Frequently Asked
Questions PA2000w

Table of Contents
Where is the Serial Number located for the PA2000w? ..............................3
How do I check the Toner Level on my PA2000w?......................................4
How do I replace my Toner Container?.......................................................5
Where do I get the Client tool and what are the benefits?..........................8
What Types of Paper and Sizes can I use in my PA2000w? ........................9
How do I change paper size in the MA2000w? .........................................10
How do I Configure Network Connection
Using the Wireless Network Setup Tool ....................................................12
Configuring Network Connection Using the Push Button? ........................14
How do I install the Windows Print Driver for my PA2000w? ...................15
Installing Software in Mac Computer........................................................21
My PA2000w has poor image quality ........................................................24
How do I replace my Drum Unit? ..............................................................26
My PA2000w displays an error indication .................................................29
My PA2000w does not turn ON .................................................................31
My PA2000w has a message on the display that
a Paper Jam has occurred. Also, there is a flashing Attention light ..........32

FAQs PA2000w
3
Where is the Serial Number
located for the PA2000w?
The Serial Number is located on the back
panel of the device. It will be a white label
that looks like a barcode.
Note: The serial # is also located in the
upper right corner on the printed status
page.

FAQs PA2000w
4
How do I check the Toner Level on
my PA2000w?
Remaining Toner can be found on the printer Status Page. You can print reports to check the
machine status, and event log.
Remaining Toner can also be located on the Client tool under supplies.
When [Main power] is pressed. Attention indicator
and Main Power Indicator flash at the same time, and
the machine switches to the Report Print Mode. A
report can be printed by pressing and holding [Main
power] in this state.
A report to be printed can be selected with the
pressing length.
+Pressing for 5 seconds: Prints the status page.
+Pressing for 10 seconds: Prints the network status
page (MA2000 / MA2000w).
+Pressing for 15 seconds: Prints the event log page.
Note: While pressing [Main Power]. Attention
indicator and Main Power indicator blink twice
alternately in 5 seconds intervals.

FAQs PA2000w
5
How do I replace my Toner
Container?
1. Open the top cover.
2. Push the toner cartridge lock button and then, lift the toner cartridge out of the machine.
Note: Put the old toner cartridge in the plastic bag (supplied with the new toner kit) and discard it
later according to the local code or regulations for waste disposal.

FAQs PA2000w
6
3. Take the new toner cartridge out of the toner kit. Shake the new toner cartridge at least 5 times as
shown in the figure in order to distribute the toner evenly inside the container.
4. Remove the cover from the toner cartridge.

FAQs PA2000w
7
5. Set the new toner cartridge to its position, aligning the guides at both ends with the slots in the
machine. Next, press the levers on both ends of the toner cartridge until they click.
6. Press the center of the top cover to close.

FAQs PA2000w
8
Where do I get the Client tool and
what are the benefits?
The Kyocera Client tool is installed if the box is checked when running the Web Installer. The Utility
enables current and all supported devices status, features and settings to be accessed.
When KYOCERA Client Tool is installed, the following utilities are installed. For more information
download the Client tool operation guide.
Status Monitor
Preset Tool
Configuration
Maintenance Menu
You can also use KYOCERA Client Tool to order
toner, download printer drivers, access KYOCERA
NetViewer, open the company website and view
machine documentation. For more information
download the Client tool operation guide.

FAQs PA2000w
9
What Types of Paper and Sizes
can I use in my PA2000w?
For best results, use High Quality Multipurpose Paper within Kyocera’s guidelines as outlined.
Paper
Weight
64 to 105g/m2, 20lb, to 28lb
Paper Type
Plain, Preprinted, Bond, Recycled, Rough, Letterhead, Color,
Prepunched, High Quality, Custom 1-8
Paper Size
Letter, Legal
Custom (Width: 5.8”, Length 5,8” – 14”)

FAQs PA2000w
10
How do I change paper size in the
MA2000w?
1. Open the KYOCERA Client Tool.
Click Start button on the Windows > Kyocera > KYOCERA Client Tool.
3. Select Device > Configuration. 4. Select OK.
1. Open the top cover.
1. Open the top cover.
1. Open the top cover.

FAQs PA2000w
11
5. Select the Paper size drop down and choose the paper you have in the paper tray.
6. Press OK.

