Landa SEA3-1100 User manual

PRESSURE WASHERS
®
OPERATOR’S MANUAL
LANDA, INC. ■ 4275 N.W. Pacific Rim Blvd. ■ Camas, WA 98607 ■ USA
For technical assistance or the Landa Dealer nearest you, call 800-LANDA-4-U (800-526-3248) or [phone]
or consult our web page at www.landa-inc.com
■ SEA3-1100 ■ SEA4-2000 ■ SEA4-3000
SEA
L
I
S
T
E
D
®

CONTENTS
2
SEA Manual •Form #96-6042 •Revised 4/02
Model Number ______________________________
Serial Number ______________________________
Date of Purchase ____________________________
The model and serial numbers will be found on a decal attached to
the pressure washer. You should record both serial number and
date of purchase and keep in a safe place for future reference.
Introduction ...................................................................................................................................3
Important Safety Information .....................................................................................................3, 4
Component Identification ..............................................................................................................4
Pre-Operation Check ....................................................................................................................5
Set-Up Procedures ....................................................................................................................... 5
Operating Instructions ...................................................................................................................5
Shut Down Procedures .................................................................................................................5
How To Use the Detergent Injector ...............................................................................................6
General Washing Techniques........................................................................................................ 7
Maintenance ................................................................................................................................. 7
Time Delay Operation ...................................................................................................................7
Exploded View, Left Side...............................................................................................................8
Exploded View, Right Side ............................................................................................................9
Exploded View Parts List .......................................................................................................10-12
Hose, Spray Gun, Wand & Nozzle .............................................................................................. 13
Troubleshooting ..................................................................................................................... 14-15
Preventative Maintenance........................................................................................................... 16
Oil Change Record ..................................................................................................................... 16
Warranty .....................................................................................................................................17

SEA SERIES PRESSURE WASHER OPERATOR’S MANUAL
3
LANDA SEA •Rev. 4/02
INTRODUCTION
Thank you for purchasing a Landa Pressure Washer.
This manual covers the operation and maintenance of
the SEA3-11021D, SEA4-20021A, SEA4-20021B,
SEA4-20021C, SEA4-20021F, SEA4-20021G,
SEA4-20021H, SEA4-30021B, SEA4-30021C,
SEA4-30021F, and SEA4-30021H washers. All informa-
tion in this manual is based on the latest product infor-
mation available at the time of printing.
Landa, Inc. reserves the right to make changes at any
time without incurring any obligation.
The SEA Series was designed for maximum
use of 8 hours per day, 5 days per week.
Owner/User Responsibility:
The owner and/or user must have an understanding of
the manufacturer’s operating instructions and warnings
before using this Landa pressure washer.Warning infor-
mation should be emphasized and understood. If the op-
erator is not fluent in English, the manufacturer’s instruc-
tions and warnings shall be read to and discussed with
the operator in the operator’s native language by the pur-
chaser/owner, making sure that the operator compre-
hends its contents.
Owner and/or user must study and maintain for future
reference the manufacturers’ instructions.
This manual should be considered a permanent
part of the machine and should remain with it if
machine is resold.
When ordering parts, please specify model and
serial number.
IMPORTANT SAFETY
INFORMATION
CAUTION:To reduce the risk of
injury, read operating instruc-
tions carefully before using.
1. Read the owner's manual thor-
oughly. Failure to follow instruc-
tions could cause malfunction
of the machine and result in
death, serious bodily injury and/
or property damage.
2. Know how to stop the machine and bleed pressure
quickly. Be thoroughly familiar with the controls.
3. Stay alert -- watch what you are doing.
4. All installations must comply with local codes. Con-
tact your electrician, plumber, utility company or the
selling distributor for specific details.
To comply with the National Electrical code (NFPA
70) and provide additional protection from risk of elec-
tric shock, these pressure washers are equipped with
a UL approved ground fault circuit interrupter (GFCI)
power cord.
WARNING: Flammable liquids
can create fumes which can ignite
causing property damage or se-
vere injury.
WARNING: Risk of explosion —
do not spray flammable liquids.
5. Risk of explosion — do not
spray flammable liquids or op-
erate in an explosive location.
WARNING: Keep water spray
away from electrical wiring or fa-
tal electric shock may result.
6. To protect the operator from
electrical shock, the machine
must be electrically grounded.
It is the responsibility of the
owner to connect this machine
to a UL grounded receptacle of
proper voltage and amperage ratings. Do not spray
water on or near electrical components. Do not touch
machine with wet hands or while standing in water.
Always disconnect power before servicing.
7. Grip cleaning wand securely with both hands before
starting. Failure to do this could result in injury from
a whipping wand.
WARNING: High pressure stream
of fluid that this equipment can
produce can pierce skin and its un-
derlying tissues, leading to serious
injury and possible amputation.
8. High pressure developed by
these machines will cause
personal injury or equipment
damage. Use caution when op-
erating. Do not direct discharge stream at people, or
severe injury or death will result.
9. Never make adjustments on machine while in op-
eration.
WARNING: High pressure spray
can cause paint chips or other
particles to become airborne and
fly at high speeds.
10. Eye safety devices and foot
protection must be worn when
using this equipment.
WARNING
RISK OF EXPLOSION:
DO NOT USE WITH
FLAMMABLE
LIQUIDS.
WARNING
USE PROTECTIVE
EYEWEAR
WHEN OPERATING
EQUIPMENT.
WARNING
HIGH PRESSURE
STREAM CAN
PIERCE SKIN AND
TISSUES.
WARNING
KEEP WATER SPRAY
AWAY FRO M
ELECTRICAL WIRING.
WARNING
READ OPERATOR’S
MANUAL
THOROUGHLY
PRIORTO USE.
CAUTION

