LCG LCG-301C User manual

User Manual
Please read this manual carefully before use!
Mixlaser RB
LCG-301C

Mixlaser RB User Manuel
- - 1 - -
Contents
Introduction----------------------------------------------------------------------------P2
Silkscreen on light ----------------------------------------------------------------P3
Safety instruction and product specification-------------------------------P4
Menu operation, function ---------------------------------------------------------P5
Channel instruction ------------------------------------------------------------------P6
Remote control----------------------------------------------------------------------- P7
DMX-512 connection and Address setting-------------------------------------P8
Installation and Size--------------------------------------------------------------- P9
Warning and warranty card------------------------------------------------------- P10

Mixlaser RB User Manuel
- - 2 - -
Introduction
Thank you for purchasing this product. To optimize the performance of this product,prior to
use,please read these operating instructions carefully to familiarize yourself with the basic operation
of this unit.Please keep the manual in safe price for future reference.
This unit has been tested at our factory before being shipped to you, there is no assembly required.
Once after received this product , please take and put carefully. And check cautiously that whether
the product was damaged or not during the transportation.
Checking Parts
Please check if the following parts are included:
1 x LED Laser Light
1 x Power cable
1 x User manual
1 x Remote control
Caution
Before out factory, this device has passed strict inspection, functions stable and perfect
packing. If this device will be operated in any way different to the one described in this
manual, the product may suffer damages and the guarantee becomes void. Furthermore,
any other operation may lead to dangers like short circuit, burns, electric shock, crash etc.
If any technology changes of this manual, company do not notice in further and have
interpretation.
CAUTION!
Keep this device away from rain and moisture!
Unplug mains lead before opening the housing!
Warning!
Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any resulting defects or
problems.

Mixlaser RB User Manuel
- - 3 - -
Silkscreen on light
-------------------------------------------------------------------------------CE compliant
-----------------------------------------------------------------------------Only indoor use
--------------------------------------------------------------------------RoHS Certificate
---------------------------The minimum distance from lighted objects(meter)
----------------------------------------------------------------Max. Ambient Temp
-------------------------------------------------------Max. Housing Temp
-------------------------------------------------------------------------- Safety caution
-------------------------------------------------------------------------Careful burns
-----------------------------------------------------------------Careful electric shock
---- Not suitable for directly installed on the surface of ordinary combustible
materials

Mixlaser RB User Manuel
- - 4 - -
1.Safety Instructions
1)Please open and check whether break or not for transport once receive this fixture, if yes, not use
it and contact dealer or manufacture as soon as possible.
2)The Max applicable temperature for the light is 40°C. Do not use the light under or above the
temperature. ta=40℃
3)The fixture is applicable for many occasions, it should keep clean, and avoid long use in
overheating or dusty environment. To prevent the fixture from the chemical liquid .
4)User must be careful of fire, heat, electric and fall-off that make heavy or fatal injury. Please read
this user manual carefully before power on and installation, following safety and operation
instruction in it. If still have any questions, please contact dealer or manufacture.
5)User must following this user manual, do not open fixture by yourself, if any problems, please
contact professional technician, maintenance should by technician.
Do not power on or start the fixture before installation, please stop after working more than 8
hours, which will longer use life.
6)Fixed installation, do not by strong shocks.
7)The minimum distance between light and the illuminated surface must be more than 1 meter.
8)Never look directly into the light source to avoid hurt to eyes (especially epileptics)!
9) When dustproof glass at light output breaks, cracks or other visible damage, user should replace
with new glass to continue to use.
2. Installation
When install this equipment please make sure there's no flammable surfaces (decorated things,
etc) and minimum distance of 0.5M from the equipment to the flammable.
The installation of the effect has to be built and constructed in a way that it can hold 10 times the
weight and without any harming deformation.
The installation must always be secured with a secondary safety attachment, e.g. an appropriate
safety rope.Never stand directly below the device when mounting, removing or servicing the
fixture.
3、Technical Specifications
1. Power supply: AC100V~240V 50/60Hz
2. Amp:：BGDP ￠5x20mm 250VAC T2A
3. Rated power: 90W
4. Laser: R:150m/650nm,B:150mw/450nm
5. LED：1pc 60W RGBW 4in1；8pcs 3W White LED
6. LED effect:Derby
7. Laser effect:8 grating effect
8. Control mode: Sound Active/ Auto-play/DMX512/Master-Slave
9. Channel：10
10. Scan system：Step motor
11. Operating temperature:10℃~40℃
12. Inner Packing(mm):340*270*340
13. Outer Packing(mm):560*360*365 (2pcs)

Mixlaser RB User Manuel
- - 5 - -
4、LED Digital Display
Operating Instruction: press button marked as “A” to select a function, For details, please see
the “OPERATION MENU” section. Press button marked as “B” or button marked as “C” to modify
values . Press button marked as “D” to save your settings.
LED Digital Display Operation Menu:
ID
Menu
Function
Default Values
1
Addr
DMX address DOWN/UP to +/- (1-512)
001
2
SLND
Mast, Master mode
Master
Slav, Slave mode
3
SHOW
Sh1, show 1 mode, Led effect
Show7 mode
Sh2, show 2 mode, Strobe effect
Sh3, show 3 mode, Laser effect
Sh4, show 4 mode, Led + Laser effect
Sh5, show 5 mode, Led + Strobe effect
Sh6, show 6 mode, Laser + Strobe effect
Sh7, show 7 mode,Led + Strobe + Laser effect
4
SENS
SESE,sound sensitivity 0-100
75
5
SOUN
Sound ON/OFF
ON
6
Vers
Ve1.0 , software version
E
A B C D
A．（MENU）
B．（UP）
C．（DOWN）
D．（ENTER）
E．LED Display

