User & Installation Guide
LAM3201
LAM3205
LAM3206
Built-in
Conventional Oven

www.howdens.com
Page _ 2
LAMONA Appliances
Dear Customer,
Congratulations on your choice of oven which has been designed to give you excellent service.
The user manual will help you use your product quickly and safely.
Please read this user manual before installing and using the oven.
Always follow the safety instructions.
Keep this user manual within easy reach for future reference.
Please read any other documents supplied with the product.
Explanation of symbols
Throughout this user manual the following symbols are used:
This product’s packaging material is recyclable. Help recycle it and protect the
environment by dropping it off in the municipal receptacles provided for this purpose.
Your product also contains a great amount of recyclable material. It is marked with this
label to indicate used appliances that should not be mixed with other waste. This way, the
appliance recycling organised by your manufacturer will be done under the best possible
conditions, in compliance with European Directive 2002/96/EC on Waste Electrical
and Electronic Equipment. Contact your town hall or your retailer for the used appliance
collection points closest to your home. We thank you doing your part to protect the
environment.
Important information or useful tips about usage.
Warning for possible hazards to health and property.
Warning possibility of electric shock.

Exclusive to Howdens Joinery.co Page _ 3
User manual LAM3201 / LAM3205 / LAM3206
Index
Before using the oven & Safety 04
General 05
Safety for children 07
Safety when working with electricity 07
General information 08
Oven layout 08
Control panel layout 08
Accessories 08
Operation modes 09
Operating modes 09
Preparation 10
First cleaning of the appliance 10
Initial heating 10
Tips for energy saving 10
How to operate the main oven 11
How to use the main oven 11
Select a temperature and operating mode 11
Shelf positions 11
Switch off the oven 11
Cooking and baking advice 12
Cooking table 14
Oven cooking table 14
Grill cooking table 15
Care and maintenance 16
General information 16
Cleaning the control panel 16
Cleaning the door 16
Removal of the oven door 16
Removing the inner door glass 17
Replacing the oven Lamp 18
Installation 19
Before installation 19
Installation and connection 20
Connection to mains supply 20
Cooling Fan 21
22
Troubleshooting 23
Your Guarantee 24
Important Safety Information 05

Exclusive to Howdens Joinery.co
Page _ 4
User manual LAM3201 / LAM3205 / LAM3206
t This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision
The appliance and its accessible parts become hot during use.
Care should be taken to avoid touching heating elements.
Children less than 8 years of age shall be kept away unless
continuously supervised.
Do not use steam cleaners to clean the appliance as this may
cause an electric shock.
If the power connection cable for the product is damaged, it
must be replaced by the manufacturer, its service agent or
similary qualifed persons in order to avoid a hazard.
During use the appliance becomes hot. Care should be taken
to avoid touching heating elements inside the oven.
The appliance must be installed so that it can be completly
disconnected from the network. The separation must be
provided either by a mains plug, or a switch built into the
regulations.
Accessible parts may become hot during use. Young children
should be kept away.
Importantinstructionsandwarningsforsafetyandenvironment
t
t
t
t
t
t
t
t

Safety_ 05
User manual LAM3201 / LAM3205 / LAM3206
t Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the oven door glass since they can scratch the surface,
which may result in shattering of the glass.
Rear surface of the oven gets hot when it is in use. Make sure
that the gas/electrical connection does not contact the rear
surface; otherwise, connections can get damaged.
lamp to avoid the possibility of electric shock.
Importantinstructionsandwarningsforsafetyandenvi
ronment
t
t

