LaCimbali M26 Technical manual

M26
997-184-000 (rev. 1948)
USA
USE AND INSTALLATION
UTILISATION ET INSTALLATION
Translation of the original instructions
Traduction du manuel d’origine

https://order.gruppocimbali.com/explorer/spareparts/page/login
User ID: guest
PW: Entr@nc3
An updated, electronic version of the manual can be accessed from the website shown at
the bottom of the page, using the credentials below.
Une copie actualisée du présent manuel est disponible au format électronique en accédant
au site indiqué en bas de la page, en utilisant les identi¿ants communiqués cidessous.

I
English Français
English
Français
Translation of the original instructions
......................................................
Traduction du manuel d’origine
......................................................

1
1a
DT C
21 20
2
19 18 17
(17a)*
2
(2a)*
163
10* 11 15 OK
14
12 13
17 10
45678 9
II

III
EN FR
LEGEND
1Main ON/OFF switch
1a Boiler heat resistance switch (*)
2Steam adjustment knob
2a Turbosteam selector (*)
3Cups-warmer (*)
4Dispensing push button - 1 short coffee
5Dispensing push button - 2 short coffees
6STOP-continuous / Prog - push button
7Dispensing push button - 1 long coffee
8Dispensing push button - 2 long coffees
9Coffee dispensing switch
10 Electrical cup warmer button (*)
11 Hot water button
12 “ ” key (to quit programming mode / cancel entered data)
13 " " key (to modify parameters / clock)
14 " " key (to access programming mode / menu)
15 " " key (to modify parameters / clock)
16 Graphical display (*)
17 Swivel steam jet pipe
17a Turbosteam pipe (*)
18 Pan
19 Pump pressure gauge / Boiler pressure gauge (*)
20 Hot water dispensing pipe
21 Filter holder
OK On / Off switch boiler resistance - con¿rm entered data
The components - * - are applied only in some produit
con¿gurations
LÉGENDE
1Interrupteur général
1a Interrupteur branchement résistance chaudière (*)
2Poignée de réglage de la vapeur
2a Sélecteur Turbosteam (*)
3Chauffe-tasses (*)
4Touche débit 1 café court
5Touche débit 2 café court
6Touche STOP-CONTINU / Prog
7Touche débit 1 café long
8Touche débit 2 café long
9Interrupteur de débit du café
10 Touche chauffe-tasses electrique (*)
11 Bouton de l'eau chaude
12 Touches ” ” (sortir de la programation /
données introduites non valables)
13 Bouton” ” (modi¿er les paramètres / horloge)
14 Touches ” ” (entrer en programation / menu)
15 Bouton” “ (modi¿er les paramètres / horloge)
16 Ecran graphique (*)
17 Tuyau (lance) orientable de la vapeur
17a Tuyau Turbosteam (*)
18 Cuvette
19 Manomètre de la pompe / Manomètre de la chaudière (*)
20 Tuyau (lance) d’eau chaude
21 Porte-¿ltres
OK Bouton poussoir d'activation / désactivation résistance
chaudière - con¿rmation des données introduites
Les composants - * - sont montés seulement dans
quelques con¿gurations de produits

IV
Pmax
[ bar ]
[ psi ]
Tmax
[ °C ]
[ °F ]
Type of machine
type de machine
2 groups
2 groupes
3 groups
3 groupes
Fluid - Fluide Capacity - Capacité [ L ]
Service boiler
Chaudière
2
29
133
271
water/steam
eau/vapeur 10 15
Heat exchanger
Échangeur de chaleur
12
174
133
271
water
eau 0.18 x 2 0.18 x 3
~260(10.2)
Ø~100(3.9)
~ ½ L
L1
L
121 (4.8)
548 (21.6)
547 (21.5)
495 (19.5)
315 (12.4)
528 (20.8)
L
L1 mm
inches
Weight Kg
pounds
DIMENSIONS
2 gr. 3 gr.
mm
inches 794
31.3 994 39.1
570
22.4 770 30.3
75
165 87
192
* 140 (5.51) for VA version
75 (2.9)*

V
3
Symbols - Symboles
Generic warning - Avertissement générique
WARNING: Electrical Hazard - ATTENTION: danger électrique
WARNING: Trapping Hazard, Take Care with Hands - ATTENTION: danger d'écrasement des mains
WARNING: Hot surface - ATTENTION: Surface chaude
Environmental protection - Sauvegarde de l’environnement
These pages in the manual are to be used by quali¿ed, authorized technical staff.
Ces pages du manuel sont réservés au personnel technique quali¿é et autorisé.
These pages of the manual are for the use of the worker operating the machine.
Ces pages du manuel sont destinées à l'opérateur.

