Leadshine Technology EM2RS Series User manual

EM2RS Series
Modbus RS485 Stepper Drive
User Manual
For Models of EM2RS-522, EM2RS-556, EM2RS-870 and EM2RS-A882
©2019 Leadshine Technology Co., Ltd.
Address: 15-20/F, Block B, Nanshan I Valley, No.3185, Shahe West Road, Nanshan District,
Shenzhen, Guangdong, 518055, China
Tel: [phone] Fax: [phone]
Web: www.leadshine.com Sales: [e-mail]
Support: [e-mail]

EM2RS Modbus RS485 Stepper Drive User Manual
Notice
Read this manual carefully before any assembling and using. Incorrect handling of products in this manual can
result in injury and damage to persons and machinery. Strictly adhere to the technical information regarding
installation requirements.
This manual is not for use or disclosure outside of Leadshine except under permission. All rights are reserved. No
part of this manual shall be reproduced, stored in retrieval form, or transmitted by any means, electronic,
mechanical, photocopying, recording, or otherwise without approval from Leadshine. While every precaution has
been taken in the preparation of the book, Leadshine assumes no responsibility for errors or omissions. Neither is
any liability assumed for damages resulting from the use of the information contained herein.
This document is proprietary information of Leadshine that is furnished for customer use ONLY. Information in
this document is subject to change without notice and does not represent a commitment on the part of Leadshine.
Therefore, information contained in this manual may be updated from time-to-time due to product improvements,
etc., and may not conform in every respect to former issues.
◆Thank you for purchasing Leadshine EM2RS Series Products
◆Please read this manual carefully before operating
◆Please keep this manual appropriately
Record of Revisions
Manual
Reversion
Data
Description of Release
V1.0
20190517
Initial Release
V1.1
20191220
Modified Section 4 and Section 5
V1.5
20210830
Addition of some parameters.
Adding the content of safety precautions.
Adding the IO filtering configuration section.

EM2RS Modbus RS485 Stepper Drive User Manual
Safety Precautions
Overall Notes
Precautions for Storage and Transportation
Do not remove the housing with the drive powered on. Cables. Connectors and
optional equipment.
Please disconnect the power supply for at least 2 minutes and make sure the
power indicator is off before wiring and checking. Even if the power is
disconnected, voltage may remain inside the drive. Therefore, do not touch the
power terminals while the power indicator is on.
Please use the power supply specifications (number of phases.) that match the
product. Voltage. Frequency. AC/DC).
Be sure to connect the ground terminal of the driver (mounting surface) and
motor to the ground pole.
Do not damage or drag the cable, do not overstress the cable, do not hang
heavy objects on the cable, or get caught in the cabinet door.
Please do not disassemble the product yourself. Repair or modification.
When the machine is connected to the machine and starts to operate, make sure
that the machine is ready for emergency stop.
Do not touch the inside of the drive.
The heat sink of the driver may be hot when the power is on or when the power
is just cut off. The motor, etc. may be in a high temperature. Take safety
measures such as installing a cover to prevent accidental touching by hands and
parts (cables, etc.).
Use double-insulated or reinforced insulation for control power.
Do not use in places where water can be splashed. Corrosive environments. Do
not use the product in the vicinity of flammable gases and combustible
materials.
Do not use damaged. Drivers and motors with missing parts.
Please set up an emergency stop circuit externally to ensure that the
power can be cut off and the operation can be stopped immediately in case of
an abnormality.
If the product is used under poor power conditions, install protection
equipment (AC reactor, etc.) to ensure that the input power is supplied within
the specified voltage variation range.
Please use a noise filter to reduce the influence of electromagnetic interference.
The driver and motor should be used in the specified combination.
Please follow the Commands on the packaging for storage and do not overload
the product.
Please place this product in the following environment:
→No direct sunlight in the place.
→Ambient temperature does not exceed the product specification.
→Humidity does not exceed product specifications. Without condensation.
→No corrosive gases. Place of flammable gas.
→Dust. Dust. The place where there is less salt and metal powder.
→No water. Oil. The place where the splash of medicine, etc. occurs.
→Vibration or shock does not exceed product specifications.
→No equipment generating strong magnetic fields in the vicinity.