www.howdens.com
Page _ 6
LAMONA Appliances
Make sure that you have removed all packaging, wrappings, stickers and from the oven’s
surface.
It is recommended that you clean and wash the oven’s surface before using for the time.
Before using the Oven
This appliance is for domestic cooking
purposes only. It must not be used for other
purposes, for example room heating, or drying
towels and dish cloths. Commercial use will void
the guarantee.
The manufacturer shall not be liable for any damage
caused by improper use or handling errors.
General
This product is not intended to be used by persons
with physical, sensory or mental disorders or
unlearned or inexperienced people (including
children) unless they are supervised by a person
who will be responsible for their safety or who will
instruct them accordingly in the use of the product.
Children must be supervised to prevent them from
tampering with the product.
Connect the product to an earthed outlet
protected by a fuse of suitable capacity
as stated in the “Technical
table. Our company shall not be liable for
any problems arising due to the product not
being earthed in accordance with the local
regulations.
Do not operate the product if the power cable
is damaged. Call service agent.
Do not operate the product if it is defective or
has any visible damage.
Do not carry out any repairs or
on the product. However, you may remedy
issues that do not require any repairs or
See Troubleshooting, later in
this booklet
Never wash down the product with excessive
water, as there is the risk of electric shock!
Never use the product when your judgment or
coordination is impaired by the use of alcohol
and/or drugs.
Product must be disconnected from the mains
during installation, maintenance, cleaning and
repair procedures.
Repair procedures must always be performed
by service agents. The manufacturer
shall not be held responsible for damages
arising from procedures carried out by
unauthorised persons, which may also void
the guarantee.
Be careful when using alcoholic drinks in
your dishes. Alcohol evaporates at high
temperatures and may cause since it can
ignite when it comes into contact with hot
surfaces.
Do not heat closed tins and glass jars in the
oven. The pressure that would build-up in the
tin/jar may cause it to burst.
Do not place any materials close
to the product as the sides may become hot
during use.

WARNING FIRE RISK -
Do not place aluminium foil, baking trays
or cook on the base of this oven, doing so
will cause permanent damage to your
appliance and cabinetry with the potential
Do not place aluminium foil on the base of the
baking tray.
Keep all ventilation slots clear of obstructions,
as this may cause premature failure of the
oven element.
Parts of the appliance may become hot during
or immediately after use. Care should be
taken to avoid touching the heating elements,

Exclusive to Howdens Joinery.co Page _ 7
User manual LAM3201 / LAM3205 / LAM3206
and components inside the oven which maybe
hot. Always allow time for the oven
to cool.
Do not allow the oven to cool with the door
open. Even if the appliances door is only open
a little, front panels of adjacent units could
become damaged over time.
If the door seal is very dirty this can prevent
the door from closing properly during use,
resulting in possible damage to adjacent
furniture and poor Always ensure
the door seal is clean.
Product may become hot when it is in use.
Please be careful not to touch these hot
surfaces.
Always use heat resistant oven gloves when
putting dishes in or removing dishes from the
hot oven.
Do not use the product if any door glass is
removed or damaged.
Rear surface of the oven may get hot when
it is in use. Make sure that the electrical
connections do not contact the rear surface;
otherwise, connections may be damaged.
Do not trap the mains cable and do not route
it over hot surfaces. The cable insulation may
melt and cause a as a result of a short
circuit.
Make sure that the product function knobs are
switched off after every use.
When hot and cold air meet, condensation
can form. The outer door is air cooled and the
inner glass will become hot during cooking,
therefore some condensation might form.
This is perfectly normal. All condensation
will disappear as the oven reaches cooking
temperature.
Product must be installed by a person
in accordance with the regulations in force.
Otherwise, the guarantee may become void.
Safety for children
Electrical products can be dangerous to children.
Keep children away from the product when it is
operating and do not allow them to play with or near
the product.
“CAUTION: accessible parts of the oven may
become hot when the oven or grill is in use. Children
should be kept away until the product has cooled
down.”
Do not store any items above the appliance that
children may reach for.
When the door is open, do not load any heavy object
on it and do not allow children to sit on it. The door
or door hinges may be damaged.
The packaging materials will be dangerous for
children. Keep the packaging materials away
from children. Please dispose of all parts of the
packaging according to environmental standards.
Safety when working with
electricity
Any work on electrical equipment and systems
should only be carried out by authorised and
persons.
In case of any damage, switch off the product and
disconnect it from the mains. To do this, turn off the
fuse at the fuse box.
Make sure that fuse rating is compatible with the
product.
Do not switch the oven off at the mains
isolation switch immediately after cooking.
Cooling fan continues to run for up to 20-30
minutes (approx) even after the oven control is
turned off.

