Lamona LAM1746 Guide

www.howdens.com/appliance-registration
4-Zone Ceramic Hob LAM1746
Instructions and Installation
ISSUE v3. 030522

2www.howdens.com
4-Zone Ceramic Hob LAM1746

3
Instructions and Installation
Welcome
Dear Customer,
Congratulations on your choice of hob.
The user manual will help you use your product quickly
and safely.
• Please read this user manual before installing
and using the hob.
• Always follow the safety instructions.
• Keep this user manual within easy reach for future reference.
• Register your appliance to access a digital copy of your user
manual for future reference.
• Please read any other documents supplied with the product.
Explanation of symbols
Throughout this manual the following symbols are used.
Warning for possible hazards to health
and property.
Warning possibility of an electric shock.
Warning of risk of fire.
Warning of hot surfaces.
Important information or useful usage tips.
Read the user manual.

4www.howdens.com
4-Zone Ceramic Hob LAM1746
Contents
1. Before using the hob 5
2. Safety 5
General 5
Fire safety advice 7
If a pan catches fire 7
Deep-fat frying 7
If you have an electrical fire 7
3. Environmental instructions 8
Waste regulation 8
Package information 8
Future transportation 8
4. Information about cooking 9
5. Using the hob 11
Controls layout 11
Turning on the hob 11
Booster 12
Key lock 13
Operation time limits 14
Residual heat functions 14
Sensor calibration
and error codes 15
6. Cleaning and maintenance 16
How to clean your hob 16
7. Installation 17
General information 17
Positioning 17
Clearances and dimensions 18
Before installation 19
Self-adhesive seal 20
Protecting the hob cut-out 20
Fitting the hob 20
8. Electrical connections 21
9. Technical specifications 24
10. Troubleshooting 25
11. Your guarantee 26

5
Instructions and Installation
1. Before using the hob
2. Safety
• This appliance is for domestic cooking purposes only.
It must not be used for other purposes, for example room heating.
General
• WARNING: Accessible parts will become hot during use. Care
should be taken to avoid touching heating elements. To avoid
burns, children less than 8 years of age should be kept away unless
continuously supervised. This appliance can be used by children
aged 8 years and above, persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children must not play with the appliance. Cleaning and user
maintenance must not be made by children without supervision.
• CAUTION: Cooking process should be supervised continuously.
• Servicing should be carried out only by authorised personnel.
• This appliance must be installed so that it can be electrically isolated
by a switch after installation.
• Only use the connection cable supplied and as specified if cable
is damaged, it should be replaced by a suitably qualified person.
• Do not spray aerosols in the vicinity of this appliance while it is
in operation.
• Do not store or use flammable liquids or items in the vicinity
of this appliance.
• Do not use steam cleaners to clean the appliance as this may cause
an electric shock.
• Always position pans over the centre of the heat zone, and turn
the handles to a safe position so they cannot be knocked over or
grabbed by children.
• Never use pans smaller than 100mm (4") and larger than 250mm (10").
• Make sure that you have removed all packaging, wrappings,
stickers and films from the hob surface.
• It is recommended that you clean the hob surface before using
for the first time (see page 16).

