KYMCO Downtown 200i User manual

To avoid damage from the scooter's electronic
fuel injection system, do not remove or install a
battery wire when the ignition switch is at the
"ON" position.
WARNING
Battery & EFI Damage Alert

This Owner’s Manual contains important information on safety, operation and maintenance of your KYMCO
scooter. Any one who operates your scooter should carefully read and understand the
contents of this manual before riding the scooter. For your safety, understand and follow all of the warnings
contained in this Owner’s Manual and the labels applied to your scooter. This Owner’s Manual should be
considered a permanent part of the vehicle, keep it with your scooter at all times. ON-ROAD USE ONLY This
scooter has been designed to be used on the road.
Downtown 200i
Read this manual carefully.
The NOTE symbol indicates key information about a procedure or to clarify
an operation.
The SAFETY ALERT symbol with the exclamation point in the triangle
meansATTENTION! BE ALERT! YOUR SAFETY CAN BEAFFECTED.
Failure to follow instructions associated with a WARNING symbol could
result in severe injury or death to the rider, a passenger, a bystander, or a
person inspecting or repairing the scooter.
A CAUTION symbol indicates that special precautions must be taken to
avoid damaging the scooter.
NOTE
WARNING
CAUTION
Particularly important information is called out in this manual by the following icons
and notations:

Identification Numbers Record
3
Record the Vehicle Identification Number , Engine Serial Number and Frame Serial Number in the
boxes above for future reference (to assist you in ordering parts from your authorized KYMCO dealer or for
reference in case the vehicle is stolen).
2. ENGINE SERIAL NUMBER (ESN)
1. VEHICLE IDENTIFICATION NUMBER (VIN)
3. FRAME SERIAL NUMBER (VIN)
123
21

TABLE OF CONTENTS
SECTION 1 - SAFETY .............................1-8
Forward .........................................................1
Scooter Safety.............................................2 - 3
Accessories & Modifications.............................4
Locations of Parts & Controls.........................5 - 8
SECTION 2 - CONTROLS & FEATURES.9 - 19
Ignition Switch ................................................9
Security shutter .............................................10
Instruments ............................................11 - 12
Digital clock...................................................13
Right-hand Handlebar Switch..........................14
Left-hand Handlebar Switch......................15 - 16
Fuel Recommendation...................................17
Seat..............................................................18
Suspension...................................................19
SECTION 3 - OPERATION.......................21 - 23
Pre-ride Inspection........................................21
Starting the Engine..................................22 - 23
SECTION 4 - MAINTENANCE...............19- 34
Maintenance Schedule.............................26 - 28
Engine Oil.....................................................29
Engine Oil Replacement...........................30 - 31
Transmission Fluid Change............................32
Air Filter Element Change...............................33
Throttle Operation..........................................33
Spark Plug....................................................34
Coolant level inspection.................................35
Side stand.....................................................36
Brake Fluid Level Inspection...........................37
Brake Lever Adjusters..............................38 - 39
Battery & Fuse...............................................40
Tires.............................................................41
Clean the windshield.................................42
EMISSION CONTROL ...........................43
SPECIFICATIONS..............................44
5
6
4
3
1
2

SECTION 1 -
FORWARD & SAFETY INTRODUCTION
Thank you for purchasing this KYMCO scooter, and welcome to the KYMCO riding
family.
Please read this owner's manual carefully before riding so that you will be thoroughly familiar with the
proper operation of your scooter controls, its features, capabilities, and limitations.
To ensure a long, trouble-free life for your scooter, provide it with the proper care and maintenance as
described in this manual.
For replacement parts and accessories, you should always use genuine KYMCO products, as they have
been specially designed for your vehicle and manufactured to meet KYMCO's demanding standards.
Keep this owner's manual aboard your scooter at all times so that you can refer to it whenever you need
information. This manual should be considered a permanent part of the scooter and should remain with
the scooter when it is sold.
All information, illustrations, photographs and specifications contained in this manual are based on the
latest product information available at the time of publication. Due to improvements or other changes,
there may be information in this manual that differs slightly from your vehicle. KYMCO reserves the right to
make product and publication changes at any time without notice and without incurring any obligation.
DOWNTOWN 200i
1

Your scooter can provide you many years of
service and pleasure if you take responsibility for
your own safety and understand the challenges
that you can meet on the road. There is much that
you can do to protect yourself when you ride. You
will find many helpful recommendations
throughout this manual. Here are some very
important safety tips:
IMPORTANT SAFETY INFORMATION
Wear a helmet
Scooter safety equipment starts with a quality
helmet. One of the most serious injuries you can
suffer in a crash is a head injury. Always wear a
properly approved helmet. You should also wear
suitable eye protection.
Make yourself easy to see
To make yourself more visible, wear bright
reflective clothing, position yourself so other
drivers can see you, signal before turning or
changing lanes, and use your horn when it will help
others notice you.
Know your limits
Ride within the boundaries of your own skill at all
times. Knowing these limits and staying within
them will help you to avoid accidents.
For safe riding, it's important to inspect your
scooter before every ride and perform all
recommended maintenance. Never exceed load
limits, and only use accessories that have been
approved by KYMCO for this scooter.
Keep your scooter in safe condition
Do not forget to perform an entire safety inspection
to ensure you, and your passenger's safety, before
each ride.
Inspect your scooter before riding
Riding on bad weather days, especially wet ones,
requires extra caution. Braking distance can
double on a rainy day. Stay off of the painted
surfaces, manhole covers and greasy appearing
areas on the pavement, as they can be especially
slippery. Use extreme caution at railway crossings
and on metal gratings and bridges. Whenever your
are in doubt about the road conditions, slow down.
Be extra safety conscious on bad
weather days
Modification of your scooter, or removal of original
equipment may render the vehicle unsafe or illegal.
Obey all applicable equipment regulations in your
area.
Modification
2
SCOOTER SAFETY

