La Crosse Technology WT-941 User manual

MODEL: WT-941
WWVB—RADIO CONTROLLED WATCH
ABOUT WWVB (Radio Controlled Time)
The NIST (National Institute of Standards and Technology—Time and Frequency
Division) WWVB radio station is located in Ft. Collins, Colorado, and transmits the
exact time signal continuously at 60 kHz. The signal can be received up to 2,000
miles away through the internal antenna in the watch. However, due to the nature of
the Earth’s Ionosphere, reception is very limited during daylight hours. The Watch
will search for a signal every night when reception is best. The WWVB radio station
derives its signal from the NIST Atomic clock in Ft. Collins, Colorado. A team of
atomic physicists is continually measuring every second, of every day, to an accuracy
of ten billionths of a second per day. These physicists have created an international
standard, measuring a second as 9,192,631,770 vibrations of a Cesium-133 atom in a
vacuum. This watch is regulated by the WWVB transmitter.
SET-UP GUIDE, FEATURES, AND OPERATION
I.
II.
III.
IV.
V.
TIME ZONE SELECTION
The default Time Zone is Eastern Time (EST, also GMT-5). There are 25
Time Zones to choose from. The selection will cycle from GMT-5 to GMT-
12, then GMT+12 to GMT +1, then GMT, then GMT-1 to GMT –5.
1. Hold down the TIME ZONE button for 2 seconds, or until a Time
Zone abbreviation and “ZONE” flash in the LCD, and release.
2. Repeatedly press the TIME ZONE button until the appropriate Time
Zone is displayed.
3. Wait 6 seconds for the automatic time-out to exit the Time Zone
selection mode.
ACTIVATION
The Radio-Controlled watch is programmed and shipped in a battery-saving
mode. The LCD (Liquid Crystal Display) displays “OFF” and must be
activated before set-up can begin. Your watch may not be in this mode; if not
all you need to do is set your time zone (the correct time may or not be
shown).
DAYLIGHT SAVING TIME (DST)
Through the WWVB signals, the watch automatically adjusts for Daylight
Saving Time.
SHUTDOWN AND RESETTING
This procedure will clear all information. Follow the above sections (I, II) to
activate the watch again.
1. Press the TIME ZONE button briefly to activate the WWVB reception
search. The LCD lights up briefly and will then display “-:--” and the
watch will begin to search for the WWVB signal. If a signal is found,
a “tower” icon will flash; if no signal is present, no icon will flash.
1. Hold down the TIME ZONE button for 6 seconds. The LCD will
cycle from normal display, to Time Zone display, and back to normal
display. The final display will be “OFF.”
2. Within six minutes, the watch will either set to the exact time and
date (Eastern is the default), or will display “-:--”.
TIME ZONE key
Atlantic Time (ATL): GMT-4 Alaska Time (ALA): GMT-9
Eastern Time (EST): GMT-5 Hawaii Time (HAW): GMT-10
Central Time (CST): GMT-6
Mountain Time (MST): GMT-7
Pacific Time (PST): GMT-8 Greenwich Mean Time (GMT): GMT
“Hawaii Time displayed
(GMT-10)
MANUALLY ACTIVATING THE WWVB SEARCH
At any time after the Time Zone has been selected, and during the normal
operating mode:
Do not press the TIME ZONE button while the watch is searching for the
WWVB signal, which normally takes 6-10 minutes. However, the optimal
time for WWVB reception is between midnight and 6:00 a.m., reception may
not occur until this time period. When the WWVB search is complete the
time and date will automatically be displayed in the LCD. If the watch is not
within range of WWVB signals for an extended period of time it will still
continue to operate as a highly accurate quartz controlled clock.
1. Hold down the TIME ZONE button for 4 seconds (the LCD will
display the time zone then will revert back to normal view). The
WWVB tower icon will appear in the upper right corner of the LCD,
indicating that the watch is searching for a WWVB signal.
Note: It is important not to hold the TIME ZONE button down long
enough to shutdown or reset the watch.

VI.
VII.
VIII.
TROUBLESHOOTING
LOW BATTERY INDICATOR
The watch is supplied with, and powered by a high quality 3V lithium battery
with a life expectancy of over 2 years. There is a low-battery indicator that
appears between the minutes and the date when the battery is low. The
battery should be replaced within 2 months of the appearance of the low-
battery indicator.
