Lagoon 450 User manual

WELCOME ABOARD
We share a common passion for the sea; we, LAGOON, as catamaran builders and you who want to live your passion on the
seven seas.
We are delighted to welcome you to the family of LAGOON catamaran owners and we congratulate you on it.
This instruction guide is intended to help you to enjoy your boat in comfort and safety. It includes the boat specifications, the
equipment provided or installed, the systems on board and tips on her use and maintenance.
We advise you to read this guide carefully before setting sail in order to take the greatest advantage of your sailing.
Our network of LAGOON official retailers is entirely at your disposal in order to help you discovering your boat. They will be
the most able to do the maintenance on your boat.

This user guide is a tool that will enable you to get to know your boat and apprehend the use of the components that are necessary for running her.
A WAY TO MAKE THE MOST OF THIS USER GUIDE
In order to have an easier apprehension, this guide offers you two complementary reading levels:
. The pages with text on the right hand side of the document develop the different subjects dealt with in the chapters,
. The pages on the left hand side are given to the related photos, layouts or block diagrams.
The different warnings used throughout this guide are as follows:
Before you put out to sea, please read the owner’s manual (CE standard manual) delivered with your boat and please follow the instructions.
PREAMBULE
Shows a piece of advice to do the appropriate actions or
manoeuvres adapted to what you are thinking of doing.
Draws your attention on dangerous ways of doing that may
bring about injuries to people or damages to the boat or her
components.
Warns you about the existence of a hazard that may have
serious or fatal consequences if the appropriate precautions
are not taken.
WARNING
DANGER
RECOMMENDATION

CONTENTS
1. SPECIFICATIONS
1. SPECIFICATIONS
............................
............................
PAGE 7
PAGE 7
1.1 I D of your boat
1.1 I D of your boat
1.2 Technical specifications
1.2 Technical specifications
2. HULL / DECK
2. HULL / DECK
.................................
.................................
PAGE 13
PAGE 13
2.1 Construction
2.1 Construction
2.2 Careening
2.2 Careening
2.3 Deck equipment
2.3 Deck equipment
2.4 Cockpit
2.4 Cockpit
2.5 Access to fly helm station
2.5 Access to fly helm station
2.6 Steering system
2.6 Steering system
2.7 Anchoring
2.7 Anchoring
2.8 Deckwash pump
2.8 Deckwash pump
2.9 Gangway
2.9 Gangway
2.10 Davits
2.10 Davits
3. RIGGING / SAILS
3. RIGGING / SAILS
...........................
...........................
PAGE 27
PAGE 27
3.1 Sailing
3.1 Sailing
3.2 Standing rigging
3.2 Standing rigging
3.3 Running rigging
3.3 Running rigging
3.4 Sails
3.4 Sails
4. ACCOMMODATIONS
4. ACCOMMODATIONS
.....................
.....................
PAGE 41
PAGE 41
4.1 Saloon - Galley
4.1 Saloon - Galley
4.2 Lighting
4.2 Lighting
4.3 Portholes - Deck hatches
4.3 Portholes - Deck hatches
4.4 Window blinds
4.4 Window blinds
5.
5.
UTILITY ABOARD
UTILITY ABOARD
...........................
...........................
PAGE 47
PAGE 47
5.1 Refri
5.1 Refri
gerators - Conservator - Ice
gerators - Conservator - Ice
maker
maker
5.2 Microwave oven
5.2 Microwave oven
5.3 Oven,
5.3 Oven,
hotplate
hotplate
5.4 Dishwasher
5.4 Dishwasher
5.5 Washer dryer
5.5 Washer dryer
5.6 Television
5.6 Television
5.7 Air conditioning system
5.7 Air conditioning system
5.8 Heating system
5.8 Heating system
6.
6.
WATER SYSTEMS
WATER SYSTEMS
.........................
.........................
PAGE 57
PAGE 57
6.1 Bilge pump system
6.1 Bilge pump system
6.2 Grey waters
6.2 Grey waters
6.3 Black waters
6.3 Black waters
6.4 Fresh water
6.4 Fresh water
6.5 Watermaker
6.5 Watermaker
7.
7.
ELECTRICITY
ELECTRICITY
.................................
.................................
PAGE
PAGE
69
69
7.1 12 V circuit
7.1 12 V circuit
7.2 Inverters
7.2 Inverters
7.3 110 V - 220 V circuits
7.3 110 V - 220 V circuits
7.4 Electronics
7.4 Electronics
8.
8.
MOTORIZATION
MOTORIZATION
.............................
.............................
PAGE 83
PAGE 83
8.1 Engines
8.1 Engines
8.2 Fuel
8.2 Fuel
8.3 Propellers - Anodes
8.3 Propellers - Anodes
8.4 Dash board
8.4 Dash board
8.5 Optional controls
8.5 Optional controls
9.
9.
WINTER STORAGE
WINTER STORAGE
........................
........................
PAGE 91
PAGE 91
9.1 Laying up
9.1 Laying up
9.2 Protection
9.2 Protection
10.
10.
HANDLING
HANDLING
...................................
...................................
PAGE 95
PAGE 95
10.1 Preparation
10.1 Preparation
10.2 Crane lifting
10.2 Crane lifting
10.3 Mast stepping and removal
10.3 Mast stepping and removal
11.
11.
SAFETY
SAFETY
........................................
........................................
PAGE 99
PAGE 99
11.1 Prevention
11.1 Prevention
11.2 Gas system
11.2 Gas system
11.3 Fire
11.3 Fire
11.4 Bilge pump system
11.4 Bilge pump system
11.5 Safety equipments
11.5 Safety equipments
11.6 General remarks
11.6 General remarks
12. MAINTENANCE
12. MAINTENANCE
.....................................
.....................................
111
111
12.1 Maintenance schedule
12.1 Maintenance schedule
5
Code 130597 - Indice A