FAQs PA2000w
12
How do I Configure Network
Connection Using the Wireless
Network Setup Tool
To send the wireless network settings configured using the Wireless Network Setup Tool to the
machine, connect the computer with the machine locally. The connection method is wired connection
via USB cable.
1. Connect the machine with a computer via USB cable when the machine is powered on.
2. Turn on the computer.
3. Open the KYOCERA Client Tool.
4. Click Start button on the Windows > Kyocera > KYOCERA Client Tool.
5. Click the Wireless Network settings tab > Wireless Network Setup Tool.

FAQs PA2000w
13
6. Configure the settings.
1Select “Do not use WPS”.2 Press next.
3Select an access point you want to
connect the device, and then click Next.
4 Enter the pre-shared key, and then
click Next.
5Select the check boxes of functions you
want to use with Wireless Network
connection, and click Finish.
The network between this machine and the
computer is configured.
Note: Event if show “Setup Complete”, If you
have the problems communicating with the
access point, please check that access point
information you set is correct. To reconfigure
the settings, uninstall the drivers and utilizes,
and reinstall them again.

FAQs PA2000w
14
Configuring Network Connection
Using the Push Button?
If your router supports WPS, you can configure network connection using the push button.
1. Turn on the computer.
2. Press [Wireless Network] on the operation panel of the machine. The wireless network
indicator flashes.
3. Press the push button on the router.
4. The network between this machine and the router is configured. If the network connection
between this machine and the router is complete, [Wireless Network] will light up.
5. Install the printer driver for wireless network connection on your computer.

FAQs PA2000w
15
How do I install the Windows Print
Driver for my PA2000w?
Supported operating systems:
Windows 11
Windows 10
Windows 8.1
Windows Server 2022
Windows Server
2019
Windows Server 2016
Windows Server 2012
R2
Windows Server 2012
Note: If you install the driver in unsupported operating systems including Windows 7, Windows
Server 2008 R2, and Windows Server 2008, a security message appears. To proceed with the
installation, allow the installer to make changes to your computer. For more information on Microsoft
Windows support policy, go to the Microsoft Support website.
Downloading and installing from the website
1. Enter "https://kyocera.info/" to the browser's address bar or location bar.
2. Enter and search the product name and select this product from the candidate list.

FAQs PA2000w
16
3. Change the selected operating system and its language setting as needed.
4. Under the Recommended section, select the driver you want to download
5. Read the license agreement. Click Agree to contract and download if there is no problem.
An installer of the selected software will be downloaded.
6. Double-click the downloaded installer
to launch. Follow the guidance on the
screen to install the software.
Note: Installation on Windows must be
done by a user logged on with
administrator privileges. If the user
account management window appears,
click [Yes] [Allow]

FAQs PA2000w
17
Using the web installer
Install a software by using a web installer downloaded from our website.
1. Launch a web browser.
2. Enter "https://kyocera.info/" to the browser's address bar or location bar.
3. Enter and search the product name, and select this product from the candidate list.
4. Change the selected operating system and its language setting as needed.
5. Click "Web installer".

FAQs PA2000w
18
6. Read the license agreement. Click Agree to contract and download if there is no problem. A
web installer will be downloaded.
7. Double-click the downloaded installer to launch.
Note: Installation on Windows must be done by a user logged on with administrator privileges. If the user
account management window appears, click [Yes] [Allow]
8. Read the license agreement. Click Accept if there is no problem.

FAQs PA2000w
19
9. Click Install.
10. Select a model and click Next.
11. Select softwares you want to install.
Note: The machine cannot be detected
unless it is on. If the computer fails to
detect the machine, verify that it is
connected to the computer via a network
or USB cable.
If a desired is not displayed, select Add
custom device to directly select the
device you want to use.
Note: Softwares recommended to install
have in their checkboxes by default.
Configure them as needed.

FAQs PA2000w
20
12. Click Install.
When Install is clicked, a screen which asks for cooperation for data collection may appear. Select
one of the choices and click OK.
13. Finish the installation.
Click Next > Finish to finish the installation wizard.
If a system restart message appears, restart the computer by following the screen prompts. This
completes the printer driver installation procedure.
Note: If the Windows security window
appears, click install this driver
software anyway. If the Microsoft .NET
Framework installation screen is displayed,
click Yes to install it.
