Larson Electronics SLEDB-110V-MS User manual

SLEDB-110V-MS
Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
1 of 5
Class II Strobe Light with Motion Sensor
110-120V AC - 54 Flashes Per Minute - 5 Color Options
Instruction Manual
Thank you for your purchase of the Larson Electronics SLEDB-110V-MS.
WARNING:
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CRITICAL SAFETY INSTRUCTIONS:
•INSTALLATION SHOULD ONLY BECONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY
RELEVANT LOCAL BUILDING CODES.
•RISK OFFIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF FIXTURE'S ELECTRICAL
SYSTEMS. IFNOTQUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.
•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
•MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE FIXTURE'S RATED VOLTAGE.
•TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP
OBJECTS. SUITABLE FOR DAMP LOCATIONS.
IMPORTANT
READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE. THE SLEDB-110V-MS MUST BE WIRED IN ACCORDANCE WITH NATIONAL ELECTRICAL
CODE AND ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.
WE STRONGLY ENCOURAGE ONLY ALICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS
PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET,
CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.
WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE
INSTALLATION OR PERFORMING ANY MAINTENANCE.
RISK OF FIRE/ELECTRIC SHOCK –DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.
RISK OF PERSONAL INJURY –FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOT INSTALLED PROPERLY.
RISK OF BURN –ALLOW FIXTURE TO COOL BEFORE SERVICING.
IMPORTANT
READ CAREFULLY BEFORE OPERATING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. IF UNSURE ABOUT ANY PART OF THESE INSTRUCTIONS, CONSULT A QUALIFIED ELECTRICAL
PROFESSIONAL.
WARNING: OPERATE ONLY AT THE VOLTAGE LISTED ON THE PRODUCT. DO NOT OPERATE IN CLOSE
PROXIMITY OF COMBUSTIBLE OR FLAMMABLE MATERIALS. NEVER LOOK DIRECTLY AT LIGHT WHEN ON.
WARNING: CONSULT A QUALIFIED ELECTRICAL PROFESSIONAL/ELECTRICIAN TO INSTALL THIS DEVICE IN
ACCORDANCE WITH APPROPRIATE LOCAL AND NEC CODES AND REGULATIONS.
WARNING: TO BE INSTALLED AND/OR USED IN ACCORDANCE WITH APPROPRIATE ELECTRICAL CODES
AND REGULATIONS.
WARNING: DEVICE IS SUITABLE FOR INSTALLATION IN WET LOCATIONS; GFCI PROTECTION
RECOMMENDED.
WARNING: ALTHOUGH FIXTURE IS WATERPROOF, IT IS NOT DESIGNED OR INTENDED TO BE SUBMERGED.
WARNING: DO NOT ALLOW LINE VOLTAGE WIRES TO BECOME SUBMERGED!
•ALL OUTDOOR INSTALLATIONS AND INDOOR INSTALLATIONS NEAR A WET LOCATION REQUIRE THE
USE OF A GFCI DEVICE FOR SAFETY, ACCORDING TO THE NATIONAL ELECTRICAL CODE® (NEC).
•KEEP AWAY FROM FLAMMABLE OBJECTS. DO NOT POSITION WITHIN ONE (1) INCH OF ANY
COMBUSTIBLE MATERIALS.
•IF DROPPED OR DAMAGED, THE UNIT MAY NO LONGER BE WATERPROOF AND SHOULD BE
REPLACED.
•TO AVOID HAZARDS TO CHILDREN, ACCOUNT FOR ALL PARTS AND DESTROY PACKING MATERIALS.

SLEDB-110V-MS
Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
2 of 5
MOUNTING
Mount to any flat surface capable of holding the weight utilizing the predrilled
mounting holes. Mount in any direction as long as the motion sensor can still detect
motion.
WIRING
We strongly encourage a licensed electrician install this product, especially in outdoor locations
where weatherproofing may be required. Voltage driver permitsoperation at 110-120V AC.
Warning: Check product label for correct inputvoltage!
Attach supply line wires to the appropriate light fixture
wires as shown in the diagram
Take precautionary steps for weatherproofing all
connections if installed in a location where water may
come in contact with the unit. Ensure the unit is properly
grounded.
The Larson Electronics SLEDB-110V-MS Class II Beacon works on 110-120V AC, offers a choice of several colors
and is equipped with an aluminum base. The SLEDB-110V-MS comes equipped with a motion sensor that turns the
light on when movement is detected. The motion sensor has a user adjustable time delay.
INSTALLATION
This unit comes pre-assembled with the selected color from factory.Follow the steps below for installing and
maintaining the strobe light.

