Lauterbach AVR8 User manual

MANUAL
Release 02.2022
AVR8 Debugger

AVR8 Debugger | 2
©1989-2022 Lauterbach
AVR8 Debugger
TRACE32 Online Help
TRACE32 Directory
TRACE32 Index
TRACE32 Documents ...................................................................................................................... 
ICD In-Circuit Debugger ................................................................................................................ 
Processor Architecture Manuals .............................................................................................. 
AVR8 ......................................................................................................................................... 
AVR8 Debugger .................................................................................................................... 1
History ................................................................................................................................ 4
Warning .............................................................................................................................. 5
Introduction ....................................................................................................................... 6
Brief Overview of Documents for New Users 6
Demo and Start-up Scripts 7
Configuration ..................................................................................................................... 8
System Overview 8
Quick Start ......................................................................................................................... 9
Troubleshooting ................................................................................................................ 11
FAQ ..................................................................................................................................... 12
AVR Specific Implementations ........................................................................................ 13
Breakpoints 13
Software Breakpoints 13
On-chip Breakpoints for Instructions 13
On-chip Breakpoints for Data 13
Overwriting Fuse and Lock Bits 13
Memory Classes 14
Programming the On-chip FLASH of the megaAVR 15
Special Hints, Restrictions, and Known Problems 15
Restrictions 15
Known Problems 15
CPU specific SYStem Settings ......................................................................................... 16
SYStem.CONFIG.state Display target configuration 16
SYStem.CONFIG Configure debugger according to target topology 17
SYStem.CONFIG.DEBUGPORTTYPE Select debug port type 20
SYStem.CPU Select the used CPU 21

AVR8 Debugger | 3
©1989-2022 Lauterbach
SYStem.JtagClock Define JTAG clock 22
SYStem.LOCK Lock and tristate the debug port 22
SYStem.MemAccess Real-time memory access (non-intrusive) 23
SYStem.Mode Establish the communication with the target 24
SYStem.Option.IMASKASM Disable interrupts while single stepping 24
SYStem.Option.IMASKHLL Disable interrupts while HLL single stepping 25
CPU specific TrOnchip Commands .................................................................................26
TrOnchip.state Display on-chip trigger window 26
TrOnchip.CONVert Adjust range breakpoint in on-chip resource 26
TrOnchip.VarCONVert Adjust complex breakpoint in on-chip resource 27
TrOnchip.RESet Set on-chip trigger to default state 27
Connectors ........................................................................................................................ 28
Debug Connector 28
Mechanical Description of the 10-pin Debug Cable 28
Converter 10-pin JTAG to 6-pin SPI for AVR8 28
Converter 10-pin JTAG to 6-pin UPDI for AVR8 29
Converter 10-pin JTAG to 8-pin UPDI for AVR8 29

AVR8 Debugger | 4
©1989-2022 Lauterbach
AVR8 Debugger
Version 09-Mar-2022
History
30-Sep-20 Added descriptions for the commands SYStem.LOCK and SYStem.MemAccess
StopAndGo.

AVR8 Debugger | 5
©1989-2022 Lauterbach
Warning
WARNING: To prevent debugger and target from damage it is recommended to connect or
disconnect the debug cable only while the target power is OFF.
Recommendation for the software start:
1. Disconnect the debug cable from the target while the target power is
off.
2. Connect the host system, the TRACE32 hardware and the debug
cable.
3. Power ON the TRACE32 hardware.
4. Start the TRACE32 software to load the debugger firmware.
5. Connect the debug cable to the target.
6. Switch the target power ON.
7. Configure your debugger e.g. via a start-up script.
Power down:
1. Switch off the target power.
2. Disconnect the debug cable from the target.
3. Close the TRACE32 software.
4. Power OFF the TRACE32 hardware.

