Lauterbach TRACE32 User manual

MANUAL
Release 02.2022
Meta Debugger

Meta Debugger | 2
©1989-2022 Lauterbach
Meta Debugger
TRACE32 Online Help
TRACE32 Directory
TRACE32 Index
TRACE32 Documents ...................................................................................................................... 
ICD In-Circuit Debugger ................................................................................................................ 
Processor Architecture Manuals .............................................................................................. 
Meta .......................................................................................................................................... 
Meta Debugger ..................................................................................................................... 1
Introduction ....................................................................................................................... 5
Brief Overview of Documents for New Users 5
Demo and Start-up Scripts 6
Warning .............................................................................................................................. 7
Quick Start of the Debugger ............................................................................................. 8
Troubleshooting ................................................................................................................ 10
Communication between Debugger and Processor can not be established 10
FAQ ..................................................................................................................................... 10
Meta specific Implementations ........................................................................................ 11
Meta Configuration 11
Access Classes 12
Breakpoints 13
Software Breakpoints 13
On-chip Breakpoints 13
On-chip Watchpoints 13
SYStem.CONFIG Configure debugger according to target topology 15
<parameters> describing the “DebugPort” 16
<parameters> describing the “JTAG” scan chain and signal behavior 18
SYStem.CONFIG.state Display target configuration 21
SYStem.CPU Select the used CPU 21
SYStem.JtagClock Define JTAG frequency 21
SYStem.LOCK Lock and tristate the debug port 22
SYStem.MemAccess Run-time memory access (non-intrusive) 23
SYStem.Mode Establish communication with target 24
SYStem.Option.IMASKASM Disable interrupts while single stepping 24
SYStem.Option.IMASKHLL Disable interrupts while HLL single stepping 26
SYStem.Option.MINIM Map execution- to storage address range 26

Meta Debugger | 3
©1989-2022 Lauterbach
SYStem.state Display SYStem.state window 26
TrOnchip.RESet Set on-chip trigger to default state 27
TrOnchip.state Display on-chip trigger window 27
Target Adaption ................................................................................................................. 28
Interface Standards JTAG, Serial Wire Debug, cJTAG 28
Connector Type and Pinout 28
Debug Cable 28

Meta Debugger | 4
©1989-2022 Lauterbach
Meta Debugger
Version 09-Mar-2022

Meta Debugger | 5
©1989-2022 Lauterbach
Introduction
This manual serves as a guideline for debugging Meta cores and describes all processor-specific
TRACE32 settings and features.
Please keep in mind that only the Processor Architecture Manual (the document you are reading at the
moment) is CPU specific, while all other parts of the online help are generic for all CPUs supported by
Lauterbach. So if there are questions related to the CPU, the Processor Architecture Manual should be your
first choice.
Brief Overview of Documents for New Users
Architecture-independent information:
•“Training - Debugger Basics” (training_debugger.pdf): Get familiar with the basic features of a
TRACE32 debugger.
•“T32Start” (app_t32start.pdf): T32Start assists you in starting TRACE32 PowerView instances
for different configurations of the debugger. T32Start is only available for Windows.
•“General Commands” (general_ref_<x>.pdf): Alphabetic list of debug commands.
Architecture-specific information:
•“Processor Architecture Manuals”: These manuals describe commands that are specific for the
processor architecture supported by your Debug Cable. To access the manual for your processor
architecture, proceed as follows:
- Choose Help menu > Processor Architecture Manual.
•“OS Awareness Manuals” (rtos_<os>.pdf): TRACE32 PowerView can be extended for operating
system-aware debugging. The appropriate OS Awareness manual informs you how to enable the
OS-aware debugging.
To get started with the most important manuals, use the Welcome to TRACE32! dialog (WELCOME.view):

Meta Debugger | 6
©1989-2022 Lauterbach
Demo and Start-up Scripts
Lauterbach provides ready-to-run start-up scripts for known Meta-based hardware.
To search for PRACTICE scripts, do one of the following in TRACE32 PowerView:
• Type at the command line: WELCOME.SCRIPTS
• or choose File menu > Search for Script.
You can now search the demo folder and its subdirectories for PRACTICE start-up scripts
(*.cmm) and other demo software:
You can also inspect the demo folder manually in the system directory of TRACE32.
The ~~/demo/meta/ folders contain:
hardware/ Ready-to-run debugging and flash programming demos for
evaluation boards. Recommended for getting started!

