Larson Electronics GL-30675-F User manual

GL-30675-F
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com
1of 2
The GL-30675-F LED Golight Stryker Combination Spotlight/Floodlight from Larson
Electronics produces a 2,520 lumen light beam capable of reaching over 900 feet in
distance in spot and 150 feet in distance by 125 feet in width. This 36 watt LED Golight
offers wireless remote pan and tilt control, a portable handheld remote control, a dash
mounted remote control and a housing finished in a durable white finish. This Golight is
weatherproof with a weatherproof remote control and operates with 12 Volt DC.
MOUNTING INSTRUCTIONS
Light Unit/Magnetic Mount
The light is magnetically mounted. The magnet is water tight and has a 100 pound grip base and is
tested to 60 mph.
Note: Once power is applied to the system the light will pan and tilt prior to illumination. Each
spotlight needs to be wired on a single dedicated circuit and the power fused at 5 amps. With the
power connected, your light is ready for operation.
POWER SUPPLY
This light operates with 12 volts DC and draws 3 amps, making it ideal for vehicles, boats, ATVs, and similar
sources of 12 volt direct current. It is equipped with a 16 foot, outdoor rated cord with a cigarette plug. Weather
tight connector enables operators to disconnect cord at 12 inches from the light for storage or vehicle
portability.
REMOTE OPERATION
Remote control functions include on/off, and 4 buttons which control up, down, left and right
movement. The light will continue movement as long as the buttons are pressed. Releasing the
buttons stops movement and holds the Golight in position. A fast and slow mode button (turtle/hare)
controls the speed of the motor while the pan and tilt function buttons are depressed. Holding the
button for 12 seconds in fast mode results in a full 370 degree rotation, and 8 seconds for full tilt. Slow
mode is used for pinpoint accuracy at distance and is approximately 35 seconds for full rotation and 20
seconds for one full range of tilt.
BATTERY
Both remotes includes have an internal 12 volt battery rated at 1 year of operation and a single red
LED to indicate remote control activity.
PROGRAMMABLE REMOTE INSTRUCTIONS
Remote Control Programmable with More than 60,000 Possible Channels. Remotes Can be
Programmed to Control One Golight or Several.
Golight Stryker Wireless Remote Control Flood and
Spot Light Combo - Handheld and Dash Mount Remote
Instruction Manuel

GL-30675-F
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com
2of 2
USAGE:
This light is intended for off-road and utility use only
This light is intended to be mounted outside the vehicle while in use
This light may only be disassembled and repaired by an authorized representative
MISUSE:
This light is not approved for road or highway use
This light is not approved for underwater use
This light is not approved for inverted mounting
This light is not approved for use inside a vehicle or enclosure and power should be
disconnected prior to placing the light in such circumstance
This light may be damaged if operated in icing conditions
This light may only be dismantled by an authorized representative
Any violation of the above referenced misuses will be considered grounds for warranty
refusal
If the lens becomes dirty, wash with a mild soap and water.
IMPORTANT SAFETY INFORMATION
This symbol is to alert you to important operating or servicing instructions that appear in your instructions. Always follow
basic safety precautions when using this product to reduce the risk of injury, fire or electric shock.
This light is for off road and utility use only. It is not designed for road use as a driving light.
The GL-2085-M complies with Part. 15.105 of the FCC Rules. This equipment has been tested and found to comply with the limits
for a Class B digital device. These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
FCC RULE Part. 15.21 - Changes or modifications made by the user not expressly approved by Larson Electronics, LLC for
compliance could void the user’s authority to operate the equipment.
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS. SHOULD FURTHER
INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT [email protected] OR BY PHONE AT
1-800-369-6671 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