VI
This page is intentionally left blank.
Cette page est délibérément laissée vierge.

English
1 EN
Page Page
Index
1. General Rules ................................................. 2
2.1 Transport and handling ................................. 3
2.2 Installation Rules............................................ 4
3. Electrical Installation Rules........................... 5
4. Water Installation Rules................................. 5
5. Installation Check-up..................................... 6
6. Rules for the worker operating
the machine .................................................... 7
7. Caution............................................................ 8
8. Maintenance and Repairs.............................. 9
9. Decommissioning the machine ................... 10
USE
10. Daily operation ................................................ 11
11. Description display symbols
(only DT version with display) ....................... 14
12. Changing the water in the boiler
(only DT version with display) ....................... 15
13. Cup Warmer (where applicable)..................... 15
14. Coffee dispensing ........................................... 16
15. Hot water dispensing...................................... 16
Programming measures using the
“SELF-LEARNING” function .......................... 17
16. Steam dispensing........................................... 18
16.1 Dispensing with the Turbosteam selector
(where applicable)........................................... 19
17. Cleaning and maintenance............................. 20
Groups of DT version with display................ 21
Simultaneous washing ...................................... 22
Sequential washing ........................................... 23
Single washing .................................................. 24
Block function.................................................... 25
Changing the water in the boiler.................... 25
Groups of C version /
DT version without display............................. 26
Filter-holders ................................................... 26
Steam and hot-water dispensing pipes......... 27
Grille and Drip Basin ...................................... 27
Draining tray ................................................... 27
Bodywork ....................................................... 27
18. Defects - Malfunctions .................................... 28
Messages in explicit mode............................. 28
CUSTOMER PROGRAMMING
(only DT version with display)
19. Data Àow chart................................................. 29
20. Clock adjustment ............................................ 30
21. How to access the programming mode ........ 30
22. Key menu - Coffee selection .......................... 31
23. Key menu - Hot water selection..................... 31
24. Washing ........................................................... 31
25. DATA menu - Counter display and zeroing... 32
26. Customer parameters menu........................... 33
Language selection ........................................... 33
Service time menu............................................. 34
Date and time.................................................... 34
ILLUSTRATIONS ............................................ VII
Changing the Voltage of the Transformer..... VII
Service Line ................................................... VIII

English
2 EN
1. General Rules
Please read the warnings and rules in this User’s Manual carefully before using
or handling the machine in any way because they provide important information
regarding safety and hygiene when operating the machine.
Keep this booklet handy for easy reference.
• The machine was designed solely for preparing espresso coffee and hot beverages using hot
water or steam, and for warming cups. Any other use is considered irregular.
• The machine must be installed in a place where it is only used by carefully trained staff that know
the risks attached to using the machine.
• The machine is for professional use only.
• This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they are supervised
or given instruction concerning the safe use of the appliance and understand the hazards involved.
Children must not play with the appliance.
Cleaning and user maintenance must not be made by children without supervision.
Use by minors, with or without adult supervision, must not contravene local employment laws.
• Never leave the appliance unattended while it is in use.
• The appliance must not be used outdoors.
• If the appliance is stored in rooms where the temperature can drop below the freezing point,
empty the boiler and water circuit tubes.
• Do not expose the appliance to atmospheric agents (rain, sun, and cold).
• Do not clean the appliance with jets of water.
• Noise: assessed acoustic pressure level 77 dB(A) (+/- 2.5dB).
• If the power-supply cord is damaged, it can only be replaced by quali¿ed and authorized
technicians.
• If the machine is used improperly or for purposes other than those described above, it can be a
source of danger. The manufacturer will not be held responsible for damages caused by improper
use of the appliance.