7
SPECIFICATIONS
1.1 I D of your boat
1.2 Technical specifications
1

9
1
NAME OF YOUR BOAT: ...................................................................
VERSION: .......................................................................................
DELIVERY DATE: .............................................................................
HULL NUMBER: ..............................................................................
MAKE OF THE ENGINES: ................................................................
NUMBERS OF THE ENGINE KEYS: ..................................................
STARBOARD ENGINE SERIAL NUMBER: ..........................................
PORT ENGINE SERIAL NUMBER: .....................................................
FURTHER INFORMATION: ...............................................................
.......................................................................................................
.......................................................................................................
.......................................................................................................
.......................................................................................................
..........................................................................................................
OWNER’S NAME: ....................................................................................
ADDRESS: ..............................................................................................
................................................................................................................
................................................................................................................
E-MAIL ADDRESS: ..................................................................................
LANDLINE PHONE NUMBER: ...................................................................
MOBILE PHONE NUMBER: ......................................................................
SPECIFICATIONS
YOUR BOAT
www.cata-lagoon.com
162, quai de Brazza - 33100 Bordeaux - France zTel. 33 (0) 557 80 92 80 zFax 33 (0) 557 80 92 81 zE-mail: [email protected]
EMERGENCY CONTACT

LAGOON 450
10
SPECIFICATIONS
DESIGN CATEGORIES
CATEGORY A
The boat is designed for sailing in winds that may exceed force 8 on
the Beaufort Scale and in waves of a significant height of 4 m and
more and the boat is to a large extent self-sufficient.
Unusual conditions such as hurricanes are excluded.
You may meet with such conditions when you sail long crossings, for
instance across the oceans, or close to the shore when you are not
protected from the wind or waves over several hundreds of nautical
miles.
CATEGORY B
The boat is designed for sailing in winds that may exceed force 8 on
the Beaufort Scale and in waves of a significant height of 4 m and
more and the boat is to a large extent self-sufficient.
You may meet with such conditions when sailing at open sea, or close
to the shore when you are not protected from the winds and waves
over several hundreds of nautical miles. You may also meet with
such conditions when sailing quite important inland seas which could
produce waves of this height.
CATEGORY C
The boat is designed for sailing in winds that do not exceed force 6
on the Beaufort Scale and in the corresponding waves (waves of a
significant height inferior or equal to 2 m).
You may meet with such conditions in exposed inland waters, in
estuaries and in coastal waters with mild weather conditions.
CATEGORY D
The boat is designed for sailing in winds that do not exceed force 4 on
the Beaufort Scale and in the corresponding waves (occasional 0.5 m
high waves at a maximum).
You may meet with such conditions in sheltered inland waters and in
coastal waters in fine weather.
NOTE:
The significant height of a wave is the average height of the upper
third of the waves; this corresponds more or less to the height of a
wave an experienced observer can assess.
Some waves will be twice as high as this value.

LAGOON 450
Length Over All...................................................... 13.96 m / 45'10"
Waterline length .................................................... 13.38 m / 43'11"
Beam......................................................................... 7.84 m / 25'9"
Air draft .................................................................23.05 m / 75'62"
Keel draft................................................................... 1,30 m / 4'28"
Light displacement ......................................... 16900 kg / 37265 lbs
Full load displacement (cat. A)........................ 22015 kg / 48543 lbs
Full load displacement (cat. B)........................ 22150 kg / 48841 lbs
Full load displacement (cat. C)........................ 22520 kg / 49657 lbs
Full load displacement (cat. D)........................ 23350 kg / 51487 lbs
Maximum load (cat. A)...................................... 5115 kg / 11279 lbs
Maximum load (cat. B)...................................... 5120 kg / 11290 lbs
Maximum load (cat. C)...................................... 5620 kg / 12392 lbs
Maximum load (cat. D) ..................................... 6410 kg / 14134 lbs
Water capacity............... 2 x 175 l + 2 x 175 l (option) / 2x46 US gal
Fuel oil capacity.......................................... 2 x 500 l / 2x132 US gal
Refrigeration unit capacity.. 130 l + 130 l (optional) + 80 l (optional)
....................34 US gal + 34 US gal (optional) + 21 US gal (optional)
BATTERY CAPACITY
Standard................................................................ 3 x 140 Ah (12 V)
Optional................................................................. 3 x 140 Ah (12 V)
Engines ................................................................. 2 x 110 Ah (12 V)
Generator .................................................................... 110 Ah (12 V)
Engine power .................................................................... 2 x 40 HP
CE CATEGORY Maximum number of persons
A..............................................................12 persons
B .............................................................14 persons
C .............................................................20 persons
D .............................................................30 persons
Bottom surface: approx. 58 m2/ 624 sq ft
TECHNICAL SPECIFICATIONS
SPECIFICATIONS
1
11