AVR8 Debugger | 6
©1989-2022 Lauterbach
Introduction
This manual serves as a guideline for debugging AVR8 cores and describes all processor-specific
TRACE32 settings and features.
Please keep in mind that only the Processor Architecture Manual (the document you are reading at the
moment) is CPU specific, while all other parts of the online help are generic for all CPUs supported by
Lauterbach. So if there are questions related to the CPU, the Processor Architecture Manual should be your
first choice.
Brief Overview of Documents for New Users
Architecture-independent information:
•“Training - Debugger Basics” (training_debugger.pdf): Get familiar with the basic features of a
TRACE32 debugger.
•“T32Start” (app_t32start.pdf): T32Start assists you in starting TRACE32 PowerView instances
for different configurations of the debugger. T32Start is only available for Windows.
•“General Commands” (general_ref_<x>.pdf): Alphabetic list of debug commands.
Architecture-specific information:
•“Processor Architecture Manuals”: These manuals describe commands that are specific for the
processor architecture supported by your debug cable. To access the manual for your processor
architecture, proceed as follows:
- Choose Help menu > Processor Architecture Manual.
• To get started with the most important manuals, use the Welcome to TRACE32! dialog
(WELCOME.view):

AVR8 Debugger | 7
©1989-2022 Lauterbach
Demo and Start-up Scripts
To search for PRACTICE scripts, do one of the following in TRACE32 PowerView:
• Type at the command line: WELCOME.SCRIPTS
• or choose File menu > Search for Script.
You can now search the demo folder and its subdirectories for PRACTICE start-up scripts
(*.cmm) and other demo software:
You can also inspect the demo folder manually in the system directory of TRACE32.
The ~~/demo/avr8/ folder contains:
compiler/ Hardware independent compiler examples.
flash/ Binaries for target based programming and example declarations
for internal flash.

AVR8 Debugger | 8
©1989-2022 Lauterbach
Configuration
System Overview
Example configuration for an AVR8 debugger.

POWER DEBUG USB INTERFACE / USB 3
POWER DEBUG INTERFACE / USB 3
PC or
Workstation
USB
Cable
Target
Debug
Connector
Debug Cable

AVR8 Debugger | 9
©1989-2022 Lauterbach
Quick Start
Starting up the debugger is done as follows:
1. Select the device prompt B (BDM debugger) and reset TRACE32.
The device prompt B:: is normally already selected in the TRACE32 command line. If this is not the
case, enter B:: to set the correct device prompt. The RESet command is only necessary if you do
not start directly after booting the TRACE32 development tool.
2. Set your connection type.
This command selects one of the two possible connections: JTAG or SPI.
3. Specify the CPU specific settings.
This command selects the CPU type.
4. Inform the debugger about the cashable address range (FLASH/EEPROM).
This is important to speed up the TRACE32 PowerView GUI responsiveness. The specified address
range will be accessed only once after a break, thus avoiding unnecessary memory accesses.
5. Reset the target and enter debug mode.
This command resets the CPU on the target, enables On-Chip-Debug Mode and issues a breakpoint
right after the reset interrupt routine.The CPU stops executing any instruction, and the user is able to
download and test the code. After this command is executed, it is possible to access memory and
registers.
B::
RESet
SYStem.CONFIG.DEBUGPORTTYPE JTAG|SPI|UPDI
SYStem.CPU ATMEGA1280
NOTE: For a multicore target it is most likely necessary to configure the multicore
settings using SYStem.CONFIG before continuing.
MAP.UpdateOnce p:0x8000--0xffff
SYStem.Mode Up

AVR8 Debugger | 10
©1989-2022 Lauterbach
6. Load the program into the flash..
A typical start sequence of the AVR8 is shown below. This sequence can be written to a PRACTICE script
file (*.cmm, ASCII format) and executed with the command DO <file>.
*) These commands open windows on the screen. The window position can be specified with the WinPOS
command.
DO ~~/demo/avr8/flash/atmegaxxx.cmm
B:: ; Select the ICD device prompt
RESet ; Reset the TRACE32 software
SYStem.CONFIG.DEBUGPORTTYPE
JTAG
; Select the connection type JTAG or SPI
or UPDI
MAP.UpdateOnce p:0x80000--
0xfffff
; Specify the address range for caching
WinCLEAR ; Clear all windows
SYStem.Up ; Reset the target and enter debug mode
DO
~~/demo/avr8/flash/atmegaxxx.
cmm
; Load the target application
; Set the stack pointer to address 8000
PER.view ; Show clearly arranged peripherals
; in window *)
List.Mix ; Open source code window *)
Register.view /SpotLight ; Open register window *)
Frame.view /Locals /Caller ; Open the stack frame with
; local variables *)
Var.Watch %SpotLight flags ast ; Open watch window for variables *)
Break.Set 0x1000 /Program ; Set software breakpoint to address
; 1000 (address 1000 is within RAM
; address range)
Break.Set 0x101000 /Program ; Set on-chip breakpoint
; to address 101000 (address 101000 is
; within Flash address range)