Meta Debugger | 7
©1989-2022 Lauterbach
Warning
WARNING: To prevent debugger and target from damage it is recommended to connect or
disconnect the Debug Cable only while the target power is OFF.
Recommendation for the software start:
1. Disconnect the Debug Cable from the target while the target power is
off.
2. Connect the host system, the TRACE32 hardware and the Debug
Cable.
3. Power ON the TRACE32 hardware.
4. Start the TRACE32 software to load the debugger firmware.
5. Connect the Debug Cable to the target.
6. Switch the target power ON.
7. Configure your debugger e.g. via a start-up script.
Power down:
1. Switch off the target power.
2. Disconnect the Debug Cable from the target.
3. Close the TRACE32 software.
4. Power OFF the TRACE32 hardware.

Meta Debugger | 8
©1989-2022 Lauterbach
Quick Start of the Debugger
Starting up the debugger is done as follows:
1. Reset the debugger.
The RESet command is only necessary if you do not start directly after booting the TRACE32
development tool.
2. Set the target CPU to configure the debugger.
The default values of all other options are set in such a way that it should be possible to work without
modifications. Please consider that this may not be the best configuration for your target.
3. Establish the communication to the target.
This command resets the target and tries to stop it. After this command is executed, it is possible to
access memory and registers.
4. Load the program into the memory.
A typical start sequence is shown below. This sequence can be written to a PRACTICE script file (*.cmm,
ASCII format) and executed with the command DO <file>.
RESet
SYStem.CPU <cpu>
SYStem.Up
Data.LOAD.Elf sieve.elf ; .ELF specifies the file format
; sieve.elf is the file name
RESet ; Reset the debugger
System.CPU META-MTP ; Set target CPU, here the generic
; META-MTP to configure the debugger
SYStem.Up ; Establish communication to target
Data.LOAD.Elf sieve.elf ; Load the application program
WinCLEAR ; Remove all windows
List.Mix ; Open source window *)
Register.view ; Open register window *)

Meta Debugger | 9
©1989-2022 Lauterbach
*) These commands open windows on the screen. The window position can be specified with the WinPOS
command.

Meta Debugger | 10
©1989-2022 Lauterbach
Troubleshooting
Communication between Debugger and Processor can not be established
Typically the SYStem.Up command is the first command of a debug session where communication with the
target is required. If you receive error messages like “debug port fail” or “debug port time out” while executing
this command, this may have the reasons described below. “target processor in reset” is just a follow-up
error message. Open the AREA.view window to view all error messages.
• The target has no power or the debug cable is not connected to the target or the target reference
voltage is not connected to the debug connector. This results in the error message “target power
fail”.
• The target is in reset.
• The target is in an unrecoverable state. Re-power your target and try again.
• You have selected the incorrect CPU with SYStem.CPU.
• There is an issue with the JTAG interface. See “ARM JTAG Interface Specifications”
(app_arm_jtag.pdf) and the manuals or schematic of your target to check the physical and
electrical interface. Maybe there is the need to set jumpers on the target to connect the correct
signals to the JTAG connector.
• The default JTAG clock speed is too fast, especially if you emulate your core or if you use an
FPGA-based target. In this case try SYStem.JtagClock 50kHz and optimize the speed when you
got it working.
• You might have several TAP controllers in a JTAG-chain. Example: You have a multicore system
with chained TAPs. In this case you have to check your pre- and post-bit configuration. See
SYStem.CONFIG IRPRE or SYStem.CONFIG DRPRE.
FAQ
Please refer to our Frequently Asked Questions page on the Lauterbach website.

