Laguna Tools Dake 972200 Operating and maintenance manual

Dake Corporation Phone: [phone] www.dakecorp.com
1809 Industrial Park Dr Fax: [phone] [e-mail]
Grand Haven, MI 49417
DAKE 10- & 20-Ton Floor/Bench Utility Press
INSTRUCTIONAL MANUAL
(This is a F-20 model so there may be slight differences)
WARNING! Read and understand all instructions and responsibilities before operating.
Failure to follow safety instructions and labels could result in serious injury.

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 2 REV#072020
Table of Contents
DAKE Standard Limited Warranty.........................................................................................................3
Finished Machines ............................................................................................................................3
Parts ..................................................................................................................................................3
Sale of Service (Repairs)...................................................................................................................3
Warranty Process..............................................................................................................................3
Warranty Exceptions .........................................................................................................................4
Return & Refund Policy.........................................................................................................................5
Returns..............................................................................................................................................5
Refunds.............................................................................................................................................5
Specifications........................................................................................................................................7
Machine Specifications:.....................................................................................................................7
Safety Warnings....................................................................................................................................8
Practice Safe Operation ....................................................................................................................8
Assembly Instructions: 10 Ton Bench Model .....................................................................................10
Assembly Instructions: 10 / 20 Ton Floor Model .................................................................................12
Operation ............................................................................................................................................14
Procedure........................................................................................................................................14
How to Add Fluid to Hydraulic Pump:..............................................................................................15
Trouble Shooting.................................................................................................................................15
Gauge Conversions ............................................................................................................................16
10 Ton: ............................................................................................................................................16
20 Ton: ............................................................................................................................................16
Parts List.............................................................................................................................................17
10 Ton Bench Press:.......................................................................................................................17
10 Ton Floor Utility Press: ...............................................................................................................19
20 Ton Floor Utility Press: ...............................................................................................................21
Order Information................................................................................................................................23

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 3 REV#072020
DAKE Standard Limited Warranty
Finished Machines
- Dake warrants to the original purchaser the finished machine manufactured or distributed
by it to be free from defects in material and workmanship under normal use and service
within 1 year (12 months) from the delivery date to the end user.
Parts
- Dake warrants to the original purchaser the component part manufactured or distributed
by it to be free from defects in material and workmanship under normal use and service
within 30 days from the delivery date to the end user.
- The standard limited warranty includes the replacement of the defective component part
at no cost to the end user.
Sale of Service (Repairs)
- Dake warrants to the original purchaser the component part repaired by Dake
Corporation at the manufacturing facility to be free from defects in material and
workmanship under normal use and service within 90 days from the return date to the
end user, as it pertains to the repair work completed.
- The standard limited warranty includes repair of the defective component part, at no cost
to the end user.
Warranty Process
- Subject to the conditions hereinafter set forth, the manufacturer will repair or replace any
portion of the product that proves defective in materials or workmanship. The
manufacturer retains the sole right and option, after inspection, to determine whether to
repair or replace defective equipment, parts, or components. The manufacturer will
assume ownership of any defective parts replaced under this warranty.
- All requested warranty claims must be communicated to the distributor or representative
responsible for the sale. Once communication has been initiated, Dake Customer Service
must be contacted for approval:
•Phone: [phone]
•Email: [e-mail]
- When contacting Dake, please have the following information readily available:
1. Model #
2. Serial #
3. Sales Order #

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 4 REV#072020
- Purchasers who notify Dake within the warranty period will be issued a Case number and/or a
Return Material Authorization (RMA) number. If the item is to be returned per Dake’s request,
the RMA number must be clearly written on the exterior packaging. Any item shipped to Dake
without an RMA will not be processed.
Warranty Exceptions
The following conditions are not applicable to the standard limited warranty:
(a) Part installation or machine service was not completed by a certified professional,
and is not in accordance with applicable local codes, ordinances, and good trade
practices.
(b) Defects or malfunctions resulting from improper installation or failure to operate or
maintain the unit in accordance with the printed instructions provided.
(c) Defects or malfunctions resulting from abuse, accident, neglect, or damage outside
of prepaid freight terms.
(d) Normal maintenance service or preventative maintenance, and the parts used in
connection with such service.
(e) Units and parts which have been altered or repaired, other than by the manufacturer
or as specifically authorized by the manufacturer.
(f) Alterations made to the machine that were not previously approved by the
manufacturer, or that are used for purposes other than the original design of the
machine.