6www.howdens.com
4-Zone Ceramic Hob LAM1746
• Always match the size of pan to the heat zone – do not use large
pans on small zones or vice versa.
• Always lift pans onto and off the hob, rather than sliding them across
the surface to avoid marks and scratches.
• Never use double pans, rim-based pans, old or misshapen pans,
or any pan that is not stable on a flat surface.
• Never use commercial simmering aids, or heat diffusers, as they
create excessive heat and can damage the surface of the hob.
• Never use the hob for any other purpose than cooking food.
• WARNING OF FIRE
• Never store items or leave plastic utensils close to, or on top of the hob.
• Never leave any cook zone on without a pan covering it. This causes a
potential fire hazard.
• Never use the hob surface as a chopping board or food preparation
area, as this may lead to it becoming damaged.
• Never put metal cooking utensils, cutlery, knives or other metal objects
on the hob. They could become hot if they are near a cooking area
which is in use.
• Never leave aluminium foil on the hob top, it reflects heat back into
the element which leads to damage.
• Never heat up a sealed tin of food on the hob, as it may explode.
• Never leave pans overhanging the edge of the hob.
• WARNING: Only use hob guards designed by the manufacturer of
the appliance or as indicated in the instructions for use as suitable or
hob guards incorporated in the appliance. The use of inappropriate
guards can cause accidents.
• The appliance is not intended to be operated by means of an external
timer or separate remote control system.
• Do not modify this appliance.
• WARNING: Never leave cooking fat, or oil unattended.
• CAUTION: If the glass surface is cracked or broken do not use the
appliance. Risk of an electric shock.

7
Instructions and Installation
• Fire safety advice
• Most kitchen fires occur when people are distracted or leave things
unattended, so remember:
• If you’re called away from the hob – by the phone or someone at
the door, either take pans off the heat, or switch off your hob.
• Don’t let yourself be distracted while cooking. Do not leave unattended.
• If you do have a fire in the kitchen, don’t take any risks – get everyone
out of your home and call the Fire Service.
If a pan catches fire
• Do not move it as it’s likely to be extremely hot.
• Turn of the heat if it’s safe to do so, but never lean over a pan
to reach the controls.
• WARNING: Use fire blanket or a damp tea-towel to cover the pan.
Deep-fat frying presents more dangers in your kitchen
• If you have put the fire out, leave the pan to cool completely.
• Never fill a chip pan (or other deep fat fryer) more than one-third
full of oil.
• Do not use a fire extinguisher on a pan of burning oil – the force of
the extinguisher can spread the fire and create a fireball.
If you have an electrical fire in the kitchen
• Switch off the power at the fuse box – this may be enough to stop
the fire immediately.
• Smother the fire with a fire blanket, or use a dry powder or carbon
dioxide extinguisher.
• REMEMBER: Never use water on an electrical or cooking oil fire.

8www.howdens.com
4-Zone Ceramic Hob LAM1746
Waste regulation
Disposing of the old product. Compliance with the WEEE Directive
and disposing of the waste product:
This product complies with EU WEEE Directive (2012/19/EU).
This product bears a classification symbol for waste
electrical and electronic equipment (WEEE).
This product has been manufactured with high quality
parts and materials which can be reused and are suitable
for recycling. Do not dispose of the waste product with
normal domestic and other wastes at the end of its
service life. Take it to the collection centre for the recycling
of electrical and electronic equipment. Please consult your local
authorities to learn about these collection centres. Appropriate disposal
of used appliance helps prevent potential negative consequences for
the environment and human health.
Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive
(2011/65/EU). It does not contain harmful and prohibited materials
specified in the Directive.
Package information
• Packaging materials of the product are manufactured from
recyclable materials in accordance with our National Environment
Regulations. Do not dispose of the packaging materials together with
the domestic or other wastes. Take them to the packaging material
collection points designated by the local authority.
Future transportation
• Keep the product’s original carton and transport the product in it.
Follow the instructions on the carton. If you do not have the original
carton, pack the product in bubble wrap or thick cardboard and
tape it securely.
Check the general appearance of your product for any
damages that might have occurred during transportation.
3. Environmental instructions