AVR8 Debugger | 11
©1989-2022 Lauterbach
Troubleshooting
Error Message Event Reason
Ta r g e t p o we r fa i l SYStem.Mode.Up See below.
Target processor in
reset
SYStem.Down See below.
Target not connected or
JTAG chain not
configured correctly:
Returned IR[1:0] != “01”
SYStem.Mode.Up
SYStem.Mode.Go
The debugger expects to receive the
bit sequence “01” for every command
that is sent over JTAG. If this is not the
case, an error message is displayed.
Check the JTAG connections.
The number of
<number> accessed
bytes in memory is not a
multiple of the access
size <size> bytes.
No special event Internal error, please consult your
Lauterbach representative.
Memory address
<address> is not aligned
to access size <size>.
No special event Internal error, please consult your
Lauterbach representative.
Invalid memory access
size: <size> bytes (@
address <address>)
No special event Internal error, please consult your
Lauterbach representative.
Memory access timeout:
Reading from address
<address>
No special event Corrupted JTAG connection. Check
JTAG hardware and settings.

AVR8 Debugger | 12
©1989-2022 Lauterbach
Typically the SYStem.Up command is the first command of a debug session where communication with
target is required. If you receive error messages like “debug port fail” or “debug port time out” while executing
this command, this may have the reasons below. “target processor in reset” is just a follow-up error
message.
• Open the AREA.view window to display all error messages.
• If the target has no power or the debug cable is not connected to the target, this results in the
error message “target power fail”.
• Did you select the correct core type with SYStem.CPU <cpu>?
• There is an issue with the JTAG interface. Maybe there is the need to set jumpers on the target to
connect the correct signals to the JTAG connector. The debugger will not work, for example, if
nTRST signal is directly connected to ground on target side.
• The target is in an unrecoverable state. Re-power your target and try again.
• The default JTAG clock speed is too fast. In this case try SYStem.JtagClock 50kHz and optimize
the speed when you got it working.
• The core is used in a multicore system and the appropriate multicore settings for the debugger
are missing. See for example SYStem.CONFIG IRPRE. This is the case if you get a value.
• The core has no clock.
• The core is kept in reset.
• There is a watchdog which needs to be deactivated.
FAQ
Please refer to our Frequently Asked Questions page on the Lauterbach website.

AVR8 Debugger | 13
©1989-2022 Lauterbach
AVR Specific Implementations
Breakpoints
Software Breakpoints
The Microchip megaAVR architecture does not support the software breakpoints.
On-chip Breakpoints for Instructions
The megaAVR MCUs support a total of four on-chip breakpoint registers which can be used as program
breakpoints to stop and debug the program which executes always in the Flash.
On-chip Breakpoints for Data
Data breakpoints are used to analyze the read and write accesses to global variables. The data breakpoints
can be triggered with respect to the data address or access type, i.e. read, write or both, or the data value.
The two instruction breakpoints of megaAVR MCUs can be used as data breakpoints
In case of an on-chip data breakpoint, every load and store instruction is checked with respect to the
breakpoint address, access type and the value. The data breakpoints are especially useful to find out when
a global variable is written with a certain value. It is not possible to implement a similar breakpoint in software
without affecting the real-time behavior of the system. Since the load and store instructions work on RAM,
data breakpoints always point to addresses on RAM.
Overwriting Fuse and Lock Bits
There are two options when overwriting the Fuse or Lock Bits. The preferred way is to use the periphery
window (i.e. PER command), where you can manually check and overwrite single bits using the standard
right-click and select method.
Optionally, you can modify the Fuse and Lock Bits with the PER.Set.simple command as given below:
SYStem.RESet
SYStem.Up
;Setting the LockBits
PER.Set.simple EE:0x200000 %Byte <8_bit_lock_bit_setting>
;Setting the FuseBits
PER.Set.simple EE:0x100000 %Long <24_bit_fuse_bit_setting>
SYStem.Down