Meta Debugger | 11
©1989-2022 Lauterbach
Meta specific Implementations
Meta Configuration
For code compression the Meta architecture provides a so-called MiniM instruction set. But unlike to other
architectures the HLL debug information are not created for this reduced -, but for the expanded program
code. So the Meta tool chain creates an additional output file with the extension *.ldr which includes the
Minim code without debug information and a storage address which is different to the linker execution
address.
This file must be loaded with the command Data.load.LDR <file_name> which will also enable the MiniM
operating mode in the Core, by setting the MinimEnable flag in the TXPRIVEXT register.
To provide HLL debugging capabilities for this concept the T32 Lauterbach SW is reading the MiniM
opcodes from the storage- and encodes it to the linker execution address. The HLL debug information are
disposed by additionally loading the referring *.elf file with the /NoCODE option. To get this working the
storage and execution memory range must be declared by the System.Option.MINIM command. HLL
debugging is working as usual and breakpoints are automatically mapped to storage memory.
NOTE: Loading the *.elf file code, compiled for MiniM usage, to the target will fail,
because tit is linked in a way that parts of the instruction memory will be
overloaded by the .data section!

Meta Debugger | 12
©1989-2022 Lauterbach
Access Classes
Access classes are used to specify which memory to access. For background information about the term
access class, see “TRACE32 Glossary” (glossary.pdf).
The following common access classes have the same meaning for all CPUs of the Meta architecture.
To perform an access with a certain access class, write the class in front of the address.
Examples:
Access Class Description
P Program or data memory access. Target implementation defined.
D Data memory access
R0A Data Unit D0 DSP RAM Block A.
R0B Data Unit D0 DSP RAM Block B.
R1A Data Unit D1 DSP RAM Block A.
R1B Data Unit D1 DSP RAM Block B.
DBG Special, virtual memory. Target implementation defined.
E Prefix: Run-time access specifier.
VM Virtual Memory. Memory on the debug host system.
List P:0x80000
List EP:0x120000
Data.dump D:0x4--0x7
PRINT Data.Long(R0B:0x6)

Meta Debugger | 13
©1989-2022 Lauterbach
Breakpoints
For general information about setting breakpoints, refer to the Break.Set command.
Software Breakpoints
If a software breakpoint is used, the original code at the breakpoint location is temporarily patched by a
breakpoint code (Meta switch instruction). There is no restriction in the number of software breakpoints.
Software breakpoints are break before make.
On-chip Breakpoints
If on-chip breakpoints are used, the resources to set the breakpoints are provided by the hardware of the
core itself. The Meta supports up to 8 program on-chip breakpoints. The debugger is able to detect the
number of available on-chip breakpoints by analyzing the contents of the Meta core revision register.
If programmed, the breakpoint hardware compares its breakpoint address and the current program counter.
If they are equal, a breakpoint exception is raised which in general will set the Meta core into debug mode.
On-chip breakpoints are break before make.
Examples:
On-chip Watchpoints
If on-chip watchpoints are used, the resources to set the watchpoints are provided by the hardware of the
core itself. The Meta supports up to 8 data on-chip watchpoints. The debugger is able to detect the number
of available on-chip watchpoints by analyzing the contents of the Meta core revision register.
On-chip watchpoints compare their programmed address and their read, write or read-write access
condition with addresses of load and store instructions. If addresses and conditions match, a watchpoint
exception is raised which in general will set the M core into debug mode. On-chip watchpoints are break
before make.
In TRACE32, the on-chip watchpoint functionality is mapped to data address breakpoints. That means to set
a watchpoint, the Break.Set command is used in conjunction with the Read, Write or ReadWrite options.
Break.Set 0x80000024 /Program
/Onchip
; Configures an on-chip breakpoint
; which activates when the program
; counter matches 0x80000024
Break.Set 0x80000024 /Onchip ; Same as above, since the default
; for breakpoints is /Program

Meta Debugger | 14
©1989-2022 Lauterbach
Examples:
Break.Set 0x80001000 /Read /Onchip ; Configures an on-chip read
; watchpoint which activates when
; a load instruction accesses
; address 0x80001000
Break.Set 0x80001000 /Read ; Same as above, since read
; breakpoints are always on-chip
Break.Set 0x80001000 /Write ; Write watchpoint for store
; instructions
Break.Set 0x80001000 /ReadWrite ; ReadWrite watchpoint for load and
; store instructions