9
Instructions and Installation
The following information will
help you to use your appliance
in an ecological way, and to
save energy:
• Defrost frozen dishes before
cooking them.
• Use pots/pans with cover for
cooking. If there is no cover,
energy consumption may
increase 4 times.
• Select the burner which is
suitable for the bottom size
of the pot to be used. Always
select correct pot size for your
dishes. Larger pots require
more energy.
• Pay attention to use flat bottom
pans when cooking with
electric hobs.
• Pots with thick a thick bottom
will provide a better heat
conduction. You can obtain
energy saving up to 1/3.
• Vessels and pots must be
compatible with the cooking
zones. Bottom of the vessels or
pots must not be smaller than
the hot plate.
• Keep the cooking zones and
bottom of the pots clean.
Dirt will increase the heat
conduction between the
cooking zones and the bottom
of the pot.
• For long cooking periods, turn
off the cooking zone 5 or 10
minutes before the end of
cooking time. You cab obtain
energy savings up to 20% by
using residual heat.
• NEVER fill the pan with oil
more than one third of it. Do not
leave the hob unattended with
oil. Overheated oil brings risk
of fire.
Never attempt to extinguish a
possible fire with water! When oil
catches fire, cover it with a fire
blanket or damp cloth. Turn off
the hob if it is safe to so and call
the fire department.
• Before frying foods, always
dry them well and gently place
into hot oil. Ensure complete
thawing of frozen foods
before frying.
• Do not cover the vessel you
are using when heating oil.
• Place pans and saucepans
in a manner so that their
handles are not over the hob
to prevent heating of handles.
Do not place unbalanced and
easily tilting vessels on the hob.
• Do not place empty vessels
and saucepans on cooking
zones that are switched on.
They might get damaged.
• Operating a cooking zone
without a vessel or saucepan
on it will cause damage to
the product.
Turn off the cooking zones after
the cooking is complete.
4. Information about cooking

10 www.howdens.com
4-Zone Ceramic Hob LAM1746
• As the surface of the product
can be hot, do not put plastic
and aluminium vessels on it.
Clean any melted materials on
the surface immediately. Such
vessels should not be used to
keep food either.
• Use flat bottomed saucepans
or vessels only.
• Put appropriate amount of
food in saucepans and pans.
Thus, you will not have to make
any unnecessary cleaning by
preventing the dishes from
over flowing.
• Do not put covers over the
saucepans or pans on the
cooking zones.
Place the saucepans in a
manner so that they are
centred on the cooking zone.
When you want to move the
pan onto another cooking zone,
lift and place it onto cooking
zone rather than sliding it.
Tips about glass ceramic hobs
• Glass ceramic surface is
heatproof and is not affected
by big temperature differences.
• Do not use the glass ceramic
surface as a place to store or
as a cutting board.
• Use only saucepans and pans
with machined bottoms. Sharp
edges create scratches on
the surface.
• Do not use aluminium
vessels and saucepans.
Aluminium damages the
glass ceramic surface.

11
Instructions and Installation
5. Using the hob
• Do not use the ceramic hob
if the glass surface is cracked,
as electrical parts are directly
beneath.
• Switch off the appliance at the
supply to prevent an electric
shock and contact your supplier.
• The appliance is not
intended to be operated by
means of an external timer or
separate control system.
• The hob surface remains hot
after use. DO NOT TOUCH.
List of pots to be used
on each burner:
1Single circuit cooking plate
18-20cm
2Single circuit cooking plate
14-16cm
3Single circuit cooking plate
18-20cm
4Single circuit cooking plate
14-16cm
Controls layout
Turning on the hob
Touch the key on the control
panel for 1 second. Cooking
zone displays illuminate. The
hob is ready use now. You can
select different cooking zones
within the following 10 seconds.
Other controls are not allowed to
function when the main key is
being operated.
and all relevant decimal
point will flash in all cooking
zone displays.
If no operation is performed
within 10 seconds, the hob
will automatically return to
stand-by mode.
If you press the main key
for longer than 2 seconds the
hob will turn off and return to
stand-by mode.
Symbol Description
Main key – On/Off
Power/timer set
Cooking zone
selection controls
Cooking zone display
Dual/triple cooking
zone operation LED
N
Q
OP
1
4
3
2