1
SCOOTER SAFETY
Be sure you and your passenger always
wear an approved motorcycle helmet
that fits properly. You should also wear
eye protection and other protective
apparel when you ride.
WARNING
4
3
2
1
5
3
For your safety, always wear an approved motorcycle
or scooter helmet, eye protection, boots, gloves, long
pants, and a long- sleeved shirt or jacket whenever you
ride your scooter.
PROTECTIVE APPAREL
Your helmet is your most important piece of riding gear
because it offers the best protection against head
injuries. Your helmet should fit your head comfortably
and securely. Always wear a face shield or goggles to
protect your eyes and to aid your vision.
Helmets and protection
In addition to a helmet and eye protection, you should
also use:
Additional riding gear
Sturdy boots with nonslip soles to help protect your
feet and ankles.
Leather gloves to keep your hands warm and help
prevent blisters, cuts, burns and bruises.
A motorcycle or scooter riding suit or jacket that has
been designed for comfort as well as protection.
Bright colored and reflective clothing can help make
you more noticeable in traffic. Be sure to avoid loose
clothes that could get caught on any part of your
scooter.
Wear gloves
Clothes should be fit properly (not too tight or
loose)
Always wear a helmet. You should also wear
eye protection
Wear bright or reflective clothing
Footwear should be the proper size, have low
heels, and offer ankle protection
1
2
3
4
5
WARNING
Not wearing a helmet increase your
chance of serious injury or death in a
crash.

4
ACCESSORIES & MODIFICATION
There is a large variety of accessories available to KYMCO scooter owners. KYMCO cannot have direct
control over the quality or suitability of accessories you may wish to purchase. The addition of unsuitable
accessories to your scooter can lead to unsafe operating conditions. It is not possible for KYMCO to
test each accessory on the market or combinations of all the available accessories; however, your
KYMCO dealer can assist you in selecting quality accessories and then install them correctly.
Use extreme caution when selecting and installing the accessories for your
scooter.
No modifications
KYMCO strongly advises you against removing any original equipment or modifying your scooter in any
way that would change its design or operation.
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
Improper accessories or modifications can make your scooter unsafe and can lead to an accident.
Never modify your scooter through the improper installation or use of accessories. All parts and
accessories added to this vehicle should be genuine KYMCO or equivalent components designed for use
on this scooter and should be installed and used according to instruction. If you have any questions,
consult an authorized KYMCO dealer.
WARNING

5
LOCATIONOFPARTS&CONTROLS
6
Air Filter
7
Taillamp, Stoplamp
Rear Brake Lever
1
Headlamp
2
Left Turn Signal Lamp
3
Side Stand
4
NOTE: Your scooter may differ slightly in appearance from the images in this manual.
5
Seat
1
2
3
4
5
6
7
8
8
Coolant Reservoir

10
6
LOCATIONOFPARTS&CONTROLS
NOTE: Your scooter may differ slightly in appearance from the images in this manual.
Muffler
9
Rear Passenger Foot Peg
12
Oil Filler Cap/dipstick
10
9
11
Fuel Filler Cap
11
12
Right Turn Signal Lamp
13
13

7
LOCATIONOFPARTS&CONTROLS
NOTE: Your scooter may differ slightly in appearance from the images in this manual.
Front Turn Signal Lamp
14
Headlamp( Low Bean Lamp)
15
Headlamp( High Bean Lamp)
16
14
15
16

8
LOCATIONOFPARTS&CONTROLS
19
18
Taillamp, Stoplamp
Rear Turn Signal Lamp
Right Handlebar Switch
Ignition Switch
20
21
22
Battery and fuses
(under seat)
Windshield
23
Output voltage 12V
18
19
20
21
22
23
17
17

9
SECTION 2 -
CONTROLS&FEATURES
To operate the ignition switch and it s functions:'
IGNITION SWITCH
All electrical circuits are off. The engine will not
start or run.
“ ” Position:
The ignition circuit is "ON" and engine can now be
started. The key can not be removed from the
ignition switch in this position.
“ ” Position:
“ ” Position:
To lock the steering, turn the handlebar all the way
to the left, push down and turn the key to the " "
position and remove the key. All electrical circuits
are off.
“ ” Position:
With the ignition key at the " " position (the
engine is running), push the key in and turn it
counterclockwise from " " to the position.
""
With the ignition key in the " " position (the
engine is not running), turn the counterclockwise
from the " " to the position.
Pull up on the back portion of the seat to lift it up.
""

