Landa SEA Series User manual

8.913-999.0 - AK 12/16/20
SEA
Cold Water - Electric Powered
Operator Manual Pressure Washer
MODELS:
SEA3-11024D 1.106-500.0
SEA4-20024A 1.106-501.0
SEA4-20024B 1.106-502.0
SEA4-20024C 1.106-503.0
SEA4-20024G 1.106-505.0
SEA4-20024H 1.106-506.0
SEA4-30024B 1.106-507.0
SEA4-30024C 1.106-508.0
For the Landa Dealer nearest
you, consult our web page at
www.landa.com

2Landa SEA Operator Manual 8.913-999.0 - AK
Machine Data Label

3
Table of Contents
Machine Data Label . . . . . . . . . . . . . . . . . . . . . . . . . .2
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . .3
How To Use This Manual . . . . . . . . . . . . . . . . . . . . .4
Safety
Introduction & Safety Information . . . . . . . . . . . . . . .5
Important Safety Information. . . . . . . . . . . . . . . . . . .6
Operations
Component Identification . . . . . . . . . . . . . . . . . . . . .8
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . .9
Operating Instructions. . . . . . . . . . . . . . . . . . . . . . .10
Detergent and General Operating Techniques . . . .11
Thermal Pump Protection . . . . . . . . . . . . . . . . . . . . 11
Cleaning Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Rinsing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Shutting Down And Clean-Up . . . . . . . . . . . . . . . . . 12
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Maintenance
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Preventative Maintenance . . . . . . . . . . . . . . . . . . .16
Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . 16
Oil Change Record . . . . . . . . . . . . . . . . . . . . . . . . . 17
Parts
Landa SEA - Left. . . . . . . . . . . . . . . . . . . . . . . . . . 20
Landa SEA - Right . . . . . . . . . . . . . . . . . . . . . . . . 21
Float Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Handheld Wireless - 1 Step . . . . . . . . . . . . . . . . . 28
Handheld Wireless - 2 Step . . . . . . . . . . . . . . . . . 30
Handheld Wireless Operating Instructions . . . . . . . 32
Transmitter/Receiver Communication Set-up at
Factory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Hose And Spray Gun . . . . . . . . . . . . . . . . . . . . . . 34
Pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
LB Series Pump . . . . . . . . . . . . . . . . . . . . . . . . . . 38
LT.2 Series Pump . . . . . . . . . . . . . . . . . . . . . . . . . 40
VRT3 Unloader . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
VB8 Unloader Valve . . . . . . . . . . . . . . . . . . . . . . . 44
Landa SEA Operator Manual 8.913-999.0 - AK

4
How To Use This Manual
This manual contains the following sections:
• How to Use This Manual
•Safety
• Operations
• Maintenance
• Parts List
The HOW TO USE THIS MANUAL section will tell you
how to find important information for ordering correct
repair parts.
Parts may be ordered from authorized dealers. When
placing an order for parts, the machine model and
machine serial number are important. Refer to the
MACHINE DATA box which is filled out during the
installation of your machine. The MACHINE DATA box
is located on the inside of the front cover of this manual.
The model and serial number of your machine is
located on the back of the machine.
The SAFETY section contains important information
regarding hazardous or unsafe practices of the
machine. Levels of hazards are identified that could
result in product damage, personal injury, or severe
injury resulting in death.
The OPERATIONS section is to familiarize the operator
with the operation and function of the machine.
The MAINTENANCE section contains preventive main-
tenance to keep the machine and its components in
good working condition. They are listed in this general
order:
• Troubleshooting
• Preventative Maintenance
The PARTS LIST section contains assembled parts
illustrations and corresponding parts list. The parts lists
include a number of columns of information:
•REF – column refers to the reference number
on the parts illustration.
•PART NO. – column lists the part number for
the part.
•QTY – column lists the quantity of the part used
in that area of the machine.
•DESCRIPTION – column is a brief description
of the part.
•NOTES – column for information not noted by
the other columns.
NOTE: If a service or option kit is installed on your
machine, be sure to keep the KIT INSTRUCTIONS
which came with the kit. It contains replacement parts
numbers needed for ordering future parts.
NOTE: The manual part number is located on the
lower right corner of the front cover.
Model:
Date of Purchase:
Serial Number:
Dealer:
Address:
Phone Number:
Sales Representative:
Landa SEA Operator Manual 8.913-999.0 - AK

