Launch X431 V User manual

Version: V1.00.001
Revised date: 2014-07-15

LAUNCH X-431 V User’s Manual — Safety Precautions
Copyright Information
Copyright © 2014 by LAUNCH TECH. CO., LTD. All rights reserved. No part of
this publication may be reproduced, stored in a retrieval system, or transmitted
in any form or by any means, electronic, mechanical, photocopying, recording or
otherwise, without the prior written permission of LAUNCH. The information
contained herein is designed only for the use of this unit. LAUNCH is not
responsible for any use of this information as applied to other units.
Neither LAUNCH nor its affiliates shall be liable to the purchaser of this unit or
third parties for damages, losses, costs, or expenses incurred by purchaser or
third parties as a result of: accident, misuse, or abuse of this unit, or
unauthorized modifications, repairs, or alterations to this unit, or failure to strictly
comply with LAUNCH operating and maintenance instructions. LAUNCH shall
not be liable for any damages or problems arising from the use of any options or
any consumable products other than those designated as Original LAUNCH
Products or LAUNCHApproved Products by LAUNCH.
Trademark Information
LAUNCH is a registered trademark of LAUNCH TECH CO., LTD. (also called
LAUNCH for short) in China and other countries. All other LAUNCH trademarks,
service marks, domain names, logos, and company names referred to in this
manual are either trademarks, registered trademarks, service marks, domain
names, logos, company names of or are otherwise the property of LAUNCH or
its affiliates. In countries where any of the LAUNCH trademarks, service marks,
domain names, logos and company names are not registered, LAUNCH claims
other rights associated with unregistered trademarks, service marks, domain
names, logos, and company names. Other products or company names referred
to in this manual may be trademarks of their respective owners. You may not
use any trademark, service mark, domain name, logo, or company name of
LAUNCH or any third party without permission from the owner of the applicable
trademark, service mark, domain name, logo, or company name. You may
contact LAUNCH by visiting the website at www.cnlaunch.com, or writing to
LAUNCH TECH. CO., LTD.，Launch Industrial Park, North of Wuhe Avenue,
Banxuegang, Bantian, Longgang, Shenzhen, Guangdong, P.R.China, to request
written permission to use Materials on this manual for purposes or for all other
questions relating to this manual.
i

LAUNCH X-431 V User’s Manual — Safety Precautions
Safety Precautions
Before using X-431 V, please read the following safety information carefully.
Never collide, throw, or punch X-431 V, and avoid falling, extruding and
blending it.
Do not use X-431 V in exceptionally cold or hot, dusty, damp or dry
environments.
In places where X-431 V is forbidden or using X-431 V may cause
interference or generate a potential risk, please turn off it.
To ensure a safe driving, please do not use X-431 V while driving.
Turn off X-431 V before boarding any airplane.
Do not dismantle X-431 V by yourself. If there is any inquiry, please contact
the dealer.
Never place X-431 V into apparatus with strong electromagnetic field.
Keep X-431 V far away from magnetic devices because its radiations may
erase the data stored on the devices.
Store X-431 V out of reach of children and do not allow children to use it
unsupervised.
Please use the included battery and charger. Otherwise, explosion may
happen.
Do not disconnect power abruptly when X-431 V is being formatted or in
process of uploading or downloading. Or else it may result in program error.
Precautions on Using X-431 V
zThe ignition switch should be OFF while plugging or unplugging the
DBScar diagnostic connector.
zWhen DBScar connector is not used, remember to place it into the
diagnostic connector housing located at the back of the protection sleeve
to avoid loss.
zIf your vehicle keeps unattended for a week or a long period, it is
suggested to unplug the connector from vehicle’s DLC to save battery
power.
zWhile diagnosing a vehicle, you are not advised to use phone or
ii

LAUNCH X-431 V User’s Manual — Safety Precautions
messaging, because it may cause a data communication interruption. If it
happens, it is abnormal and just try to re-do it.
Precautions on Operating Vehicle’s ECU
zDo not disconnect the vehicle inner consumer when the ignition switch is
on. High voltage transients may encounter at the moment of disconnecting,
which may damage the sensors and the ECU.
zProtect the computer from magnetic object.
zDo cut off the power supply of ECU system before welding on the vehicle.
zPay more attention to the ECU and the sensors when the operation is next
to them.
zGround yourself when you disassemble PROM, otherwise ECU and
sensors will be damaged by static electricity.
zDo connect ECU harness connector firmly, otherwise electronic elements,
such as IC inside ECU, will be damaged.
iii