Mixlaser RB User Manuel
- - 6 - -
5、Channel
Channel
Value 0-255
Details
CH1
Control Mode
0-9
Black- out
10-39
Show 1，Led
40-69
Show 2, Strobe
70-99
Show 3, Laser
100-129
Show 4, Led + Laser
130-159
Show 5, Led + Strobe
160-189
Show 6, Laser + Strobe
190-219
Show 7, Led + Strobe + Laser
220-255
DMX mode
CH2
RGBW control
0-9
RGBW off
10--198
Choose colors（15 groups）, each 13 data for 1 color
group
199-225
Color chase1（single color）
226-255
Color chase 2(single or multiple）
CH3
Auto,LED
chase speed
0-255
Auto speed，LED color chase speed from slow to fast
CH4
RGBW Strobe
0-9
LED no strobe
10-244
Strobe Speed（from slow to fast）
245-255
LED strobe by sound
CH5
Strobe LED
0-9
Strobe off
10-134
Strobe position choose，5 data for only 1 choose
135-255
Strobe chase effect choose
CH6
Strobe chase
speed
0-127
no strobe, but White LED chase speed from slow to fast
127-255
With strobe, white LED chase speed from slow to fast
CH7
Laser Color
Control
0-9
Laser off
10-49
Red
50-89
Blue
90-129
Red and Blue
130-169
Red and Blue flicker
170-209
Blue and Red flicker
210-249
Red, Blue synchronous flicker
250-255
Red, Blue alternative flicker
CH8
Laser Strobe
Control
0-9
Strobe Off
10-244
Strobe Speed（from slow to fast）
245-255
Laser strobe by sound
CH9
LED Step
Motor Control
0-9
Step motor Off
10-127
Step Motor clockwise from slow to fast
128-255
Step Motor counterclockwise from slow to fast
CH10
Laser Step
Motor Control
0-127
Laser pattern choose
128-255
Laser pattern chase from slow to fast

Mixlaser RB User Manuel
- - 7 - -
6.Remote control menu:
NO.
Button
Function
1
StandBy
Stand By
2
DMX
Inter DMX control mode
3
Show 1
Show 1，Led
4
Show 2
Show 2, Strobe
5
Show 3
Show 3, Laser
6
Show 4
Show 4, Led + Laser
7
Show 5
Show 5, Led + Strobe
8
Show 6
Show 6, Laser + Strobe
9
Show 7
Show 7, Led + Strobe + Laser
10
Show8
Hold on, no function
11
LED Color
Choosing LED color (15 sets)
12
LED Random
LED color random
13
Laser Color
Choosing laser color (3 sets)
14
Laser Random
Laser color random
15
Sound ON
Sound on, Show 1-Show7 by sound control
16
Sound OFF
Sound off，Show 1-Show7 by auto
17
Speed-
Speed down
18
Speed+
Speed increase
19
Speed
Speed set as defaults value

Mixlaser RB User Manuel
- - 8 - -
7. DMX-512 connection
3-Pins DMX Out 3-Pins DMX In
(Female) (Male)
1 Earth 2 DMX- 3 DMX+
10CH for example
First（address 001）Second（address 011）Third（address021）
DMX in DMX out to next light
8、DMX address setting
Each fixture must set a specific starting address. When receiving signal transmission, fixture will
receive channel control signals which from the starting address.
According to different requirements or easy to use, the user can set many value fixtures to the same
address, also can set up a separate address for every device.
If you set the same address,all the devices will receive from DMX channels signal. All connecting
fixtures are jointly controlled, controller can't separate control a device.
If you set a different address, each device will be separate from its particular set the starting address
and begin accepting DMX512 control signal, so that more convenient separate control one device.
Using this method must be based on channel quantity of device to determine a starting address.
This light has 10 channels. When you use 10CH, you should set the starting address of the first unit
to 1, the second unit to 11(10+1), the third unit to 21 (11+10), and so on.

Mixlaser RB User Manuel
- - 9 - -
9、Installation
1 Clamp
2 Handle
When install this equipment please make sure there's no flammable surfaces
(decorated things, etc) within at least 2.5M and maintain minimum distance of 0.5M
from the equipment to the walls.
Please make sure that there's no other equipment or decorating materials obstructed
the exhaust fan and the vent-pipe.
Products should be install immobility.
In case of safety, it's very important that to connect the earth with line.
10、Product size

Mixlaser RB User Manuel
- - 10 - -
Declaration
Cleaning and maintenance
Cleaning should be performed every 15-day period, by using a sponge which is dipped with
alcohol, rather than wet cloth or other chemical liquid, to clean the mirror.
Attention
Do not see directly light source when open the light, and make sure power off before do any
installation or maintenance.
Warranty Card
This product is made of high-brightness transistor. We will provide 1 year
warranty under the condition that user has operated the light normally and
lifetime service. We won't provide warranty if the damage is caused by
artificial or force majeure event. Cost of fittings should be charged by user if
product need maintenance after 1 year .Please cut this warranty card and
shipped it along with the product to our factory when applying for warranty.
Product：Purchasing date：Code of invoice：
Warranty date: From To
User’s name：Add：
Company：Tel：
Cut off power before cleaning and maintenance!
CAUTION
Wires connection must be professional person!
CAUTION
