Kyocera 9130DN - B/W Laser Printer User manual

Operation Guide
FS-9130DN
FS-9530DN

OPERATION GUIDE i
Contents
1 Machine Parts.............................................................................................................................1-1
Components at the Front of the Printer .......................................................................................1-2
Components at the Left and the Rear of the Printer ...................................................................1-3
Components at the Right of the Printer .......................................................................................1-4
2 Printing Operation......................................................................................................................2-1
Loading Printer Driver .................................................................................................................2-2
Printing from Application Software ..............................................................................................2-3
3 Maintenance ...............................................................................................................................3-1
General Information ....................................................................................................................3-2
Toner Container Replacement ....................................................................................................3-3
Cleaning the Printer ....................................................................................................................3-9
4 Troubleshooting.........................................................................................................................4-1
General Guideline .......................................................................................................................4-2
Print Quality Problems ................................................................................................................4-4
Indicators and Messages ............................................................................................................4-7
Correcting a Paper Jam ............................................................................................................4-14
5 Specifications.............................................................................................................................5-1

ii OPERATION GUIDE

OPERATION GUIDE iii
Legal and Safety Information
CAUTION: NO LIABILITY IS ASSUMED FOR ANY DAMAGE CAUSED
BY IMPROPER INSTALLATION.
Notice on Software
SOFTWARE USED WITH THIS PRINTER MUST SUPPORT THE
PRINTER'S EMULATION MODE. The printer is factory-set to emulate the
PCL. The emulation mode can be changed.
Notice
The information in this guide is subject to change without notification.
Additional pages may be inserted in future editions. The user is asked to
excuse any technical inaccuracies or typographical errors in the present
edition.
No responsibility is assumed if accidents occur while the user is following
the instructions in this guide. No responsibility is assumed for defects in the
printer's firmware (contents of its read-only memory).
This guide, any copyrightable subject matter sold or provided with or in
connection with the sale of the page printer, are protected by copyright. All
rights are reserved. Copying or other reproduction of all or part of this
guide, any copyrightable subject matter without the prior written consent of
Kyocera Mita Corporation is prohibited. Any copies made of all or part of
this guide, any copyrightable subject must contain the same copyright
notice as the material from which the copying is done.
Regarding Tradenames
PRESCRIBE is a registered trademark of Kyocera Corporation. KPDL and
KIR (Kyocera Image Refinement) are trademarks of Kyocera Corporation.
Hewlett-Packard, PCL, and PJL are registered trademarks of Hewlett-
Packard Company. Centronics is a trade name of Centronics Data
Computer Inc. PostScript is a registered trademark of Adobe Systems
Incorporated. Macintosh is a registered trademark of Apple Computer, Inc.
Microsoft, Windows, and Windows NT are registered trademarks of
Microsoft Corporation. Microsoft Windows Server is a trademark of
Microsoft Corporation. PowerPC is a trademark of International Business
Machines Corporation. Microdrive is a registered trademark of Hitachi
Global Storage Technologies Netherlands B.V. in the US and other
countries. CompactFlash is a trademark of SanDisk Corporation.
ENERGY STAR is a U.S. registered mark. All other brand and product
names are registered trademarks or trademarks of their respective
companies.

iv OPERATION GUIDE
This product uses PeerlessPrintXL to provide the HP LaserJet compatible
PCL 6 language emulation. PeerlessPrintXL is a trademark of Peerless
Systems Corporation, 2381 Rosecrans Ave. El Segundo, CA 90245,
U.S.A.
This product was developed using the Tornado™ Real Time Operating
System and Tools from Wind River Systems.
This product contains UFST™ and MicroType®from Monotype Imaging
Inc.
USB
This product has been certified by the USB Implementers Forum, Inc.

OPERATION GUIDE v