12 www.howdens.com
4-Zone Ceramic Hob LAM1746
Selecting cooking zones:
1. Turn on the hob.
2. Touch one of the cooking
zone selection controls to turn
on the desired cooking zone.
After selecting the cook zone
of the hob decimal point will
flash on the relevant cooking
zone display.
If no operation is performed
within 10 seconds, the hob
will automatically return to
stand-by mode.
3. Touch or keys to set the
temperature level to a value
between 1and 9or between
9and 1. and keys are
equipped with repeat function.
If you touch any of these keys for
a long time, temperature level
will continuously increase or
decrease at every 0.4 seconds.
If you start with key, 1
appears on the display. If you
start with a key, set value
appears on display (e.g. half
second Aand half second 9).
This indicates that the booster
is activated.
Booster
This function facilitates cooking.
When the booster is activated,
the cooking will operate at
maximum power for a certain
period of time. Booster time
depends on the selected
temperature level. This is indicated
with an Aand the set temperature
value which flash alternately on
cooking zone display (e.g. Ahalf
second, half second 9) once the
booster time is over, power of
the cooking zone will be reduced
and the temperature value will be
displayed continuously.
All cooking zones are equipped
with the booster function.
Enabling the booster function:
1. Turn on the hob.
2. Select the desired cooking zone
by touching the cooking zone
selection keys.
3. Use the key to set the cooking
zone temperature value to 9.
Once the temperature setting
is made, 9and Awill appear
on the display alternately. This
indicates that the temperature
value is set to 9and booster
function is activated.
4. Then use key within
10 seconds to select the
temperature setting you want
to be activated for the
remainder of the cooking
process after the booster time
is over. Use or keys to set
the cooking zone to a value
between 1or 9(it is supposed
that level 6is selected for
the example).
5. Aand 6appear alternately
on the display during the
booster function. (At the end
of booster period 6will be
displayed continuously).
Turning off the booster function:
1. Touch key until temperature
level decreases to 0to disable
the booster function earlier.

13
Instructions and Installation
2. If 9will be selected as
temperature level that will be
activated after booster period
and no other lower level is
selected, then flashing of the
screen will cease in 10 seconds.
Booster is now deactivated.
Turning off the hob
If you press the main key
for longer than 2 seconds, the
hob will turn off and return to
standby mode. If there is residual
temperature that can be used
after the hob is turned off, this will
be indicated with a symbol that
appears on the relevant cooking
zone display continuously.
Turning off cooking zones
individually
A cooking zone can be turned off
in two different ways:
1. By touching the and
keys simultaneously. Select
the desired cooking zone
selection key . Decimal
point appears on cooking
zone display. Touch and
keys simultaneously to turn
off the cooking zone.
2. By decreasing the temperature
level to 0 with the key.
Furthermore, cooking zone
can also be turned off by
decreasing the temperature
level to 0.
Key lock
You can protect the hob against
being operated unintentionally
in order to prevent children from
turning on the cooking zone.
Key lock function contains a few
complex steps to lock the touch
control unit. Key lock can only be
activated and deactivated in
stand-by mode.
Locking the module
1. Touch the main key to turn
on the hob.
2. Touch and keys
simultaneously for at least
2 seconds.
3. Then touch key once
again. Key lock function is
activated and appears on all
cooking zones.
Disabling key lock
You can disable the key lock as
you have activated it.
1. Touch the main key to turn
on the hob.
2. Touch and keys
simultaneously for at least
2 seconds.
3. Then touch key once again.
Key lock function is activated
and appears on all cooking
zones as long as the key lock
is active. will disappear
when the lock is deactivated
successfully.