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 5 REV#072020
Return & Refund Policy
- Thank you for purchasing from Dake! If you are not entirely satisfied with your
purchase, we are here to help.
Returns
- All Dake manufactured / distributed machines, parts and couplings include a 30-day return
option. These policies are valid from the date of final shipment to the end user. To be
eligible for a return, the item must be unused and in the same condition as received.
- All requested warranty claims must be communicated to the distributor or representative
responsible for the sale. Once communication has been initiated, Dake Customer Service
must be contacted for approval:
- Phone: [phone]
- Email: [e-mail]
- Once the return request has been approved by Customer Service, a representative will
supply a Return Material Authorization (RMA) number.
- The returned item must have the provided RMA number clearly marked on the outside
packaging. Any item received without an RMA number clearly visible on the packaging
will not be processed.
- An RMA number can only be provided by the Dake Customer Service team and must
be obtained prior to the return shipment.
Refunds
- Once the item has been received and inspected for damages, a representative will
notify the requestor referencing the provided RMA number. If the return is approved, a
refund will be issued to the original method of payment, less a 20% restocking fee.
- The restocking fee may be waived if an order is placed at the time of return with like-
value merchandise. Transportation costs are the responsibility of the end user and will
not be credited upon return approval.
- Any item that is returned after the initial 30 days or has excessive/obvious use will not
be considered for a full refund.

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 6 REV#072020
SAFEGUARDING THE POINT OF OPERATION
ANSI B11.2 – Hydraulic Power Presses
Safety Requirements for Construction, Care and Use
It is important that Dake press users have a clear understanding of their responsibility involving the
care and use of their Dake hydraulic press, including point-of-operation safeguards. Dake strongly
recommends that Dake press users obtain a copy of the current American National Standard Institute
(ANSI) B11.2 standard, for a more complete understanding of their responsibilities.
ANSI B11.2 states the following, relative to point of operation safeguarding:
“Normally, only the employer (press user) can determine the requirements of the press productions
system components, including the dies and methods for feeding. Therefore, the employer is ultimately
responsible to designate and provide the point-of-operation safeguarding system”.
The standard also discusses additional responsibilities of the employer. Some of the key
responsibilities are:
The employer is responsible for the safety, use and care of the hydraulic power press production
system.
The employer is responsible to consider the sources of hazards for all tasks to be implemented on the
hydraulic power press production system.
The employer is required to eliminate, or control identified hazards in the scope of their work activity.
The employer is responsible for the training of personnel, caring for, inspecting, maintaining, and
operating hydraulic press production systems to ensure their competence.
The employer is responsible to provide and ensure that point-of-operation safeguarding is used,
checked, maintained and where applicable, adjusted on ever production operation performed on a
press production system.
A complete and current copy of the ANSI B11.2 standard can be obtained by contacting the
following:
American National Standards Institute
1430 Broadway
New York, NY 10018
AMT – The Association for Manufacturing Technology
7901 Westpark Drive
Mclean, VA 22102

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 7 REV#072020
Specifications
Machine Specifications:
- In the space provided record the serial number and model number of the machine. This
information is only found on the black Dake tag. If contacting Dake this information
must be provided to assist in identifying the specific machine.
Model No:
Part No:
Serial No:
Date of Purchase:
10 Ton Bench
10 Ton Floor
20 Ton Floor
Press Type
Manual 10-ton Bench
Manual 10-ton Floor
Manual 20-ton floor
Cylinder Type
Single Acting
Single Acting
Single Acting
Max. Press Capacity
10 Ton
10 Ton
20 Ton
Ram Diameter
1- 1/2"
1- 1/2"
2"
Ram Stroke
6"
6"
8"
Head Travel
Left / Right of center
Left / Right of center
Left / Right of center
Ram Travel Per Stroke
1/8" approx.
1/8" approx.
3/16” approx.
Width Between Uprights
16-3/4"
16-3/4"
23"
Width Between Channels
3"
3"
4"
Max. Ram to Table
16"
38"
39"
Overall Height
36"
60"
74"
Weight
132 lbs.
149 lbs.
283 lbs.