EM2RS Modbus RS485 Stepper Drive User Manual
Precautions for Installation
Precautions for Wiring
Precautions during operation
Please install the drive in a cabinet that provides fire protection. Electrical
protection in the control cabinet.
Please install the driver and motor in a position with sufficient weight
resistance.
Please install this product in the following environment:
→No direct sunlight in the place.
→Ambient temperature does not exceed the product specification.
→Humidity does not exceed product specifications. Without condensation.
→No corrosive gases. Place of flammable gas.
→Dust. Dust. The place where there is less salt and metal powder.
→No water. Oil. The place where the splash of medicine, etc. occurs.
→Vibration or shock does not exceed product specifications.
→No equipment generating strong magnetic fields in the vicinity.
Do not block the air inlet and exhaust ports, and do not allow foreign objects to
enter the drive and motor.
Do not step on the product or place heavy objects on the drive.
Please install the driver in the specified direction.
Make sure to keep the specified intervals between the inner surfaces of the
drive control cabinet and other machines.
Do not pass the magnetic contactor in the wiring between the drive and the
motor.
Please connect the power terminal and motor terminal firmly.
Keep a minimum distance of 10mm between the drive and the control cabinet
or other equipment.
Allow at least 30mm of wiring space above and below the driver.
Signal cable. The encoder cable should be a twisted shielded cable with the
shield grounded at both ends.
The wiring length of the encoder is up to 20m.
Reduce the frequency of power on/off as much as possible.
To prevent accidents, perform a test run of the servo motor at no load (without
the driver connected).
When you install the machine and start operation, please set the user
parameters in advance to match the machine.
Positive limit (POT) during JOG operation and zero return operation. The
signal of negative limit (NOT) is not valid.
When using the motor on a vertical axis, please provide a safety device to
avoid dropping the work-piece in case of alarm or over travel.
When an alarm occurs, please reset it after investigating the cause and making
sure it is safe.
Do not use the brake of the holding motor for normal braking.

Table of Contents
1 Introduction................................................................................................................................................. - 1 -
1.1 Product Introduction.................................................................................................................................. - 1 -
1.2 Features...................................................................................................................................................... - 1 -
1.3 Application Scenarios................................................................................................................................ - 1 -
1.3.1 Hands-on Tuning.............................................................................................................................- 1 -
1.3.2 Practical Application Scenarios...................................................................................................... - 1 -
1.4 Check of Product........................................................................................................................................- 3 -
1.4.1 Arrival inspection............................................................................................................................- 3 -
1.4.2 Nameplate information................................................................................................................... - 3 -
1.4.3 Part number.....................................................................................................................................- 3 -
1.4.4 Parts description..............................................................................................................................- 4 -
1.4.5 Accessories Information................................................................................................................. - 4 -
2 Installation........................................................................................................................................................... - 4 -
2.1 Storage and Installation Conditions...........................................................................................................- 4 -
2.1.1 Storage condition............................................................................................................................ - 4 -
2.1.2 Operating ambience conditions...................................................................................................... - 4 -
2.2 Dimensions.................................................................................................................................................- 5 -
2.3 Installation Direction and Space................................................................................................................ - 5 -
3 Product Specifications........................................................................................................................................ - 7 -
3.1 Electrical and Operating Specifications.....................................................................................................- 7 -
3.1.1 Electrical and Operating Specifications......................................................................................... - 7 -
3.2 Wiring Instructions.....................................................................................................................................- 8 -
3.2.1 Power Supply Cable & Motor Cable..............................................................................................- 8 -
3.2.2 I/O Signal Cable..............................................................................................................................- 8 -
3.2.3 RS485 Communication Cable........................................................................................................ - 8 -
3.3 Interface Specifications..............................................................................................................................- 9 -
3.3.1 Connectors Definition.....................................................................................................................- 9 -
3.3.2 CN1 &CN2 Input Power Connector...............................................................................................- 9 -
3.3.3 CN3-I/O Signals Connector..........................................................................................................- 10 -
3.3.4 CN4-RS485 Communication Connector......................................................................................- 10 -
3.3.6 CN5-RS232 Tuning Port...............................................................................................................- 11 -
3.3.8 DIP Switches.................................................................................................................................- 11 -
3.4 I/O Connection.........................................................................................................................................- 12 -
3.4.1 Digital Inputs................................................................................................................................ - 12 -
3.4.2 Digital Output............................................................................................................................... - 13 -
3.4.3 Brake Output.................................................................................................................................- 13 -
4 Modbus RTU..................................................................................................................................................... - 14 -
4.1 Communication Specifications................................................................................................................- 14 -