5
Safety
Introduction & Safety Information
Thank you for purchasing this Pressure Washer.
We reserve the right to make changes at any time
without incurring any obligation.
Owner/User Responsibility:
The owner and/or user must have an understanding of
the manufacturer’s operating instructions and warnings
before using this pressure washer. Warning information
should be emphasized and understood. If the operator
is not fluent in English, the manufacturer’s instructions
and warnings shall be read to and discussed with the
operator in the operator’s native language by the
purchaser/owner, making sure that the operator
comprehends its contents.
Owner and/or user must study and maintain for future
reference the manufacturers’ instructions.
The operator must know how to stop the machine
quickly and understand the operation of all controls.
Never permit anyone to operate the engine without
proper instructions.
SAVE THESE INSTRUCTIONS
This manual should be considered a permanent
part of the machine and should remain with it if
machine is resold.
When ordering parts, please specify model and
serial number. Use only identical replacement
parts.
This machine is to be used only by trained opera-
tors.
Landa SEA Operator Manual 8.913-999.0 - AK

6
Safety
Important Safety Information
WARNING: To reduce the risk of
injury, read operating instructions
carefully before using.
AVERTISSEMENT: Pour réduire le
risque de blessures, lire
attentivement les instructions de
fonctionnement avant l'utilisation.
1. Read the owner's manual thor-
oughly. Failure to follow instruc-
tions could cause malfunction of the machine and
result in death, serious bodily injury and/or property
damage.
2. Know how to stop the machine and bleed pressure
quickly. Be thoroughly familiar with the controls.
3. Stay alert — watch what you are doing.
4. All installations must comply with local codes.
Contact your electrician, plumber, utility company
or the selling dealer for specific details. If your
machine is rated 250 volts or less, single phase a
ground fault circuit interrupter (GFCI) will be
provided. If rated more than 250 volts, or more
than single phase this product should only be
connected to a power supply protected by a GFCI.
DANGER: Improper connection of
the equipment-grounding
conductor can result in a risk of
electrocution. Check with a
qualified electrician or service
personnel if you are in doubt as to
whether the outlet is properly
grounded. Do not modify the plug
provided with the product - if it
will not fit the outlet, have a
proper outlet installed by a qualified electrician. Do
not use any type of adapter with this product.
DANGER: Une mauvaise connexion du conducteur
de terre de l'équipement peut entraîner un risque
d'électrocution. Vérifier auprès d'un électricien
qualifié ou du personnel d'entretien si vous avez
des doutes quant à savoir si la sortie est
correctement mise à la masse. NE PAS modifier la
fiche fournie avec le produit - si elle n'entre pas
dans la sortie, faire installer une sortie appropriée
par un électricien qualifié. NE JAMAIS utiliser un
adaptateur avec ce produit.
DANGER: Keep wand, hose, and water spray away
from electric wiring or fatal electric shock may
result.
DANGER: Garder la lance, le boyau et le jet d'eau à
l'écart de tout câblage électrique ou des chocs
électriques mortels pourraient survenir.
5. To protect the operator from electrical shock, the
machine must be electrically grounded.It is the
responsibility of the owner to connect this machine
to a UL grounded receptacle of proper voltage and
amperage ratings. Do not spray water on or near
electrical components. Do not touch machine with
wet hands or while standing in water. Always
disconnect power before servicing.
WARNING: Flammable liquids
can create fumes which can
ignite, causing property damage
or severe injury.
AVERTISSEMENT: Des liquides
inflammables peuvent produire
des vapeurs qui peuvent
s'enflammer, causant ainsi des
dommages à la propriété ou des
blessures graves.
WARNING: Risk of explosion — Do not spray
flammable liquids.
AVERTISSEMENT: Risque d'explosion — Utiliser
uniquement dans des endroits où l'utilisation d'une
flamme nue ou d'une torche est permise.
6. Do not allow acids, caustic or abrasive fluids to
pass through the pump.
7. Never run pump dry or leave spray gun closed
longer than 1-2 minutes.
8. Keep operating area clear of all persons.
WARNING: High pressure spray
can cause paint chips or other
particles to become airborne and
fly at high speeds. To avoid
personal injury, eye, hand and
foot safety devices must be worn.
AVERTISSEMENT: Un jet haute
pression peut écailler la peinture
ou provoquer l'émission d'autres
particules dans l'air et leur projection à hautes
vitesses. Pour éviter les lésions corporelles, une
protection des yeux, du visage, des mains et des
pieds doit être portée lors de l'utilisation de cet
équipement.
Landa SEA Operator Manual 8.913-999.0 - AK
WARNING
READ OPERATOR’S
MANUAL THOROUGHLY
PRIOR TO USE.
OPERATIONS
SAFETY
MAINTENANCE
DANGER
KEEP WATER
SPRAY AWAY FROM
ELECTRICAL WIRING.
WARNING
RISK OF EXPLOSION:
DO NOT SPRAY
FLAMMABLE
LIQUIDS.
WARNING
USE PROTECTIVE
EYE WEAR
AND CLOTHING
WHEN OPERATING
THIS EQUIPMENT.

