Lasermet GLASER JAILER User manual

Glaser Jailer Active Window Instruction Manual
CEB00XXX-53-000 Issue 7 19 January 2021
LASERMET
GLASER JAILER
INSTRUCTION MANUAL
ACTIVE WINDOW
LASER PROTECTION SYSTEM

Glaser Jailer Active Window Instruction Manual
CEB00XXX-53-000 Page 2 of 12 Issue 7 19 January 2021
LASERMET GLASER JAILER
Instruction Manual
Contents
1 Declaration of Conformity .................................................................................................. 3
2 Safety Warnings .................................................................................................................. 5
3 Concept ............................................................................................................................... 6
4 Wiring ................................................................................................................................. 7
5 Operation ............................................................................................................................ 7
5.1 Laser Detection ........................................................................................................... 8
6 Specifications ...................................................................................................................... 8
6.1 Filter Window Specification ........................................................................................ 9
6.2 Dimensions ................................................................................................................ 10
6.3 Environmental Conditions ......................................................................................... 11
7 Warranty ........................................................................................................................... 11
8 Contact Details .................................................................................................................. 12

Glaser Jailer Active Window Instruction Manual
CEB00XXX-53-000 Page 3 of 12 Issue 7 19 January 2021
1 Declaration of Conformity
LASERMET LIMITED
Glaser Jailer – Active Laser Guarding Window
Part no. GLASER JAILER
DECLARATION OF CONFORMITY
This is to certify that Lasermet’s Glaser Jailer Active Laser Guarding Window System has been tested in accordance
with the following directives and standards and found to comply.
Lasermet certifies that this product complies with the basic requirements for health and safety as provided by the
following directives and standards:
Directives: Machinery Directive 2006/42/EC June 2010
Low Voltage Directive 2014/35/EU
EMC Directive 2014/30/EU
Standards: EN 60825-4:2006 +A2: 2011 Safety of Laser Products – Laser Guards
EN ISO 13849-1:2015 Safety of Machinery - Safety-related parts of Control Systems
EN 60947-1:2007 +A2:2014 Low Voltage Switchgear and Controlgear
EN 61010-1:2010 +A1:2016 Safety Requirements for Electrical Equipment
The Glaser Jailer Active Guarding Window System has a response time of 50ms and meets Performance Level ‘e’
(PLe) under EN ISO 13849-1.
The Active Guard Protection Times, in accordance with EN IEC 60825-4 are shown below.
The user must ensure that the Laser Termination Time is less than the Active Guard Protection Time to ensure
safety. The window must be installed with the active element between the laser and the passive filter window. Both
active window circuits must be connected to the interlock controller Dual Active Guard Board (01811-00-000) on an
ICS-6 System, or the Active Guard Monitor Board (01675-00-000) on ICS-6-OEM System.
Active Guard Response Time
Beam Area Average Irradiance Active Guard Protection Time
4 mm2 1.25 GW/m2 150 ms
4 mm2 250 MW/m2 700 ms
80 mm2 62 MW/m2 1 s
80 mm2 12 MW/m2 4 s
2000 mm2 2.5 MW/m2 8 s
2000 mm2 0.5 MW/m2 48 s
Supplier: Lasermet Limited, Lasermet House, 137 Hankinson Road,
Bournemouth BH9 1HR, Dorset, United Kingdom
Country of Origin: England
Date: 10 June 2019

Glaser Jailer Active Window Instruction Manual
CEB00XXX-53-000 Page 4 of 12 Issue 7 19 January 2021
LASERMET LIMITED
Passive Filter Window
Part no. FW-LM-1064-7
DECLARATION OF CONFORMITY
This is to certify that the Laser Protection Filter Window (Passive Filter Window) designated by Lasermet Part
Number FW-LM-1064-7 has been tested in accordance with the following directives and standards and found to
comply.
Lasermet certifies that this product complies with the basic requirements for health and safety as provided by the
following directives and standards:
Standards: EN 207:2009 +AC:2011
Essential Requirements according to
Annex II of the PPE Directive 89/686/EEC
Product Type: Laser Protection Filter Window – screen for laser working places
Material and Mechanical Properties: PMMA, Increased Robustness (S)
Wavelength Ratings
EN 207:2009 +AC:2011
180 - 315 D LB8 + IR LB4
> 315 - 380 D LB4 + IR LB6 + M LB6Y
915 - 1180 D LB6 + IR LB7
2720 - 2940 DI LB4
5000 - 11000 DI LB3
Supplier: Lasermet Limited,
Lasermet House
137 Hankinson Road
Bournemouth BH9 1HR
Dorset
United Kingdom
Country of Origin: England
Date: 10 June 2019