CONTROLS & FEATURES
Push the shut-button on the ignition switch cover
and then the shutter should be closed.
To open the ignition switch security
shutter:
To shut the ignition switch security
shutter:
Insert the specific key until the fillister is
facing the pin.
Turn clockwise and then the security shutter
should be opened.
The keys have a unique code that is stamped on
the tab supplied with the keys. This code is not
stamped on the scooter and is not recorded in the
vehicle's basic documentation for security
reasons. Since this code is required if you need
replacement keys, record this important code in
the box provided on the inside, rear cover of this
Owner's Manual.
SECURITY SHUTTER
10

CONTROLS & FEATURES
Instruments
Odometer/Tripmeter: Press the MODE button
to toggle between the overall and trip mileage.
""
Press the “ADJ” button for two seconds, then
displays the ODO, TRIP(A,B) or SERVICE
mode.
Press the “ADJ” and “MODE” button
simultaneously at the TRIP mode, then the
figure reset automatically.
Speedometer: Indicates the road speed in K/PH
(kilometers per hour).
Turn Signal Indicator Light: Flashes when either
turn signal is being used.
High Beam Indicator Light:This light is
illuminated when the headlight high beam is on.
Tachometer: Indicates the engine speed in the
revolutions per minute (RPM)
Clock Coolant temperature gauge
Fuel refill indicator “ “: This indicator lights
when the fuel tank is near empty to alert the rider
to refill the fuel tank as soon as possible.
11
TPM button isn’t installed on Downtown 200 i※
MODE ADJ

CONTROLS & FEATURES
12
CELP indication: If flashing, it indicates that a
fault has been detected in the scooter’s EFI or
electrical system. Requires immediate
inspection by a KYMCO dealer.
Press the ADJ. button for two second, then
displays the ODO TRIP or empty mode.
Press the ADJ. and MODE button
simultaneously at the empty mode, then the
indicator go out automatically.
,
NOTE: The CELP indicator lights momentarily
when the scooter is turned ON before the
engine is running.
,
Oil service indicator: Lights when the scooter
has reached the oil service interval mileage.
The indicator also lights when the ignition is
turned ON but should go out once the engine is
running.
10
10
11
Battery voltage too low warning Indicator:
While user starting the engine, if the battery
voltage is too low. The indicator will Bright light.
Reminded user wanted to charge or replace new
battery .
11

13
CONTROLS & FEATURES
Multifunction display - Digital clock
The clock indicates the time in hours and minutes
when the ignition is “ON”.
To adjust the clock’s time manually,
follow this procedure:
Turn the ignition switch “ON
Press and hold the ADJUST button for more
than two seconds to select the ODO mode.
”
NOTE: The digital clock can be only adjusted
in ODO mode, don’t select the tripmeter or oil
service meter mode if you want to adjust the
time on the clock.
1.
2.
Press and hold both the Mode button and Adjust
button at the same time for more than two seconds.
The “hour” digits will be begin flashing, indicating the
clock time can be adjusted.
3.
To set the hour display, press the ADJUST button
until it displays the correct “hour” time
4.
To change the minute display, press the MODE
button until the “minute” digits begin flashing
5.
To set the minute display, press the ADJUST
button until it displays the correct “minute” time
6.
To end the clock adjustment, press both the
MODE and ADJUST buttons at the same time.
The display will stop flashing automatically. The
adjustment will be cancelled if any button is not
pressed within approximately ten seconds
7.

CONTROLS & FEATURES
Right handlebar switch
Headlight switch " " position:
The headlight and taillight will be lit.
The position light and taillight (running lamps) will
be lit.
“ ” position:
The headlight and taillight will be off.
“ ” position:
Electric starter button " " position:
Press the electric starter button to activate the
starter motor.
NOTE: The starter motor will not engage
unless a brake lever is squeezed at the same
time the starter button is pressed.
Downtown 200i is also equipped with an
safety interlock that prevents the starter
motor from being engaged unless the side-
stand is fully up.
Engine stop switch " " position:
The ignition circuit is off. The engine will not start or
run.
The ignition circuit is on, and the engine can start
and run.
“ ” position:
14

CONTROLS & FEATURES
Left handlebar switch
Turn signal switch :
Use the turn signal indicator to signal to other traffic
your intention to turn or change lanes. The turn
signal light on the dash will flash to alert the rider
that the switch is engaged.
for turning to the "left".
for turning to the "right".
To cancel the turn signal, press the switch in when
it is in the center position.
""
""
Press the horn button to sound the horn.
Horn button :
4
5
45
15

""
""
switch position turns the headlight low beam
on.
switch position turns the headlight high beam
on and the high beam indicator light on the dash is
activated as well.
Use this button to rapidly flick the headlamp high
beam on and off to signal other vehicles that you
wish to pass.
Passing light button :
Dimmer switch :
CONTROLS & FEATURES
6
7
6
7
16
