laerdal Resusci Anne Simulator User manual

Resusci Anne
Simulator
&
Resusci Anne
Advanced SkillTrainer
Paddle & Link Versions
Important Product Information
www.laerdal.com
EN

2

English
Resusci Anne Simulator & Resusci Anne Advanced Skill Trainer
3
Read these instructions thoroughly. Observe
all warnings, precautions and instructions on
the product, in the User Guide and in this
Important Product Information booklet.
Retain this booklet for future reference.
Refer to SimPad User Guide for SimPad
specifications.
Warnings and Cautions
A Warning states a condition, hazard, or
unsafe practice that can result in serious
personal injury or death.
A Caution states a condition, hazard, or unsafe
practice that can result in minor personal
injury or damage to the product.
Note
A note states important information about
the product or it’s operation.
Disclaimer
Use of the Rescusci Anne Simulator system
to train personnel should be undertaken
under supervision of suitably trained
medical personnel with an understanding of
educational principles as well as recognized
medical protocols.
As with all Patient Simulators or other such
training devices there may be approximations,
variations and inaccuracies in anatomical
features and the physiological modeling.
This being the case, Laerdal Medical does not
guarantee that all features are completely
accurate.
The medical equipment and simulated medical
equipment included in the product might
be modified and should be used for training
purposes only.
General Simulator Handling
It is important to follow the instructions
below, as well as other available User
Information, in order to maintain optimum
performance and longevity of the simulator
components.
Warranty
Refer to the Laerdal Global Warranty for
terms and conditions. For more information
visit www.laerdal.com

English
Resusci Anne Simulator & Resusci Anne Advanced Skill Trainer
4
Airway
Caution
The use of silicon or any other lubricant not
approved by Laerdal may cause damage to
the airway.
Note
Electronic components are mounted inside the
simulator's head.The following techniques should
not be performed on this simulator due to the
inability to properly sanitize the airway if they
are performed:
• Mouth-to-mouth/Mouth-to-mask ventilation.
• Insertion of simulated vomit for suctioning.
• If simulator is turned off while closure
valve is in closed position, valve will open
automatically when simulator is turned on.
Pulses
Note
Do not use excessive force when palpating the
carotid pulse as this will result in no pulse felt.
IV-Arm
Notes
• To extend life of IV arm, a 22 gauge needle
or smaller is recommended for use.
• If training session involves administration of
fluids and/or drugs, empty arm immediately
following session.This to avoid damage/stains
on manikin while stored.
Chest Compressions (RA Sim only)
Note
To avoid damaging the spontaneous breathing
bladder, do not perform chest compressions while
the spontaneous breathing function is activated.
Debrillation with Paddle:
Cautions
• Defibrillation must be performed over the two
defib connectors only. Paddle adapters are
supplied for use with manual defibrillators.
• Only apply the defibrillator to a defibrillation
chest skin which is properly mounted on the
manikin's chest.
• Do not provide more than 2 x 360J
defibrillator discharges per minute as an
average over a period of time to prevent
overheating.
• The manikin chest must be kept dry. Special
attention should be taken when using IV Arm.
• Do not apply conductive gel or conductive
defibrillation pads intended for patient use to
prevent chest skin pitting.
• Do not use cables or connectors with
visible damage. Observe all normal safety
precautions for use of defibrillators.
Debrillation with Shocklink:
Cautions
• Defibrillation must be performed using
ShockLink only. Refer to ShockLink Important
Product Information. Paddle adapters are not
possible to use.
• Refer to ShockLink Important Product
Information for defibrillator discharge rate.
• The manikin chest must be kept dry. Special
attention should be taken when using IV Arm.
• Do not apply conductive gel or conductive
defibrillation pads intended for patient use to
prevent chest skin pitting.
• Do not use cables or connectors with
visible damage. Observe all normal safety
precautions for use of defibrillators.
Troubleshooting
• No chest rise (RA Sim only) when
spontaneous breathing is activated: If
spontaneous breathing is activated and no
chest rise is observed, make sure there is
enough air in the air container. Check also
that the breathing bladder has no leakage.
• Electromagnetic radiation from other radio
transmitters or other electronic equipment
may cause noise in the head speaker.To
eliminate this noise move manikin away from
the radiation source or turn the head speaker
volume to zero.