4 SEA SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA SEA •Rev. 4/02
11. When the machine is working, do not cover or place
in a closed space where ventilation is insufficient.
12. Protect from freezing.
13. Be certain all quick coupler fittings are secured be-
fore using pressure washer.
14. Do not allow acids, caustic or abrasive fluids to pass
through the pump.
15. Inlet water must be no hotter then 90° and clean
fresh water.
16. The best insurance against an accident is precau-
tion and knowledge of the machine.
17. LANDA will not be liable for any changes made to
our standard machines or any components not pur-
chased from LANDA .
18. To reduce the risk of injury, close supervision is nec-
essary when a machine is used near children. Do
not allow children to operate the pressure washer.
This machine must be attended during opera-
tion.
19. Do not operate this machine when fatigued or under
the influence of alcohol or drugs.
20. Keep operating area clear of all persons.
Variable
Pressure
Wand
Spray
Gun
Garden Hose
(not included)
Detergent
Injector
High Pressure
Hose
GFCI
Power
Supply
Variable Pressure
Control Handle
Nozzle
Quick
Coupler
Water
Supply
Detergent
Bucket
(not
included)
Detergent
Pick-Up Tube
Pump Access
Panel
Trigger
Discharge
Nipple
Quick
Coupler
ON/OFF
Switch
Inlet
Connector
High
Pressure
Nozzles
Top
Cover
COMPONENT IDENTIFICATION