www.howdens.com
Page _ 8
LAMONA Appliances
a. Control panel
b. Handle
c. Oven Door
General Information
d. Heating element
e. Light
f. Oven shelf positions
a oven/ grill function knob
b Main oven temperature indicator
c oven / grill temperature indicator
a
b
c
ba c
Oven tray / grill pan Grill pan wire rack / trivet Oven shelf (x2 included)
Oven layout
Control panel layout
Accessories
5
4
3
2
1
e
f
d

Exclusive to Howdens Joinery.co Page _ 9
User manual LAM3201 / LAM3205 / LAM3206
Operating modes
Operating modes
All functions for the ovens and grill are listed in this section. Please note* depending on the model of your
oven, the number and order of operating modes available may deviate from the illustrations shown below.
Top and bottom heat
Top and bottom heat is used. The
foodstuffs are heated simultaneously
from above and below. Suitable for cakes,
cookies and casseroles. For best results
cook with one tray only.
Bottom heat
Only bottom heat is used. Is particularly
suitable for dishes, such as pizza, which
are required to be baked from beneath.
Grill-small
The inner grill element in the top oven is
in operation. This is suitable for small or
medium-sized portions
Ensure correct shelf position is used, set
the temperature to desired level, and
turn the food as required to ensure even
cooking.
Grill -Full
The full grill element in the top oven is in
operation. This is suitable for grilling
larger dishes

www.howdens.com
Page _ 10
LAMONA Appliances
Preparation
First cleaning of the appliance
1. Remove all packaging materials.
2. Wipe the surfaces of the appliance with a
damp cloth or sponge and dry with a clean
cloth
The surface may get damaged by some detergents
or cleaning materials.
Do not use aggressive detergents, cleaning powder/
cream or any sharp objects.
Initial heating
It is recommended to heat up the product for
about 30 minutes and then switch it off. Thus, any
production residues or layers will be burnt off and
removed.
1. Take the tray and the wire grid out of the oven.
2. Close the oven doors.
3. Select the highest oven & grill power levels
(See How to use the oven and grill section).
4. Operate oven & grill for about 30 minutes.
5. Turn off your oven & grill and allow to cool.
Small amounts of fumes may emit during the
initial heating process; this is normal, however
monitor the oven at all times and ensure that the
room is well ventilated.
Tips for saving energy
The following information will help you to use your
appliance in an ecological way, and to save energy:
Use dark coloured or enamel coated cookware
in the oven as the heat transmission will be
better.
Perform a preheating operation if it is advised
in the user manual or cooking instructions.
Do not open the door of the oven frequently
during cooking.
Try to cook more than one dish in the oven at
the same time whenever possible. You can
place two cooking vessels onto the wire shelf.
Cook one dish after another. The oven will
already be hot.
You can save energy by switching off your oven
a few minutes before the end of the cooking
time. Do not open the oven door.
Defrost frozen dishes before cooking them if
possible.