4.2 Modbus Function Codes (FC)..................................................................................................................- 14 -
4.2.1 Read Holding Registers FC= 03...................................................................................................- 15 -
4.2.2 Preset Single Register FC= 06......................................................................................................- 16 -
4.2.3 Preset Multiple Registers FC= 10.................................................................................................- 17 -
4.3 Modbus & PR Parameters........................................................................................................................- 18 -
4.3.1 Basic Parameters...........................................................................................................................- 18 -
4.3.2 Input and Output Parameters........................................................................................................ - 20 -
4.3.3 Smooth Filter Time Setting for Digital Inputs..............................................................................- 21 -
4.3.4 Status Monitoring Parameters.......................................................................................................- 22 -
4.3.5 Control Word and Status Word..................................................................................................... - 23 -
4.4 Error Codes and Troubleshooting............................................................................................................- 23 -
4.4.1 Communication Error Codes........................................................................................................ - 23 -
4.4.2 Drive Alarm Codes and Troubleshooting..................................................................................... - 24 -
4.4.3 Error Clear.................................................................................................................................... - 25 -
4.5 Register Mapping Continuous Read/Write Function.............................................................................. - 25 -
4.6 S-code Application...................................................................................................................................- 26 -
4.7 Enable Drive............................................................................................................................................ - 27 -
5 PR Mode (Indexer Table)................................................................................................................................. - 28 -
5.1 PR Main Features.....................................................................................................................................- 28 -
5.2 Homing / Return to Zero Position........................................................................................................... - 28 -
5.2.1 Homing Parameters.......................................................................................................................- 29 -
5.2.2. Homing by Home Switch............................................................................................................ - 30 -
5.2.3. Homing by Limit Switch............................................................................................................. - 32 -
5.3 Soft Limit & JOG & Quick Stop............................................................................................................. - 33 -
5.3.1 Soft Limit...................................................................................................................................... - 33 -
5.3.2 JOG............................................................................................................................................... - 33 -
5.3.3 Quick Stop.................................................................................................................................... - 34 -
5.4 PR Path.....................................................................................................................................................- 35 -
5.4.1 PR Parameters...............................................................................................................................- 35 -
5.4.2 PR Path Configuration.................................................................................................................. - 36 -
5.4.3 Other functions of PR................................................................................................................... - 37 -
5.5 Trigger Methods.......................................................................................................................................- 38 -
5.5.1 CTRG Trigger............................................................................................................................... - 39 -
5.5.2 IO Combination Trigger............................................................................................................... - 39 -
5.5.3 Fixed Trigger.................................................................................................................................- 40 -
5.5.4 Immediate Trigger.........................................................................................................................- 41 -
6 Tuning Operations.............................................................................................................................................- 43 -
6.1 Basic operation of Leadshine MotionStudio........................................................................................... - 43 -
6.1.1 Preparation and Steps....................................................................................................................- 43 -