14 www.howdens.com
4-Zone Ceramic Hob LAM1746
Temperature
setting
Off time
(seconds)
On time
(seconds)
Operation time
limit (hours)
Booster time
(seconds)
0 0 0 0 –
1 45.6 1.4 6 60
2 43.6 3.4 6 180
3 41.3 5.7 5 288
4 38.4 8.6 5 390
5 35.9 11.1 4 510
6 33.1 13.9 1.5 150
7 26.2 20.8 1.5 210
8 19.2 27.8 1.5 270
9 0 47 1.5 –
Operation time limits
The hob control is equipped with an operation time limit.
When one or more cooking zones are left on.
Residual heat functions
For a deactivated cooking zone whose surface temperature is
sensed above 60ºC or whose display indicates a value above 60ºC
a (residual heat) symbol appears on the display. When the power
restores after a power failure and if the residual heat of the relevant
cooking zone was above 60ºC before the failure, residual heat display
flashes. Display continues to flash until the maximum residual heat time
is over of the cooking zone is selected and enabled.

15
Instructions and Installation
Sensor calibration
and error codes
When the supply power is
applied, hob control system
performs calibration depending
on the sensor, glass and ambient
conditions. Do not cover the
sensor with anything during
calibration. Hob control system
should also not be exposed to
strong light sources such as sun
light, strong halogen lamps etc.
Sample application:
• Following lighting conditions
will allow a smooth calibration:
• Illumination with a bulb without
a reflector (100W dull) 70cm
above the glass ceramic hob.
After a successful calibration,
it is warranted that the hob
will operate as intended even
under a strong illumination such
as halogen spot lamp
with reflector (50W).
• If an error occurs, calibration
is repeated until the ambient
conditions allow for a successful
calibration. Hob control system
can only be operated when
the calibration of all the sensors
is successful.
• You must be remove all
substances on the hob during
calibration. Also the ambient
illumination should not be too
strong during calibration. If
one of the F1, F1, F3 messages
is obtained, user must turn off
all light sources or close the
window during the calibration
process at first connection
to the power supply. When
the calibration is completed
successfully, control system
can tolerate a high amount
of ambient light.
• Hob control system changes
in ambient conditions while it
is in use.
• Touch control is equipped
with a sensor ensuring
protection against overheating.
Relevant cooking zone will be
deactivated when reacting
to this sensor. To obtain more
information on error messages,
please see the table opposite.
• If a key is activated repeatedly
(for longer than 10 seconds),
all control system is deactivated
and an audio signal is given.
Cause of the error Display
Communication error AF10
Button failure – (open circuit,
short circuit etc.) AF20
Relay – short circuit error AF30
Pressing one button during
more than 12 seconds F-F-F-F
Touch control card is too hot t-t-t-t

16 www.howdens.com
4-Zone Ceramic Hob LAM1746
6. Cleaning and maintenance
How to clean your hob
• The ceramic hob top can
be cleaned using a clean,
damp cloth or kitchen paper.
Do not use a used dishcloth
or sponge as they can leave
a film of detergent on the
surface which can lead to
discolouration. Please ensure
that the elements are cooled
fully to avoid steam burns.
• You can use a specialist
ceramic cleaner to restore
the surface, but use sparingly
to avoid coating the hob
top too thickly. Too much
cream cleaner will lead to
discolouration. Use a dry, clean
cloth to polish the surface.
• For stubborn marks, a specialist
hob scraper can be used.
• Do not use steam cleaners
or high pressure cleaning
equipment.
• Regular cleaning will prevent
any salts or minerals from
accumulating on your hob
and discolouring the glass.
• Wipe any spillage as soon
as possible.
• Clean the hob top as regularly
as possible, this will prevent any
build up of grease which may
be a fire hazard.
• Foods with high sugar content
(toffee, fruit juice, jam, etc.)
that boil over while cooking,
or spattered sugar stains must
be immediately removed using
a scraper even if hot.
• Do not use abrasive products,
bleach, hob cleaner spray or
pan scourers.