Exclusive to Howdens Joinery.co Page _ 11
User manual LAM3201 / LAM3205 / LAM3206
Select temperature
& Operating mode
a
a. Oven function knob*
b. Oven thermostat knob
Please note* oven functions may differ
depending on your oven model
The operating modes of the electric oven are
selected with the function knob. The temperature is
adjusted with the thermostat knob.
How to use the oven & Grill
1. Set thermostat knob to the desired
temperature.
2. Set function knob to the required operating
mode.
3. Close the oven door
The oven heats up to the adjusted temperature
and maintains it. During heating, the temperature
indicator light will remain on until the desired
temperature is reached.
Shelf positions
The oven has 5 shelf positions as illustrated below,
It is important to position the wire shelf into the
runners correctly.
5
4
3
2
1
Please ensure shelves are fully inserted before
closing the oven door, failure to do so could lead to
damage to the door.
WARNING FIRE RISK -
Do not place aluminium foil, baking trays or
cook on the base of this oven, doing so will
cause permanent damage to your appliance and
Warning –Do not place plates, dishes or trays on
the of oven cavity when oven is in use.
Warning - Do not use the oven or grill cavity for
storage when not in use.
Switch off the electric oven
Turn function knob and thermostat knob to off
position (top).
How to operate the main oven and grill
b

www.howdens.com
Page _ 12
LAMONA Appliances
Risk of scalding by hot steam! Take care when
opening the oven door as steam may escape.
Tips for baking
Use nonstick coated appropriate metal trays
and containers or heat-resistant silicone
moulds.
Make best use of the space on the shelf.
It is recommended to place the vessels in the
middle of the shelf.
Select the correct shelf position before turning
the oven or grill on - don’t move oven shelves
when hot.
Keep the oven door closed.
Tips for roasting
Seasoning with lemon juice and black pepper
will improve the cooking performance when
cooking a whole chicken, turkey or a large
piece of meat.
Meat with bones takes about 15 to 30
minutes longer to cook than a roast of the
same size without bones.
Let meat rest in the oven for about 10 minutes
after the cooking time. The juices will be better
distributed thought the meat and will not run
out when the meat is cut.
Fish in a heat proof dish should be placed at
the medium or lower level.
Tips for grilling
Grilling is ideal for cooking meat, and
poultry and will achieve nice browning without
drying out the food. Flat pieces, meat skewers
and sausages are particularly suited for
grilling, as are vegetables with a high water
content, such as tomatoes and onions.
Distribute the pieces to be grilled on the wire
rack.
Use tray or grill pan under the wire rack in
order to collect dripping fat or juices.
Adding some water to the grill pan will assist
with cleaning.
Cooking and baking advice
Tips for baking cake
If the cake is too dry, increase the temperature
by 10°C and decrease the cooking time.
If the cake is wet, use less liquid or lower the
temperature by 10°C.
If the cake is too dark on top, place it on
a lower shelf, lower the temperature and
increase the cooking time.
If cooked well on the inside but sticky on the
outside use less liquid, lower the temperature
and increase the cooking time.
Tips for baking pastry
If the pastry is too dry, increase the
temperature by 10°C and decrease the
cooking time. Dampen the layers of pastry with
a wash composed of milk, oil, egg.
If the pastry takes too long to bake, pay
attention to the thickness of the pastry you
have prepared
If the upper side of the pastry gets browned,
but the lower part is not cooked, make sure
that the amount of wash you have used for the
pastry is not too much at the bottom of the
pastry. Try to spread the wash equally over the
pastry for an even browning.
Cook the pastry in accordance with the mode
and temperature given in the cooking table.
Tips for cooking vegetables
If the vegetable dish runs out of juice and gets
too dry, cook it in a dish with a lid instead of
an open tray. Closed vessels will preserve the
juice of the dish.
If a vegetable dish is not cooked, boil the
vegetables beforehand.

Exclusive to Howdens Joinery.co Page _ 13
User manual LAM3201 / LAM3205 / LAM3206

