Leadshine Technology EM522-CAN User manual

User Manual
EM522-CAN
2-Phase Field Bus Stepper Drive
Revision 1.0
©2016 China Leadshine Technology Co., Ltd.
Address: Floor 11, Block A3, Nanshan iPark, Xueyuan Avenue 1001, Shenzhen, Guangdong, 518055, China
Tel: [phone] Fax: [phone]
Web: www.leadshine.com Sales: [e-mail]
Support: [e-mail]

EM522-CAN Field bus Stepper Drive User Manual V1.0
Notice
Read this manual carefully before any assembling and using. Incorrect handling of products in this manual can result in
injury and damage to persons and machinery. Strictly adhere to the technical information regarding installation requirements.
This manual is not for use or disclosure outside of Leadshine except under permission. All rights are reserved. No part of this
manual shall be reproduced, stored in retrieval form, or transmitted by any means, electronic, mechanical, photocopying,
recording, or otherwise without approval from Leadshine. While every precaution has been taken in the preparation of the
book, Leadshine assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting
from the use of the information contained herein.
This document is proprietary information of Leadshine that is furnished for customer use ONLY. Information in this
document is subject to change without notice and does not represent a commitment on the part of Leadshine. Therefore,
information contained in this manual may be updated from time-to-time due to product improvements, etc., and may not
conform in every respect to former issues.
Record of Revisions
Revision
Date
Description of Release
1.0
Mar, 2017
Initial Release

EM522-CAN Field bus Stepper Drive User Manual V1.0
Preface
Thank you for you choose EM522-CAN stepper drive system of Leadshine Technology Co,.Ltd. This
manual gives required knowledge & precautions for using EM522-CAN.
Improper operation may cause an accident, please read this manual carefully before
operation.
●Manual content may change due to product improvement, please forgive without prior notice.
●Leadshine will not undertake any responsibility in case of user's unauthorized product changes,
product warranty will be invalid.
Please pay attention to the following reminders:
CAUTION
●Only the technical personnel to install,debug or maintain the product.
●To ensure correct wiring before power-on test.
●Incorrect voltage or power polar can cause damage to drive or other accidents

EM522-CAN Field bus Stepper Drive User Manual V1.0
Table of Contents
1. Introduction...............................................................................................................................................................................1
1.1 Overview.................................................................................................................................................................................. 1
1.2 Features....................................................................................................................................................................................1
1.3 Application...............................................................................................................................................................................1
2. Specification...............................................................................................................................................................................1
2.1 Electrical Specification...........................................................................................................................................................1
2.2 Environment............................................................................................................................................................................ 1
2.3 Mechanical Specification........................................................................................................................................................2
2.4 Elimination of Heating........................................................................................................................................................... 2
3. Connection Pin Assignment & DIP Switch & LED Indication............................................................................................2
3.1 Connection Pin Assignment................................................................................................................................................... 2
3.1.1 Connector P1......................................................................................................................................................... 2
3.1.2 Connector P2......................................................................................................................................................... 3
3.1.3 Connector P3......................................................................................................................................................... 3
3.2 DIP Switch............................................................................................................................................................................... 3
3.2.1 CAN ID Setup........................................................................................................................................................4
3.2.2 CAN Baud Rate Setup...........................................................................................................................................5
3.3 LED Light Indication............................................................................................................................................................. 6
4. Getting Started.......................................................................................................................................................................... 6
4.1 Wiring Instruction.................................................................................................................................................................. 6
4.1.1 Power supply & motor cable................................................................................................................................. 6
4.1.2 I/O signal cable...................................................................................................................................................... 6
4.1.3 CAN communication cable................................................................................................................................... 6
4.1.4 Terminal resistance................................................................................................................................................ 7
4.2 Typical Connection................................................................................................................................................................. 7
4.3 Motor Connection................................................................................................................................................................... 8
4.3.1 Connections of 4-lead Motor.................................................................................................................................8
4.3.2 Connections of 6-lead Motor.................................................................................................................................9
4.3.3 Connections of 8-lead Motor.................................................................................................................................9
4.4 Power Supply Selection........................................................................................................................................................ 10