6.1.2 Operation of Trial Run..................................................................................................................- 45 -
6.1.3 Operation of PR Function.............................................................................................................- 46 -
6.2 Basic Operation of Serial Port Tools Software........................................................................................- 48 -
6.2.1 Preparation and Steps....................................................................................................................- 48 -
6.2.2 Operation Instruction Format....................................................................................................... - 49 -
6.2.3 Command Cases of Modbus RTU................................................................................................ - 49 -
Appendix A Parameters List............................................................................................................................... - 51 -

EM2RS Modbus RS485 Stepper Drive User Manual
-1-
1 Introduction
1.1 Product Introduction
EM2RS Series are stepper drive based on standard Modbus RTU protocol, using RS485 communication can network up to 31
axes. They built-in PR feature with 16-segment position table (PR Mode) can save additional controllers in most of point-to-
point applications, to greatly enhance system reliability and reduce the cost. EM2RS Series also support the feature of teaching,
the operation modes of Profile Position, Profile Velocity and Homing. They can power 2-phase NEMA 8, 11, 14, 17, 23, 24, 34
stepper motors.
The EM2RS series is highly reliable and affordable and performs excellently in many industrial applications such as solar
equipment, textile, civil, robotics, power generation equipment, 3C, packaging...
1.2 Features
Low noise and vibration, smooth motion
Support Modbus RTU protocol, Internal 16-segment position Commands
Motion can be started by External IO or RS485 or HMI
Support operation modes: Profile Position, Profile Velocity, Homing
7 configurable digital inputs, 3 optically isolated digital outputs
Limit +, Limit -, Origin, Quick stop, Enable, JOG +, JOG - and Position Table inputs
Alarm, Brake, Homing complete, In Position complete, Commands complete, Path complete outputs
20-50VDC supply voltage for EM2RS-522, max output current 2.2A
20-50VDC supply voltage for EM2RS-556, max output current 5.6A
20-80VDC supply voltage for EM2RS-870, max output current 7.0A
20-80VAC or 30-100VDC supply voltage for EM2RS-A882, max output current 8.2A
RS232 communication for parameters configuration
Protections for over voltage, over current, motor cable error, etc.
Compare with Step/Direction
Built-in single-axis control can save the PLC in most of point-to-point applications to reduce cost;
Built-in rich diagnostic functions and input and output signals to setup easily;
Modbus brings more expansion possibility to add value;
1.3 Application Scenarios
Divided into simple hands-on tuning and practical application scenarios
1.3.1 Hands-on Tuning
(1) The trial run can be performed with Leadshine's MS tuning software, which requires Leadshine’s tuning software, RS232
tuning cable (provided by Leadshine), RS232toUSB converter, drive and motor, as described in Section 6.1
(2) Simple motion can also be performed with serial port tools, which requires General serial port tools software, RS485 tuning
cable (User-provided), RS485toUSB converter, drive and motor, as described in Section 6.2.
1.3.2 Practical Application Scenarios
(1) Controlled by Modbus RS485 (PLC or HMI)

EM2RS Modbus RS485 Stepper Drive User Manual
-2-
The RS485 (Modbus-RTU protocol) communication triggers the drive's PR motion register, which can realize the drive's path
motion. Both PLC and HMI have RS485 communication, so user can choose one or both. Using PLC can write more complex
programs to let motion more intelligent, and the HMI can monitor and modify the drive parameters in real time.
(2) Controlled by I/O (switch signal or PLC)
The user only needs to turn off the switch signal to realize the PR motion, which is simple to control and low-cost design.
Users can also use PLC I/O module to realize PR motion, which is more intelligent than switch signal control.