English
3 EN
WARNING
Installation, dismantling, and adjustments must only be performed by quali¿ed and
authorized technicians.
Carefully read the warnings and rules in this manual because they provide important
information regarding safe installation, use and maintenance of the machine.
Keep this booklet handy for easy reference.
2.1 Transport and handling
3
Packaging
• The machine is delivered in a robust cardboard package, with appropriate internal protection. The
package features the standard symbols indicating rules to be followed when handling and storing
the appliance.
• Transport must be carried out according to the instructions on the package, handling with
appropriate caution and avoiding impact of any type.
• Do not expose the appliance to atmospheric agents (rain, sun, and cold).
Checks on receipt
• On receipt of the appliance, carefully check all transport documentation is correct (against label
on package).
• Check that the original packaging is not damaged.
• After removing the appliance from its packing materials, make sure that the appliance and its
safety devices are intact.
• Packing materials (plastic bags, polystyrene foam, staples, etc.) must be kept out of the reach of
children because they are potentially hazardous.
Advice for disposal of packaging
The packaging materials are eco-compatible and recyclable. For the protection of the
environment they must not be dumped, but taken to a recovery / waste-disposal centre,
according to local regulations.

English
4 EN
Handling
Staff responsible for moving the appliance must be aware of the risks in moving heavy loads.
Move the appliance carefully, using, where possible, the correct lifting equipment (fork lift, for
example).
If moving the appliance by hand, make sure:
- enough people are available for the task, depending on the appliance weight and how
dif¿cult it is to handle
- to always use the necessary safety equipment (shoes/gloves).
2.2 Installation Rules
• Before plugging in the appliance, make sure that the information on the nameplate (voltage, etc.)
matches that of the electrical and water systems.
• Check the condition of the power-supply cordif it is damaged it must be replaced.
• Completely unwind the power-supply cable.
• The coffee machine should sit on a Àat, stable surface at least 1 inch (20 mm) from walls and
from the counter. Keep in mind that the highest surface on the machine (the cup-warmer tray) sits
at a height of at least 47 inches (1.2 meters). Make sure there is a shelf nearby for accessories.
• 5oom temperature must range between 50°F and 89.°F (10° and 32°C).
• An electrical outlet, water connections, and a drain with siphon must be in the immediate vicinity.
• Do not install in rooms (kitchens) that are cleaned with jets of water.
• Do not obstruct openings or ventilation and heat vents.
• Do not install the appliance outdoors.
• Do not install or use the appliance in potentially explosive environments.
• Do not install the appliance in the presence of Àammable substances.

English
5 EN
Prior to installation, make sure there is a circuit breaker installed with a distance between the contacts
that allows for complete disconnection when there is a category III overload and that provides
protection against current leakage equal to 30 mA. The circuit breaker must be installed on the
power-supply in compliance with installation rules.
If the power-supply is not working properly, the appliance can cause transitory voltage drops.
The electrical safety of this appliance is only ensured when it is correctly connected to an ef¿cient earthing system in
compliance with the electrical safety laws in force. This fundamental safety requirement must be veri¿ed. If in doubt,
request that a quali¿ed electrician inspect the system. The manufacturer cannot be held responsible for any damage
caused by the lack of an earthing system on the electrical supply.
Do not use adaptors, multiple plugs, and/or extension cords.
Check that the type of connection and voltage correspond with the information on the nameplate: see illustrations chapter,
Figure 1.
For machines with a single-phase connection: see illustrations chapter, Figure 2.
3. Electrical Installation Rules
4. Water Installation Rules
WATER REQUIREMENTS
Water used in coffee machines must be suitable for human consumption (see laws and regulations in force).
Check on the machine’s water inlet that the pH and chloride values comply with current law.
If the values do not fall within the limits, an appropriate water-treatment device must be inserted (respecting the local laws
and compatible with the machine).
If the machine uses water with a hardness exceeding 8 °f (4.5 °d), a speci¿c maintenance plan must be implemented
according to the hardness detected and machine usage.
WARNING
Only use the supplied parts for installation. If other parts are installed, they must be new (unused
pipes and gaskets for the water connection) and they must be permitted for contact with water
suitable for human consumption (according to local laws in force).
WATER CONNECTIONS
Place the appliance on a Àat surface and stabilize it by adjusting and securing the feet.
Hook up the water connections as shown in the Illustrations chapter, Figure 3, respecting the hygiene, water safety, and
anti-pollution laws in the country of installation.
Note: If the water pressure can rise above 87 psi (bar), install a pressure reducer set at 29·43 psi (2·3 bar). See
Illustrations chapter, Figure 4.
Water draining tube: place the end of the water draining tube in a drain with a siphon for inspection and cleaning.
IMPORTANT: The curves of the water-draining tube must NOT bend as shown in Illustrations chapter, Figure 5.
ATTENTION: This equipment is to be installed with adequate backÀow protection to comply with the applicable
federal, state or local plumbing codes having jurisdiction.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.