4.4.1 Regulated or Unregulated Power Supply............................................................................................................ 10
4.4.2 Power Supply Sharing......................................................................................................................................... 10
4.4.3 Selecting Supply Voltage.....................................................................................................................................10
4.5 Object Dictionary Introduction...........................................................................................................................................11
4.5.1 Common list objects............................................................................................................................................ 11
4.5.2 Model and control................................................................................................................................................14
4.6 Parameters Configuration via Leadshine CANopen Software........................................................................................17
4.6.1 Installing software............................................................................................................................................... 17
4.6.2 Connecting Leadshine CANopen software......................................................................................................... 17
5. CANopen Communication Overview................................................................................................................................... 22
5.1 EM522-CAN Communication Standard............................................................................................................................ 22
5.2 Explanation of Nouns........................................................................................................................................................... 23
5.2.1 Object dictionary................................................................................................................................................. 23
5.2.2 Process data objects ( PDO)................................................................................................................................ 23
5.2.3 Service data object (SDO)................................................................................................................................... 24
5.2.4 Homing mode...................................................................................................................................................... 25
6. Trouble Shooting.....................................................................................................................................................................28
7. Warranty....................................................................................................................................................................................30
8. Contact Us.................................................................................................................................................................................31

EM522-CAN Field bus Stepper Drive User Manual V1.0
1
1. Introduction
1.1 Overview
EM522-CAN is one of the new high performance stepper drive which can support CANopen communication protocol. By
implementing latest 32-bit DSP technology, this stepper drive is able to power 2 phase and 4 phase stepper motors. It can
configure drive parameters and motor operation in real time via CANopen commander. Especially in multi-axis linkage of
applications, can greatly reduce the wiring, enhance the drive running reliability.
1.2 Features
Power supply 20~50VDC, recommended 24VDC
Output current 0.1~2.2A(peak), default value 1.0A(peak)
Support CAN field bus control, meet CANopen standard protocol of DS301 V4.02 and DSP 402 V2.01
Setting address and the baud rate via DIP switch
Operates in velocity, position or home mode
3 opto-isolation differential digital inputs, max. frequency 20KHz, and wide input voltage +5~24VDC
1 opto-isolation differential digital output, max. current 100mA, largest external pull-up voltage 24VDC
Protections for over-voltage and over-current,etc.
1.3 Application
Suitable for all kinds of multi-axis linkage control of small and medium-sized automation equipment and instrumentation:
such as manipulator, packaging machinery etc.
2. Specification
2.1 Electrical Specification
Parameters
EM522-CAN
Min
Typical
Max
Unit
Output Current
0.1
-
2.2
A
Supply Voltage
20
24
50
VDC
Input signal current
6
10
16
mA
Input signal voltage
5
-
24
VDC
Over voltage Value
-
90
-
VDC
Isolation resistance
500
MΩ
2.2 Environment
Cooling
Natural Cooling or Forced cooling
Operating Environment
Environment
Avoid dust, oil fog and corrosive gases
Ambient Temperature
0°C －65°C (32°F - 149°F)
Humidity
40%RH－90%RH
Operating Temperature
0°C －50°C (32°F - 122°F)
Vibration
10-50Hz / 0.15mm
Storage Temperature
-20°C －65°C (-4°F - 149°F)
Weight
Approx. 227g (8 oz)

EM522-CAN Field bus Stepper Drive User Manual V1.0
2
2.3 Mechanical Specification
(unit: mm [1inch=25.4mm])
Figure 1: Mechanical specifications
* Side mounting recommended for better heat dissipation
2.4 Elimination of Heating
EM522-CAN reliable working temperature should be < 60℃(140°F) and stepper motor should be <120℃(248°F)
It is recommended to use automatic idle-current mode to reduce drive and motor heating. That means output current will
be reduce to 50% when the motor at standstill.
It is recommended to mount the drive vertically to maximize heat sink area. Use forced cooling method to cool if
necessary.
3. Connection Pin Assignment & DIP Switch & LED Indication
The EM522-CAN has three connector blocks P1&P2&P3 (see above picture). P1 is for IO signals connections, P2 is for
power and motor connections, and P3 is for CAN communication connection. The following tables are brief descriptions of
the two connectors. More detailed descriptions of the pins and related issues are presented in section 4, 5, 9.
3.1 Connection Pin Assignment
3.1.1 Connector P1
Pin Function
Details
118
112
34
112
22.5
4.5
4-Ф3.5
75.5
25.3
47.8
P2
P1
P3

