Laird CMS38606P Programming manual

SAFETY
165-00177_AC
CMS38606P
ASSEMBLY INSTALLATION
INSTRUCTIONS
Please read all instructions carefully before attempting to
install and use this product.
The CMS38606P and all associated equipment should be installed
in accordance with all applicable local and national electrical code
guidelines to ensure safe operation.
STANDARD MOUNTING
A threaded post on the back of the antenna and a supplied
mounting nut are the primary mounting method when access is
available to both sides of the mounting surface, such as a
suspended ceiling tile. Mark the desired mounting location on the
tile and cut a ø40mm (1.57") hole for threaded post. Feed the
cables through the hole and secure the antenna with the mounting
nut. (See figure 1).
PRECAUTION
For best PIM results:
PARAMETER
Frequency 380-520 MHz
600-960 MHz
1395-1435 MHz
1690-6000 MHz
VSWR (Max) 3.0:1 (380-520 MHz)
2.0:1 (600-960 MHz)
2.0:1 (1395-1435 MHz)
2.0:1 (1690-6000 MHz)
Max Gain
Polarization Vertical
PIM, 3rd order, 2X20W
50Ω
Power 50W @ ambient temp 25o C (77oF)
RF Connector Model specific
Radome Color White
Operating Temperature -30°C +70°C
Storage Temperature -40°C +85°C
Water/Foreign Body Ingress IP-67
Antenna Weight 0.8kg (1.76 lbs)
<-150dBc
PERFORMANCE
CMS38606P
Laird Model Number
LOCATION
For the best results, mount the antenna near the center of the
coverage area. A line-of-sight path between the antenna and active
floor locations generally works best. Although microwave signals
penetrate cubical dividers and interior walls with little attenuation,
reinforced block attenuate signals or cause multipath, a condition
where reflected signals interfere with the primary signal path. Avoid
mounting next to a column or vertical support that could create a
''shadow zone'' of reduced coverage to one portion of the room.
Make sure the connectors are clean and free from any
metal flakes/dirt & tighten the connectors using torque
wrench according to connector torque specification below.
Avoid extreme bending to the cable. Do not remove
the dust cap from connectors when not in use.
1.
2.
Americas: +1.847 839.6907
[email protected]
Europe: +44.1628.858941
[email protected]
Asia: +86.21.5855.0827.127
[email protected]
www.lairdtech.com
PIM Test Frequencies UHF Band (380-384MHz)
Low Band Cellular (776-786MHz)
High Band Cellular (1870-1910MHz)
SPECIFICATIONS
Figure 1
Patent Pending
Impedance
Flammability UL94-V0
3.1 dBi @ 380-520 MHz
2.9 dBi @ 600-960 MHz
5.4 dBi @ 1395-1435 MHz
7.0 dBi @ 1690-6000 MHz

165-00177_AC
OPTIONAL MOUNTING
Note: The optional mounting kits are NOT INCLUDED with the antenna; it needs to be purchased separately
CMS38606P
ASSEMBLY INSTALLATION
INSTRUCTIONS

QR CODES
There is a unique QR Code placed on the back of each
antenna, so system managers can simply scan the code
with a smartphone and instantly see all of the needed
performance data. The solution provides fast, accurate
data and allows customers to instantly track even more
information than they could previously review.
CMS38606P-XXX-SNYYWWZZZZ
VSWR: V@380-520MHz, V@600-960MHz, V@1395-1435MHz, V@1690-6000MHz
LOW PIM 380-520 MHz: -L dBc, 600-960 MHz: -L dBc, 1690-2700 MHz: -L dBc
QR CODE:
CMS38606P-XXX-SNYYWWZZZZ = SERIAL NUMBERING
V = VALUE OF VSWR @ FREQUECY BANDS (380-520MHz, 600-960MHz, 1395-1435MHz, 1690-6000MHz).
L = PIM Performance Level
TEXT EMBEDDED IN QR BARCODE:
CMS38606P
ASSEMBLY INSTALLATION
INSTRUCTIONS
165-00177_AC
