lap 172PG Manual

Instruction leaflet
Half Lantern PIR
Outdoor Wall Light
19/07/2021
172PG, 430PG
• Fitting/Replacing the bulbs - MAX 15W LED E27 GLS.
• When changing a bulb, always, switch off at the
mains and allow the bulb to cool before handling.
Dispose of used bulbs carefully. Do not exceed the
wattage stated or use a different shape bulb from
that indicated on the fitting.
• Do not exceed the wattage stated or use a different
shape bulb from the indicated on the fitting.
• Unscrew the bulb anti clockwise to remove.
• Carefully locate the bulb in the lampholder and turn
clockwise to secure.
Fitting/replacing bulbs
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice. The packaging on this product can also be recycled.
Recycling advice
Safety information
We recommend cleaning with a soft dry cloth.
Do not use solvents or abrasive cleaners as these could
damage the finish.
Glass parts – Wipe clean with a damp cloth. Do not use
abrasive materials as these will damage the finish.
Cleaning
For your safety, always switch off the supply before changing lightbulbs, or cleaning.
The glass shade must be replaced if it becomes cracked or damaged.
Do not use product without glass shade attached. Replace Cracked
Shade
UK Manufacturer:
Kingfisher International Products Limited,
3 Sheldon Square, London, W2 6PX,
United Kingdom.
EU Manufacturer:
Kingfisher International Products B.V.
Rapenburgerstraat 175E,
1011 VM Amsterdam, The Netherlands.
The unit must be installed in a vertical position, and fitted
1-2m above the ground. The PIR sensor can be adjusted
using the SENS and TIME dials.
The detection angle is set at 105 degrees. The maximum
detection distance is 8m.
The length of time that the light is on can be adjusted
by turning the ‘Time’ dial, which can be altered between
8 seconds to 9 minutes duration. See (1) below.
Adjust the light level that the lamp switches on by
adjusting the 'LUX' screw (2).
PIR Adjustment
L
N
Max. 8M
1-2M
1.7M

Thank you for purchasing this light fitting. Please read the instructions carefully before use to ensure safe and satisfactory
operation of this product. Please retain these instructions for future reference.
Warning
Layout
Specification
Voltage: 240V 50Hz
Lamp: Max. 1 x 15W LED E27 GLS
IP rating: 44
• Plan the desired layout of this fitting carefully,
ensuring the cables will reach the distance between
the junction box and the light fitting.
• Avoid locating any cables in positions that would
cause a hazard. Position cables and junction boxes
(not supplied) away from areas where they may be
at risk from being cut, trapped or damaged.
• Cables in walls must be protected using suitable
conduit or plastic trunking.
• The mains supply cable must have a minimum cross
sectional area of 1.0mm2.
• This product has special protection against the
ingress of moisture and is IP44 rated.
Existing fittings must be completely removed before
installation of a new product. Before removing the existing
fitting, carefully note the position of each set of wires.
• Undo the screw (1) at the top and front of the lantern
and remove the cover. Set them aside for refitting later.
• Undo the screw (2) from the plastic base under the
lampholder to remove the plastic base and set them
aside for refit. Hold the rear plate in place and mark
the position of the holes. Ensure that the product is
level. Ensure the wall is capable of holding the weight
of the product. Take care to avoid
damaging any concealed wiring
and pipes. The correct fixings
should be used for brick,
cavity walls or plasterboard.
• Pull supply wires through rubber
grommet on wall back then fix
the wall back to the wall using
screws (3) and plugs (4).
• Wire as detailed below.
• Refit the plastic cover over the terminal block and
secure in place using the screw.
• Fit the bulb (5) (Never fit bulbs of a higher wattage
than those specified on the label as these may
cause over heating and damage the fitting).
• Refit the screws to fit the lantern cover in place.
• Replace fuse or circuit breaker and switch on.
Your light is now ready for use.
Installation
Check that...
• You have correctly identified the house wires.
• The connections are tight.
• No loose strands have been left out of the
connection block.
Wiring
Having correctly identified the wiring from your existing
light fitting, pull the wire through the hole and connect
to the connection block inside the product in the
following way:
This product is Double Insulated and does
not require connection to an Earth circuit.
Please read these instructions carefully before
commencing any work.
This unit must be fitted by a competent and qualified
electrician.
Install in accordance with IEE Wiring regulations and
current Building Regulations.
To prevent electrocution switch off at mains supply
before installing or maintaining this fitting. Ensure
other persons cannot restore the electrical supply
without your knowledge. If you are in any doubt,
please consult a qualified electrician.
This light fitting should be connected to a fused
circuit.
If replacing an existing fitting, make a careful note
of the connections.
Always use the correct type and wattage bulb.
Never exceed the wattage stated.
When changing a bulb, always switch off at the
mains and allow the old bulb to cool down before
handling. Dispose of used bulbs carefully and
responsibly.
Waste electrical products should not be disposed of
with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for
recycling advice.
This product is rated at IP44.
The entire unit gets hot whilst on for a period of time.
L
N
Max. 8M
1-2M
1.7M
1
3
4
5
3
2
