LED Group ROBUS R8EMLED User manual

The Installation must be carried out by an electrician
LED Group
Western Retail Park Tel: [phone]
Nangor Road Fax: [phone]
Dublin 12 Email: [email protected]
Ireland Website: www.led.ie
Page 1
ISO 9001:2008
Q UAL IT Y ASS U RED C O MPANY
Issue 1 281212
Information for the Product user
1. Please note the requirement to dispose of Waste Electrical & Electronic Equipment separately from household waste (WEEE
marked with crossed out wheelie bin symbol).
2. Please consider your role in contributing to re-use and recycling by returning this product at end of life to a collection centre
for waste electrical equipment or a Civic Amenity site, or to a retail outlet from which you are purchasing a replacement.
3. This equipment may contain substances that are hazardous to health and the environment if disposed of carelessly. It is
important that it is separated from normal household waste and recycled in the WEEE chain
4. The “crossed out wheelie bin symbol” on a product indicates this equipment must not be disposed of in normal household
waste, but should be disposed of according to local WEEE regulations
Specification:
Installation:
Model No. R8EMLED-01
Operating mode maintained and non-maintained
Lamp 12X0.15watt White LED Strip
Dimensions (L)390mm x (H)190mm x (D)60mm
Weight 1.4kg
Insulation Class I, Must be earthed
Supply voltage 220-240V~ 50/60Hz
Discharge Duration >3 hours after minimum 24Hr charge
Battery 3.6V x 1.8Ah Ni-Cd cells
Battery Life up to 4 years normal use
Operating ambient temperature 5°C ~ +25°C
Case materials Iron/ PC sign panel
Connection: Screw terminals
Suitable for mounting on a normally flammable surface
Green LED indicator indicates battery charging mode
Safety and performance in accordance with EN55015, EN61547,EN60598-1,
EN60598-2-22 , EN61000-3-2, EN61000-3-3
Suitable for Indoor use, wall mounted
! Electrical products can cause death or injury, or damage to property. If in any doubt about
the installation or use of this product, consult a competent electrician.
1. Ensure mains supply is switched off before commencing installation.
2. Remove front panel and metal panel on the side from the body.
3. Mark appropriate fixing points on wall; check that fixings will not impinge on
concealed cables of pipes before drilling holes.
4. Introduce supply cable. ( Normally, the emergency fitting must be
powered from the lighting circuit feed)
5. Fix luminaire to the wall/ceiling using suitable screws.
6. Write installation date on battery and connect battery
7. Connect wires from unswitched supply to terminals on gear tray, brown to L,Blue to N
and green/yellow to earth (Non Maintained)；In the maintained emergency unit: for
LEDs always on , link terminal “Ls” to terminal “L”,install control switch between Ls
and L.
Note: if both “Ls” terminal not connected, fitting works as non-maintained.
8. Refit appropriate panel.
9. Switch on supply: In the non-maintained unit the green LED should come on indicating
correct battery charge has started. The LEDs only lights if the mains supply fails.
In the maintained unit, the green LED will come on indicating correct battery charge
has started and the LEDs will lights (if switched live on). When supply to the
unswitched live is lost, battery will operate LEDs in emergency mode.
R8EMLED
LED Maintained Eixt Box,IP20,White
Please read instructions before commencing installation and
retain for future reference.

Testing:
Installer
Installation Type
Installation test duration & Date
5st Year
Signed Date
Signed Date
Signed Date
Signed Date
Signed
Month Test
Short
1
2
3
4
5
6
7
8
9
10
11
12
Short
Short
Short
Short
Short
Short
Short
Short
Short
1Hr.
1Hr.
3Hr.
Date
xxxxx xxxxx xxxxx xxxxx
xxxxx xxxxx xxxxx xxxxx xxxxx xxxxx
4st Year
3st Year
2st Year
1st Year
The Installation must be carried out by an electrician
LED Group
Western Retail Park Tel: [phone]
Nangor Road Fax: [phone]
Dublin 12 Email: [email protected]
Ireland Website: www.led.ie
Page 2
ISO 9001:2008
Q UAL IT Y ASS U RED C O MPANY
Installation and Maintenance Record:
The emergency lighting must be inspected and tested regularly in accordance with local
codes of practice: note: for safety reasons tests should be carried out during daylight
hours.
The minimum recommended test schedule is as follows:
After installation, allow 36 hours to ensure full battery charge and then interrupt the
supply; check after 3 hours that tube is still lighting.
1. Daily check that charge indicator LED is working
2. Monthly, interrupt mains for a short period and check LEDs light
3. Six-monthly, check 1 hour duration
4.At the end of year 3 and subsequently every year, check 3 hour duration: batteries
must be replaced when they can no longer support 3 hour operation.
5. Complete record sheet on installation and retain in maintainance file.
6. Update file with ongoing test records for inspection by fire officer or
other duly authorised person

Installation diagram:
The Installation must be carried out by an electrician
LED Group
Western Retail Park Tel: [phone]
Nangor Road Fax: [phone]
Dublin 12 Email: [email protected]
Ireland Website: www.led.ie
Page 3
ISO 9001:2008
Q UAL IT Y ASS U RED C O MPANY
Figure 5
To mains lighting
To additional em ergency lum inaires
Tamper proof test switch
non-maintained
emergency luminaire
Wiring Details
Non-maintained Installation
Tamper proof test switch
To mains lighting
To additional em ergency lum inaires
Maintained fluorescet
emergency luminaire
Maintained or sustained
installation (fluorescent)
mains lighting fuse
mains lighting fuse
Maintained lighting control switch
Ls
Figure 1
390mm
190mm
60mm
Figure 2
Figure 3 Figure 4
122mm
138mm
276mm
Red +
Black -
From
battery
LED indicator
E L LsN
SW
Non-maintained maintained
Blue
Brown
Y/G
E LN
Blue
Brown
Y/G
