Kygo XENON User manual

USER GUIDE
XENON
Bluetooth Active Noise Cancelling Headphones
Kygo Life unites my love of music with modern Scandinavian design. The aim
is to develop top-quality audio equipment that sounds amazing and looks
great. Future classics that capture the euphoric feeling of my music.
Like my approach to everything, Kygo Life is driven to continually improve. So
as each product evolves it embraces the latest technology and focuses on
perfecting the details until I’m absolutely happy the end result is the best it
can be.
I hope that by creating new and inspiring audio experiences, you’ll enjoy
listening to your favourite tunes even more.
Getting started
Congratulations! Thank you for choosing Xenon Bluetooth Active Noise
Cancelling Headphones. Before using them, you should read this manual to
familiarise yourself with the functions of the product.

Precautions
1. Before using Xenon headphones, we would strongly encourage you to read
through this user manual. Please follow the instructions given in this manual
carefully to ensure your safety.
2. Pay particular attention to any edges, uneven surfaces, metal parts,
accessories and packaging to avoid any possibility of injury.
3. Do not dismantle, repair or modify this product as this could lead to fire,
electric shocks or other product damage, which are not covered under
warranty.
4. Do not use any solvents or volatile liquids to clean Xenon headphones.
5. Do not use your Xenon headphones in hazardous situations.
This device complies with Part 15 of the FCC regulations. Operation is subject to
the following two conditions: (1) this device will not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications or change to this equipment. Such modifications or
change could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class
B digital device, according to part 15 of the FCC Regulations. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used following the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:

• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The device can be used in portable exposure conditions without restriction.
The device has been evaluated and meets general RF exposure requirements.
This equipment complies with FCC's RF radiation exposure limits established for
an uncontrolled environment. This device and its antenna(e) must not be co-
located or linked with another antenna or transmitter.
Features
1. Bluetooth 5.0
2. Hybrid Active Noise-Cancelling
2. 3.5mm music line-in function
3. Supports connection with 2 phones or devices
4. The headphone battery power status is displayed on iOS
5. Qualcomm® aptX™, Qualcomm® aptX™ - Low latency, SBC and AAC® audio
technology
6. USB-C Charging
7. Microphone

General function
Operation Status LED
Power on: Blue LED flashes 2 times
Power off: Red LED flashes 2 times
Pairing: Red LED & Blue LED flash alternately
Standby: Blue LED flashes 3 times in 5 seconds
Incoming call: Blue LED flashes continuously
Low battery: Red LED flashes 2 times every 2 seconds
Charging: Red LED stays lit
Charging complete: Blue LED stays lit
ANC mode on: White LED stays lit
Basic button operation
Power on: Press the POWER ON/OFF button for 1 second. The blue LED will
indicate that the headphones are turned on.
Power off: Press the POWER ON/OFF button for 3 seconds. The red LED will
flash twice to indicate that the headphones are turned off.
Adjust volume: short press volume button “+” to increase volume. Short press
volume button“-" to decrease volume. When the volume reaches max or min,
listen for a “beep” sound.
Play/Pause: Short press multifunction button to pause music. Press
again to restart.

Previous: Press the "-" button for 1s to go to the previous track
Next: Press the "+" button for 1s to go to the next track
Answer Calls: Short press the multifunction button to answer incoming calls.
End call: Short press multifunction button to end the call.
Reject call: Press the "-" button for 1s
to reject calls.
ANC mode: Use the slide button to turn the noise-cancelling function on and
off. The white LED will indicate that it is activated.
Battery Capacity status: When connected to iOS devices, the
headphone's battery power status is displayed in the upper right corner of
device’s screen.
Charging: New headphones have enough power to listen to music for several
hours. When the battery runs low, recharge it for 2 hours with the included
USB-C cable. During charging, the red LED will blink. A blue LED will indicate
that the headphones are fully charged.
Reset Mode: Connect the headphones to a computer via the included USB-C
cable. When red LED lights up, the reset is complete.
3.5mm music line-in function: Connect the 3.5mm audio jack cable to
the headphones for wired music. You can also use it during calls, thanks to the
built-in microphone on the cable.
Before connecting the cable, please ensure that the headphones are powered
OFF.
1. Connect the 3.5mm audio cable to the headphones and device.
2. Adjust the volume on the device

(ILLUSTRATION)
1. Connect the 3.5mm audio cable to the headphones and device.
2. Press the button once to pause/play music.
3. Press 2 times to skip a track
4. Press 3 times to go to the previous track.
5. Control the volume directly on your device.
Bluetooth Pairing
Pairing with a phone or other devices:
1. Make sure the headphones are powered OFF.
2. Press and hold the multifunction button for 5 seconds to enter pairing mode.
3. The red & blue LEDs will blink alternately and a sound will alert you that the
headphones are in pairing mode.
4. Activate the Bluetooth function on your phone or device and select Kygo
Xenon.

5. The Headphones can now be used to play your phone music or
phone calls.
Pairing with two phones or other devices at the same time
1. Pair with phone "A" successfully and turn off the headphones.
2. Follow the same procedure with phone "B".
3. Power up headphones again. They will automatically connect to phone
"B" (the last one connected). Go to Bluetooth configurations on phone "A" and
select Kygo Xenon to connect.
Clearing pairing records
Connect headphones to a computer using the USB-C cable. Press the “+" and "-
" buttons at the same time until the BLUE and RED LED start blinking. This,
indicates the pairing records are cleared.
Sound quality
Sound quality with AAC®
Sound quality with Qualcomm® aptX™ and Qualcomm® aptX™ Low Latency
Thanks to Qualcomm® aptX™ codec, the headphones can connect wirelessly to
any aptX enabled devices. Doing so vastly improves the quality of Bluetooth
streaming and delivers CD-quality sound.
Qualcomm aptX is a product of Qualcomm Technologies International, Ltd.

Kit content
1 x pair XENON Bluetooth Active Noise Cancelling Headphones
1 x USB-C charging cable
1 x user manual
1 x 3.5mm audio cable
1 x Carrying case
Caution
1. Always use an approved charger from a reputable manufacturer to charge
your headphones.
2. Always recharge your headphones if they have not been used for more than
twelve months.
Specifications:
Bluetooth version: 5.0
Talk time: 25 hours
Standby time: 180 hours
Playing time: BT+LED: 14 hours
BT+LED+ANC: 12 hours
BT: 24 hours
BT+ANC: 16 hours
Wireless range: 10m
Bluetooth profiles: A2DP/AVRCP/HSP/HFP
Audio codec: SBC/AAC/AptX/AptX-LL
Impedance: 32±15%Ω
Sound pressure level: 110 98±3dB
Frequency response (±3dB): 15/20Hz - 22/20kHz
Weight: 320 g
Dimensions: 190 x 176 x 90mm

FCC Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