English
EN
WATER CONNECTIONS
• No leaks from the connections or tubes
FUNCTIONING
• Boiler and operating pressures are normal.
• The pressure gauge is working properly.
• The self-levelling device is working properly.
• The expansion valves are working properly
GROUPS
• Hook up the ¿lter holders to the groups (without coffee).
• Let each group dispense water for about a minute.
HOT WATER
• Continuously dispense hot water (pressing the appropriate button) until at least 5 liters of water have been used for
a machine with 2 groups, and 8 liters for a machine with 3 groups.
See the “Hot water dispensing” chapter in the User’s Manual.
STEAM (also with Turbosteam)
• Dispense steam from the nozzles for about a minute, using the appropriate buttons.
WARNING: AFTER INSTALLATION, CHECK TO SEE IF THE MACHINE IS WORKING PROPERLY (see the
Installation Module C).
WARNING: ONCE THE MACHINE HAS BEEN INSTALLED AND IS READY FOR USE, BEFORE ALLOWING
THE WORKER TO START USING THE MACHINE, WASH THE INTERNAL COMPONENTS ACCORDING
TO THE INSTRUCTIONS BELOW:
5. Installation Check-up

English
7 EN
BEFORE YOU START
Groups
• Hook up the ¿lter holders to the groups (without coffee).
• Let each group dispense water for about a minute.
Hot Water
• DT version with display. Run the water replacement as indicated in the section "Changing the
water in the boiler".
• C version / DT version without display. Continuously dispense hot water (pressing the
appropriate button) until at least 5 liters of water have been used for a machine with 2 groups,
and 8 liters for a machine with 3 groups.
See the “Hot water dispensing” chapter in the User’s Manual.
Steam (also with Turbosteam)
• Dispense steam from the nozzles for about a minute, using the appropriate buttons.
DURING OPERATION
Steam dispensing (also with Turbosteam)
• Before heating the beverage (water, milk, etc.), open the steam nozzle for at least 3 seconds and
let the steam escape so that condensation is eliminated.
Coffee dispensing
• If the machine has not been used for more than an hour, before using the hot water, dispense
about 100 cc and discard the liquid.
Hot water dispensing
• If the machine has not been used for more than an hour, before using the hot water, dispense
about 200 cc and discard the liquid.
Cleaning the coffee
• Please read the speci¿c section in the user’s manual to learn how to clean these circuits.
WARNING: BEFORE YOU START OPERATING THE MACHINE, WASH THE INTERNAL
COMPONENTS FOLLOWING THE INSTRUCTIONS INDICATED BELOW.
THESE STEPS MUST BE REPEATED AT LEAST ONCE A DAY AND WHEN THE MA-
CHINE HAS NOT BEEN OPERATED FOR MORE THAN 8 HOURS.
6. Prescrizioni per l’operatore6. Rules for the worker operating the machine

WARNING: Hot surface
ACHTUNG: Heisse OberÀlche
ATTENTION: Surface chaude
ATTENZIONE: Super¿cie calda
English
8 EN
GENERAL
The manufacturer disclaims all liability for
damages to items or persons due to improper
use or due to the coffee machine being used
for purposes other than its intended use.
Do not operate the coffee machine with wet hands
or bare feet.
Ensure that the appliance is not used by children
or persons who have not been instructed in its
correct use.
Danger of Burns
Do not place the hands or other parts of the body
close to the coffee dispensing groups, or near to
the steam and hot-water nozzles.
Cup-warmer tray
Place only coffee cups, cups and glasses to be
used in conjunction with the coffee machine on
the cup-warmer tray.
Ensure that the coffee cups are completely
drained before placing them on the cup-warmer
tray.
No other objects shall be placed on the cup-
warmer tray.
Danger of burns
The areas marked with this sign become
hot. Great care should be taken when
in the vicinity of these areas.
7. Caution
MACHINE CLOSE-DOWN
When the machine is left unattended
for a prolonged period (for example
out of hours), carry out the following steps:
• Clean as indicated in the dedicated
chapter;
• Remove the plug or turn off the main
off-on switch;
• Close the water tap.
NOTE: for machines which can
be programmed to switch on and off
automatically, the power must be left on
only if this function is active.
Non-compliance with these safety measures
exonerates the manufacturer from all liability
for malfunctions, damage to property and/
or injury to persons and/or animals.

