Explosion Proof Rechargeable White Forklift LED Forward Projection Light
C1D1-2 - C2D1-2 - Aluminum
Instruction Manual
Thankyou for your purchase of the Larson Electronics EXHL-TRN-RPS-LE4-FKWL-WHT-M.
•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
•PRODUCT MUST BE CONNECTED TO A WIRING SYSTEM WITH AN EQUIPMENT-GROUNDING
CONDUCTOR.
TO AVOID EXPLOSION:
•MAKE SURE THE SUPPLY VOLTAGE IS WITHIN THE VOLTAGE RATING.
•ENSURETHE MARKED TRATING IS LESS THAN THE IGNITION TEMPERATURE OF THE HAZARDOUS
ATMOSPHERE.
•DO NOT OPERATE IN AMBIENT TEMPERATURES ABOVETHOSEINDICATED ON THE PRODUCT
NAMEPLATE.
•DO NOT OPERATE IF THE LENS, CORD, SEALS, HOUSING, RECEPTACLES, ETC. IS CRACKED OR
DAMAGED. IFSO, DISCONTINUE USEAND CONTACT MANUFACTURER FOR REPLACEMENT PARTS.
•ALL FASTENERS SHOULDBE PROPERLY SEATED.
IMPORTANT
READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. THE EXHL-TRN-RPS-LE4-FKWL-WHT-M MUST BE WIRED IN ACCORDANCE WITH NATIONAL
ELECTRICAL CODE AND ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.
WE STRONGLY ENCOURAGE ONLY A LICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS
PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET,
CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.
WARNING
TO AVOID THE RISK OF FIRE, EXPLOSION OR ELECTRIC SHOCK,THIS PRODUCT SHOULD BE
INSTALLED, INSPECTED AND MAINTAINED BY AQUALIFIED ELECTRICIAN ONLY,IN
ACCORDANCE WITH ALL APPLICABLE ELECTRICAL CODES.
TO AVOID ELECTRIC SHOCK:
Magnetic Warning
•PEOPLE WITH PACEMAKERS SHOULD CONSULT THEIR PHYSICIAN(S) BEFORE USE.
ELECTROMAGNETIC FIELDS INCLOSE PROXIMITY TOHEART PACEMAKER COULD CAUSE
PACEMAKER INTERFERENCE OR PACEMAKER FAILURE.
•KEEP FINGERS AWAY FROM MAGNET WHEN MOUNTING ASINJURY COULD OCCUR.
The EXHL-TRN-RPS-LE4-FKWL-WHT-M from Larson Electronics is an Explosion Proof Rechargeable White Forklift
LED Warning Light that produces 2,250 lumens while drawing only 25 watts. Forklift operators may use this compact,
forward projection luminary as a forklift headlight to illuminate the operating area in front of the forklift. This light is also
ideal for providing increased visibility when loading a pallet onto a shelf. The EXHL-TRN-RPS-LE4-FKWL-WHT-M is
Class I, Divisions 1 & 2, Groups B, C, D, Class I, Zones 1 & 2, Groups IIB+H2, IIA, Class II, Divisions 1 & 2, Groups E, F,
G and Class III Divisions 1 & 2 rated for hazardous areas and is listed for use worldwide including the United States,
Canada, Europe and Asia. This explosion proof LED light offers 8 hours of runtime from the 8.8aH lithium ion
rechargeable battery.
Mounting
The EXHL-TRN-RPS-LE4-FKWL-WHT-M uses a magnetic trunnion mount
system that allows the user to mount the light anywhere magnetic that is flat,
and capable of supporting the load of the fixture. The adjustable flat surface
bracket has two set screws on the bracket, allowing operators to loosen the
mounting bracket, adjust the light`s tilt orientation, and re-tighten to hold the
fixture in position.

EXHL-TRN-RPS-LE4-FKWL-WHT-M
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 2of 2
Power
The EXHL-TRN-RPS-LE4-FKWL-WHT-M is battery operated and rechargeable. The fixture is shipped with the hot (+)
wire between the light and the battery disconnected. First, loosen the set screw holding the lid cover on the battery side,
unscrew the lid and remove, then complete the connection of the hot (+) wires in accordance with all applicable local,
state, and national electric code. The light will now operate as long as the battery has been charged. Replace lid and
tighten set screw to hold in place. A 120V general area charger is included, do not plug this charger in inside the
hazardous area. A charger port is installed on the fixture via one of the hubs at the bottom of the unit. The battery offers
8 hours of runtime before recharging is required. Seal the hub with explosion proof compound in accordance with
local, state, and national codes to maintain explosion proof status of the fixture.
MAINTENANCE
There are no serviceable parts inside the fixture. However, it is good practice to routinely clean and check the
fixture for proper function.
•Disconnect power running to the lamp and be sure the fixture is cool to the touch.
•Use a non-abrasive glass cleaning solution to clean the lens.
Note: It is not necessary to open the fixture and clean or touch the LED’s.
USE AND CARE
Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.
Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of
children when not in use.Inspect for good working condition prior to storage and before re-use.
REPLACEMENT PARTS
The EXHL-TRN-RPS-LE4-FKWL-WHT-M is designed to provide years of reliable performance. Should the need for
replacement parts arise, please contact Larson Electronics.
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.
SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT
SAL[email protected] OR BY PHONE AT 1-877-348-9680 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
