.
Getting started

ENGLISH
5
Precautions
1. Please read through and follow the instructions given in this manual
carefully to ensure your safety.
2. Pay particular attention to any edges, uneven surfaces, metal
parts, accessories and packaging to avoid any possibility of injury.
3. Do not dismantle, repair or modify this product to prevent fire,
electric shocks or other product damage, which are not covered
under warranty.
4. Do not use any solvents or volatile liquids to clean the Kygo A6-500
headphones.
5. Do not use your Kygo A6/500 headphones in hazardous situations.
6. This product or its battery cannot be disposed with the
household waste. It must be returned to a collection point to be
recycled. Please check with your local authorities for details.

ENGLISH
6
Features
1. Bluetooth 4.1 + EDR
2. 3.5mm music line-in function
3. Connect up to 2 phones or devices
4. The headphone battery power status is displayed on iOS device’s
screen
5. Qualcomm® aptX™ and AAC® audio technology
6. Supports NFC

ENGLISH
7
Basic buttons operation
LED indicator
Volume up / Next
Multifunction Button (MFB):
Turn on / Pairing / Play /
Pause / Turn off / Answer /
End / Reject Call
Volume down / Previous
3.5mm Audio Jack
Micro USB Slot
Microphone

ENGLISH
8
General Function
Operation LED status
Power on Blue LED flashes twice
Power off Red LED flashes twice
Pairing Blue LED and Red LED flash alternately
Standby Blue LED flashes 3 times in 5 seconds
Incoming call Blue LED flashes continuously
Low battery Red LED flashes twice every 2 seconds
Charging Red LED stays lit during charging
Blue LED stays lit when charging is completed

ENGLISH
9
Power on: Press the multi-functional button for 2 seconds.
When the blue LED flashes twice, headphones are turned on.
Power off: Press the multi-functional button for 3 seconds. When the
red LED flashes twice and then stops, headphones are turned off.
Pairing: Press the multi-functional button for 5 seconds, the blue LED
and the red LED flash alternately.
Increase volume: Press on the “+”button.. When volume reaches
maximum, you will hear a “tick” sound.
Decrease volume: Press on the “-” button. When volume reaches
minimum, you will hear a “tick” sound.
Play/Pause: Short press the MFB to pause music. Press again to
resume.
Basic Buttons Operation

ENGLISH
10
Previous song: Press and hold the “-“ button.
Next song: Press and hold the“+“ button.
Answer Call: Short press the MFB to answer incoming calls.
End call: Short press the MFB to end calls.
Reject call: Long press the MFB to reject calls.
Battery Capacity status: When headphones are connected to iOS
devices, the headphone battery power status is displayed on the
upper right corner of the screen.
Charging: New headphones have enough power for pairing and
dialing out for several times. When the battery is low, please charge it
via USB cable for 2 hours. During charging, the red LED stays lit. Once
fully charged, the red LED turns blue.

ENGLISH
11
3.5mm music line-in with mic function:：Connect audio line in cable
to 3.5mm audio jack for wired music. When plugged in, headphones
will power off. (Phone call function can still be used in this mode).

ENGLISH
12
3.5mm
Audio Cable

ENGLISH
13
Pairing with one phone or other devices
Make sure the headphones are powered off.
Press and hold the multifunctional button for 5 seconds to enter the
pairing mode. The red LED and blue LED flash alternately.
Activate the Bluetooth function on your phone or device and search
for the headphones. From the list of available devices on your mobile
phone, select the KYGO A6-500 headphones and tap to connect.
Follow the instructions to enter “0000” as a PIN code if prompted on
your mobile phone screen.
Headphones or device can be used to play music from your phone,
make calls, and do many more.
Pairing

ENGLISH
14
Pairing with a phone via NFC
1. Turn on your phone and ensure its NFC functions are activated.
2. Turn on KYGO A6-500.
3. Place your phone close to the right side of the KYGO A6-500.
4. When your phone prompts to confirm the connection, then press
YES/OK to finish pairing.

ENGLISH
15
Pairing with two phones or other devices simultaneously
1. Pair with the phone “A” successfully, then turn off the headphones.
2. Follow the same procedure with the phone “B”. Then turn off the
headphones again.
3. Turn on the headphones. The headphones will automatically
connect to phone “B”. Then check “found devices” on phone “A”
and connect to Kygo A6-500.

ENGLISH
16
Sound quality with AAC®
Sound quality with Qualcomm® aptX™
Thanks to Qualcomm® aptX™ codec, the headphones can connect
wirelessly to any aptX enabled devices. Doing so vastly improves the
quality of Bluetooth streaming and delivers CD-quality sound.
Qualcomm aptX is a product of Qualcomm Technologies International, Ltd.
Sound quality with Qualcomm® aptX™ and AAC®

ENGLISH
17
1 x Stereo Bluetooth headphones KYGO A6-500
1 x Charging micro USB cable
1 x User manual
1 x 3.5mm audio wire
Kit Contents

ENGLISH
18
If you have any problems with your Kygo A6-500 headphones or
questions about the functions, please contact us on info@kygolife.
com and we’ll be glad to assist you.
Trouble Shooting
Warning
1. You must choose a qualified charger from a regular manufacturer
to charge the headphone.
2. You must charge the headphone if it has not been used for more
than 12 months.

ENGLISH
20
Bluetooth version: 4.1
Talk time: 25h
Stand-by time: 200h
Music play time: 18h
Wireless range: 10m
Bluetooth profiles: A2DP/AVRCP/HSP/HFP
Audio codec: AAC/AptX/AptX-LL
Impedance: 32Ω
Sound pressure level: 119±3dB
Frequency Response: 20Hz---22 KHz
Weight: 135g
Dimension: 160 x 190 x 70mm
Specifications