Glaser Jailer Active Window Instruction Manual
CEB00XXX-53-000 Page 5 of 12 Issue 7 19 January 2021
2 Safety Warnings
This device is intended to be used as part of a safety system which may be used to protect personnel
and equipment from possible injury, damage, or loss.
As such it must be installed and wired according to these instructions and tested by suitably qualified
persons. No attempt may be made to tamper with the parts, open them, or use them outside of the
parameters contained herein.
The units are only designed to be fixed to surfaces using their inbuilt fixing holes. They must not
come into contact with each other or any other moving part when in use. The parts should never be
subject to impact or mechanical strain.
Safety switches should never be defeated or bypassed. It is imperative that all steps are taken to
ensure that any spare actuators are made unavailable, such that they cannot be used to defeat the
switch or reduce the protection offered by the system in any way.

Glaser Jailer Active Window Instruction Manual
CEB00XXX-53-000 Page 6 of 12 Issue 7 19 January 2021
3 Concept
Lasermet’s Active Laser Window, called Glaser Jailer, detects a laser beam striking the window
surface and causes the laser beam to be turned off.
The system uses an inherently fail-safe laser detecting sensor panel. This is sandwiched between the
glass layers. The sensor is electrically connected to a monitoring and detection circuit board which is
fitted inside a Lasermet Interlock Control System (ICS). In addition, a passive protection layer is
provided.
The ICS-6 monitors the Active Window circuitry and other interlocked devices. The ICS-6 is
connected to the interlock connector on the laser to disable the laser beam if there is an inadvertent
laser strike on the window.
Because of the inherently fail-safe detection technique used, any failure of the sensor will also
disable the laser. There are no maximum or minimum beam diameter requirements and no
maximum or minimum laser power limits (very low power densities may not cause the system to trip
but they will also be too low to cause any damage to the sensor or pass through the passive
protection layer).
When the Active Window system is tripped, the monitoring and detection circuit latches off. The
window must be replaced, and the system manually reset in order to re-arm the system.
Every effort should be made in the first instance to reduce the risk of a laser beam striking the walls
or window. Careful alignment and setting-up should always be made prior to enabling the beam.

Glaser Jailer Active Window Instruction Manual
CEB00XXX-53-000 Page 7 of 12 Issue 7 19 January 2021
The Active Window system can disable a multi-kilowatt laser before the passive protection layer
fails. The function of the passive protection layer is to contain the laser beam for long enough to
allow the laser to be shut down. The Protection Time quoted in the Protective Exposure Limit (PEL)
specification is the minimum time for which the Window will contain the laser beam, at the quoted
PEL, after the control system has issued the shutdown command. The user must ensure that the
laser beam emission can be shut down within this time.
Lasermet provides a full range of laser interlock equipment including control systems, interlock
switches, illuminated warning signs, laser shutters, door locks, external power supplies etc. which
can be connected to provide a complete laser interlock system. Full support, design and installation
is available from Lasermet, please contact us for any queries. Contact details are given at the end of
this manual.
4 Wiring
The Active Window has four connections to the ICS-6 via the plug-in Active Window Interface Card.
These connect to the start and end of two conductive tracks on the window’s sensor panel. The
terminal blocks on the Active Window Interface Card are marked A and B to indicate the separate
circuits. The two circuits are interchangeable.
The Active Window is terminated in a 1m 4-core lead which is wired to the Active Window Interface
Card, via terminals, by the installer. The connections are as follows:
Cable Core
Window Track
ICS Input Pin
Marked
Red
A start
1
A
Yellow
B start
2
B
Blue
A end
3
A
Green
B end
4
B
5 Operation
Turn on the ICS power switch.
When all the relevant interlocked doors are closed the system may be armed, as follows:
ICS-6
Press the ‘Arm Laser’ button on the front of the ICS-6. The ICS-6 will briefly test the operation of the
active window interface by applying a simulated fault. If the associated safety relays do not open at
this point, the laser will not arm. If the relays open correctly, the test will cease and the simulated
fault will be removed. The ‘Laser Armed’ light will illuminate to indicate that the system is armed.