English
Resusci Anne Simulator & Resusci Anne Advanced Skill Trainer
4 5
Federal Communications Commission
(FCC) and Industry Canada (IC) Statements
This device complies with part 15 of the FCC
Rules and RSS-210 of IC rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful
interference, and
2. This device must accept any interference
received, including interference that may
cause undesired operation.
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC
Rules.These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Consult the dealer or an experienced
radio/TV technician for help.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• The use of shielded I/O cables is required
when connecting this equipment to any
and all optional peripheral or host devices.
Failure to do so may violate FCC rules.
Caution: Changes or modifications not
expressly approved by Laerdal Medical could
void the user’s authority to operate the
equipment.
The term “IC” before the equipment
certification number only signifies that the
Industry Canada technical specifications
were met.
Mise en garde:Tout changement ou toute
modification n’ayant pas fait l’objet d’une
approbation expresse de Laerdal Medical peut
annuler le droit dont dispose l’utilisateur de se
servir de l’équipement.
Le terme « IC » qui précède le numéro
d’agrément de l’équipement signifie
uniquement que les caractéristiques
techniques spécifiées par Industrie Canada
sont respectées.
This device contains licence-exempt
transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two
conditions:
1. This device may not cause interference.
2. This device must accept any interference,
including interference that may cause
undesired operation of the device.
L’émetteur/récepteur exempt de licence
contenu dans le présent appareil est
conforme aux CNR d’Innovation, Sciences
et Développement économique Canada
applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux
conditions suivantes :
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le
fonctionnement.
Canada ICES-003 Statement
Resusci Anne Simulator contains SimPad Link
Box and Lithium Ion Battery and is used in
combination with SimPad.This Class B digital
apparatus meets all of the requirements of
the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la classe B
respecte toutes les exigences du Règlement
sur le matériel brouilleur du Canada.

English
Resusci Anne Simulator & Resusci Anne Advanced Skill Trainer
6
EU
RA Sim & RA AST contains SimPad Link
Box, which is CE marked in accordance with
Council Directive 2014/53/EU, and Lithium
Ion Battery which is CE marked in accordance
with Council Directive 2004/108/EC relating
to electromagnetic compatibility (EMC).
When used in combination with SimPad, this
product is in compliance with the essential
requirements of Council Directive 2014/53/
EU on Radio Equipment (RED)
The product is in compliance with Council
Directive 2011/65/EU on Restriction on the
use of certain hazardous substance (RoHS).
Note
Refer to SimPad User Guide for SimPad
specifications.
Waste Handling
Dispose of in accordance with your country’s
recommendations.
This appliance is marked according to the
European directive 2012/19/EC on Waste
Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of
correctly, you will help prevent potential
negative consequences for the environment
and human health, which could otherwise be
caused by inappropriate waste handling of
this product.
The symbol on the product, or on the
documents accompanying the product,
indicates that this appliance may not be
treated as household waste. Instead it shall be
handed over to the applicable collection point
for the recycling of electrical and electronic
equipment. Disposal must be carried out
in accordance with local environmental
regulations for waste disposal.
For more detailed information about
treatment, recovery and recycling of this
product, please contact your local city office,
your household waste disposal service or
Laerdal representative.
Battery
RA Sim & RA AST is operated on a Lithium
Ion (Li-Ion battery). Li-Ion batteries should be
recycled or disposed of in accordance with
local regulations.
Certication, Compliance and Labels
Symbol Denition
CE Mark
MIC Technical Conformity Mark
(Japan)
Korean Certification (KC) Mark
CSA Certification Mark
Manufacturer
Date of Manufacture
WEEE Symbol
Reference number
Serial Number
Warning / Caution symbol
Li-io
n
Li-ion batteries recycling
symbol

English
Resusci Anne Simulator & Resusci Anne Advanced Skill Trainer
6 7
Specications
RA Sim [REF 150-2xxx]
Dimensions 177 cm x 52 cm x 25 cm
(69.7” x 20.5” x 9.8”)
Weight 36 Kg 79.2 Lbs
Defibrillation Paddle:Average of 360J/
min. max
Link: Refer to ShockLink
Important Product
Information
BP accuracy +/- 4 mmHg
Operation
temperature
0°C to +35°C (32°F to
95°F), Humidity 5 – 90%
R.H. non-condensing
Storage
temperature
-20°C to +60°C (-4°F to
+140°F)
RA AST [REF 151-2xxx]
Dimensions 90 cm x 50 cm x 35 cm
(35.4” x 19.7” x 13.8”)
Weight 21,5 Kg 47 Lbs
Defibrillation Paddle:Average of 360J/
min. max
Link: Refer to ShockLink
Important Product
Information
Operation
temperature
0°C to +35°C (32°F to
95°F), Humidity 5 – 90%
R.H. non-condensing
Storage
temperature
-20°C to +60°C (-4°F to
+140°F)
Li-Ion Battery
Battery Li-ion, 4 cells
Cell type LIC18650-22PC
Voltage 7,2 V nominal
Capacity 4,4 Ah typical (32 Wh)
Size 98 x 78 x 28,1 mm
(3,86” x 3,07” x 1,11”)
Weight 270 g (0.6 lb) approx.
Supported airway management tools
Type Size Good Seal
LMA Classic 4 / 5 X
LMA Unique 5 X
LMA
Fasttrack
4 / 5 X
Combitube 37 Fr X
LTS-D 4 / 5 X
Japanese
Sumi
NA X
IV Arm contains multiple venipuncture
sites including
Dorsal Veins of Hand (3)
Antecubital
Cephalic Vein
Median Vein
Basilic Vein

20-12272 Rev B
www.laerdal.com
© 2020 Laerdal Medical AS. All rights reserved.
Manufactured by Laerdal Medical AS,
P.O. Box 377
Tanke Svilandsgate 30, 4002 Stavanger,
Norway
T: ([phone]
Printed in Norway