SEA SERIES PRESSURE WASHER OPERATOR’S MANUAL
5
LANDA SEA •Rev. 4/02
21. Do not overreach or stand on unstable support.Keep
good footing and balance at all times.
22. Follow the maintenance instructions specified in the
manual.
PRE-OPERATION CHECK
❏Read machine safety warnings
❏Pump oil (SAE 30W non-detergent oil)
❏Cold water supply (6 gpm •5/8" •20 psi)
❏Proper power supply and circuit protection
❏Hose, wand, nozzle (nozzle size per serial plate)
❏Water filter (intact, non restrictive)
❏Read operating instructions
SET-UP PROCEDURES
These machines are designed for indoor use.
Machine must be stored indoors when not in use.
1. Attach a 5/8" garden hose to inlet connector. Mini-
mum flow should be 5 gpm.
2. Attach high pressure hose to discharge nipple using
quick coupler.Lock coupler securely into place by pull-
ing back coupler collar and inserting it onto discharge
nipple, then pushing collar forward to lock in place.
3. Attach wand to spray gun using teflon tape on
threads to prevent leakage.
4. Attach swivel connector on discharge hose to spray
gun using teflon tape on threads.
5. Remove top cover and check oil level on sight glass
on side of pressure washer pump. Oil should be vis-
ible half way up sight glass (30W non-detergent).
6. For operator safety and to comply with electrical stan-
dards, the SEA3-11021D comes with a 120V 20 amp
plug end that will fit only into a 20 amp receptacle.
7. On 230V, 460V and 575V machines, attach appro-
priate plug end (not included) to power cord.
OPERATING INSTRUCTIONS
1. Read safety, installation and pre-
ventative maintenance instruc-
tions before starting machine.
2. With power switch in OFF
position, plug power cord into
a grounded type of receptacle
of proper voltage and amper-
age reading. Then push GFCI
reset button at end of power
cord if required (SEA3-11021D,
SEA4-20021A).
3. Turn on water at faucet and pull trigger on spray gun
allowing water to flow until all air has discharged
from system. Check for water leaks; tighten as
needed.
4. Pull wand coupler collar back and insert pressure
nozzle into coupler then secure by pushing collar
forward.
5. Place rocker switch in the ON position and then pull
trigger on spray gun to activate pressure switch which
will then start machine. The OFF position is for
manual shut down.
6. Turn the variable pressure control handle clockwise
to increase pressure.
7. To stop machine, release spray gun trigger. Machine
will automatically stop.
8. If machine is going to be unattended for long peri-
ods of time, turn water supply off and place rocker
switch in OFF position. Trigger spray gun to relieve
trapped pressure.
9. Protect from freezing.
SHUT DOWN PROCEDURES
1. Rinse with clean water to remove any soap residue,
by placing detergent hose into fresh water bucket
and operating injector as described on page 6.
2. Release the trigger on the spray gun which will acti-
vate a timer to shut the machine off.Turn the switch
off if the machine is going to be left unattended.
3. Turn off water supply.
4. Turn rocker switch off.
5. Open spray gun to relieve remaining pressure.
6. Remove water supply hose.
7. In freezing conditions, disconnect water supply and
open spray gun to allow water to drain, then turn off
motor. Place machine in a heated storage area.
CAUTION: Do not allow pump to run longer than one
(1) minute without water. Disconnect all hoses to al-
low water to drain.
WARNING
READ SAFETY,
INSTALLATION, &
PREVENTATIVE
MAINTENANCE
INSTRUCTIONS.

6 SEA SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA SEA •Rev. 4/02
HOW TO USE THE
DETERGENT INJECTOR
WARNING: Some detergents may
be harmful if inhaled or ingested
causing severe nausea, fainting
or poisoning. The harmful ele-
ments may cause property dam-
age or severe injury.
This machine can siphon and mix
detergents with the use of Landa's
detergent injector kit.
1. Pull injector quick coupler collar back and secure on
discharge nipple by pushing collar forward. Injector
valve body arrow should point in direction of flow.
2. Connect high pressure hose to injector nipple se-
curing quick coupler.
3. Start machine as outlined in Operating Instructions.
4. Place detergent pick-up tube into container of deter-
gent solution.
5. Turn variable pressure control handle counterclock-
wise to lower pressure and divert water flow through
the soap nozzle.
6. Pull trigger on spray gun. Water detergent ratio is
approximately 15 to 1.
7. When you finish washing, rinse by simply turning vari-
able pressure control handle clockwise.
NOTE: The detergent injector will not siphon with wa-
ter flowing through the high pressure nozzle at end
of wand.
8. For clean up, place detergent pick-up tube into con-
tainer of clear water and follow steps 5 - 8 to prevent
detergent deposits from damaging the injector.
WARNING
SOME DETERGENTS
MAY BE HARMFUL IF
INHALED OR
INGESTED
Detergent
Injector
Detergent
Pick-up
Tube
Pump
Access
Panel High Pressure
Nozzles
Quick Coupler
High Pressure
Hose
(Bucket not
Included)