13
HULL / DECK
2.1 Construction
2.2 Careening
2.3 Deck equipment
2.4 Cockpit
2.5 Access to fly helm station
2.6 Steering system
2.7 Anchoring
2.8 Deckwash pump
2.9 Gangway
2.10 Davits
2

LAGOON 450
HULL / DECK
14

Motonautisme
Motonautisme ou voile
zMotonautisme ou voile
Motonautisme
Motonautisme ou voile
zMotonautisme ou voile
LAGOON 450
HULL / DECK
HULL / DECK
2
15
2.3 Deck equipment
zDECK FITTINGS
The fittings on the deck of your LAGOON 450 were selected according
to quality criteria.
To keep them to their best look, a regular maintenance is necessary.
- Rinse the equipments with fresh water, particularly the stainless
steel parts.
- Lubricate the different blocks, sheaves, turnbuckles, winches, tracks
and travellers.
- Clean and polish the stainless steel parts with a chrome and stain-
less steel polish in case of oxidation.
zPULPITS
Regularly rinse the stainless steel parts with fresh water.
zLIFELINES
Inspect the metal lifelines for ‘hairy wires’.
Check for corrosion, in particular on the connections.
zOUTSIDE WOODWORK
Regularly rinse and brush the outside woodwork with fresh water.
There are teak cleaners and brighteners on sale.
The use of a pressure washer is not advisable on teak.
2.1 Construction
The LAGOON 450 is constructed following the infusion process of a
polyester resin and a high quality anti-osmotic resin on a core of balsa
and fibreglass layers.
The hull bottoms and keels are made of monolithic laminates by in-
fusion.
2.2 Careening
A periodical careening of your boat will keep her original performan-
ces and avoid any adhesion of marine vegetation.
The type of the water where you boat sails determines how to choose
the antifouling paint as well as how often to carry out these caree-
nings.
Please contact a professional for advice.
WARNING
Do not let the hull’s large plexiglass windscreens come
into contact with fenders or hawsers: surface damage
would be irreparable.

LAGOON 450
HULL / DECK
16
DECK EQUIPMENT
ENTRANCE DOOR
LOCKING SYSTEM
BIN LOCKER
COCKPIT TABLE
STORAGE SPACE
SHOWER IN TRANSOM
OPENING SERVING
HATCH
SUNROOF

Motonautisme
Motonautisme ou voile
zMotonautisme ou voile
Motonautisme
Motonautisme ou voile
zMotonautisme ou voile 2
LAGOON 450
HULL / DECK
HULL / DECK
17
zPLEXIGLAS
To protect the surface of your windows in plexiglas, avoid any contact
with alcohols, tanning creams, sand and all abrasive products gene-
rally speaking.
- Rinse the plexiglas with fresh water, do not use solvents.
- Brighten up with a soft rag soaked with a gentle cleaning product.
- Use polish paste to remove scratches.
2.4 Cockpit
zACCESS DOORS
The sliding door is fitted with a mechanism allowing its locking in an
open position. A latch on the door jamb allows its locking from inside
the saloon.
zCOCKPIT TABLE
The cockpit table is removable. It can be stored in the fly bridge
roof.
zBIN LOCKER
A bin locker with top opening is located on the saloon port side
entrance.
zSERVING HATCH
The cockpit is fitted with an opening serving hatch.
While sailing, please lock the serving hatch either in the open or
closed position.
zSWIM LADDER
A stainless steel swimming ladder is located on the starboard
transom. The boat may optionally be fitted with a second swimming
ladder.
zSHOWER
A shower supplied with hot and cold water is located on the starboard
side of the transom.
zSUNROOF
The sunroof, located on the fly bridge roof port side can be opened
from the cockpit.
It enables you to optimize the cockpit airing and offers a better field of
vision when manoeuvring in reverse.
WARNING
Be careful when opening the locker located under
the flying bridge roof.
WARNING
For safety’s sake, always sail with the ladder up and
kept in position.
RECOMMENDATION
While sailing, block the sliding door locking it.

LAGOON 450
HULL / DECK
STROP - ELECTRIC WINDLASS
18
1 - Electric windlass.
2 - Control of the electric windlass.
3 - Windlass automatic breakers.
STROP CIRCUIT ELECTRIC
WINDLASS
AUTOMATIC BREAKER
OF THE WINDLASS
CONTROL
OF THE WINDLASS
2
1
3