EM2RS Modbus RS485 Stepper Drive User Manual
-3-
1.4 Check of Product
1.4.1 Arrival inspection
Check whether the surface of the product is damaged or not during transportation.
Check the nameplate models of the drive and motor are what you have ordered.
Cheek if it is fully equipped with accessories. Accessories include power supply and I/O signals
connector.
1.4.2 Nameplate information
1.4.3 Part number
Neither the damaged nor missing accessories of stepper system
is allowed to install.
Contact Leadshine or local distributor if any failure was found.

EM2RS Modbus RS485 Stepper Drive User Manual
-4-
1.4.4 Parts description
1.4.5 Accessories Information
Name
Necessary
Description
Need to
cost extra
Tuning Cable(1)
No
CABLE-PC-1 cable
Yes
Network cable(2)
Yes
(CABLE-TX*M*-BUS)
Optional length: 0.1m,
0.2m, 0.3m, 0.4m, 1m,
1.5m, 2m, 3m,5m,7m,
10m,15m, 20m
Yes
Note:
(1) Tuning cable is not necessary, but it is recommended to order.
(2) Network cable is necessary, but user can also buy shielded network cable through 3rd party.
(3) Motor connector model: 39012040, 39000038, Molex
2 Installation
2.1 Storage and Installation Conditions
2.1.1 Storage condition
Correctly packaged and store in a clean and dry environment where direct sunlight is avoided.
Store within an ambient temperature ranging from -20℃to +65℃.
Store within a relative humidity ranging from 40% to 90% and non-condensed.
Avoid any type of exposure to corrosive gases.
2.1.2 Operating ambience conditions
Temperature ranging from 0℃to 50℃. The ambient temperature of drive for long-term reliability should be under 40℃.
Please install the drive in a well-ventilated area.
Operation within a relative humidity ranging from 40% to 90% and non-condensed.
Vibration lower than 0.15mm at a frequency of 10Hz-55Hz.

EM2RS Modbus RS485 Stepper Drive User Manual
-5-
2.2 Dimensions
Unit: mm (1inch=25.4mm)
Figure 2.1: EM2RS series mechanical drawing
2.3 Installation Direction and Space
The mounting of drive, wiring and motor should be under the regulations of EN 61800-5-1.
Incorrect installation may result in a drive malfunction or premature failure of the drive and /or motor. Please follow the
guidelines in this manual when installing
The drive should be mounted perpendicular to the wall or in the control panel.
In order to ensure the drive is well ventilated, ensure that the all ventilation holes are not obstructed and sufficient free
space is given to the drive, and a cooling fan is mounted in the control panel.
Please ensure grounding wires are securely connected.
DO NOT mount the drive and motor in a location subjected to corrosive or
flammable gases, and combustibles.
Please mount the drive and motor in an indoor electric control cabinet without
liquid where direct sunlight is avoided.
DO NOT mount the drive and motor in a location subjected to airborne dust.
Please ensure grounding wires are securely connected

EM2RS Modbus RS485 Stepper Drive User Manual
-6-
Figure 2.2: EM2RS series installation drawing

EM2RS Modbus RS485 Stepper Drive User Manual
-7-
3 Product Specifications
3.1 Electrical and Operating Specifications
3.1.1 Electrical and Operating Specifications
Name
EM2RS-522
EM2RS-556
EM2RS-D870
EM2RS-A882
Supply Voltage
20-50VDC
20-50VDC
20-80VDC
30-100VDC or 20-80VAC
Output Current (Peak)
0.5-2.2A
1.0-5.6A
1.0-7.0A
2.1-8.2A
Size (H*W*L mm)
118*79.5*25.5
151*91*53
Weight (kg)
0.23
0.58
Matched Motor
NEMA 8, 11,
14, 17
NEMA 17, 23,
24
NEMA 24, 34
NEMA34
Input Signals
Limit +, Limit -, Origin, Quick stop, Enable, JOG +, JOG - and Position Table
Output Signals
Brake, Alarm, In Position, GPIOs
Protection Functions
Over Current, Over Voltage, Motor Cable Error, etc.
PC Software
Leadshine MotionStudio
Operating Environment
Environment
Avoid dust, oil, fog and corrosive gases
Operating
Temperature
0-50℃(32 F – 122 F)
Storage Temperature
-20℃-65℃(-4 F – 149 F)
Humidity
40-90%RH
Vibration
10-55Hz/0.15mm
Mount
Vertical or horizontal mounting
Don’t hot plug the motor wiring, encoder wiring and RS232 communication wiring
during power on.
Be sure to check the connections and make sure the power lead polarity is correct, or there
could result in injury or fire.
Be sure wait for 5 minutes or longer to touch drives after turning off power
Be sure to give the power supply voltage dose not exceed the drive’s input range.
If using a motor with small phase current, be sure to modify the driver output current
before enabling the motor