SEA SERIES PRESSURE WASHER OPERATOR’S MANUAL
7
LANDA SEA •Rev. 4/02
GENERAL
WASHING TECHNIQUES
1. Hold spray nozzle approximately one foot from the
surface being cleaned. Spray at an angle to get un-
der the material and lift it off.
2. When washing large objects, use detergent injector
to apply detergent (see section “How to Use the De-
tergent Injector”).Start washing from the bottom and
work up. Better detergent economy and faster re-
sults will be obtained by allowing the detergent to
set 5-10 minutes. After washing, rinse from the top
down.
3. Cleaning heavy dirt or material away with a hard
stream of clear water is recommended before using
a cleaning agent.
MAINTENANCE
Pump Lubrication
LANDA PUMPS: The pump on your Landa Pressure
Washer is a triplex ceramic plunger pump. As the plung-
ers move back, water flows through the inlet valve into
the manifold chamber. Then, when the plungers move
forward, the inlet valves close and the discharge valves
open to produce discharge pressure.
Use only Landa SAE 30 weight non-detergent oil; change
oil after first 50 hours of use. Thereafter, change oil at
three months or 500 hour intervals. Oil level should be
checked through the use of the dipstick found on top of
the pump, or half way up on the oil gauge window. Oil
should be maintained at that level.
Unloader Valves
The unloader valve is connected directly to the discharge
port of the pump. Its purpose is to allow recirculation
back into the pump inlet when the trigger on the spray
gun is closed.
Nozzles
Each machine is equipped with one spray nozzle de-
pending on the flow and pressure of that particular model.
Spray nozzles vary in bore size and angle of spray. When
ordering replacement nozzles, please specify size and
angle of nozzle. Nozzle size for each machine is located
on the serial plate.
Winterizing Procedure
Damage due to freezing is not covered by warranty. Use
the following cold weather procedures whenever the
washer must be stored or operated outdoors under freez-
ing conditions.
During winter months, when the temperature drops be-
low 32°F, it is necessary to protect your machine against
freezing. A blowout valve, which can be screwed into
the garden hose swivel connecter to blow water out of
the system, is available from Landa. When compressed
air is not available or is impractical, siphon a 50/50 mix-
ture of anti-freeze into the pump by using a bucket with
a short section of garden hose attached to the bottom,
then elevate. Run the pump dry for a few seconds and
disconnect all hoses to allow water to drain.
Low Pressure Diagnosis
Refer to Troubleshooting Chart for low pressure. If, by
referring to the chart, the trouble is found to be either the
unloader or the pump, your next step is to determine
whether in fact the unloader or the pump is the problem.
This can be done by eliminating the unloader from the
system and attaching the discharge hose directly to the
pump. If high pressure is developed in this manner the
pump is good and the unloader needs to be repaired or
replaced. If low pressure is developed in this manner,
the pump is good, and the unloader needs to be repaired
or replaced. If low pressure is still present, the pump
needs repairing.
CAUTION: When using this procedure to test com-
ponents, keep the spray gun trigger open at all times.
TIME DELAY SHUTDOWN
OPERATION
Once the spray gun trigger is released, the shutdown timer
becomes activated. The machine will continue to run in
by-pass mode until the timer reaches its preset time, 1-10
minutes. When that time is reached, the machine shuts
down. To reset, push the pump switch forward.

8 SEA SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA SEA •Rev. 4/02
EXPLODED VIEW
LEFT SIDE •ALL MODELS
2
32
34
27
4
5
3
6, 7
39
41
31
10
11
12
60
25
24
30
8
15
14
65
13
37
1
23
19
40
38
26
20
9
17
22
18
21
16
28
29
35
36

SEA SERIES PRESSURE WASHER OPERATOR’S MANUAL
9
LANDA SEA •Rev. 4/02
60
59
49
73
74
75
76
49
49
47
50
52
53
51
55
64
69
70
71
44
42
43
46
72
33
54
45
48
57
56
68
65
63
62
58
61
66
67
EXPLODED VIEW
RIGHT SIDE •ALL MODELS
14
78
77
12