7
Safety
9. Always wear properly rated eye protection such as
safety goggles or face shield while spraying.
(Safety glasses do not provide full protection.)
WARNING: Grip cleaning wand
securely with both hands before
starting. Failure to do this could
result in injury from a whipping
wand.
AVERTISSEMENT: Agripper la
lance de nettoyage avec les deux
mains avant de commencer. Le
non-respect de cette consigne
pourrait mener à des blessures causées par le
mouvement violent de la lance.
WARNING: High pressure
developed by these machines will
cause personal injury or
equipment damage. Keep clear of
nozzle. Use caution when oper-
ating. Do not direct discharge
stream at people and animals, or
severe injury or death will result.
AVERTISSEMENT: La haute
pression générée par ces machines causera des
lésions corporelles ou des dommages à
l'équipement. Se tenir à l'écart de la buse. Faire
preuve de prudence lors de l'utilisation. Ne pas
décharger directement le jet vers des personnes
ou des animaux, car cela risquerait de causer des
blessures graves ou même la mort.
10. To reduce the risk of injury, close supervision is
necessary when a machine is used near children.
Do not allow children to operate the pressure
washer. This machine must be attended during
operation.
11. Never make adjustments on machine while in
operation.
12. Be certain all quick coupler fittings are secured
before using pressure washer.
WARNING: Protect machine from
freezing.
AVERTISSEMENT: Protéger la
machine contre le gel.
13. To keep machine in best
operating conditions, it is
important you protect machine
from freezing. Failure to protect
machine from freezing could
cause malfunction of the machine and result in
death, serious bodily injury, and/or property
damage. Follow storage instructions specified in
this manual.
14. Inlet water must be clean fresh water and no hotter
then 185°F.
WARNING: If connection is made
to potable water system, the
system shall be protected against
backflow.
AVERTISSEMENT: Si une
connexion est établie avec un
réseau d'eau potable, le réseau
doit être protégé contre le retour
d'eau.
15. Manufacturer will not be liable for any changes
made to our standard machines or any compo-
nents not purchased from us.
16. The best insurance against an accident is precau-
tion and knowledge of the machine.
WARNING: Be extremely careful
when using a ladder, scaffolding
or any other relatively unstable
location. The cleaning area
should have adequate slopes and
drainage to reduce the possibility
of a fall due to slippery surfaces.
AVERTISSEMENT: Faire preuve
d'une extrême prudence au
moment d'utiliser une échelle, des échafaudages
ou toute autre surface relativement instable. La
zone de nettoyage doit avoir une pente et un
drainage adéquats pour réduire la possibilité d'une
chute due à une surface glissante.
17. Do not overreach or stand on unstable support.
Keep good footing and balance at all times.
18. Do not operate this machine when fatigued or
under the influence of alcohol, prescription medica-
tions, or drugs.
WARNING: Do not spray machine
or any people, animals or elec-
trical parts.
AVERTISSEMENT: Ne pas
vaporiser sur la machine ou les
gens, les animaux ou les pièces
électriques.
Follow the maintenance instructions
specified in the manual.
Landa SEA Operator Manual 8.913-999.0 - AK
WARNING
PROCTECT FROM
FREEZING
WARNING
RISK OF INJURY
FROM FALLS WHEN
USING LADDER.
WARNING
DO NOT SPRAY
MACHINE OR ANY
PEOPLE, ANIMALS OR
ELECTRICAL PARTS.
WARNING
RISK OF INJECTION
OR SEVERE INJURY
TO PERSONS. KEEP
CLEAR OF NOZZLE.
WARNING
TRIGGER GUN KICKS
BACK — HOLD WITH
BOTH HANDS
WARNING
IF CONNECTED
TO A POTABLE
WATER SUPPLY,
PROTECT AGAINST
BACKFLOW.