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 8 REV#072020
Safety Warnings
BEFORE USE, ALL SAFTEY INSTRUCTIONS MUST BE READ
- Before the PRESS is used, the instruction manual with this machine must be read and
understood. This manual offers safe operation instructions. Offered below are safety
instructions designed for the press and general safety instructions that apply to most
machinery.
- As will all machinery there are certain hazards involved with operation and use of the
machine. Using the machine with respect and caution will considerably lessen the possibility
or personal injury. However, if normal safety precautions are overlooked or ignored, personal
injury to the operator may result.
- This machine was designed for certain applications only. We strongly recommend that this
machine NOT be modified and/or used for any application other than for which it was
designed. If you have any questions relative to its application DO NOT use the machine until
you contact with us and we have advised, you
Practice Safe Operation
•Keep hands out of point of operation.
•Never hold part while pressing.
•Always wear the eye protection.
•Clamp work piece or brace when pressing.
•Never place fingers in pin holes.
•Always use nose piece when pressing. Never press using the end of the ram, damage to ram
or threads can occur.
•Never use a press that is not fastened securely to the floor or workbench.
•Always used table pins and accessories furnished with press.
•Always have firm footing when operating press.
•Do not use press if parts are damaged or missing. (Hoses, structural components)
This is the safety alert symbol. When you see this symbol on your press be alert to the
potential for personal injury.
Employer is responsible to perform a hazard/PPE assessment before work activity.

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 9 REV#072020
Label Part # 300168
Label Part # 84399 Label Part # 84487
Follow recommended precautions and safe operating practices.
Carefully read all safety
messages in these
instructions and on your
press safety signs. Keep
safety labels in good
condition. Replace missing or
damaged safety labels.
This machine is intended to
be operated by one person.
This person should be
conscious of the press ram
movement not only for
themselves but also for
persons in the immediate
area of the machine.
Under no circumstances
increase the leverage ratio
of the press by using a
longer handle or by placing
a pipe over the handle.
Never hammer on top of the
ram.

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 10 REV#072020
Assembly Instructions: 10 Ton Bench Model
Step 1 (Bench Model Only):
- Using (2) M8 x 20mm bolts, nuts and washers install the union support to the bottom from of
the upright channels. (Pump hanger bracket on the right-hand side of the upright.) The union
support is to face outward. See drawing below.
Step 2:
- Carefully stand the unit upright. Making sure all components are square to each other, tighten
all nuts and bolts securely.
Step 3:
- Mount the head ram transverse plates. The side with two bars welded to them go inside the
frame, with the threaded plate on the bottom. Using 10mm x 120 mm bolts, washers, and nuts,
tighten only enough to allow plate to travel.
Step 4:
- With press standing upright and all bolts tightened install the worktable. Insert two table pins in
the two lowest holes.
- Take the worktable and tilt it at a sharp angle and insert it in the uprights.
- NOTE: The gussets welded to the table are at slight angles. The narrowest dimension of these
gussets goes down. See drawing below for guidance. (Step 1) Once worktable is in the
uprights turn it level and lower down and set it on the table pins. (Step 2)
- Take care when doing this, a helper would be advised.

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 11 REV#072020
Step 5:
- Locate the cylinder and remove the plastic protective cap on the end of the ram. (If applicable)
Carefully screw the cylinder from the top into the head traverse ram plate. Screw this in as tight
as possible while keeping the cylinder’s hydraulic hose fitting facing to the right or pump side.
- NOTE: Cylinder may not be totally tight while keeping the fitting facing this way, but it will not
affect the presses operation
- Using Teflon tape install the gauge to the top of the cylinder facing forward. When gauge and
hose fittings is in correct position, install the spanner nut on the bottom of cylinder and snug
up.

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 12 REV#072020
Assembly Instructions: 10 / 20 Ton Floor Model
Step 1:
- Install the union support to the inside of the upright channels and base angles, using the 4 of
the M8 x 25mm bolts, nuts and washers provided.
Step 2:
- Place union support in-between the channels and install the 2 base angles to the frame
through the union support and install nuts. Base angles face outward (See drawing below)
Hand tighten.
Step 3:
- Carefully stand the unit upright. Making sure all components are square to each other, tighten
all nuts and bolts securely.
- Install pump mounting plate on the side of the upright channel using the 3 M10 x 25mm bolts,
nuts, and washers.
Step 4:
- This step is installing the Mount Head Ram Traverse Plates. The side with two bars welded to
the plate go inside the frame with the thick threaded plate on the bottom side

