lap 179PP Manual

For your safety, always switch off the supply before adjusting or cleaning.
The light source and control gear cannot be replaced due to IP protection becoming compromised.
Recycling advice
Safety information
Do not use solvents or abrasive cleaners as these could damage the finish.
Do not clean the units with a pressure washer.
Fitting/replacing bulbs
Care and cleaning
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
This product contains non replaceable parts and cannot be serviced.
Alba LED Wall Light
179PP
This product contains a light source of energy efficiency class G.
Instruction leaflet
03/11/2021
UK Manufacturer:
Kingfisher International Products Limited,
3 Sheldon Square, London, W2 6PX,
United Kingdom.
EU Manufacturer:
Kingfisher International Products B.V.
Rapenburgerstraat 175E,
1011 VM Amsterdam, The Netherlands.

• Cables in walls must be protected using suitable conduit or plastic trunking.
• The mains supply cable must have a minimum cross sectional area of 1.0mm².
Thank you for purchasing this light fitting. Please read the instructions carefully before use to ensure safe and
satisfactory operation of this product. Please retain these instructions for future reference.
Warning
Specification
Voltage: 240V 50Hz a.c.
Lamp: 12W LED Module - 700lm
IP rating: 44
Having correctly identified the wiring from your light fitting, connect to the terminal block in the following way:
Wiring
Check that...
• You have correctly identified the
wires.
• The connections are tight.
• No loose strands have been left
out of the connection block.
NEUTRAL
EARTH
SWITCHED LIVE
BLUE (N)
BROWN (L)
GREEN/YELLOW
SUPPLY LIGHT FITTING
This is a Class 1 product and must be earthed.
Please read these instructions carefully before commencing any work.
This unit must be fitted by a competent and qualified electrician.
Install in accordance with IEE Wiring regulations and current Building Regulations.
To prevent electrocution switch off at mains supply before installing or maintaining this fitting. Ensure other persons
cannot restore the electrical supply without your knowledge. If you are in any doubt, please consult a qualified
electrician.
This light fitting should be connected to a circuit with a 30mA RCD fitted.
If replacing an existing fitting, make a careful note of the connections.
Always use the correct type and wattage bulb. Never exceed the wattage stated.
When changing a bulb, always switch off at the mains and allow the old bulb to cool down before handling.
Dispose of used bulbs carefully and responsibly.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your local authority or retailer for recycling advice.
This product is rated at IP44.
This product is not suitable for location in or near a marine environment.
The entire unit gets hot whilst on for a period of time.
Layout
Existing fittings must be completely removed before
installation of a new product. Before removing the
existing fitting, carefully note the position of each set
of wires.
• The front shade is magnetic. Simply pull it away
from the inner shade and set aside.
• Detach the inner shade by removing the 4 corner
screws. Set them aside for refitting later.
• Using the wall back as a template, mark the position
of the mounting holes.
• Drill holes and fit supplied wall plugs (suitable for
masonry only - for other surfaces use appropriate
fixings).
• Wire as detailed below
Installation
• Ensure that the screws and cable entry points are
sealed to maintain the IP rating of the product.
• Re-attach the inner shade by refitting the corner
screws set aside earlier. Then replace the outer
magnetic shade by placing it onto the inner shade.
• Replace fuse or circuit breaker and switch on. Your
light is now ready for use.
Commissioning
2X
2X
Outer
shade
Inner
shade
Wall
Back
