LP-288ai, 5.8GHz Band Fractional Bandwidth 5/10/20MHz OFDM Radio,
123 Manual for installation in Client Mode.
LP288ai_M123_ENC01W
LP-288ai, 5.8GHz Band Fractional
Bandwidth 5/10/20MHz OFDM
Radio, 123 Manual for installation
in Client Mode.
www.lanpro.com
Wireless - Equipment - 5.8 GHz - LP-288ai 123 Manual for installation in Client Mode
By following these instructions you will be able to install your LP-288AI in Client Mode.
2
Please check package contents shown in gure 1.
1
Figure 1
Please prepare the cable with the connector as shown in gure 2a, 2b and 2c.
2
Connect the cable as shown in gure 3.
3Connect the To ODU output of the PoE injector to your
LP-288AI as shown in gure 4.
4
Connect one of your PC’s or Switch’s Ethernet ports to the To Ethernet input of the PoE injector of the LP-288ai
as shown on gure 5.
5
Figure 4
Figure 5
Figure 2a
Figure 3
Figure 2b Figure 2c
www.lanpro.com
Wireless - Equipment - 5.8 GHz - LP-288ai 123 Manual for installation in Client Mode
By following these instructions you will be able to install your LP-288AI in Client Mode.
3
Go to the Properties window of your Network Interface
card(NIC): Local Area Connection Properties and
select: Internet Protocol, then select: Properties
as shown in gure 7.
7
Figure 7
In the window: Internet protocol (TCP/IP)
Properties of gure 8, select: Use the following
IP address and input an IP address in the default
IP range of the LP-288ai, in this example we have
selected address: 192.168.1.201. The LP-288ai has
a default adress of: 192.168.1.2, input in: Subnet
mask: 255.255.255.0 and in: Default gateway the
destination router address, in: DNS you will have
to input your ISP’s DNS or the destination router
address, the one that provides the Internet service,
in order that any queries are routed to the destination
network`s router.
Once nished, please select: OK and then: Close
8
Figure 8
Connect the DC Power to the PoE’s Injector Male Jack
as shown in gure 6.
6
Figure 6
www.lanpro.com
Wireless - Equipment - 5.8 GHz - LP-288ai 123 Manual for installation in Client Mode
4
It is important to mention that in this conguration of the LP-288ai, it will be a client of the destination network. In
gure 11 you can see the actual conguration used as a reference.
9
Figure 9
In this diagram, the destination network is yellow colored. In it, you have a router that provides Internet service
connection and has the delivery of addresses enabled in the 192.168.1.x segment, and number of reserved addresses
in the scope. The Router will deliver addresses from the 100th to the 200th only, and it provides the Internet
connection. The LP-288ai has the default address 192.168.1.3. in the blue colored network segment .
Open the browser application of your choice and input
the default address: 192.168.1.2, please see gure
10.
10
Figure 10
The LP-288ai will ask that you input a User and a
Password. The LP-288ai has two user levels, one with
all the privileges named by default: super , whose
password is: super and another with less privileges
named: admin with a password: admin. Now please
input as user: super and a password: super and hit:
OK , as shown in conguration in gure 11.
11
Figure 11
www.lanpro.com
Wireless - Equipment - 5.8 GHz - LP-288ai 123 Manual for installation in Client Mode
5
In this example, in the window shown in gure 12,
please select: IP Conguration and change the IP
address to 192.168.1.3
12
Figure 12
Please select : Update in the window shown in gure 13 in order to save the changes.
13
Figure 13 Figure 14
The equipment will indicate you to wait the completion
of the rebooting and application of the changes in the
window shown in gure 15.
14
Figure 15
Please open the browser of your preference and
navigate to the new address: 192.168.1.3 as shown in
the window of gure 16.
15
Figure 16
Once changes are saved, select : Reboot in the same window of gure 14.
www.lanpro.com
Wireless - Equipment - 5.8 GHz - LP-288ai 123 Manual for installation in Client Mode
6
In the window shown in gure 18, select: Operation
Mode, then select: Client, input now the SSID of
the destination network, in this example of the LP-
288ai, in: Radio Frequency input th channel of the
destination AP. If you don’t know it, please select:
SmartSelect, disable option: WDS, you could use it
if other equipment support it, as an example two LP-
288ai, select: Update to save the changes.
17
Figure 18
The equipment will save the changes, but they will
not take effect until you reboot it. In order to do it,
please select: Reboot, it is important to mention that
you can congure the equipment in a way that it only
connects to the destination AP, by using the Remote
MAC, we recommend you read the 123 Manual on how
to set the LP-288ai in Point to Point mode, (document:
LP288AI_M123_SPD01w.pdf).
Figure 19
The progress of the rebooting operation will be shown
in the window of gure 20.
Figure 20
The equipment will ask again for the user and password, input as
User: super and password: super then select: OK.
16
Figure 17
www.lanpro.com
Wireless - Equipment - 5.8 GHz - LP-288ai 123 Manual for installation in Client Mode
7
In the window shown in gure 21, select: Click here
18
Figure 21
In the window shown in gure 22, select: Security
setting , and in: Security mode, select the encryption
mode, remember to select the same mode used by the
destination AP.
19
Figure 22
Select the type of cyphering and the encryption
mode of your destination AP, yo will have to input
the corresponding encryption phrase and then select:
Update as shown in gure 23.
20
Figure 23
Once changes have been saved, please select: Reboot
in the window shown in gure 24 for the changes to
take effect. As shown in gure 24.
21
Figure 24
www.lanpro.com
Wireless - Equipment - 5.8 GHz - LP-288ai 123 Manual for installation in Client Mode
8
In the window shown in gure 26, select: Click here.
23
Figure 26
Proceed to change the User password: admin and
the super user password: super of your equipment,
please see gure 27.
In order to change the User: admin, password, select:
administration input the new password in the eld
named: password, then select: Update.
24
Figure 27
Important recommendation(Optional):
For the changes to take effect, please select: Reboot
in the window shown in gure 28.
25
Figure 28
The progress of the reboot function is shown in the
window of gure 29.
26
Figure 29
In the window shown in gure 25, the process of
rebooting will be shown
22
Figure 25
www.lanpro.com
Wireless - Equipment - 5.8 GHz - LP-288ai 123 Manual for installation in Client Mode
9
The equipment will ask again the User and Password if
you are authenticated as admin, input the value you
changed and select: OK, then select: click here. in
the window shown in gure 30.
27
Figure 30
Procceed to change the password of the user: super,
in order to be able to make this change you must be
authenticated as super user, now select option: super
user and input a new password, then select : update
(see gure 31)
28
Figure 31
For the change to take effect, please select: Reboot in
the window shown in gure 32.
29
Figure 32
Watch now the progression of the reboot function,
please see gure 33.
30
Figure 33
In the window shown in gure 34, please select: Click
here
The equipment will ask you to input the new user and
password, input the new values to proceed and select:
OK
31
Figure 34
To check the status of the connection, select: Status
Association and observe the signal in the Signal
Strength value, as shown in Figure 35, this value will
depend on the distance and link quality.
32
Figure 35
