Labelmate MC-11+ User manual

MAINTENANCE:
Your MC-11+ requires no maintenance
Product Limited Warranty
All Labelmate Products are warranted to the original end-user customer to be free from defects in
materials and workmanship. If it is determined by Labelmate that a product has failed under the terms of
this warranty, the product will be repaired or replaced at no charge to the customer. Labelmate reserves all
rights to determination of coverage and liability under this warranty. The warranty period for all new
Labelmate products is outlined below:
The warranty period for all products starts on the date purchased by the original end-user customer.
Warranty coverage is not transferable with ownership and will terminate immediately upon rental, resale or
any other change in ownership. This warranty does not cover repair to any product which is damaged, has
been modified, is missing parts, or has been opened or repaired by any unauthorised person. Use of any
unauthorised accessory or attachment will void coverage. Purchase documentation should be retained for
coverage verification.
In the event your product requires service, please contact the distributor you bought the product from. The
customer assumes responsibility for all cost and risk incurred in transport for service.
Labelmate makes no other warranty of any kind expressed or implied, or to suitability or fitness for a
particular purpose. No other person, agent or reseller is authorised to give any warranties on behalf of
Labelmate. Any obligation to warranty other than that specifically addressed above is hereby disclaimed.
Warranty Period
Products Covered
5 years
Label Rewinders
Label Unwinders
3 years
Label Counters (mechanical parts
only)
Label Slitters (mechanical parts
only)
Label Dispensers
Printer Mechanisms
1 year
Power Supply Modules
Counter modules
Encoders
Any products not specified above.
SPRL
290, Chaussée de Ruisbroek, 1620 Drogenbos, BELGIUM
TEL: [phone] –FAX: [phone]
[e-mail]
www.labelmateeurope.com
MINI-CAT Label Rewinder with Adjustable Core Holder
•Switched Bi-Directional Control.
•Build-in Speed/Torque Control
•Standard External Control
•Constant Adjustable Torque™
"CAT" Technology.
Remove all parts from the shipping container and verify contents.
PACKAGE CONTENTS:
•User Manual (this document)
•MC-11+ Rewinder Unit
•Adjustable Core Holder
•Power Supply Module
Retain the Shipping Container and Packaging for Storage and Transport
SPECIFICATIONS:
Weight of the machine: 5,6Kg
Max. Label Roll Weight: 3Kg.
Max. Label Roll Diam.: 220mm.
Start/Stop: ON/OFF/ON Direction Switch
Power Supply: Input: 220-240VAC –50-60Hz.
Output: 15VDC –800mA.
WARNING!
This Product is for indoor
use only.
Not for use in wet locations.

IMPORTANT INFORMATION:
•This product is a label rewinder It is only to be used to rewind labels of the
recommended dimensions and weight in an indoor, dry environment.
•The machine has to be unplugged before any manipulation.
•The machine is to be used on a flat surface, if the surface is not flat, it is to be fixed
using the holes in the base plate.
•Do not leave the power cable in a passageway.
•The ambient light of the working area needs to be sufficient to avoid any risk.
•The rewinder can be used in ambient temperatures of +2°C to 40°C.
•Connection of the machine to the power source must respect local and European
legislations.
SET-UP:
1. Place the MC-11+ so that the three (3) Rewind Fingers are perpendicular to the web
of the labels to be rewound. The MC-11+ is bi-directional, and can be operated in
either direction.
2. Verify that the (ON-OFF-ON) Direction Switch on the rear of the MC-11+ is in the
OFF (0) position.
3. Insert the Power Supply Cord into the Power Jack on the rear of the MC-11+.
4. Plug the AC/DC Adapter into a suitable electrical outlet. The AC/DC Adapter can be
left plugged in at all times.
5. The Rewinder has a combination Power and (ON-OFF-ON) Direction Switch on the
rear panel. See the photo below. To make the Rewinder run to the right (looking from
the rear of the Rewinder), press the Power/Direction Switch in the direction of the
right arrow. To make the Rewinder run to the left, press the Power / Direction Switch
in the direction of the left arrow.
FOR YOUR SAFETY:
Switch off device before any manipulation
REWINDING LABELS:
Rewind labels onto any core 25-101mm diameter. The Adjustable Core Holder is
supplied fully assembled. Please, refer to the ACH Manual User enclosed to set it up.
1. Pull the label web to the cardboard core and use a piece of tape to secure the label
web.
2. Adjust the position of the MC-11+ if necessary so it is square with the label path.
3. If you are using the APG-MC Adjustable Paper Guide, move the Arm into position to
guide the outer edge of the labels and lock it into place.
4. Place the MC-11+ (ON-OFF-ON) Direction Switch to the ON position in the desired
direction of operation, left or right.
5. Start the printer and adjust the "SPEED/TORQUE" Control Knob for the
desired take-up tension. Use the minimum "SPEED/TORQUE" setting
needed to rewind labels properly. Excessive torque might pull the labels
too hard and cause the printer to lose registration.
6. When finished, place the (ON-OFF-ON) Direction Switch to the OFF (0) position.
7. If the APG-MC Adjustable Paper Guide is in use, unlock and move the Arm out of the
way.
8. Slide the cardboard core and the wound labels off the MC-11+. You do not need to
loosen the three (3) Locking Levers unless you want to use a different diameter core.
EXTERNAL CONTROL
The MC+ can be controlled by the printer. A 3.5mm (mono) connector for an External
Control Input (start/stop) is provided and a matching jack is enclosed. The MC+ can react
to different types of signals provided by the printer. The selection of the signal nature is
done via 2 jumpers on the MC+ internal PCB. Four modes are selectable: Open Collector
High Active, Open Collector Low Active, Logic Level High Active (Max 10VDC) & Logic
Level Low Active (Max 10VDC).
The factory setting is “Open Collector high”. Other default setting on request.
JP2
JP3
SIG ACT LOW
1
SIG ACT HIGH
2
OPEN COL LOW
X
XX 1
OPEN COL HIGH
X
2