Problem: No WWVB signal (indicated by the absence of the WWVB tower icon).
Solution: 1) Check the selected Time Zone. If it is set between GMT+1 and GMT
+12, the WWVB signal will not be received. Change the Time Zone.
2) Move watch 10 feet (3 meters) away from any interfering sources, i.e.
electrical appliances (refrigerators, TV’s, computers), metal surfaces or
objects.
3) To help with overnight reception, place watch in a window with the
band inline with the general direction of Ft. Collins, Colorado.
4) There are a few places the signal is very weak (Los Angeles area, Some
parts of Florida and New York City). Since the watch has a much smaller
receiver than our other clocks, it is possible no reception can be made.
Please inform La Crosse Technology in this case.
Problem: The watch displays “-:--” and no date
Solution: 1) The watch entered the power off mode and was reactivated. No signal
has been located, and no time is set. Once the watch receives the time
signal successfully (usually at night), it will display the correct time and
date (Eastern Time zone is the default).
Problem: The hour or minute is incorrect, even though the tower icon is on
(indicating a successful reception of the WWVB time signal the previous
night) and it is set to the proper time zone.
Solution: 1) Electrical interference caused the time signal to be improperly received.
Be sure the watch is at least six feet from any source of electrical activity
(television, computer). Overnight it should correct itself.
2) You may need to perform a reset; follow the directions outlined in
section IV.
MAINTENANCE AND CARE
Under normal conditions, the watch is shock resistant, however avoid
excessive “rough” treatment of the watch as this may cause serious damage.
Clean the watch with a soft dry cloth, or with one moistened with a mild soap
solution. Do not use any chemical cleaning solutions, these may cause
permanent damage to the watch’s surface. While the watch is water resistant
to 100 feet, do not submerge in water for extended periods of time.
1. ADJUSTING THE STRAP
The rubber strap is adjustable to fit most all wrist sizes. It is also
replaceable with a properly sized band available at a local watch or
department store. The strap is held in place by a pin on each side.
REPLACING THE BATTERY
The battery can either be replaced by a qualified jeweler or watch repair shop,
or by the user.
Any damage resulting from this procedure
is not covered under warranty.
Note: For all questions not answered contact La Crosse Technology (contact
information is below).
WARRANTY INFORMATION
La Crosse Technology provides a 1-year warranty on this watch. Contact La Crosse Technology
immediately upon discovery of any defects covered by this warranty. Before sending the watch in
for repairs, contact La Crosse Technology. The watch will be repaired or replaced with the same
or similar model. This warranty does not cover any defects resulting from improper use,
unauthorized repairs, faulty batteries, or the watch’s inability to receive a signal due to any source
of interference.
Battery clip
Battery
compartment
1. Remove the four screws located
on the back and remove the cover.
Be sure the watch movement and
gasket do not come out of
the case. LA CROSSE TECHNOLOGY WILL NOT ASSUME LIABILITY FOR INCIDENTAL,
CONSEQUENTIAL, PUNITIVE, OR OTHER SIMILAR DAMAGES ASSOCIATED WITH
THE OPERATION OR MALFUNCTION OF THIS WATCH. THIS PRODUCT IS NOT TO BE
USED FOR MEDICAL PURPOSES OR FOR PUBLIC INFORMATION. THIS PRODUCT IS
NOT A TOY. KEEP OUT OF CHILDRENS’ REACH.
2. Remove the old battery
by gently prying up the
battery clip.
3. Insert a new battery of the type “CR1620” 3 Volt Lithium Cell battery This warranty gives you specific legal rights. You may also have other rights specific to your
State. Some States do no allow the exclusion of consequential or incidental damages therefore the
above exclusion of limitation may not apply to you. For warranty work, technical support, or
information contact
4. Please dispose of the old battery properly.
La Crosse Technology, 190 Main Street, La Crescent, MN 55947
Phone: [phone], Fax: [phone]
www.lacrossetechnology.com; [e-mail]
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE,
AND THIS DEVICE MUST ACCEPT INTERFERENCE RECEIVED, INCLUDING INTERFERENCE
THAT MAY CAUSE UNDESIRED OPERATION.
