LAZBOY 48951-A User manual

Big & Tall Chair
Assembly Instructions
Model 48951-A / 48951-B
LA-Z-BOY is a trademark of La-Z-Boy Incorporated and is used under license to LF Products Pte Ltd.
400 lbs

2
D
C
B
A
EF
IJK
GH
L
N
Allen Key
Quantity: 1
PARTS
Casters
Quantity: 5 Star Base Quantity:1 Gas Liftwith Telescoping Cover Quantity: 1 Seat Plate Quantity: 1
Arms
Quantity: 2
SeatCushion
Quantity:1
Back Cushion
Quantity: 1
D1
D2
1” Screws
Quantity: 2 2-1/4” Screws
Quantity: 2
1-1/4” Screws
Quantity: 4
M
Plastic Caps
Quantity: 4
Plastic Shroud
Quantity: 1
2-3/4” Screws with Spring Washers
Quantity: 4
WARNINGS
1. This product should be used by only one person at a time.
2. Do not use this chair unless all bolts, screws and knobs are securely tightened.
3. Save the hexagonal wrench. Check that all bolts, screws and knobs are tight every three months or as needed.
4. Dispose of packing material properly. Do not use the plastic cover as a head covering. It may cause suffocation.
5. Do not use the chair as a stepladder.
6. To clean the product, use only a clean cloth. The use of chemicals or cleaning products may affect the color
fastness.
7. Use this chair for its intended purpose only.
8. The casters sold with this chair are intended for use on carpet. They are not recommended for use on tile or
hard-wood oors. Using these casters on tile or wood ooring may cause damage to the oor surface. Please
consider using a chair mat to protect your oor surfaces.

3
Step 1
Place the star base (B) upside down and insert 5 casters (A)
into the holes on the star base (B).
Step 2
Turn the star base (B) over and insert the gas lift with telescoping
cover (C) through the center hole on top of star base (B).
B
A
B
C

4
Step 3
Attach seat plate (D) to the bottom of the seat cushion (F) (with the
front of the seat plate facing the front of seat cushion). Attach by
using two 2-1/4” screws (J) for the front holes of the seat plate (D)
and two 1” screws (I) for the rear holes of the seat plate (D) and
tighten the screws using allen key (N).
*Note:Tighten thescrews completely.
Step 4
Insert levers (D1& D2) of seat plate (D) to the pre-attached
cable lever receivers on the underside of seat cushion (F) (with
the front of levers facing the front of seat cushion). Push down the
key on the receivers to pull out the levers.
*Note:Fix the cable forthe seat plate into the plastic clips attached
to the bottom of the seat cushion.
Disassemble the lever
Assemble the lever
Insert Push
NJ
F
F
D
I
D
D1
D2

5
Step 5
Position the back support plate over the seat plate (D),
and attach the back cushion(G) to the seat cushion (F)
with four 1-1/4" screws (K).
*Note: Do NOT tighten the screws completely.
Step 6
Insert four 2-3/4" screws with spring washers (L) into
arm holes attaching arms (E) (with front of arms facing
the front of seat cushion) to sides of seat cushion (F)
and back cushion (G).
*Note: Tighten all the screws completely.
G
G
F
F
E
E
K
N
N
L
L
D

6
Step 7
Put the plastic shroud (H) over the seat plate (D) (with
front of plastic shroud facing the front of seat
cushion). Align shroud posts to holes on bottom of seat
cushion (F) and press into position.
Step 8
Position the assembled chair upright with the seat plate
facing down. Insert the gas lift with telescoping cover (C) into
the center hole of the seat plate (D).
F
H
D
F
D
C

7
Step 9
Press the plastic caps (M) into the holes on outside of the
arms once all screws have been tightened.
M
M

8
Operating Instructions
Function Instruction - 1
To Adjust Seat Height:
While seated, lean forward and reach under the right side of the
chair to find the lever. Lift the lever and raise your body up
slightly to allow the chair to rise to the desired height. Once
desired height is reached, release lever to lock chair at desired
height. To lower the seat, lift the lever while seated. The chair
will descend until the lever is released or the chair reaches the
bottom position.

Function Instruction - 2
To Operate Tilt Lockout:
While seated, reach under the left side of the chair to find the
lever. Push down the lever and lean back to allow the chair to tilt
backwards. To lock the chair in the upright or vertical position, sit
upright and pull the lever to the up position.
9

10
Function Instruction - 3
To Adjust Tension On The Tilt:
Reach under the front center of the chair, grasp the round knob
(R) and turn it counter- clockwise to stiffen the tilt mechanism for
a heavier user.Turn the knob (R) clockwise to loosen the tilt
mechanism fora lighter user. Rotate the knob (R) until the desired
resistance is reached.
R

11
Function Instruction - 4
360˚ SWIVEL
360˚ Seat swivel.