Meta Debugger | 15
©1989-2022 Lauterbach
SYStem.CONFIG Configure debugger according to target topology
The SYStem.CONFIG commands inform the debugger about the available on-chip debug and trace
components and how to access them.
The SYStem.CONFIG command information shall be provided after the SYStem.CPU command, which
might be a precondition to enter certain SYStem.CONFIG commands, and before you start up the debug
session, e.g. by SYStem.Up.
Syntax Remarks
The commands are not case sensitive. Capital letters show how the command can be shortened.
Example: “SYStem.CONFIG.TriState ON” -> “SYStem.CONFIG.TS ON”
The dots after “SYStem.CONFIG” can alternatively be a blank.
Example:
“SYStem.CONFIG.TriState ON” or “SYStem.CONFIG TriState ON”
Format: SYStem.CONFIG <parameter>
<parameter>:
(DebugPort)
CORE <core> <chip>
DEBUGPORT [DebugCable0]
DEBUGPORTTYPE [JTAG]
Slave [ON | OFF]
TriState [ON | OFF]
<parameter>:
(JTAG)
DRPOST <bits>
DRPRE <bits>
IRPOST <bits>
IRPRE <bits>
Slave [ON | OFF]
TAPState <state>
TCKLevel <level>
TriState [ON | OFF]

Meta Debugger | 16
©1989-2022 Lauterbach
<parameters> describing the “DebugPort”
CORE <core>
<chip>
The command helps to identify debug and trace resources which are
commonly used by different cores. The command might be required in a
multicore environment if you use multiple debugger instances (multiple
TRACE32 PowerView GUIs) to simultaneously debug different cores on
the same target system.
Because of the default setting of this command
debugger#1: <core>=1 <chip>=1
debugger#2: <core>=1 <chip>=2
...
each debugger instance assumes that all notified debug resources can
exclusively be used.
But some target systems have shared resources for different cores, for
example a common trace port. The default setting causes that each
debugger instance controls the same trace port. Sometimes it does not
hurt if such a module is controlled twice. But sometimes it is a must to tell
the debugger that these cores share resources on the same <chip>.
Whereby the “chip” does not need to be identical with the device on your
target board:
debugger#1: <core>=1 <chip>=1
debugger#2: <core>=2 <chip>=1
CORE <core>
<chip>
(cont.)
For cores on the same <chip>, the debugger assumes that the cores
share the same resource if the control registers of the resource have the
same address.
Default:
<core> depends on CPU selection, usually 1.
<chip> derives from the CORE= parameter in the configuration file
(config.t32), usually 1. If you start multiple debugger instances with the
help of t32start.exe, you will get ascending values (1, 2, 3,...).
DEBUGPORT
[DebugCable0]
It specifies which probe cable shall be used e.g. “DebugCable0”.
Default: depends on detection.
DEBUGPORTTYPE
[JTAG]
It specifies the used debug port type “JTAG”. It assumes the selected
type is supported by the target.
Default: JTAG.

Meta Debugger | 17
©1989-2022 Lauterbach
Slave [ON | OFF] If several debuggers share the same debug port, all except one must
have this option active.
JTAG: Only one debugger - the “master” - is allowed to control the signals
nTRST and nSRST (nRESET). The other debuggers need to have the
setting Slave OFF.
Default: OFF.
Default: ON if CORE=... >1 in the configuration file (e.g. config.t32).
TriState [ON | OFF] TriState has to be used if several debug cables are connected to a common
JTAG port. TAPState and TCKLevel define the TAP state and TCK level
which is selected when the debugger switches to tristate mode.
Please note:
• nTRST must have a pull-up resistor on the target.
• TCK can have a pull-up or pull-down resistor.
• Other trigger inputs need to be kept in inactive state.
Default: OFF.