EM522-CAN Field bus Stepper Drive User Manual V1.0
3
IN1+
Opto-isolation differential input signals (5~24V compatible)
IN1-
IN2+
IN2-
IN3+
IN3-
ALM+
Opto-isolation differential output signal is for alarm function. maximum output current 100mA,
maximum pull-up voltage 24VDC
ALM-
!
Notice
Notes: (1) The function of input signals can be configured by controller
3.1.2 Connector P2
Pin Function
Details
GND
Power supply ground connection.
+VDC
Power supply positive connection. Suggest 24-48VDC power supply voltage
A+, A-
Motor Phase A connections. Connect motor A+ wire to A+ Pin; motor A- wire to A-
B+, B-
Motor Phase B connections. Connect motor B+ wire to B+ Pin; motor B- wire to B-
!
Warning
Warning: (1) Don’t plug or unplug the P2 terminal block to avoid drive damage or injury when EM522-CAN is
powered on; (2) Don't connect the power supplier to motor connection terminal, and don't connect +VDC and GND
inversely, otherwise, drive will be damaged.
3.1.3 Connector P3
CAN port of EM522-CAN adopt shield doublet RJ45 terminal (standard RJ45 specification).
PIN definition
PIN
Signal
Details
1
CAN_H
Differential signal of CAN
2
CAN_L
3
CAN_GND
CAN ground
4~8
NC
-
!
Notice
Notes: (1) shielding cable and reliable grounding is suggested; (2) CAN_H and CAN_L should not connect
inversely; (3) Two interfaces of RJ45 without order.
3.2 DIP Switch
EM522-CAN field bus stepper drive uses an 8-bit DIP switch to set CAN ID, baud rate, as shown below:

EM522-CAN Field bus Stepper Drive User Manual V1.0
4
3.2.1 CAN ID Setup
Low 5 bits of CAN ID are set by DIP switch SW1~SW5, and high 5 bits of CAN ID are set by controller, as shown in the
following table.
CAN address ID(low 5 bits)
SW1
SW2
SW3
SW4
SW5
1
off
on
on
on
on
2
on
off
on
on
on
3
off
off
on
on
on
4
on
on
off
on
on
5
off
on
off
on
on
6
on
off
off
on
on
7
off
off
off
on
on
8
on
on
on
off
on
9
off
on
on
off
on
10
on
off
on
off
on
11
off
off
on
off
on
12
on
on
off
off
on
13
off
on
off
off
on
14
on
off
off
off
on
15
off
off
off
off
on
16
on
on
on
on
off
17
off
on
on
on
off
18
on
off
on
on
off
19
off
off
on
on
off
20
on
on
off
on
off

EM522-CAN Field bus Stepper Drive User Manual V1.0
5
21
off
on
off
on
off
22
on
off
off
on
off
23
off
off
off
on
off
24
on
on
on
off
off
25
off
on
on
off
off
26
on
off
on
off
off
27
off
off
on
off
off
28
on
on
off
off
off
29
off
on
off
off
off
30
on
off
off
off
off
31
off
off
off
off
off
!
Notice
Notes: (1) SW1~SW5 set to "on" all will be invalid ID; (2) Should restart the power after modifying CAN ID.
3.2.2 CAN Baud Rate Setup
CAN baud rate can be set by DIP switch SW6~SW8, as shown below:
Baud rate(Kbps)
SW6
SW7
SW8
20
on
on
on
50
off
on
on
100
on
off
on
125
off
off
on
250
on
on
off
500
off
on
off
1000
on
off
off
!
Notice
Notes: (1) Should restart the power after modifying baud rate.