8
Operations
Component Identification
Detergent Injector - Allows you to siphon and mix
detergents.
High Pressure Hose — Connect one end to water
pump discharge nipple and the other end to spray gun.
Spray Gun — Controls the application of water and
detergent onto cleaning surface with trigger device.
Includes safety latch.
Variable Pressure Handle — Turn counter clockwise
to siphon detergent when detergent injector is attached
or lower pressure.
Wand — Must be connected to the spray gun.
GFCI — Designed to prevent electrical shock. Has test
and reset button. Reset button must be pushed in for
operation.
NOTE: If trigger on spray gun is released for more
than 2 minutes, water will leak from valve. Warm
water will discharge from pump protector onto floor.
This system prevents internal pump damage.
Landa SEA Operator Manual 8.913-999.0 - AK
89139990-8
Variable
Pressure
Wand
Spray
Gun
Garden Hose
(not included)
Detergent
Injector
High Pressure
Hose
GFCI
Power
Supply
Variable Pressure
Control Handle
Nozzle
Quick
Coupler
Water Supply
(Not Included)
Detergent
Bucket
(not
included)
Detergent
Pick-Up Tube
Pump Access
Panel
Trigger
Discharge
Nipple
Quick
Coupler
ON/OFF
Switch
Inlet
Connector
High
Pressure
Nozzles
Top
Cover

9
Operations
Assembly Instructions
STEP 1: Attach the high pressure
hose to the spray gun using teflon
tape on hose threads.
STEP 2: Before installing nozzle,
turn on water supply and run
machine allowing water to flush
through the system until clear.
STEP 3: Connect garden hose to
the cold water source.
STEP 5: Insert nozzle into coupler.
Release the coupler collar and
push the nozzle until the collar
clicks. Pull the nozzle to make sure
it is seated properly.
Landa SEA Operator Manual 8.913-999.0 - AK
Safety
Latch
High Pressure
Hose
Spray
Gun
Outlet Fitting
Coupler Collar
Nozzle
Coupler
STEP 4: Connect the high pressure hose to the outlet
discharge fitting. Push coupler collar forward until
secure. Connect the garden hose to pump water inlet.
Inspect inlets. CAUTION: Do not run the pump
without water or pump damage will result.
ATTENTION: Ne pas faire fonctionner la pompe
sans eau pour éviter d'endommager la pompe.

10
Operations
Operating Instructions
STEP 1: Connect garden hose to
the cold water source and turn
water on completely. Never use hot
water.
STEP 4: Turn machine on by
flipping switch at front of machine.
WARNING! Never replace
nozzles without engaging
the safety latch on the spray gun
trigger.
AVERTISSEMENT: Ne jamais
remplacer les buses sans
d'abord mettre le dispositif de
sécurité sur la détente du
pistolet pulvérisateur.
STEP 2: Trigger the spray gun to
eliminate trapped air then wait for a
steady flow of water to emerge
from the spray wand. Then install
nozzle.
STEP 3: Connect to appropriate
power supply. Push reset button.
Safety
Latch
Landa SEA Operator Manual 8.913-999.0 - AK
Cold
Water
Source
Garden
Hose
NOZZLES
The five color-coded quick connect nozzles provide a wide array of spray
widths from 0° to 40° and are easily accessible when placed in the conve-
nient rubber nozzle holder, which is provided on the front of the machine.
NOTE: For a more gentle rinse, select the white 40° or green 25° nozzle.
To scour the surface, select the yellow 15° or red 0° nozzle. To apply
detergent select the black nozzle.
Variable Pressure
Control Handle Trigger
Variable Pressure
Wand (VP)
High
Pressure
Nozzle
Brass Soap
Nozzle
Selection of high or low pressure is accompanied by turning the handle.
NOTE: High pressure nozzle must be inserted at end of wand to obtain
high pressure. To apply soap read operator’s manual.