10 SEA SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA SEA •Rev. 4/02
ITEM PART NO. DESCRIPTION QTY
1 6-4013 Contactor, 120V, CH
CE15FNS3AB (3-1100) 1
6-4018 Contactor, 120V, CH
CE15HNS3AB-09 (4-2000A,G) 1
6-4007 Contactor, 120V, CH
CE15DNS3AB (4-2000B,A) 1
6-4000 Contactor, 120V, CH
CE15BNS3AB (4-2000C,F) 1
6-4010 Contactor, 120V, CH
CE15ENS3AB (4-3000B,H) 1
6-4004 Contactor, 120V, CH
CE15CNS3AB (4-3000C,F) 1
6-5009 ▲ Overload, 7.50-11.00 amp,
CH C316FNA3P (4-2000C,F) 1
6-5010 Overload, 10.00-14.00 amp,
CH C316FNA3Q (4-3000C,F,H) 1
6-5013 Overload, 24.00-32.00 amp,
CH C316FNAJT (4-3000B,H) 1
6-60101 ▲ Transformer, Micron, 240/480,
220/440-120/115/110, .050KVA
(4-2000A,B,C, 4-3000C) 1
6-6013 Transformer, Micron 230/460/575-
95/115, .050KVA
(4-2000F, 4-3000F) 1
6-6014 Transformer, Micron, 208/277-120
.050KVA (4-2000G,H, 4-3000H) 1
6-02294 ▲ Fuse, ATMR 1 amp, 240V 2
6-02295 Fuse, ATMR 1/2 amp, 480V 2
6-02297 Fuse, GDC 1/2 amp, 120V 1
2 6-03700 Timer, Multi-Function,
24V-120/240V 1
3 6-03621 Relay, 120V, RH2B-UL-AC120 1
4 6-03541 Base, Relay, SH2B-05, 1DEC 1
5 6-021595 Rail Track /inch 6
6 90-19996 Screw, 10/32" x 1/2" BH SOC,
SS 2
7 90-020 Nut, 10/32" NF ST STKEP 7
8 6-03907 Box, Plastic 8" x 8" x 4" (3-1100)1
6-03909 Box, Plastic 10" x 8" x 6" w/Lid
(4-2000, 4-3000) 1
9 95-07603907 Bracket, Support for Elec. Box 1
10 6-05152 Strain Relief, STRT, Small 1
11 6-051595 Strain Relief, STRT, Large 2
EXPLODED VIEW PARTS LIST
ALL MODELS
ITEM PART NO. DESCRIPTION QTY
12 6-0105 Cord, Service, SEO, 12/4
(4-2000C,F,N) /ft. 13
6-01059 GFCI, 240V 30A, w/36' 10-3 Cord
(4-2000A,G) 1
6-01060 GFCI, 120V 20A, w/36' 12-3 Cord
(3-1100) 1
6-0109 Cord, Service, SEO, 10/4
(4-2000B,H, 4-3000B,C,F,H,N )
/ft. 13
6-010631 Cord, Service, 240V 1PH
36' GFCI (3-1100K, 4-2000K) 1
13 5-10402 Motor, 6HP 1PH 200V 1800RPM
(4-2000G) 1
5-10401 Motor, 6HP 1PH 230V
1725 RPM (4-2000A) 1
5-10111 Motor, 6HP 3PH 200V 1800RPM
(4-2000H) 1
5-10144 Motor, 7.5HP 3PH 200V,
M3311T-8 (4-3000H) 1
5-1011 Motor, 6HP 3PH 1725RPM
(4-2000B,C) 1
5-10145 Motor, 7.5HP 3PH 1725RPM
M3311T (4-3000B,C) 1
5-10146 Motor, 7.5HP 3PH M3311T
(4-3000F) 1
5-1027 Motor, 5HP 3PH 1725RPM
M3218T-5 (4-2000F) 1
5-1047 Motor, 2HP 1PH (3-1100) 1
14 90-20063 Nut, 3/8" Whiz Loc SS 10
15 90-40021 Washer, 3/8", SAE, SS 10
16 6-021730 Switch, Flow MV60 1
17 2-00270 Elbow, 3/8", Male, Pipe 1
18 5-3207 Unloader, AL606, 7.8 GPM @
3650PSI 1
19 2-11050 Swivel, 3/4" SAE Fem, Push-on 1
20 4-02120000 Hose, 3/4" Push-on, per/ft. 1.66
21 2-10622 Elbow, 3/4" JIC x 1/2", 90°1
22 2-0079 Swivel, 1/2" JIC Fem, 3/8" Male 1
23 2-0053 Elbow, 1/2" JIC, 3/8", 90°2
24 2-0031 Elbow, 3/8", Street 1
25 2-1032 Tee, 1/2" Female, Pipe 1
26 2-1006 Nipple, 1/2" Close 1
27 2-11080 Push-on, 3/4" x 1/2" Male 1
28 2-0053 Nipple, 1/2" JIC, 3/8" Pipe 1