www.howdens.com
Page _ 14
LAMONA Appliances
Oven cooking table
CONVENTIONAL OVEN COOKING TABLE
Dish Cooking level Oven Function Temperature °C Cooking Time min
Baking
Cakes in tray* Level 3 175 25 - 30
Cakes in mould* Level 2 175 40 - 50
Cakes in bun cases Level 3 175 25 - 30
Sponge cake* Level 3 200 15 - 20
Cookies* Level 3 175 25 - 30
Dough pastry* Level 2 200 30 - 40
Rich pastry* Level 2 200 25 - 35
Meat
Lasagna* Level 2 - 3 200 30 - 40
Roast Beef Level 2 25 min at 250/max
then 180 ... 190 100 - 120
Leg of Lamb Level 2 25 min at 220
then 180 ... 190 70 - 90
Roasted chicken Level 2 15 min at 250/max
then 180 ... 190 55 - 65
Turkey (5.5kg) Level 1 25 min at 250/max
then 190 150 - 210
Fish
Fish Level 3 200 20 - 30
For best results cook on a single shelf in the centre of the oven and allow the heat to circulate evenly around the food.
* It is suggested to perform preheating for all foods
If cooking requires preheating, heat the oven until the thermostat lamp goes out.
The values indicated in the tables below are
indicative. They may vary according to the type of
food as well as your preferences of cooking.
Baking and roasting
Level 1 is the bottom level in the oven.
Cooking Tables

Exclusive to Howdens Joinery.co Page _ 15
User manual LAM3201 / LAM3205 / LAM3206
GRILL COOKING TABLE
Food Cooking level Oven Function Cooking Time (min)
Fish 4-5 Level 20 - 25
Sliced chicken 4-5 Level 25 - 30
Lamb chops 4-5 Level 20 - 25
Steak 4-5 level 25 - 30
Toast 4 Level 1 - 2
Please Note: cooking times may vary depending on their thickness of food
Grill cooking table

www.howdens.com
Page _ 16
LAMONA Appliances
Care and maintenance
General information
Service life of the product will extend and the
possibility of problems will decrease if the product is
cleaned at regular intervals.
Risk of electric shock!
Switch off the electricity before cleaning appliance
to avoid possibility of an electric shock.
Hot surfaces may cause burns!
Allow the appliance to cool down before you clean it.
Clean the product thoroughly after each use.
This way it will be possible to remove cooking
residues more easily and will avoid burning
them on the next time the appliance is used.
No special cleaning agents are required for
cleaning the product. Use warm water with
washing liquid, a soft cloth or sponge to clean
the product and wipe with a dry cloth.
Always ensure any excess liquid is thoroughly
wiped off after cleaning and any spillage is
immediately wiped dry.
Do not use cleaning agents that contain
acid or chloride to clean the stainless steel
surfaces and the handle. Use a soft cloth with
a liquid detergent (not abrasive) to wipe those
parts clean, paying attention to sweep in a
horizontal direction.
The surface may be damaged by some
detergents or cleaning materials.
Do not use aggressive detergents, cleaning powder/
cream or any sharp objects.
Do not use steam cleaners for cleaning.
Cleaning the control panel
Clean the control panel and control knobs with a
damp cloth and wipe them dry.
Do not remove the control knobs
for control panel cleaning.
Cleaning oven door
Don’t use any harsh abrasive cleaners or sharp
metal scrapers for cleaning the oven door. They
could scratch the surface and damage the glass.
Removal of the oven door
1. Open the door.
2. Unlock the clips at the hinge housing on
the right and left hand sides of the door by
pressing them down as illustrated in the
diagram.
1. Door door
2. Hinge
3. Oven
4. Raise the door to the half-way position.
5. Remove the door by pulling it up-wards to slide
it from the hinges.
Steps carried out during removing process should
be performed in reverse order to reattach the door.
Do not forget to close the clips at the hinge
housing when reinstalling the door.