11
Operations
Detergent and General Operating Techniques
WARNING: Some detergents may be harmful if inhaled
or ingested, causing severe nausea,
fainting or poisoning. The harmful
elements may cause property
damage or severe injury.
AVERTISSEMENT: Certains
détergents peuvent être dangereux
s'ils sont inhalés ou ingérés,
provoquant de fortes nausées, des
évanouissements et
l'empoisonnement. Les éléments
dangereux peuvent causer des
dommages à la propriété ou des
blessures graves.
STEP 1: Use detergent designed
specifically for pressure washers.
Household detergents could damage the pump. Prepare
detergent solution as required by the manufacturer. Fill a
container with pressure washer detergent. Place the filter
end of detergent suction tube into the detergent container.
STEP 2: Apply safety latch to spray gun trigger. Secure
black detergent nozzle into quick coupler.
NOTE: Detergent cannot be applied using the Yellow
nozzle.
STEP 3: With engine running, pull trigger to operate
machine. Liquid detergent is drawn into the machine and
mixed with water. Apply detergent to work area. Do not
allow detergent to dry on surface.
IMPORTANT: You must flush the detergent injection
system after each use by placing the suction tube into
a bucket of clean water, then run the pressure washer
in low pressure for 1-2 minutes.
Thermal Pump Protection
If you run the engine on your pressure washer for 2-3
minutes without pressing the trigger on the spray gun,
circulating water in the pump can reach high tempera-
tures. When the water reaches this temperature, the pump
protector engages and cools the pump by discharging the
warm water onto the ground. This thermal device prevents
internal damage to the pump.
Cleaning Tips
Pre-rinse cleaning surface with fresh water. Place
detergent suction tube directly into cleaning solution and
apply to surface at low pressure (for best results, limit your
work area to sections approximately 6 feet square and
always apply detergent from bottom to top). Allow
detergent to remain on surface 1-3 minutes. Do not allow
detergent to dry on surface. If surface appears to be
drying, simply wet down surface with fresh water. If
needed, use brush to remove stubborn dirt. Rinse at high
pressure from top to bottom in an even sweeping motion
keeping the spray nozzle approximately 1 foot from
cleaning surface. Use overlapping strokes as you clean
and rinse any surface. For best surface cleaning action
spray at a slight angle.
Recommendations:
• Before cleaning any surface, an inconspicuous
area should be cleaned to test spray pattern and
distance for maximum cleaning results.
• If painted surfaces are peeling or chipping, use
extreme caution as pressure washer may remove
the loose paint from the surface.
• Keep the spray nozzle a safe distance from the
surface you plan to clean. High pressure wash a
small area, then check the surface for damage. If
no damage is found, continue to pressure
washing.
CAUTION - Never use:
• Bleach, chlorine products and other corrosive
chemicals
• Liquids containing solvents (i.e., paint thinner,
gasoline, oils)
• Tri-sodium phosphate products
• Ammonia products or Acid-based products
ATTENTION: Ne jamais utiliser:
• Eau de Javel, produits à base de chlore et
autres produits chimiques corrosifs
• Liquides contenant des solvants (c.-à-d. diluant
à peinture, essence, huiles, etc.)
• Produits à base de tripolyphosphate de sodium
• Ammoniac ou produits à base d'acide
These chemicals will harm the machine and will damage
the surface being cleaned.
Rinsing
It will take a few seconds for the detergent to clear. Apply
safety latch to spray gun. Remove black soap nozzle from
the quick coupler. Select and install the desired high
pressure nozzle.
NOTE: You can also stop detergent from flowing by
simply removing detergent siphon tube from bottle.
Landa SEA Operator Manual 8.913-999.0 - AK
WARNING

12
Operations
Shutting Down And
Clean-Up
STEP 1: Remove
detergent suction tube
from container and insert
into one gallon of fresh
water. Slide nozzle
forward for low pressure
or to connect black
detergent nozzle. Pull
trigger on spray gun and
siphon water for one
minute.
STEP 2: Turn off
machine by flipping
switch on front of motor.
STEP 3: Turn off water
supply.
STEP 4: Press trigger to
release water pressure.
Landa SEA Operator Manual 8.913-999.0 - AK
Pump
Water
Inlet
Safety
Latch
High Pressure
Outlet
STEP 5: Disconnect the garden
hose from the water inlet on the
machine.
STEP 6: Disconnect the high
pressure hose from high pressure
outlet.
STEP 7: Engage the spray gun
safety lock.

13
Operations
Storage
Pump Storage
CAUTION: Always store your
pressure washer in a location where
the temperature will not fall below
32° F (0° C). The pump in this
machine is susceptible to
permanent damage if frozen.
ATTENTION:Toujours entreposer la laveuse à
pression dans un endroit où la température ne sera
pas inférieure à 32° F (0° C). La pompe sur cette
machine est susceptible de subir des dommages si
elle est exposée au gel.
FREEZE DAMAGE IS NOT
COVERED BY WARRANTY.
If you must store your pressure washer in a location
where the temperature is below 32° F, you can
minimize the chance of damage to your machine by
draining your machine as follows:
1. Stop the pressure washer and detach supply hose
and high pressure hose. Squeeze the trigger of the
spray gun to drain all water from the wand and
hose.
2. Restart pressure washer and let it run briefly (about
5 seconds) until water no longer discharges from
the high pressure outlet.
Landa SEA Operator Manual 8.913-999.0 - AK
CAUTION