EM2RS Modbus RS485 Stepper Drive User Manual
-8-
3.2 Wiring Instructions
Figure 3.1 Wiring Instructions
Note:
(1) There are two RS485 communication ports above, one of them is input port which connects with master station or previous
slave, and the other is output port which connects with the following slave.
(2) Single-ended inputs I1, I2, I3, I4, I5, I6 and I7 connection types can be common-cathode and common-anode.
(3) Single-ended outputs connection type is common-anode.
3.2.1 Power Supply Cable & Motor Cable
Wire diameter: +VDC, GND, A+, A-, B+, B- terminal wire diameter≥0.3mm2(AWG15-22)
3.2.2 I/O Signal Cable
Wire diameter: I1 - I7, O1 - O3, COM wires diameter≥0.12mm2(AWG24-26)
Recommend to adopt shielded twisted pair cable with a length of less than 3 meters (the shorter the better).
Wiring: As far as possible away from the power line wiring, in order to prevent interference
Please connect surge absorber to inductive device, such as anti-parallel diode for DC coil, parallel RC-snubbers circuit for AC
coil.
3.2.3 RS485 Communication Cable
It is recommended to use shielded Ethernet network cables that do not exceed 100 meters.

EM2RS Modbus RS485 Stepper Drive User Manual
-9-
3.3 Interface Specifications
3.3.1 Connectors Definition
Figure 3.2: EM2RS series connectors
Name
Description
CN1
Input power connector
CN2
Motor connector
CN3
I/O signals connector
CN4
RS485 communication connector
CN5
RS232 tuning connector
DIP Switch
Salve ID: SW1-SW5
Baud Rate: SW6-SW7
Terminal Resistance: SW8
3.3.2 CN1 &CN2 Input Power Connector
EM2RS-522/556/870
Name
Pic
PIN
Signal
Description
CN1
1
VDC
24V- 48V
2
GND
GND
CN2
4
A+
Motor phase A+
3
B+
Motor phase B+
2
A-
Motor phase A-
1
B-
Motor phase B-

EM2RS Modbus RS485 Stepper Drive User Manual
- 10 -
EM2RS-A882
Name
Pic
PIN
Signal
Description
CN1&
CN2
1
A+
Motor phase A+
2
B+
Motor phase B+
3
A-
Motor phase A-
4
B-
Motor phase B-
5
AC
18-80VAC or 24-100VDC;
No polarity
6
AC
Note: When the user uses an AC transformer to supply power, be sure to use an isolation transformer to prevent electric shock
or burn out the computer
3.3.3 CN3-I/O Signals Connector
Name
Pic
PIN
Signal
I/O
Description
CN3
1
DI1
I
Configurable Single-ended Digital
Inputs DI1-DI7, 12V - 24V.
DI1 is enabling signal default, DI2-
DI7 are GPIOs.
2
DI2
I
3
DI3
I
4
DI4
I
5
DI5
I
6
DI6
I
7
DI7
I
8
COMI
I
9
DO1
O
Configurable Single-ended Outputs
Signals DO1-DO3 (common-cathode
or common-anode),
Max. 24V/100mA, GPIOs.
10
DO2
O
11
DO3
O
12
COMO
O
Note:(1) DI or DO is shown as SI or SO in Leadshine MotionStudio.
(2) DI1 is normally closed, default by Enable signal. It means the motor is locked shaft after the driver powered on.
(3) When using Brake output signals, you need to connect a relay and a diode.
3.3.4 CN4-RS485 Communication Connector
Name
Pic
PIN
Signal
Description
CN4
1
RS485+
RS485 TxD+
9
RS485 RxD+
2
RS485-
RS485 TxD-

