Laird FHQ69273CD Instruction manual

FHQ69273CD
ASSEMBLY AND INSTALLATION
INSTRUCTIONS
Patent Pending
Please read all instructions carefully before attempting
to install this product.
SAFETY
The antennas and all associated equipment should be installed in
accordance with all applicable local and naonal electrical code
guidelines to ensure safe operaon.
165-00299_AC
APPLICATION
LOCATION
The FHQ69273CD antenna provides an excellent solution for
transportation application with an integration of wide range of
frequencies in within one aerodynamic housing. This antenna
covers GPS, Internal or External LTE/EVDO, Internal or External
UHF and WLAN antennas.
The antenna should be mounted on the desired locaon before
connecng the cable. This is to ensure that the cable is not twisted
or damage during the mounng of the antenna.
MODEL Phantom Fin 4‐Ports LTE/WIFI/
UHF‐1/GPS (FHQ69273CD)
698-960MHz; 1710-2700MHz (LTE/EDVO)
2400-2500MHz; 4900-5875MHz (WIFI)
380-430MHz;(UHF-1 External Antenna)
Frequency
Gain
LTE/EDVO
3.5dBi (typical), 4.0dBi (max) @ 698-806MHz
3.1dBi (typical), 3.4dBi (max) @ 824-894MHz
3.3dBi (typical), 3.4dBi (max) @ 880-960 MHz
5.7dBi (typical), 6.1dBi (max) @ 1710-1880MHz
6.0dBi (typical), 6.3dBi (max) @ 1850-1990MHz
5.4dBi (typical), 6.3dBi (max) @ 1910-2170MHz
4.8dBi (typical), 5.1dBi (max) @ 2300-2500MHz
5.9dBi (typical), 6.4dBi (max) @ 2500-2700MHz
WIFI
6.6dBi (typical), 7.1dBi (max) @2400-2500MHz
6.2dBi (typical), 7.8dBi (max) @ 4900-5875MHz
UHF-1 (External Antenna)
2.0dBi (typical), 2.6dBi (max) @ 380-430MHz
VSWR 2.0:1 Across the bands
Port-to-Port Isolation >15dB (UHF-LTE ports);
>20dB (UHF-WIFI ports);
>20dB (LTE-WIFI ports);
Nominal Impedance
Polarizaon
Azimuth Beam Width
Max Gain ±30
above Horizon 5GHz 4.1 dBi
Power Input (Max)
Operang Temperature
Storage Temperature
Cable
Dimensions HxLxW
Weight
Radome
Base Plate Material
Mount Style
RoHS
GPS ANTENNA
Frequency
Amplier Gain
Nominal Impedance
Output VSWR
DC Current
DC Voltage
Noise Figure
Cable
50Ω
Linear
Omnidireconal
10 Was (ambient temp of 25°C/77°F)
-30°C to +70°C
-40°C to +85°C
Coax Cable LMR-100
98.0mm x 70.0mm x 160.0mm
0.52kg
PC/ASA (Black)
Aluminum
Vehicle Mounted
Compliant
1575.42MHz (GPS L1)
27dB ± 3 dBc
50Ω
1.5:1 typical
20mA Nominal;< 30mA @-40°C to +85°C
2.7-12 Vdc
4 dB max
Coax Cable RG174
Ingress Rating IP67

INSTALLATION
- Maximum mounng plate thickness is 3 mm.
- The mounng area should be clean of any debris, clear from
obstrucons, and as at as possible
- Punch or drill a hole 21 mm in the roof of the vehicle at the
locaon idened.
- Place the antenna base onto the mounng plate. The
recommended orientation is facing the front of the vehicle.
Feed the cables from the bottom of the antenna through the
top side of the 21 mm hole. Peel the adhesive covering on
the bottom side of the antenna’s gasket. Place the threads of
the base plate of the antenna through the hole so the gasket
of the antenna is flat on the mounting plate. Slide the
lock-nut and washer around the 4 cables and finger-tighten to
the stud of the antenna. Orient the antenna in the desired
direction, and tighten the nut with a crescent wrench using 30
N*m of torque.
- Remove the cap and assemble the external Antenna on the
antenna base and manually ghten. Use a short service loop
(slack) with e-downs to secure the antenna cables such that
any force or movement will not be transmied to the antenna
connectors or the apparatus. Minimum bending radius for
the cable exing the boom of the antenna is 10 mm.