Meta Debugger | 18
©1989-2022 Lauterbach
<parameters> describing the “JTAG” scan chain and signal behavior
With the JTAG interface you can access a Test Access Port controller (TAP) which has implemented a state
machine to provide a mechanism to read and write data to an Instruction Register (IR) and a Data Register
(DR) in the TAP. The JTAG interface will be controlled by 5 signals:
• nTRST(reset)
• TCK (clock)
• TMS (state machine control)
• TDI (data input)
• TDO (data output)
Multiple TAPs can be controlled by one JTAG interface by daisy-chaining the TAPs (serial connection). If you
want to talk to one TAP in the chain, you need to send a BYPASS pattern (all ones) to all other TAPs. For this
case the debugger needs to know the position of the TAP it wants to talk to. The TAP position can be defined
with the first four commands in the table below.
DRPOST <bits> Defines the TAP position in a JTAG scan chain. Number of TAPs in the
JTAG chain between the TDI signal and the TAP you are describing. In
BYPASS mode, each TAP contributes one data register bit. See example
below.
Default: 0.
DRPRE <bits> Defines the TAP position in a JTAG scan chain. Number of TAPs in the
JTAG chain between the TAP you are describing and the TDO signal. In
BYPASS mode, each TAP contributes one data register bit. See example
below.
Default: 0.
IRPOST <bits> Defines the TAP position in a JTAG scan chain. Number of Instruction
Register (IR) bits of all TAPs in the JTAG chain between TDI signal and
the TAP you are describing. See example below.
Default: 0.
IRPRE <bits> Defines the TAP position in a JTAG scan chain. Number of Instruction
Register (IR) bits of all TAPs in the JTAG chain between the TAP you are
describing and the TDO signal. See example below.
Default: 0.
NOTE: If you are not sure about your settings concerning IRPRE, IRPOST, DRPRE,
and DRPOST, you can try to detect the settings automatically with the
SYStem.DETECT.DaisyChain command.

Meta Debugger | 19
©1989-2022 Lauterbach
Slave [ON | OFF] If several debuggers share the same debug port, all except one must
have this option active.
JTAG: Only one debugger - the “master” - is allowed to control the signals
nTRST and nSRST (nRESET). The other debuggers need to have the
setting Slave OFF.
Default: OFF.
Default: ON if CORE=... >1 in the configuration file (e.g. config.t32).
TAPState <state> This is the state of the TAP controller when the debugger switches to
tristate mode. All states of the JTAG TAP controller are selectable.
0 Exit2-DR
1 Exit1-DR
2 Shift-DR
3 Pause-DR
4 Select-IR-Scan
5 Update-DR
6 Capture-DR
7 Select-DR-Scan
8 Exit2-IR
9 Exit1-IR
10 Shift-IR
11 Pause-IR
12 Run-Test/Idle
13 Update-IR
14 Capture-IR
15 Test-Logic-Reset
Default: 7 = Select-DR-Scan.
TCKLevel <level> Level of TCK signal when all debuggers are tristated. Normally defined
by a pull-up or pull-down resistor on the target.
Default: 0.
TriState [ON | OFF] TriState has to be used if several debug cables are connected to a common
JTAG port. TAPState and TCKLevel define the TAP state and TCK level
which is selected when the debugger switches to tristate mode.
Please note:
• nTRST must have a pull-up resistor on the target.
• TCK can have a pull-up or pull-down resistor.
• Other trigger inputs need to be kept in inactive state.
Default: OFF.

Meta Debugger | 20
©1989-2022 Lauterbach
Daisy-Chain Example
Daisy chains can be configured using a PRACTICE script (*.cmm) or the SYStem.CONFIG.state window.
Example: This script explains how to obtain the individual IR and DR values for the above daisy chain.
SYStem.CONFIG.state /Jtag ; optional: open the window
SYStem.CONFIG IRPRE 6. ; IRPRE: There is only one TAP.
; So type just the IR bits of TAP4, i.e. 6.
SYStem.CONFIG IRPOST 12. ; IRPOST: Add up the IR bits of TAP1, TAP2
; and TAP3, i.e. 4. + 3. + 5. = 12.
SYStem.CONFIG DRPRE 1. ; DRPRE: There is only one TAP which is
; in BYPASS mode.
; So type just the DR of TAP4, i.e. 1.
SYStem.CONFIG DRPOST 3. ; DRPOST: Add up one DR bit per TAP which
; is in BYPASS mode, i.e. 1. + 1. + 1. = 3.
; This completes the configuration.
NOTE: In many cases, the number of TAPs equals the number of cores. But in many
other cases, additional TAPs have to be taken into account; for example, the
TAP of an FPGA or the TAP for boundary scan.
Core
IRPOST IRPRE
4
1
TAP1
IR
DR
3
1
TAP2
IR
DR
5
1
TAP3
IR
DR
6
1
TAP4
IR
DR
TDI TDO
DRPOST DRPRE
IR: Instruction register length DR: Data register length Core: The core you want to debug