EM522-CAN Field bus Stepper Drive User Manual V1.0
6
3.3 LED Light Indication
There are two LED lights for DM56-CAN. The GREEN one is the power indicator which will be always on generally. The
RED one is a protection indicator which will flash 1-2 times in a 3-second period, when protection enabled for a
EM522-CAN. Different number of flashes indicates different protection type ,as shown following table.
Priority
Time(s) of
Blink
Sequence wave of red LED
Description
1st
1
Over-current protection activated when peak
current exceeds the limit.
2nd
2
Over-voltage protection activated when drive
working voltage is greater than 90VDC
3rd
8
EEPROM Fault(need to configure parameter )
4th
12
Operational Amplifier Fault (need to configure
parameter )
!
Notice
Notes: (1) The protections for detecting.fault of EEPROM fault and Operational Amplifier need to turn on manually
via configuring parameter, read section 4.4 for detail; (2) When one of the protection is active, the motor shaft will be free
and the red LED blinks. Restart the power to make it function properly after removing above problems.
4. Getting Started
4.1 Wiring Instruction
4.1.1 Power supply & motor cable
Wire diameter: +VDC, GND, A+, A-, B+, B- terminal wire diameter≥0.3mm2(AWG15-22)
Recommend to connect a noise filter between power supply and drive, can improve anti-interference performance.
4.1.2 I/O signal cable
Wire diameter: IN1+, IN1-, IN2+, IN2-, IN3+, IN3- terminal wire diameter≥0.12mm2(AWG24-26)
Recommended to adopt shielded twisted pair cable, cable length as short as possible, suggest no more than 3 meters
Wiring: As far as possible away from the power line wiring, in order to prevent interference
Please connect surge absorber to inductive device, such as anti-parallel diode for DC coil, parallel RC-snubbers circuit
for AC coil.
4.1.3 CAN communication cable
There are coupling relationship between CAN bus cable length, guide line cross sectional area, terminal resistance and
communication rate, recommended combinations as below:

EM522-CAN Field bus Stepper Drive User Manual V1.0
7
Length
(m)
Bus cable
Terminal
resistance
(Ω)
Communication
rate
Resistance per unit
length(mΩ/m)
Cross-sectional area(mm²)
0~40
70
0.25~0.34
120
1 Mbit/s
40~300
<60
0.34~0.6
150~300
<500 Kbit/s
300~600
<40
0.7~0.75
150~300
<100 Kbit/s
600~1000
<26
0.75~0.8
150~300
<50 Kbit/s
!
Notice
Notes: (1) shielding and twisted-pair cable is suggested.
4.1.4 Terminal resistance
Note
Terminal resistance
It must to connect an 120Ω resistance if the
drive on the end of bus, and customer need to
order the terminal resistance as shown right
4.2 Typical Connection
EM522-CAN adopt CANopen protocol, typical schematic wiring topology structure as below:
Figure 2: The topology of the CAN network
Controller&Control card

EM522-CAN Field bus Stepper Drive User Manual V1.0
8
Each EM522-CAN of the CAN network wiring diagram:
Figure 3: The wiring diagram of each EM522-CAN
!
Notice
Notes: (1) The EM522-CAN at the end of the network need to plug a terminal resistance in any one of the P3
interface(RJ45); (2) In order to avoid bad insulation performance as heating, cable and wire should be fixed well and keep
away from motors and drives.
4.3 Motor Connection
The EM522-CAN can drive 2-phase and 4-pahse bipolar hybrid stepper motors with 4, 6, or 8 wires (frame size from
NEMA17).
4.3.1 Connections of 4-lead Motor
The 4 lead motors are the least flexible and easy to connect. And the Speed – torque of motor depends on winding inductance.
The output current from drive that is multiply the specified phase current by 1.4 to determine the peak output current.
Figure 4: 4-lead Motor Connections
A+
A-
B+
B-
GND
+VDC
Black
Red
Yellow
Blue
EM522-CAN
ALM+
ALM -
12~24VDC
噪音滤波器
DC power
24~50VDC
CANH
CANL
GND
CANH
CANL
GND
IN1 -
IN1+
IN2+
IN2 -
IN3+
IN3 -
5~24VDC

EM522-CAN Field bus Stepper Drive User Manual V1.0
9
4.3.2 Connections of 6-lead Motor
Like 8 lead stepping motors, 6 lead motors have two configurations available for high speed or high torque operations. The
higher speed configuration, or half coil, is described, because it uses one half of the motor’s inductor windings. The higher
torque configuration, or full coil, uses the full coil windings.
(1) Half Coil Configuration
As previously stated, the half coil configuration uses 50% of the motor phase windings. This gives lower inductance, hence,
lower torque output. Like the parallel connection of 8 lead motor, the torque output will be more stable at higher speeds. This
configuration is also referred to as half chopper. In setting the drive output current multiply the specified per phase (or
unipolar) current rating by 1.4 to determine the peak output current.
Figure 5: 6-lead motor half coil (higher speed) connections
(2) Full Coil Configuration
The full coil configuration on a six lead motor should be used in applications where higher torque at lower speed is desired.
This configuration is also referred to as full copper. In full coil mode, the motors should be run at only 70% of their rated
current to prevent overheating.
Figure 6: 6-lead motor full coil (higher torque) connections
4.3.3 Connections of 8-lead Motor
8 lead motors offer a high degree of flexibility to the system designer in that they may be connected in series or parallel, thus
satisfying a wide range of applications.
(1) Series Connection
A series motor configuration would typically be used in applications where a higher torque at lower speed is required.
Because this configuration has the most inductance, the performance will start to degrade at higher speed. In series mode, the
motors should also be run at only 70% of their rated current to prevent overheating.
Figure 7: 8-lead motor series connections