SLEDB-110V-MS
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 3 of 5
MOTION SENSOR
Operating voltage
Rated load
HF system 5.8GHz±75MHz, ISM wave band
Transmitting power <0.5mW
Power consumption ≤0.5W(standby)
Detection zone Max.(D x H): 16m x 15m
Detection sensitivity /// 50%10%%%%%%
Hold time 5s / 45s / 5min / 15min
Daylight sensor 2Lux/10Lux/30Lux/Disable
Mounting height 15m Max.
Motion detection 0.5~3m/s
Detection angle 150°(wall installation)
360°(ceiling installation)
Operating temperature -25℃~60℃
IP rating IP20
Setting
ON ON
ON
ON
ON ON
ON
ON
ON
ON
ON
I
II
III
IV
1 2
10%
50%
75%
100%
I
II
III
IV
3 4
5s
45s
5min
15min
I
II
10lux
2lux
30lux
III
IV
By selecting the combination on the DIP switch, sensor data can be precisely set for each specific application.
ON
ON
DDetection Area
Detection area can be reduced by selecting the combination on the
DIP switches to fit precisely each application.
HHold Time
Refers to the time period the lamp remains at 100% illumination after
no motion detected.
DDaylight Sensor
The sensor can be set to only allow the lamp to illuminate below a
defined ambient brightness threshold.
When set to Disable mode, the daylight sensor will switch on the lamp
when motion is detected regardless of ambient light level.
30lux:twilight operation, 2lux, 10lux: darkness operation only.
Disable
OONN
ON
5 6

SLEDB-110V-MS
Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
4 of 5
MOTION SENSOR
The SLEDB-110V-MS operates like a standard on/off light switch. The
circuit is normally open when no motion is present. Once motion is
detected, the internal switch changes to a closed circuit, allowing
voltage to pass through the sensor and power the device(s) at the other
end.
The sensor is an active motion detector; it emits high-frequency
electro-magnetic waves (5.8GHz) and receives their echo. The sensor
detects the change in echo from even the slightest movement in its
detection zone. A microprocessor then triggers the “switch light ON”
command. Detection is possible through doors, panes of glass or thin
walls.
IMPORTANT: persons or objects moving towards the sensor are
detected best. NOTE: the high frequency of the output of this sensor is
<10Mw – that is just one 100th of the transmission power of a mobile
phone or the output of a microwave oven.
Malfunction Cause Remedy
The load will not work - wrong light control setting selected
- load faulty
- mains switch OFF
- adjust setting
- change load
- switch ON
The load is always working - continuous movement in the
detection zone
- check zone setting
Load works without and identifiable
movement
- sensor is not mounted for detecting
movement reliably
- movement occurred, but not
identified by the sensor (movement
behind a wall, movement of small
object in immediate vicinity etc.)
- securely mount enclosure
- check zone setting
The load will not work despite
movement
-rapid movements are being
suppressed to minimize
malfunctioning or the detection zone
you have set is too small
-check zone setting

SLEDB-110V-MS
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 5 of 5
MOTION SENSOR LOCATION
This unit uses a microwave sensor, which is more reliable than the standard PIR sensor. This sensor is
enclosed in a waterproof box below the light. The sensor DOES NOT need line of sight. The microwave sensor
is capable of sensing through the waterproof enclosure and detecting motion, which in turn activates the light.
Not seeing an external sensor may make you think that your unit is missing the motion sensor. It is not. The
sensor is included and will function as intended.
MAINTENANCE
If the lens becomes dirty, wipe down with a mild soap and water solution.
It isrecommended to occasionally inspect the unit for any defects and toensure the cable isnotfrayed and is gripping tightly in all
points ofcable contact.
USE AND CARE
Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.
Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of
children when not in use.Inspect for good working condition prior to storage and before re-use.
REPLACEMENT PARTS
The SLEDB-110V-MS is designed to provide years of reliable performance. Should the need for replacement parts arise,
please contact Larson Electronics.
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.
SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT
SA[email protected] OR BY PHONE AT 1-877-348-9680 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