AVR8 Debugger | 14
©1989-2022 Lauterbach
Memory Classes
The following memory access classes are available:
To access a memory class, write the class in front of the address. For example, use D to access the data
memory:
The memory class EE is used to denote the EEprom memory.
The following examples return different results, since the megaAVR architecture uses the Harvard
Architecture.
Access Class Description
DData
PProgram
EE EEprom
Data.dump D:0x00
Data.dump EE:0x00
Data.dump D:0x100
Data.dump P:0x100

AVR8 Debugger | 15
©1989-2022 Lauterbach
Programming the On-chip FLASH of the megaAVR
The PRACTICE script for programming of the on-chip FLASH of the megaAVR can be found in the
TRACE32 demo folder ~~/demo/avr8/flash/atmegaxxx.cmm.
Please be aware that this is just an example script. The scripts has to be adapted to your memory layout,
specifically the flash and EEprom sector size must be checked.
Special Hints, Restrictions, and Known Problems
Restrictions
•JTAG: Runtime counter causes about 6 ms mismatch.
Known Problems
•JTAG: Help system not available yet.
NOTE: All problems will be fixed in one of the next SW versions without notice!

AVR8 Debugger | 16
©1989-2022 Lauterbach
CPU specific SYStem Settings
SYStem.CONFIG.state Display target configuration
Opens the SYStem.CONFIG.state window, where you can view and modify most of the target
configuration settings. The configuration settings tell the debugger how to communicate with the chip on
the target board and how to access the on-chip debug and trace facilities in order to accomplish the
debugger’s operations.
Alternatively, you can modify the target configuration settings via the TRACE32 command line with the
SYStem.CONFIG commands. Note that the command line provides additional SYStem.CONFIG
commands for settings that are not included in the SYStem.CONFIG.state window.
Format: SYStem.CONFIG.state [/<tab>]
<tab>:DebugPort |Jtag
<tab> Opens the SYStem.CONFIG.state window on the specified tab. For tab
descriptions, see below.
DebugPort Informs the debugger about the debug connector type and the
communication protocol it shall use.
Jtag Informs the debugger about the position of the Test Access Ports (TAP) in
the JTAG chain which the debugger needs to talk to in order to access the
debug and trace facilities on the chip.

AVR8 Debugger | 17
©1989-2022 Lauterbach
SYStem.CONFIG Configure debugger according to target topology
If there is more than one TAP controller in the JTAG chain, the chain must be defined to be able to access
the right TAP controller.
The four parameters IRPRE, IRPOST, DRPRE, DRPOST are required to inform the debugger of the TAP
controller position in the JTAG chain if there is more than one core in the JTAG chain. The information is
required before the debugger can be activated, e.g., by a SYStem.Up.
TriState has to be used if several debuggers are connected to a common JTAG port at the same time.
TAPState and TCKLevel define the TAP state and TCK level which is selected when the debugger switches
to tristate mode. Please note: nTRST must have a pull-up resistor on the target, TCK can have a pull-up or
pull-down resistor, other trigger inputs need to be kept in inactive state.
Format: SYStem.CONFIG <parameter>
<parameter>:IRPRE <bits>
IRPOST<bits>
DRPRE <bits>
DRPOST <bits>
IRLength <bits>
MultiCoreLocal [ON | OFF]
CoreNumber <number>
TriState [ON | OFF]
Slave [ON | OFF]
TAPState <state>
TCKLevel <level>
DRPRE (default: 0) <number> of TAPs in the JTAG chain between the core of
interest and the TDO signal of the debugger. If each core in the system
contributes only one TAP to the JTAG chain, DRPRE is the number of
cores between the core of interest and the TDO signal of the debugger.
DRPOST (default: 0) <number> of TAPs in the JTAG chain between the TDI signal
of the debugger and the core of interest. If each core in the system
contributes only one TAP to the JTAG chain, DRPOST is the number of
cores between the TDI signal of the debugger and the core of interest.
IRPRE (default: 0) <number> of instruction register bits in the JTAG chain
between the core of interest and the TDO signal of the debugger. This is
the sum of the instruction register length of all TAPs between the core of
interest and the TDO signal of the debugger.
IRPOST (default: 0) <number> of instruction register bits in the JTAG chain
between the TDI signal and the core of interest. This is the sum of the
instruction register lengths of all TAPs between the TDI signal of the
debugger and the core of interest.
See also Daisy-Chain Example.