14
Maintenance
Troubleshooting
PROBLEM POSSIBLE CAUSE SOLUTION
PUMP
RUNNING
NORMALLY
BUT PRESSURE
LOW ON
INSTALLATION
Pump sucking air Check water supply and possibility
of air seepage.
Check valves sticking Check and clean or replace if necessary.
Unloader valve seat faulty Check and replace if necessary.
Faulty or misadjusted unloader valve
Tampering with the factory setting may
cause personal injury and/or property damage,
and will void the manufacturer's warranty.
Nozzle incorrectly sized Check and replace if necessary.
Worn piston packing Check and replace if necessary.
FLUCTUATING
PRESSURE
Valves worn Check and replace if necessary.
Blockage in valve Check and clean out if necessary.
Pump sucking air Check water supply connections.
Worn piston packing Check and replace if necessary.
Insufficient water Check filter and hose for breakage.
PRESSURE
LOW AFTER
PERIOD OF
NORMAL USE
Nozzle worn Check and replace if necessary.
Suction or delivery valves worn Check and replace if necessary.
Suction or delivery valves blocked Check and clean if necessary.
Unloader valve seat worn Check and replace if necessary.
Unloader adjusted improperly Call local Landa dealer.
Worn piston packing Check and replace if necessary.
Bypass valve within unloader is
obstructed or leaking Remove and clean bypass cartridge.
PUMP
NOISY
Air in suction line Check water supply and connections
on suction line.
Broken or weak suction or delivery
valve spring Check and replace if necessary.
Foreign matter in valves Check and clean if necessary.
Worn bearings Check and replace if necessary.
Excessive temperature of water Reduce to below 140o F.
Landa SEA Operator Manual 8.913-999.0 - AK

15
Maintenance
PROBLEM POSSIBLE CAUSE SOLUTION
PRESENCE
OF WATER
IN PUMP OIL
Oil seal worn Check and replace if necessary.
High humidity in air Check and change oil twice as often.
Piston packing worn Check and replace if necessary.
WATER
DRIPPING
FROM
UNDER PUMP
Piston packing worn Check and replace if necessary.
O-Ring plunger retainer worn Check and replace if necessary.
OIL
DRIPPING
FROM PUMP
Oil seal worn Check and replace if necessary.
EXCESSIVE
VIBRATION
IN HIGH
PRESSURE
HOSE
Irregular functioning of the pump
valves Check and replace if necessary.
Obstruction in filter Clean inlet filter.
MOTOR WILL
NOT RUN
Motor overload
Push in the overload button located on the
motor (single phase) or the overload button on
the magnetic start switch (three phase).
Stepdown transformer fuses Check fuses and voltage. Replace
if necessary.
Coil of magnetic starter defective Replace coil after the timer and unloader switch
have been tested.
MACHINE
WILL NOT
TURN ON
WHEN SWITCH
IS PUSHED
Timer is defective Join wires 15 and 16 together on timer.
If machine works, replace timer.
Landa SEA Operator Manual 8.913-999.0 - AK

16
Maintenance
Preventative Maintenance
This pressure washer was produced with the best available materials and quality craftsmanship. However, you as
the owner, have certain responsibilities for the correct care of the equipment. Attention to regular preventative main-
tenance procedure will assist in preserving the performance of your equipment. Contact your dealer for mainte-
nance. Regular preventative maintenance will add many hours to the life of your pressure washer. Perform
maintenance more often under severe conditions.
Maintenance Schedule
Pump Oil
Inspect 25 hours or Weekly
Change Yearly
Use 10W-40 non-foaming oil for pump
Water Filter Inspect Daily
Change Yearly
Belt Tension Inspect Every 3 months
Electric Cord Inspect Daily
Coupler )-rings Inspect Yearly
Landa SEA Operator Manual 8.913-999.0 - AK

17
Maintenance
Oil Change Record
Date Oil Changed
Month/Day/Year
Estimated Operating
Hours Since Last
Oil Change
Date Oil Changed
Month/Day/Year
Estimated Operating
Hours Since Last
Oil Change
Landa SEA Operator Manual 8.913-999.0 - AK
Check pump oil level before first use. Change pump oil after first 50 hours and every month or 500 hours thereafter.
Use SAE 10W-40 non-foaming oil.

18
Notes
Landa SEA Operator Manual 8.913-999.0 - AK
