LAZBOY Colton User manual

Colton 4pc Seating Set
Owner’s Manual
If you have any problems with this product, DO NOT RETURN IT TO THE
STORE. CALL OUR CUSTOMER SERVICE HOT-LINE AT
855-561-6913
Monday – Thursday, 8AM-
5PM (EST) Friday, 8AM-4PM
(EST)
La-Z-Boy® is a registered trademark of La-Z-Boy Incorporated and is used under license
to BJI, Inc.
© 2017 La-Z-Boy Incorporated.

This product is not intended for commercial use and is for residential use only. All warranties are limited and
apply to the original purchase only. Proof of purchase is required.
Please visit us at www.LaZboyOutdoor.com. There you can review our full warranty details and other
helpful information. Or, you may call us at 855-561-6913, 8am-5pm (EST), Monday-Thursday, 8am-4pm
(EST), Friday.
Care and Maintenance
Be careful to never allow water to build up in frames as this will cause corrosion and freeze damage in cold
climates. Wash all frames with a solution of mild soap and water. Rinse with clean water and dry with a soft
absorbent cloth towel. Frames can be treated with a liquid wax for maximum protection against UV rays and/or
salty damp air. If your set includes cushions, slings, and/or an umbrella they may be cleaned by hand with a
solution of soap and water with a clean water rinse. (Never machine wash cushions, slings or umbrella covers
as this will result in shrinkage or damage).
After cleaning cushions tip on end and allow to drip dry. (Never use a commercial or home dryer to tumble dry
fabric goods). Do not use bleach or solvents to clean any product! This will void the warranty.
Lack of original receipt will void warranty!
CAUTION: Read all the instructions before assembly. Failure to do so may result in faulty assembly and potential
injury! Assemble product on a soft, non-abrasive surface such as a carpet or cardboard to avoid damaging the
item. Seek assistance to assemble bulky or heavy items. After final alignment, make sure all bolts and nuts are
securely tightened with screw head covers pressed in place.
Note: Do not allow children to play with plastic wraps or small parts to prevent potential choking hazard.
PART LIST
PARTS NO. PARTS NAME PARTS QTY
A
Table top
1
B Table leg 2
C Leg connector 2
D
Allen/Hex head bolt
M6 X 15
12
E
Washer
M6
12

F
Allen wrench
4mm
1
G
Plastic cap
12
Assembly Steps:
Step 1: Attach leg connector to table leg with bolts and washer. Cover bolts with bolt caps. (Figure 1)
Figure 1

Step 2: Attach table leg to table with bolts and washer. Cover bolts withbolt caps. (Figure 2)
Figure 2
Step 3: Position the table by turning it upright. After final alignment, make sure all bolts and nuts are securely
tightened with screw head covers pressed in place. (Figure 3)
Figure 3

Page 2 of 4

Page 1 of 5
Colton 4pc Seating Set
Owner’s Manual
If you have any problems with this product, DO NOT RETURN IT TO THE STORE.
CALL OUR CUSTOMER SERVICE HOT-LINE AT
855-561-6913
Monday – Thursday, 8AM-5PM (EST)
Friday, 8AM-4PM (EST)
La-Z-Boy® is a registered trademark of La-Z-Boy Incorporated and is used under license to BJI, Inc.
© 2017 La-Z-Boy Incorporated.

Page 2 of 5
This product is not intended for commercial use and is for residential use only. All warranties are limited and
apply to the original purchase only. Proof of purchase is required. Please visit us at www.LaZboyOutdoor.com.
There you can review our full warranty details and other helpful information. Or, you may call us at 855-561-
6913, 8am-5pm (EST), Monday-Thursday, 8am-4pm (EST), Friday.
Care and Maintenance
Be careful to never allow water to build up in frames as this will cause corrosion and freeze damage in cold climates. Wash all
frames with a solution of mild soap and water. Rinse with clean water and dry with a soft absorbent cloth towel. Frames can be
treated with a liquid wax for maximum protection against UV rays and/or salty damp air. If your set includes cushions, slings,
and/or an umbrella they may be cleaned by hand with a solution of soap and water with a clean water rinse. (Never machine
wash cushions, slings or umbrella covers as this will result in shrinkage or damage).
After cleaning cushions tip on end and allow to drip dry. (Never use a commercial or home dryer to tumble dry fabric goods).
Do not use bleach or solvents to clean any product! This will void the warranty.
Lack of original receipt will void warranty!
CAUTION: Read all the instructions before assembly. Failure to do so may result in faulty assembly and potential injury!
Assemble product on a soft, non-abrasive surface such as a carpet or cardboard to avoid damaging the item. Seek assistance to
assemble bulky or heavy items. After final alignment, make sure all bolts and nuts are securely tightened with screw head covers
pressed in place.
Note: Do not allow children to play with plastic wraps or small parts to prevent potential choking hazard.
PART LIST
PARTS NO. PARTS NAME PARTS QTY
A
Loveseat
frame
1
B Seat 1
C Seat cushion 2
D Back cushion 2

Page 3 of 5
E Pillow 2
F
Allen/Hex head bolt
M6*20
5
G
Allen/Hex head bolt
M6*35
2
H
Washer M6
7
I
Allen wrench
4mm
1
J
Plastic cap
7

Page 4 of 5
Assembly Steps:
Step 1: Attach legs to chair with bolts and washer. Cover bolts with bolt caps. (Figure 1)
Figure 1

Page 5 of 5
Step 2: Position the chair by turning it upright. After final alignment, make sure all bolts and nuts are securely
tightened with screw head covers pressed in place. (Figure 2)
Figure 2
