Before You Start
Your Shredder Kit is exclusively designed for your Land
Pride 55 and 65 Series Rotary Cutter. Please read these
installation instructions and your Rotary Cutter
Operator’s Manual thoroughly before beginning.
Especially read information relating to safety concerns.
Also included in the Operator’s Manual is important
information on operation, adjustment, troubleshooting,
and maintenance for this attachment (some manual
sections do not apply to all accessories).
A separate Rotary Cutter Parts Manual is available free
of charge at www.landpride.com or can be purchased
from your nearest Land Pride dealer. Have the model
and serial numbers of your cutter handy when placing an
order.
Manual Part Numbers:
•Operator’s Manual. . . . . . . . . . . . . . . . . 318-721M
•Parts Manual . . . . . . . . . . . . . . . . . . . . . 318-721P
General Information
These assembly instructions apply to the Shredder Kit
listed below:
330-094A RC(M)5515 & RC(M)6515 SHREDDER KIT
When you see this symbol, the subsequent
instructions and warnings are serious - follow
without exception. Your life and the lives of
others depend on it!
!
IMPORTANT: Before you begin, read these
instructions and check to be sure all parts and tools
are accounted for. Please retain these installation
instructions for future reference and parts ordering
information.
NOTE: Land Pride recommends safety glasses and
work gloves be worn while working on the Rotary
Cutter.
Further Assistance
Your dealer wants you to be satisfied with your new
ShredderKit.Ifforanyreasonyoudonotunderstandany
part of this manual or are not satisfied with the service
received, the following actions are suggested:
1. Discuss the matter with your dealership service
manager making sure he is aware of any problems
you may have and that he has had the opportunity to
assist you.
2. If you are still not satisfied, seek out the owner or
general manager of the dealership, explain the
problem and request assistance.
3. For further assistance write to:
Land Pride Service Department
1525 East North Street
P.O. Box 5060
Salina, Ks. 67402-5060
E-mail address
lpser[email protected]
Safety Information
!WARNING
Never work under equipment supported by hydraulics.
Hydraulics can drop equipment if controls are actuated or if
hydraulic lines burst. Either situation can drop the cutter
instantly even when power to the hydraulics is shut off.
!DANGER
Always disconnect main driveline from tractor PTO before
servicing the cutter deck. Cutter can be engaged if tractor is
started resulting in damage to the cutter, bodily injury and/or
death.
Shredder Assembly Instructions
Adetailed listingofparts forthisaccessory kitisprovided
on page 4. Use the list as a checklist to inventory parts
received.Please contact your local Land Pridedealer for
any missing hardware.
Refer to Figure 2 on page 2:
1. Remove all three existing blade carrier assemblies
from the gearbox output shafts. Keep flat washers
(D), slotted hex nuts (E) and cotter pins (F) for reuse.
IMPORTANT: Read “Safety Information” above
before installing the shredder blades.
For RC(M)5515 & RC(M)6515 Rotary Cutters
Shredder Kit
8/20/07
Manual No. 330-094M

2Manual No. 330-094M 8/20/07
Land Pride
Shredder Assembly Instructions
■
Left Wing Shredder Assembly
Refer to Figure 3:
1. Attach left wing shredder assembly (#3) to gearbox
output shaft (C) with existing washer (D) and slotted
hex nut (E). Torqued slotted nut to 550 ft-lbs.
2. Install cotter pin (F) in the slotted nut with legs
securely bent around the nut.
CCW Rotation
Right Wing Shredder Blades - 60" Cut
Figure 1
CW Rotation
Left Wing Shredder Blades - 60" cut
Figure 3
CCW Rotation
Center Deck Shredder Blades - 72" Cut
Figure 2
25602
Right Wing Shredder Assembly
Refer to Figure 1:
1. Attach right wing shredder assembly (#1) to gearbox
output shaft (A) with existing washer (D) and slotted
hex nut (E). Torqued slotted nut to 550 ft-lbs.
2. Install cotter pin (F) in the slotted nut with legs
securely bent around the nut.
Center Deck Shredder Assembly
Refer to Figure 2:
1. Attach Center Deck shredder assembly (#2) to
gearboxoutputshaft(B)withexistingwasher(D)and
slotted hex nut (E). Torqued slotted nut to 550 ft-lbs.
2. Install cotter pin (F) in the slotted nut with legs
securely bent around the nut.