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 13 REV#072020
Step 5:
- Using two 10mm x 120 mm bolts, washers, and nuts, snug only enough to allow plate to travel.
Step 6:
- Install the pumping device to the mounting plate using 2 M10 x 25mm bolts, nuts, and
washers. Make sure pump is aligned in the center on this mounting plate for proper installation.
Step 7:
- With press standing upright and all bolts tightened install the worktable. Insert two table pins in
the two lowest holes. Take the worktable and tilt it at a sharp angle and insert it in the uprights.
(NOTE: The gussets welded to the table are at slight angles. The narrowest dimension of
these gussets goes down. See drawing) (Step 1) Once worktable is in the uprights turn it level
and lower down and set it on the table pins. (Step 2) Take care when doing this, a helper
would be advised.

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 14 REV#072020
Operation
Procedure
- Always use the supplied nose pieces. The flat nose piece will be good for most pressing and
flattening operations. The step style nose piece will work well for pressing bearing, bushing
and parts that have a hole that the nose piece will fit into. This nose piece will help support or
hold the piece during pressing operations.
- There are two table plates that should always be used as a backing plate during pressing
operations. You will find notches in these table plates to allow you to use the press as a
straightening press for axles, shafts, etc. and most round stock.
- When using your press always use the highest table setting to minimize the stroke distance of
the ram.
NOTE: Only use supplied table pins. Do not weld or pin table.
- Once a part is put in the press and is clamped or braced securely, close the pumping unit
release valve handle. (Clockwise).
- Pump the handle to lower the ram. Pump until pressing operation is completed. If you need to
maintain pressure leave the valve on the pumping unit closed.
- When operation is complete, turn the valve counterclockwise to release pressure and raise the
ram. Once the ram has been raising just above the work close valve again and repeat
operation on the next part. There is no need to raise the ram all the way to the top each time.
- If pressing application requires a certain tonnage, press until the gauge reads the appropriate
tonnage then stop. Release pressure and repeat operation.
NOTE: Never pump the ram down fully and dead head the ram in the cylinder. Only build pressure
when using the table plates or a part is being pressed. Failure to do this may cause ram seal damage
and leaking.
- If the application requires off center pressing, loosen the head ram traverse plate bolts and
slide head left or right to the area where pressing is required. You may now proceed with the
operation. When head is returned to the center position snug these bolts up to prevent
unexpected movement.

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 15 REV#072020
How to Add Fluid to Hydraulic Pump:
1. Retract the ram that is connected to the pump.
2. Place the pump on a smooth, level surface so that that handle is in the up position.
3. Remove filler plug (small plug near the top).
4. Lift the plug end of the pump 3
8
 3
4
of an inch off the ground to properly fill the reservoir.
5. Replace the plug to ensure quality sealing.
6. Reinstall pump on press.
7. Open the valve and pump continuously to properly bleed the system.
Trouble Shooting
Question: Oil leaking around the ram?
Solution: Secure the ram under pressure for 1 hour. This is a cause of a bad seal.
Question: Ram is jerky or sluggish?
Solution: With the valve open, repeatedly pump the handle to allow air to be released from the
lines.
Question: Ram does not return to the starting position at the top of the stroke?
Solution: Open and close the valve multiple times. If no progress has been made, the return
spring may have failed.
Question: What should I do if the pump will not build pressure?
Solution: Check and see if the valve is at the completely at the closed position.
Check oil fluid level. If low, add fluid and bleed to maximize efficiency.
Question: The pressure gauge on the press is leaking.
Solution: Apply thread sealer (Teflon Tape) with the flow threads on the gauge. Do not apply the
Teflon Tape against the threads, this will not allow the gauge to seal properly.
Question: Leaking oil around the hoses?
Solution: Make sure to check all fittings. Tighten if they are loose, and check for any
damage on the hose itself.
Question: The press will not reach the maximum allowable tonnage?
Solution: Check the valve to make sure it is fully in the closed position. You may have to bleed
the system to maximize efficiency.
Question: The press will not hold pressure?
Solution: Check the valve and make sure it is in the closed position. Some cases, press will
naturally bleed itself. If not, bleed the system.