EM522-CAN Field bus Stepper Drive User Manual V1.0
10
(2) Parallel Connection
An 8 lead motor in a parallel configuration offers a more stable, but lower torque at lower speeds. But because of the lower
inductance, there will be higher torque at higher speeds. Multiply the phase (or unipolar) current rating by 1.96, or the bipolar
current rating by 1.4, to determine the peak output current.
Figure 8: 8-lead motor parallel connections
4.4 Power Supply Selection
The EM522-CAN can power medium and small size stepping motors (frame size from NEMA17 to 24) made by Leadshine
or other motor manufacturers. To get good driving performances, it is important to select supply voltage and output current
properly. Generally speaking, supply voltage determines the high speed performance of the motor, while output current
determines the output torque of the driven motor (particularly at lower speed). Higher supply voltage will allow higher motor
speed to be achieved, at the price of more noise and heating. If the motion speed requirement is low, it’s better to use lower
supply voltage to decrease noise, heating and improve reliability.
4.4.1 Regulated or Unregulated Power Supply
Both regulated and unregulated power supplies can be used to supply the drive. However, unregulated power supplies are
preferred due to their ability to withstand current surge and fast response for current change. If you prefer to a regulated
power supply, it is suggested to choose such a power supply specially designed for stepper/servo controls such as Leadshine
RPS series (http://www.leadshine.com/producttypes.aspx?producttype=regulated-switching). Or, in the case when only
normal switching power supplies are available, it is important to use “OVERSIZE” high current output rating power supplies
(for example, using a 4A power supply for 3A stepper motor) to avoid problems such as current clamp. On the other hand, if
unregulated supply is used, one may use a power supply of lower current rating than that of motor (typically 50%~70% of
motor current). The reason is that the drive draws current from the power supply capacitor of the unregulated supply only
during the ON duration of the PWM cycle, but not during the OFF duration. Therefore, the average current withdrawn from
power supply is considerably less than motor current. For example, two 3A motors can be well supplied by one power supply
of 4A rating.
4.4.2 Power Supply Sharing
Multiple EM522-CAN drives can share one power supply to reduce cost, if that power supply has enough power capacity. To
avoid cross interference, connect each stepper drive directly to the shared power supply separately. To avoid cross
interference, DO NOT daisy-chain connect the power supply input pins of the Drivers. Instead connect them to power supply
separately.
4.4.3 Selecting Supply Voltage
The EM522-CAN is designed to operate within +20 - +50VDC voltage input. When selecting a power supply, besides
voltage from the power supply power line voltage fluctuation and back EMF voltage generated during motor deceleration
needs also to be taken into account. Ideally it is suggested to use a power supply with the output range of +24 - +48 VDC,
leaving room for power line voltage fluctuation and back-EMF.
Higher supply voltage can increase motor torque at higher speeds, thus helpful for avoiding losing steps. However, higher
voltage may cause bigger motor vibration at lower speed, and it may also cause over-voltage protection or even drive damage.