EM2RS Modbus RS485 Stepper Drive User Manual
- 11 -
10
RS485 RxD-
5, 6, 13, 14
GND
GND
7, 8, 15, 163, 4, 11, 12
NC
Received
Connector cover
PE
Shield GND
3.3.5 CN5-RS232 Tuning Port
Name
Pic
PIN
Signal
CN5
1
NC
2
TxD
3
GND
4
RxD
3.3.6 DIP Switches
The EM2RS series drives use an 8-bit DIP switched to set Salve ID (also called Site Alias), Baud Rate and Terminal Resistance,
they are shown as below:
(1) Slave ID: SW1-SW5 (off=1, on=0)
Slave ID
SW1
SW2
SW3
SW4
SW5
1(default)
on
on
on
on
on
1(factory)
off
on
on
on
on
2
on
off
on
on
on
3
off
off
on
on
on
4
on
on
off
on
on
5
off
on
off
on
on
6
on
off
off
on
on
7
off
off
off
on
on
8
on
on
on
off
on
9
off
on
on
off
on
10
on
off
on
off
on
11
off
off
on
off
on
12
on
on
off
off
on
13
off
on
off
off
on
14
on
off
off
off
on
15
off
off
off
off
on

EM2RS Modbus RS485 Stepper Drive User Manual
- 12 -
16
on
on
on
on
off
17
off
on
on
on
off
18
on
off
on
on
off
19
off
off
on
on
off
20
on
on
off
on
off
21
off
on
off
on
off
22
on
off
off
on
off
23
off
off
off
on
off
24
on
on
on
off
off
25
off
on
on
off
off
26
on
off
on
off
off
27
off
off
on
off
off
28
on
on
off
off
off
29
off
on
off
off
off
30
on
off
off
off
off
31
off
off
off
off
off
Note: (1) When the SW1-SW5 is default (all are on), the Slave ID can be configured by the PC software
(2) Baud Rate: SW6 - SW7
Baud Rate
SW6
SW7
115200 (Default)
on
on
38400 (Factory)
off
on
19200
on
off
9600
off
off
Note: (1) When the SW6-SW7 is default (all are off), the Baud Rate can be configured by the PC software
(3) Terminal Resistance Selection: SW8
SW8=ON: terminal resistance is valid;
SW8=OFF: terminal resistance is invalid (Factory setting)
Note: (1) The last slave in the network needs to connect a 120Ω terminal resistance, it means set the SW8 to on
3.4 I/O Connection
3.4.1 Digital Inputs
The connections of input signals are as below:

EM2RS Modbus RS485 Stepper Drive User Manual
- 13 -
Figure 3.3: Input Interface Connection
3.4.2 Digital Output
Figure 3.4: Output Interface Wiring
Note: (1) The power supply (12-24VDC) above is provided by user, and if the polarity of power supply is reversed, it will
damage the drive.
(2) Digital output is OC output with the maximum capacity of 100mA/24V (recommended 50mA/24V), the provided power
supply should be under 30V (recommended 24V), otherwise it will cause damage to the drive.
3.4.3 Brake Output
Use PC software (from Leadshine or Controller or PLC vendor) to configure this output as a BRAKE CONTROL output. In
this case, this signal can be used for automatic brake control while system power failure. It is recommended to connect a fly-
wheel diode in parallel to a 24VDC relay and brake coil connection. Refer to the following figure for brake connection.
Figure 3.5: Brake output connection