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 16 REV#072020
Gauge Conversions
10 Ton:
10 Ton
45MM Bore = 1.77 Inch Bore
Tons
Bar
PSI(lbs/in2)
1
55
799
2
110
1598
3
165
2397
4
220
3196
5
275
3996
10
551
7992
20 Ton:
20 Ton
65MM Bore = 2.56 Inch Bore
Tons (1-10)
PSI (lbs/in2)
Tons (11- 20)
PSI (lbs/in2)
1
388.86
11
4277.51
2
777.73
12
4666.38
3
1166.59
13
5055.25
4
1555.46
14
5444.11
5
1944.32
15
5832.97
6
2333.19
16
6221.84
7
2722.06
17
6610.70
8
3110.92
18
6999.57
9
3493.78
19
7388.43
10
3888.65
20
7777.30

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 17 REV#072020
Parts List
10 Ton Bench Press:

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 18 REV#072020
10 Ton Bench Press Parts List
Ref #
Part #
Description
Quantity
1
301139
Frame Upright Channel
2
2
301138
Head Frame Channel
2
3
301137
Head Ram Traverse Plate
1
4
301136
Bolt M12 x 110mm
6
5
301135
Lock washer 12mm
6
6
301134
Nut M12 x 4
6
7
301132
Union Support
1
8
301131
Base Angle
2
9
301130
Bolt M8 x 20
6
10
301129
Lock Washer 8mm
6
11
301128
Nut M8
6
12
301127
Flat Nose Piece
1
13
301126
Step Nose Piece
1
14
301125
Table Pin
2
15
301124
Table Plate
2
16
301123
Worktable
1
17
301122
Ram / Cylinder
1
17A
302382
Cylinder Spring
1
18
301121
Pump Unit
1
19
301133
Head Ram Traverse Plate
1
20
301150
Bolt M10 x 140
2
21
302277
Washer 10mm
2
22
301149
Lock Washer 10mm
2
23
301141
Nut 10mm
2
24
302019
Gauge (Original)
1
25
302276
Ring
1
Items Not Shown
Part #
Description
302318
Cylinder Seal kit
302382
Spring for cylinder
302310
Fitting Nipple
302309
Fitting Coupler
302554
Pump repair kit
302508
Hydraulic hose w/Coupling
302019
10 Ton Gauge
302019C
10 Ton Certified Gauge
302596
0-5000lbs. Gauge
302777
Max Hand Gauge 1-10 Ton

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 19 REV#072020
10 Ton Floor Utility Press:

Dake Corporation
1809 Industrial Park Dr
Grand Haven, MI 49417
www.dakecorp.com
#972200, 972210, 972220 20 REV#072020
Additional Parts Not Shown
Part #
Description
302318
Seal Kit
302383
Cylinder Spring (21A)
302310
Fitting Nipple
302309
Fitting Coupler
302554
Pump Repair kit
302508
Hydraulic Hose w/Coupling
302019
10 Ton Gauge
302019C
10 Ton Certified Gauge
302596
0-5000lbs. Gauge
302777
Max Hand Gauge 1-10 Ton
10 Ton Floor Press Parts List
Ref #
Part #
Description
Quantity
1
301154
Frame Upright Channel
2
2
301153
Head Frame Channel
2
3
301152
Head Ram Traverse Plate (Upper)
1
4
300151
Head Ram Traverse Plates (Lower)
1
5
301150
Bolt M10 x 120mm
2
6
301149
Lock Washer 10mm
2
7
301148
Union Support
1
8
301147
Base Angle
2
9
301146
Bolt M8 x 25
12
10
301129
Lock Washer 8mm
12
11
301128
Nut M8
12
12
301145
Angle Support Strap
4
13
301144
Pump Support Bracket
1
14
301143
Bolt M10 x 25
5
15
301142
Lock Washer 10mm
4
16
301141
Nut M10
4
17
301123
Worktable
1
18
301124
Table Plate
2
19
301127
Flat Nose Piece
1
20
301126
Step Nose Piece
1
21
301140
Ram / Cylinder
1
21A
302383
Cylinder Spring
1
22
301121
Pumping Unit
1
23
301125
Table Pin
2
24
301136
Bolt M12 x 110mm
4
25
301135
Lock Washer 12mm
4
26
301134
Nut M12
4
27
302274
Bolt M8 x 25
4
28
302019
Gauge (Original)
1
29
302275
Ring
1
