Larson Electronics EPL-16C-1MLED-50 User manual

EPL-16C-1MLED-50
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com
1of 2
Explosion Proof LED Tank Light
17,500 Lumens LED - Wheelbarrow Cart- 50' Cord
Instruction Manual
This explosion proof wheelbarrow light is designed for illumination of industrial locations. It uses the latest in
solid state lighting technology for long life, low maintenance and high efficiency.
The unique design focuses the light where it is needed, giving improved efficiency over a conventional HID
luminaire.
An internal, universal input, power-factor-corrected switch-mode supply allows it to be used from any nominal
120-277V AC 50/60 Hz power supply without any variation in light output.
WARNING
To avoid the risk of fire, explosion or electric shock, this product should be installed, inspected and
maintained by a qualified electrician only, in accordance with all applicable electrical codes.
To avoid electric shock:
•Be certain electrical power is OFF before and during installation and maintenance.
•Luminaire must be connected to a wiring system with an equipment-grounding conductor.
To avoid explosion:
•Make sure the supply voltage is within the luminaires’ voltage rating.
•Ensure the marked T rating is less than the ignition temperature of the Hazardous Atmosphere.
•Do not operate in ambient temperatures above those indicated on the luminaire nameplate.
•Do not operate if the lens is cracked or damaged. All fasteners should be properly seated.
The light fixture on this wheelbarrow cart is factory sealed.
CART OPERATION
The wheelbarrow cart assembly consists of 2 parts:
1. Light head
2. Wheelbarrow cart base
To assemble cart, insert light head over center hole of wheelbarrow cart and tighten hand screw. The
wheelbarrow cart is now ready for use.
Tilt cart using both handles and maneuver like a wheelbarrow. Simply roll entire assembly to a new location
once assembled. Make sure light head is secure prior to maneuvering cart.
WARNING: Be sure all hand screws are tight before transporting! Use caution when maneuvering near
inclines or drop offs.
Run power cord to a nearby receptacle outputting voltage listed on product label.
WARNING: check nameplate for proper voltage. Damage from improper voltage may void warranty.
To adjust light head vertically, loosen hand screws on either side. Once desired angle is achieved, tighten
both hand screws to secure light in its place. Loosen the single hand screw holding light head to rotate
horizontally. Be sure all hand screws are tight before transporting!

EPL-16C-1MLED-50
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com
2of 2
WIRING (see attached wiring diagram)
This unit comes preconfigured with selected cord cap, color temperature, and beam spread. Once deployed,
plug cord cap into compatible receptacle with Voltage: 120-277 Volts AC, 50/60Hz
MAINTENANCE
Caution: To avoid personal injury, disconnect power to the light and allow the unit to cool down before
performing maintenance.
Warning: No user serviceable parts inside of fixture. Risk of electric shock. Removal of the lens will void
the warranty.
1. Perform visual, mechanical and electrical inspections on a regular basis. We recommend routine
checks to be made on a yearly basis. Frequency of use and environment should determine this. It is
recommended to follow an Electrical Preventive Maintenance Program as described in NFPA 70B:
Recommended practice for Electrical Equipment.
2. The lens should be cleaned periodically as needed to ensure continued photometric performance.
Clean the lens with a damp, non-abrasive, lint-free cloth. If not sufficient, use mild soap or a liquid
cleaner.
3. Inspect the cooking fins on the luminaire to ensure that they are free of any obstructions or
contamination (i.e. excessive dust build-up). Clean with a non-abrasive cloth if needed.
4. Do not operate if the lens is cracked or damaged. All fasteners should be properly seated.
WARRANTY
Should further information not covered by these instructions be required, please contact Larson Electronics at
1-800-369-6671 or [e-mail] for further assistance.
Please visit LarsonElectronics.com for Warranty and Return information.
WARNING: CHECK NAMEPLATE
FOR PROPER VOLTAGE. DAMAGE
FROM IMPROPER VOLTAGE MAY
VOID WARRANTY.