Exclusive to Howdens Joinery.co Page _ 17
User manual LAM3201 / LAM3205 / LAM3206
Removing the inner door glass
The inner glass panel of the oven door can be
removed for cleaning.
When cleaning, avoid the use any harsh
abrasive chemicals or sharp metal scrapers for as
this could scratch the surface and damage the
glass.
In order to do this:
1. open the door fully.
2. The top plastic cap can be pulled away from
the retaining clips.
3. The inner glass can then be lifted from its
retaining slots.
4. To replace the glass follow this process in
reverse ensuring the printed surface of the
glass is facing downwards.
Ensure the glass is fully located in the lower
retaining slots before attempting to the top
cap.

www.howdens.com
Page _ 18
LAMONA Appliances
Replacing the oven lamp
Hot surfaces may cause burns!
Make sure that the appliance is switched off
and cooled down in order to avoid the risk of an
electrical shock or burns.
The oven lamp is a special electric lamp that
can resist up to 300°C. See Technical
for details.
Position of lamp might vary from the diagram.
1. Disconnect the product from mains.
2. Turn the glass cover counter clock-wise to
remove it.
3. Remove the oven lamp by turning it counter
clockwise and replace it with the new one.
4. Install the glass cover

Exclusive to Howdens Joinery.co Page _ 19
User manual LAM3201 / LAM3205 / LAM3206
Before installation
The product should only be installed by suitably
persons.
The product must be installed in accordance
with all local regulations.
Prior to installation, visually check the product
for any damage/defects. Do not install if any issues
are found.
Damaged products may cause risks to your own
safety.
Installation
The appliance is intended for installation in
Howdens kitchen cabinets.
Surfaces, synthetic laminates and adhesives
used must be heat resistant.
Kitchen cabinets must be set level and
If there is a drawer beneath the oven, a shelf
must be installed between oven and drawer.
The following installation drawings are
representational and may not match exactly
with your appliance.
560mm
560mm
590 mm
(min)
555mm
547mm
555mm
570mm
547mm
20 mm
20 mm
550 mm
min depth
550 mm
min depth
*
*
*
570mm
594mm
595mm
595mm
594mm
590 mm
(min)
Note: Remove carcase rear panel to assist with oven ventilation.
A minimum of 150cm² ventilation gap is required as Illustrated
(35mm x 500mm) cut out positioned centrally.
*
Tower Unit Installation
Built under installation

www.howdens.com
Page _ 20
LAMONA Appliances
Installation and connection
Material damage!
The door and/or handle must not be used for lifting
or moving the appliance.
We recommend 2 people handling of the
product.
Use the handle slots located at both sides of
the oven to move the appliance.
Connection to the mains supply
This appliance must be earthed!
Howdens shall not be held responsible for any
damage caused by using the appliance without an
earthed connection.
Risk of electric shock,
unprofessional installation!
The appliance may be connected to the mains
supply only by an authorized person and
the appliance is only guaranteed after correct
installation.
Risk of electric shock,
damage of the mains lead!
The mains lead must not be clamped, bent, trapped
or come into contact with hot parts of the appliance.
If the mains lead is damaged, it must be replaced
by a person.
The mains supply must correspond to the data
on the rating plate of the appliance.
The rating plate can be seen when the main
oven door is opened.
The appliance mains cable must correspond
to
the and the power consumption;
see Technical page.
Risk of electric shock. Before starting any
work on the electrical installation, please
disconnect the mains supply.
1. This appliance must only be installed by a
electrician, e.g. a local electricity
company or a NICEIC registered contractor,
to a suitable double-pole control unit with
a minimum contact clearance of 3 mm in
all poles. the work should be carried out
in accordance with IEE regulations. Failure
to observe this instruction may result in
operational problems and invalidation of the
appliance Guarantee.
Additional protection by a residual current circuit
breaker is recommended.
2. Open the terminal block cover with
screwdriver.
3. Pass the mains lead through the cable clamp
under the terminal and the mains lead to
main body with supplied screw via cable grip.
4. Connect the cables according to the supplied
diagram.
LN
Terminal Block
Live: Brown
Earth: Green / Yellow
Neutral : Blue
Cable clamp
5. Close the cover of the terminal block once the
wiring is complete. Mains cable must not be
longer than 2 metres for safety reasons.
6. The mains lead should be routed away from
the appliance and not be trapped between the
appliance and the wall.