Glaser Jailer Active Window Instruction Manual
CEB00XXX-53-000 Page 8 of 12 Issue 7 19 January 2021
5.1 Laser Detection
If a powerful laser beam strikes the Active Window, the detection system in the interlock controller
will shut off the laser beam. The ‘hit’ is recorded by a Fault latch. The setting of this latch is indicated
on the front panel of the ICS, as follows:
ICS-6
A yellow light is illuminated next to the legend ‘Expansion’.
If this happens the system needs to be investigated and repaired prior to release of the fault latch.
Although it may be possible (though unlikely) to arm the laser after a laser strike to the window, it is
strongly recommended that a damaged window is repaired or replaced prior to any use of the laser.
6 Specifications
IEC 60825-4 Protective Exposure Limit
8900 x 540mm Active Window
For 450 – 1200 nm wavelength
Area
PEL
Active Guard Protection Time
4 mm2
5 GW/m2
0.5 s
2000 mm2
10 MW/m2
5 s
Note that the Active Guard Protection time is the time the window will contain the laser beam after
the Interlock Control System has issued the shutdown signal. Therefore, the laser must cease output
within 0.5 s of receiving the signal from the Lasermet Interlock Controller.
EN 13849-1 Performance Level
When included in ICS-6, the Active Window subsystem meets EN13849 PLe.

Glaser Jailer Active Window Instruction Manual
CEB00XXX-53-000 Page 9 of 12 Issue 7 19 January 2021
6.1 Filter Window Specification
Lasermet’s filter window for fibre lasers, FW-LM-1064-7, is amongst the best performing material
available today.
The material can be supplied to engineering drawings ready for assembly in sizes up to a maximum
of 600 x 800mm.
Laser Filter viewing windows enable processes to be viewed within a laser enclosure.
Specifications
Part No. FW-LM-1064-7
Wavelength 920 - 1175nm
Material Acrylic
Maximum Size 800 x 600
Thickness 3.5mm
Wavelength 1064
OD 7+
VLT 40%
Wavelength Ratings to relevant standards
EN 207:2009 +AC:2011
180 - 315 D LB8 + IR LB4
> 315 - 380 D LB4 + IR LB6 + M LB6Y
915 - 1180 D LB6 + IR LB7
2720 - 2940 DI LB4
5000 - 11000 DI LB3

Glaser Jailer Active Window Instruction Manual
CEB00XXX-53-000 Page 10 of 12 Issue 7 19 January 2021
EN 12254: 2010 +AC:2011
D AB8 + IR AB3 180 - 315
D AB5 + IR AB6 + M AB6Y > 315 - 380
D AB5 + IR AB7 915 - 1180
D AB2 2720 - 2940
D AB2 + I AB3 5000 – 11000
6.2 Dimensions
The active protection is effective only on the window area and not on the mounting flange. The
window is mounted with the flange on the outside of the laser enclosure.
Dimensions are approximate. Values given as ‘typical’ are average values measured across a number
of samples and are not guaranteed. Lasermet reserve the right to alter any specification without
prior notice.

Glaser Jailer Active Window Instruction Manual
CEB00XXX-53-000 Page 11 of 12 Issue 7 19 January 2021
6.3 Environmental Conditions
Operating and Storage: -10°C to +55°C 10% - 80% relative humidity non-condensing.
The window is intended for fixed indoor benign environments and should not be exposed to water
or moisture exceeding the above limits.
7 Warranty
Lasermet provide a 12-month warranty for defects in materials and manufacture, from the date of
installation or delivery. Installations completed by Lasermet are covered against defects in
workmanship for 12 months.
Damage or defects caused by other factors are not covered. For example, industrial contamination,
incorrect cleaning, storm damage. Consequential loss is not covered under warranty. Compensation
for indirect or direct loss or damage is expressly excluded. Rectification of the defects or a
replacement does not initiate a new warranty period.
For all deliveries, payments and other legal transactions, English law takes precedence for any
litigation.

Glaser Jailer Active Window Instruction Manual
CEB00XXX-53-000 Page 12 of 12 Issue 7 19 January 2021
8 Contact Details
Lasermet provide a full range of laser interlock equipment including interlock switches, illuminated
warning signs, laser shutters, entry keypads with built-in fail-safe override timer, door locks, external
power supplies etc. which can be interconnected to provide a complete system. We also supply
equipment and consultancy covering all aspects of laser safety. Full support, design, and installation
is available from Lasermet, please contact us for any queries.
For sales and technical support:
Lasermet Ltd.
Lasermet House,
137 Hankinson Road,
Bournemouth
BH9 1HR
United Kingdom.
Tel: [phone]
Fax: [phone]
Email: [email protected]om
Website: www.lasermet.com
Lasermet Inc.
10N Martingale Road, Suite 400,
Schaumburg, Illinois 60173
United States.
Tel: [phone]
Email: [email protected]
Website: www.lasermet.com