EM522-CAN Field bus Stepper Drive User Manual V1.0
11
Therefore, it is suggested to choose only sufficiently high supply voltage for intended applications.
4.5 Object Dictionary Introduction
Object Dictionary is an organized group of objects, which maps the stepper drive related parameters and variables.
Parameters of EM522-CAN can be configured via CAN to USB adaptor and Leadshine CANopen software or PLC &
controller & control card, use SDO communication mode to modify the drive parameters. Corresponding ESD file and
Leadshine CANopen software can be free download in Leashine official website: http://www.leadshine.com.
4.5.1 Common list objects
(1)Factory parameters
CANopen
Address
Parameter Name
Property
Default
Value
Range
Description
2000+00
Peak current
R/W/S
1000
100~maximum
current
Current Accuracy 100mA,
maximum current is due to peak
current output of drive (mA).
2001+00
Motor resolution
R/W/S
50000
200~51200
Required pulse for each rotation
circle of motor
2002+00
Stand-by time
R/W/S
500
100~10000
unit: ms
2003+00
Standby current
percentage
R/W/S
50
0~100
unit: %
2005+01
Digital output IO
function Selection
R/W/S
1
0~32768
1: Alarm output
4: Arrive output
16: Master station controls the
output port(set by 60FEH )
2008+00
ALM output
impedance setting
R/W/S
0
0/1
0: Optocoupler conduction
when alarm activated
1: Optocoupler shut off when
alarm activated
2013+00
Enable current
loop auto-tuning
R/W/S
1
0/1
0:Enable 1:Disable
2015+00
Current loop Kp
R/W/S
1000
200~32767
Only can be read when enable
auto-tuning, can be wrote when
disable auto-tuning
2016+00
Current loop Ki
R/W/S
200
0~32767
Only can be read when enable
auto-tuning, can be wrote when
disable auto-tuning
2020+00
Motor resistance
R/W/S
1000
1~20000
Unit: mOhms
2021+00
Motor inductance
R/W/S
1
1~6000
Unit: uH
2039+00
External position
amount high 16 bit
R
Received location instruction
accumulated value high 16bit
2040+00
External position
amount low 16 bit
R/W
Received location instruction
accumulated value low 16bit
2043+00
Speed reference
R
Unit: r/s
2051+00
Motor running
direction
R/W/S
0
0/1
0:Motor running direction is
constant

EM522-CAN Field bus Stepper Drive User Manual V1.0
12
1:Motor running direction
reverse
2056+00
Alarm detection
selection
(this parameter
Enable
over-current and
over-voltage by
default)
R/W/S
0x03
0~0xffff
Alarm detection selection:
1:Enable.0:Disable
bit0: Over-current (error code:1,
red LED flashes 1 time)
bit1:Over-voltage (error code:2,
red LED flashes 2 times)
bit2:EEPROM (error code:8,
red LED flashes 8 times)
bit11: Operational amplifier
fault (error code:9, red LED
flash 12 times)
2060+00
First anti-vibration
amplitude values
R/W/S
0
0~100
First low speed resonance point
inhibition amplitude values
2061+00
First anti-vibration
phase A
R/W/S
0
0~255
First low speed resonance point
inhibition phase A
2062+00
First anti-vibration
phase B
R/W/S
0
0~255
First low speed resonance point
inhibition phase B
2063+00
Second
anti-vibration
amplitude values
R/W/S
0
0~100
Second low speed resonance
point inhibition amplitude
values
2064+00
Second
anti-vibration
phase A
R/W/S
0
0~255
Second low speed resonance
point inhibition phase A
2065+00
Second
anti-vibration
phase B
R/W/S
0
0~255
Second low speed resonance
point inhibition phase B
2066+00
Third
anti-vibration
amplitude values
R/W/S
0
0~100
Third low speed resonance
point inhibition amplitude
values
2067+00
Third
anti-vibration
phase A
R/W/S
0
0~255
Third low speed resonance
point inhibition phase A
2068+00
Third
anti-vibration
phase B
R/W/S
0
0~255
Third low speed resonance
point inhibition phase B
2069+00
Fourth
anti-vibration
amplitude values
R/W/S
0
0~100
Fourth low speed resonance
point inhibition amplitude
values
2070+00
Fourth
anti-vibration
phase A
R/W/S
0
0~255
Fourth low speed resonance
point inhibition phase A
2071+00
Fourth
anti-vibration
phase B
R/W/S
0
0~255
Fourth low speed resonance
point inhibition phase B
2072+00
Z axis
anti-vibration
phase
R/W/S
0
0~255
Z axis low speed resonance
point inhibition phase