AVR8 Debugger | 18
©1989-2022 Lauterbach
CoreNumber <number> of cores in a shared-memory or local-memory multicore
system. (default: 1)
TriState [ON | OFF] The debugger switches to tristate mode after each debug port access. If
several debuggers share the same debug port, this option is required.
Then other debuggers can access the port. (default: OFF)
Slave [ON | OFF] Defines the master in a multicore chip. Only one core can be the master
of the chip reset, the TAP reset and the chip initialization features. All
other cores are slave cores. (default: OFF)
TAPState This is the state of the TAP controller when the debugger switches to
tristate mode. All states of the JTAG TAP controller are selectable.
(default: 7 = Select-DR-Scan)
TCKLevel [0| 1] Level of TCK signal when all debuggers are tristated. (default: 0)

AVR8 Debugger | 19
©1989-2022 Lauterbach
Daisy-Chain Example
Daisy chains can be configured using a PRACTICE script (*.cmm) or the SYStem.CONFIG.state window.
Example: This script explains how to obtain the individual IR and DR values for the above daisy chain.
SYStem.CONFIG.state /Jtag ; optional: open the window
SYStem.CONFIG IRPRE 6. ; IRPRE: There is only one TAP.
; So type just the IR bits of TAP4, i.e. 6.
SYStem.CONFIG IRPOST 12. ; IRPOST: Add up the IR bits of TAP1, TAP2
; and TAP3, i.e. 4. + 3. + 5. = 12.
SYStem.CONFIG DRPRE 1. ; DRPRE: There is only one TAP which is
; in BYPASS mode.
; So type just the DR of TAP4, i.e. 1.
SYStem.CONFIG DRPOST 3. ; DRPOST: Add up one DR bit per TAP which
; is in BYPASS mode, i.e. 1. + 1. + 1. = 3.
; This completes the configuration.
NOTE: In many cases, the number of TAPs equals the number of cores. But in many
other cases, additional TAPs have to be taken into account; for example, the
TAP of an FPGA or the TAP for boundary scan.
Core
IRPOST IRPRE
4
1
TAP1
IR
DR
3
1
TAP2
IR
DR
5
1
TAP3
IR
DR
6
1
TAP4
IR
DR
TDI TDO
DRPOST DRPRE
IR: Instruction register length DR: Data register length Core: The core you want to debug

AVR8 Debugger | 20
©1989-2022 Lauterbach
TapStates
SYStem.CONFIG.DEBUGPORTTYPE Select debug port type
Specifies the used debug port type “JTAG” or “SPI”. It assumes the selected type is supported by the
target.
0 Exit2-DR
1 Exit1-DR
2 Shift-DR
3 Pause-DR
4 Select-IR-Scan
5 Update-DR
6Capture-DR
7Select-DR-Scan
8 Exit2-IR
9 Exit1-IR
10 Shift-IR
11 Pause-IR
12 Run-Test/Idle
13 Update-IR
14 Capture-IR
15 Test-Logic-Reset
Format: SYStem.CONFIG.DEBUGPORTTYPE [<type>]
<type>:JTAG |SPI | UPDI