English
9 EN
8. Maintenance and Repairs
If the machine is not working properly, turn off the
machine, turn off the main off-on switch, and call
the service centre.
If the power-supply cord is damaged, switch off
the machine and request a replacement from the
service centre.
WARNING! Maintenance by unquali¿ed
individuals can jeopardize the safety
and conformity of the machine.
Only use quali¿ed, authorized technicians for
repairs.
WARNING! Only use original spare parts
guaranteed by the manufacturer.
If original spare parts are not used, the
manufacturer's warranty will no longer be valid.
WARNING! After maintenance, perform the
installation CHECK-UP as indicated in the
speci¿c section of the user’s manual.
To ensure safety during operation, it
is absolutely necessary to:
• follow all the manufacturer’s instructions;
• have quali¿ed and authorized technicians
periodically check that all safety devices
are intact and functioning properly (the
¿rst inspection within three years of
purchase and every year after that). For California only
WARNING: Consuming beverages that have
been prepared in this machine will expose you to
lead, a chemical known to the State of California to
cause birth defects and other reproductive harm.

English
10 EN
ENVIRONMENTAL INFORMATION (only DT version with display)
This product contains a non-rechargeable lithium (chemical components: lithium manganese dioxide)
button cell battery fully encapsulated in the ¿nal product.
Recycle or dispose of batteries in accordance with the battery manufacturer's instructions and local/
national disposal and recycling regulations.
Location of the battery
9. Decomissioning the machine
Electrical equipment cannot be disposed of as
ordinary urban waste.
Suitable differentiated waste disposal so
that the machine can then be recycled,
treated and disposed of in an
environmentally friendly manner contributes
to avoiding possible negative effects on the
environment and health, and encourages the
reuse and/or recycling of the materials from which
the machine is made.
Improper disposal of electric equipment that fails
to respect the laws in force will be subject to
administrative ¿nes and penal sanctions.
To protect the environment, please proceed
in compliance with the local laws in force.
3

1
3
2
ON
English
11 EN
10. Daily operation
USE
“Before setting the machine to work, make sure that:
• the main electric power switch is on;
• the mains water tap has been turned on".
DT version with display
MANUAL POWERING
Press the luminous main switch.
The the keys light up and the following message will appear
on the display:
While waiting for the machine to be ready for use, insert
the ¿lter holders in the units.
The machine is ready to work when the display indicates
the working pressure:
If the water level in the boiler is lower than the minimum
limit, the boiler will be ¿lled to the right level. At the end of
this phase, the icon will appear in the lower left hand
corner of the display.
The preset working pressure must be reached before the
machine is ready for use.
If one of the keys is pressed during this phase, coffee
will be served at the temperature reached at that moment.
If any dispensing key is pressed, the following message will
appear on the display:
20 September 2017
wednesday 15:18:12
20 September 2017
wednesday 15:15:04
20 September 2017
wednesday 15:15:04
MACHINE COLD
PLEASE WAIT

19
9
P
21
11A
1 2
1
1A
English
12 EN
C version / DT version without display
CAREFULLY PAY ATTENTION TO THE
SEQUENCEFORACTIVATINGTHESWITCHES
(1) AND (1A).
Press the luminous main switch (1) into position the
related indicator light switches on and the key also light up.
If the water level in the boiler is lower than the minimum
limit, the boiler will be ¿lled to the right level, indicated by
restored pressure in the manometer-pump.
During heating, if one of the coffee dispensing push buttons is pressed, the machine dispenses a coffee at the temperature
reached at the time.
Heating is completed when the boiler gauge indicator (19) remains stable in the Pgreen area.
The machine is now ready to dispense coffee, steam and hot water.
To make sure that the dispenser unit and the ¿lter holder (21) are at similar temperatures, press the coffee dispensing push
button (9) and let the machine dispense coffee for a few seconds. Then press again the push button (9) to stop dispensing.
ONLY AFTER the boiler ¿lling process has been
completed should you press the light switch that
activates the resistance (1A) into position the related
indicate light switches on and the heating phase begins.
Wait until the operating pressure (approx. 17psi - 1.2 bar)
appears on the manometer (19).
At this point, the machine is ready for use.