3
8/20/07 Manual No. 330-094M
Shredder Assembly Instructions
Land Pride
■
Replacing Blade Spacers
Refer to Figure 4:
The cutting blades should not have more than 3/4" free
vertical movement at the blade tips. If vertical movement
exceeds 3/4", install or change to thicker spacers (#1)
following steps 1-5.
Order spacers (#1) and locknuts (#8) from your nearest
Land Pride Dealer.
IMPORTANT: Read “Safety Information” on page 1
before disassembling the shredder blades.
IMPORTANT: Locknuts can lose their ability to lock
properly once removed. Always use a plain throw
away nut during pre-assembly of spacers.
IMPORTANT: Spacers (#1) are not used if vertical
movement at the blade tip is 3/4" or less without
spacers. However, spacers are required if vertical
movement at the blade tips are greater than 3/4".
1. Check blade deflection. If vertical deflection at the
blade tip is greater than 3/4", remove blade bolt (#4)
and reassemble using a thicker spacer (#1). Select
spacer thickness based on deflection. The greater
the deflection, the thicker the spacer.
2. Assemble blades by inserting 1"-8 x 4 1/2" GR8 hex
head bolt (#4) through blade bushing (#2),
spacer (#1), lower cutting blade (#6, #7 or #8), blade
carrier (#3), upper flat cutting blade (#10 or #9),
spacer (#1) and blade bushings (#2). Temporarily
secure blade with a plain hex nut (Plain hex nut
furnished by customer.) Draw nut up snug. Do not
tighten.
3. Check blade vertical movement. If movement at the
blade tip is greater than 3/4", remove blade bolt and
reassemble as before except use a thicker spacer.
4. Once blade deflection is correct, replace plain nut
with supplied locknut (#5) & torque to 450 ft-lbs.
5. Repeat instructions for “Replacing Blade Spacers”
for the remaining shredder blade assemblies.
Figure 4
(#2) Center Deck & Shredder Assemblies
Counterclockwise Rotation
(#3) Left Wing Shredder Assembly
Clockwise Rotation
Position Beveled
Edges Down
(#1) Right Wing Shredder Assembly
Counterclockwise Rotation
Lower Blade Cutting Edges
Position Beveled Edges Up
Blade
Cutting
Edges
25603

Land Pride
Listing of Parts
Manual No. 330-094M 8/20/07
4
Item Qty. Part No. Part Description
■
Corporate Office: P.O. Box 5060
Salina, Kansas 67402-5060 USA
www.landpride.com
Item Qty. Part No. Part Description
1 330-094M SHREDDER KIT INSTALLATION MANUAL
1 1 330-091S CCW BLADES, SHREDDER 60" . . . . . . . . . . . . . . . . . . . . . . . . . . . (See Figure 1 on page 2)
2 1 330-092S CCW BLADES, SHREDDER 72" . . . . . . . . . . . . . . . . . . . . . . . . . . . (See Figure 2 on page 2)
3 1 330-093S CW BLADES, SHREDDER 60" . . . . . . . . . . . . . . . . . . . . . . . . . . . . (See Figure 3 on page 2)
Refer to Figure 4 on page 3:
(#1) Components for 330-091S CCW Blade Assembly (Left Wing Shredder - 60" cut)
1 4 312-075D BLADE SPACER 16 GA
1 4 312-082D BLADE SPACER 18 GA
1 4 312-089D BLADE SPACER 20 GA.
1 4 312-808D BLADE SPACER 24GA
2 4 318-309D BLADE BUSHING
3 1 330-090H BLADE BAR, SHREDDER 5515
4 2 802-680C HHCS 1-8 X 4 1/2 PLT GR8
5 2 803-168C NUT HEX TOP LOCK 1-8 PLT
7 2 820-169C CUTTER BLADE 1/2X4X23 CCW
10 4 820-217C CUTTER BLADE 1/2X4X22.5 FLAT
Refer to Figure 4 on page 3:
(#2) Components for 330-092S CCW Blade Assembly (Center Deck Shredder - 72" cut)
1 4 312-075D BLADE SPACER 16 GA
1 4 312-082D BLADE SPACER 18 GA
1 4 312-089D BLADE SPACER 20 GA.
1 4 312-808D BLADE SPACER 24GA
2 4 318-309D BLADE BUSHING
3 1 330-090H BLADE BAR, SHREDDER 5515
4 2 802-680C HHCS 1-8 X 4 1/2 PLT GR8
5 2 803-168C NUT HEX TOP LOCK 1-8 PLT
6 2 820-168C CUTTER BLADE 1/2X4X29 CCW
9 2 820-216C CUTTER BLADE 1/2X4X28.5 FLAT
Refer to Figure 4 on page 3:
(#3) Components for 330-093S CW Blade Assembly (Right Wing Shredder - 60" cut)
1 4 312-075D BLADE SPACER 16 GA
1 4 312-082D BLADE SPACER 18 GA
1 4 312-089D BLADE SPACER 20 GA.
1 4 312-808D BLADE SPACER 24GA
2 4 318-309D BLADE BUSHING
3 1 330-090H BLADE BAR, SHREDDER 5515
4 2 802-680C HHCS 1-8 X 4 1/2 PLT GR8
5 2 803-168C NUT HEX TOP LOCK 1-8 PLT
8 2 820-170C CUTTER BLADE 1/2X4X23 CW
10 4 820-217C CUTTER BLADE 1/2X4X22.5 FLAT
Kit No. 330-094A RC(M)5515 & RC(M)6515 SHREDDER ASSEMBLY
A maximum of four spacers
are used per assembly.
A maximum of four spacers
are used per assembly.
A maximum of four spacers
are used per assembly.