17
Instructions and Installation
7. Installation
General information
• Installation should only be
carried out by a registered
competent person.
• Installations MUST be carried
out in line with the National
Regulations applicable with
this product type.
• Please note:
Although every care has been
taken to ensure this appliance
has no burrs, or sharp edges,
We recommend that you wear
protective gloves when installing
and moving this appliance. This
will prevent injury.
The hob should not be fitted
above a washing machine, a
fridge or a freezer. Wall surfaces
above the work surface and in the
immediate vicinity of the cooking
hob must be heat resistant.
• Prior to installation, visually
check the product for any
damage/defects. Do not install
if any issues are found.
• Damaged products may cause
risks to your own safety.
• The appliance is intended for
installation in Howden kitchen
cabinets.
• Surfaces, synthetic laminates
and adhesives used must be
heat resistant.
• Kitchen cabinets must be set
level and fixed.
• If there is a drawer beneath the
oven, a shelf must be installed
between oven and drawer.
• The following installation
drawings are representational
and may not match exactly
with your appliance.
Positioning
The hob is designed to be built
into a work top as detailed in
the image (overleaf).
Aperture width 560mm (+2) x
depth 490mm (+2).

18 www.howdens.com
4-Zone Ceramic Hob LAM1746
Clearances and dimensions requirements
AMinimum distance between
cabinets must be equal to the
overall width of all hobs.
BMinimum height to extractor
as recommended in extractor
instruction manual.
C400mm minimum between
worktop and cabinetry within
170mm either side of the hob.
D170mm minimum between
cut-out and vertical surface
above the worktop.
No shelf or overhang of
combustible material should
be closer than 650mm directly
above the hob.
There must be a minimum
clearance of 50mm between
the rear edge of the cut-out
and the rear wall. This clearance
must be maintained up to
650mm above the worktop
(unless otherwise stated in your
extractor manual).
The rear wall is any vertical
surface behind the hob. If any
tiles, backboards, splashbacks
or upstands are fitted, the distance
is taken from the front face of
these items.
50mm min.
560mm
50mm min.
A
B C
D
490mm

19
Instructions and Installation
Before installation
The product should only
be installed by a registered
qualified person.
The product must be installed
in accordance with all local
regulations.
Prior to installation, visually
check the product for any
damage/defects. Do not install
if any issues are found.
Damaged products may cause
risks to your own safety.
The appliance is intended for
installation in Howdens kitchen
cabinets.
• Surfaces, synthetic laminates
and adhesives used must be
heat resistant.
• Kitchen cabinets must be set
level and fixed.
• If there is a drawer beneath the
oven, a shelf must be installed
between oven and drawer.
• The following installation
drawings are representational
and may not match exactly
with your appliance.
Installation above an oven
If the appliance is installed with
an oven underneath, please
leave at least 15mm of ventilation,
unless otherwise stated in your
oven installation guidelines.
Installation above
a cupboard/drawers
If the installation is not above an
oven and the underside of the
hob is accessible, a wooden
shield is required to be installed at
least 15mm below the underside
of the hob unit.
5mm
Worktop Hob
15mm
15mm min.

20 www.howdens.com
4-Zone Ceramic Hob LAM1746
Self-adhesive seal
Turn the hob underside down,
place it on a flat protected surface.
Apply the self adhesive seal to the
underside edges of the hob glass.
For best results, the seal should be
adhered along each side in turn,
as close to the edge as possible,
and trimmed at each corner,
taking care to ensure a neat join.
DO NOT fit silicone sealant
under the glass hob instead of the
self-adhesive seal.
Protecting the hob cut-out
The types of chipboard used
for work surfaces swell relatively
quickly in contact with humidity.
Apply a special varnish or adhesive
to the cut edge to protect and
seal it from moisture ingress.
Fitting the hob
Once the seal is on the glass the
hob can be fitted into the cut-out.
Position rear side of the hob into
the cut-out, lowering the front
edge, gently pressing the hob
into position.
To remove hob
Push hob up from below by
placing hands at front of hob.
Or
Use fingers under the edge of
the glass (never use a screwdriver
etc.) to lift the hob.
