laerdal SimMan 3G Bleeding Module Manual

SimMan 3G Bleeding Modules
Directions for Use
www.laerdal.com

Items Included
The following items are included with this kit:
– Amputated Arm SimMan 3G
– Gunshot Arm SimMan 3G
– Amputated Leg SimMan 3G
– Gunshot Leg SimMan 3G
– Hardware kit
– Directions for Use
– Warranty booklet
Contents
Removing SimMan 3G Left Arm 4
Attaching SimMan 3G Amputation or Shotgun Arm 5
Replacing SimMan 3G Left Leg with Trauma Leg 6
Spare Parts 7
Introduction
The SimMan 3G Bleeding Module kit includes trauma modules which can be fitted to SimMan 3G
to simulate bleeding patient cases. After the simulation is completed, leave the trauma modules
connected, and perform the cleaning instructions as stated in SimMan 3G Directions for Use.

4
2
3 4
Removing SimMan 3G Left Arm
LA PULSES BP
LA CONV
P
B
L
BP
PULSES
L
L
L
A
B
56
1. Unzip the clothing zippers on the right
side. Remove the shirt.
2. Unzip the zippers on the left side of the
torso. Open the Torso Skin to one side.
3. Open the Stomach Foam to one side. 4. Lift the hinged chest plate to access the
arm bolt.
5. Unscrew the left Arm screw with the
allen key and disconnect all Arm cables.
Note: Do not unscrew the Arm Screw fully.
6. Remove the arm with cables from the
arm socket.
1

5
Attaching SimMan 3G Amputation or Shotgun Arm
1
LA PULSES BP
LA CONV
BP
U
PU
PU
PU
L
A PULS
PU
A PU
1
2 3
45
The Arm Adapter and Adapter Screw
are designed to attach an Amputation or
Gunshot Arm to the SimMan 3G manikin.
1. Fit the Arm Adapter into the hole in the
arm bracket from inside of the torso.
Ensure that the flat edge of the adapter
is facing the chest hinge.
2. The Adapter is now in place and the
Trauma Arm can now be connected
with the Adapter Screw.
3. Thread the Adapter Screw through the
Amputation Arm and align the screw with
the hole in the Arm Adapter.
4. Secure the Adapter with one hand from
inside the torso. Screw the Adapter Screw
using the Phillips screwdriver.
Note:Tighten screw as desired to simulate
more or less Arm Range of Motion.
5. Connect the red tube from the
Amputation Arm to the nearest blood
port on the torso.
Caution: Do not over rotate arm. Over rotating
the Arm may cause the red vinyl tubing to
disconnect.

6
1 2
3 4
Replacing SimMan 3G Left Leg with Trauma Leg
56
1. Remove the SimMan 3G default leg.
Open Torso skin and stomach foam as
shown in steps 1-3, page 4.
2. Unscrew hip joint connector. Remove
the leg cables/tubes from the connector.
3. Carefully remove the left leg with cables
and tubes.
4. Insert the Amputation or Gunshot leg
with blood tube into the leg socket.
5. Insert the blood tube into the side
slot of the connector. Screw the
connector in place with one hand.
6. Connect the leg tube to the
corresponding tube, as labelled inside
the torso.
7. Close the stomach foam and zip the
torso skin back into place.

7
Spare Parts
Items listed below are replacements parts for the SimMan 3G Bleeding Module kit.
212-07850 Amputated Arm SimMan 3G
212-07950 Gunshot arm SimMan 3G
212-08150 Amputated Leg SimMan 3G
212-08250 Gunshot Leg SimMan 3G
212-08350 Hardware Kit
212-08450 SimMan 3G Bleeding Trauma Directions for Use
212-07650 Arm Adapter Screw
212-14250 Arm Adapter

© 2010 Laerdal Medical AS. All rights reserved
20-02373 Rev B