EM522-CAN Field bus Stepper Drive User Manual V1.0
13
2073+00
Motor
auto-running when
power on
R/W/S
0
0/1
0: Motor normal standby when
power on
1: Motor turns 30°and reverse
30 when power on, then
standby
2150+00
CAN ID high 2 bit
R/W/S
0
0~3
Slave station address:
Activate after repower
2151+00
CANopen baud
rate
R/W/S
0
0~7
0:1000kBit/sec
1:Invalid
2:500 kBit/sec
3:250 kBit/sec
4:125 kBit/sec
5:100 kBit/sec
6:50 kBit/sec
7:20 kBit/sec
2152+01
Digital input
IN1 function
selection
R/W/S
1
0~32768
1:Home signal
2:Positive limit
4:Negative limit
32768:Emergency stop
2152+02
Digital input
IN2 function
selection
R/W/S
2
0~32768
1:Home signal
2:Positive limit
4:Negative limit
32768:Emergency stop
2152+03
Digital input
IN3 function
selection
R/W/S
4
0~32768
1:Home signal
2:Positive limit
4:Negative limit
32768:Emergency stop
2153+01
Digital input
IN1 filter time
R/W/S
1000
50~60000
unit: us
2153+02
Digital input
IN2 filter time
R/W/S
1000
50~60000
unit: us
2153+03
Digital input
IN3 filter time
R/W/S
1000
50~60000
unit: us
2154+00
Level polarity of
digital inputs
IN1,IN2,IN3
R/W/S
0
0~7
0:Low level Optocoupler has no
input, port is in free status;
Optocoupler has no input , port
is in trigger status
1: High level Optocoupler has
no input, port is in trigger
status; Optocoupler has no
input , port is in free status
bit0: IN1 polarity setting;
bit1: IN2 polarity setting;
bit2: IN3 polarity setting.
2155+00
Digital input
IN1,IN2,IN3 level
R/W/S
0
0~7
Read input IO port polarity Low
3 bits corresponding external 3
input IO port
0:Three digital input
IN1,IN2,IN3 are low level
7:Three digital input
IN1,IN2,IN3 are high level

EM522-CAN Field bus Stepper Drive User Manual V1.0
14
60FD+00
Input port status
display
R
0
bit0: Negative limit;
bit1: Positive limit;
bit2: Home signal
bit3~bit15: Reserved;
bit16: Emergency stop
60FE+01/02
Output port status
display
R
0
When IO output function switch
to main station control, master
controller can use the
combination of 60FE+01 and
60FE+02 to control IO output:
When bit16 of 60FE+01and
60FE+02 are both "1",
OUTPUT1 have output
When bit17 of 60FE+01and
60FE+02 are both "1",
OUTPUT2 have output
and so on……
(EM522-CAN has only one
output port)
1010+01
Save configuration
R/W
Write 1702257011
(0x65766173) to save
configuration
1011+01
Reset to factory
R/W
Write 1684107116
(0x64616F6C ) to reset to
factory
2093+00
Eliminate
malfunction
records
R/W
Write 1 to eliminate alarm
records
!
Notice
Notes: (1) R/W/S means the parameter can be read/wrote/saved
4.5.2 Model and control
CANopen
Address
Name
property
Description
6040+00
Control word
R/W
Control the drive's status and operation
6041+00
Status word
R
Feedback current status of the drive
6060+00
Operational
mode
RW
1: Position mode
3: Speed mode
6: Homing mode
6061+00
Mode query
R
Check the operation mode of the drive
607A+00
Target
position
R/W
Target position under working mode 1
6064+00
The actual
position
R
The actual position

EM522-CAN Field bus Stepper Drive User Manual V1.0
15
6081+00
Maximum
speed
R/W
Maximum speed under working mode 1 (Position mode)
60FF+00
Target Speed
R/W
Target speed under working mode 3 (Speed mode)
606C+00
Actual speed
R/W
The actual speed of the motor, unit: p/s
6083+00
Acceleration
speed
R/W
Acceleration speed under working mode 1 (Position mode) and
working mode 3 (Speed mode), unit: p/s2
6084+00
Deceleration
speed
R/W
Deceleration speed under working mode 1 (Position mode) and
working mode 3 (Speed mode), unit: p/s2
6085+00
Deceleration
speed of
emergency
stop
R/W
Deceleration speed of emergency stop under all modes, unit:
p/s2
6098+00
Method of
back to home
position
R/W
Method of back to original point
6099+01
Speed1 of
back to home
position
R/W
Back to home position in high speed
6099+02
Speed1 of
back to home
position
R/W
Back to home position in low speed
609A+00
Acceleration
speed of back
to home
position
R/W
Acceleration speed of back to home position
607C+00
Home position
offset
R/W
Home position offset
EM522-CAN can running under PP(position mode),PV(speed mode)and Homing(Back to the original point mode), 3 modes
in total.(Specific protocol specification is in conformity with standard Canopen, specific operation can refer to
《DM-CAN series CANopen Technical instruction manual》)
