WE-EF AFL100 Series User manual

Surge Protection
This product features built-in surge protection circuitry in compliance
with applicable standards.
For comprehensive protection of a luminaire installation against lightning
and electrical surges, it is essential to cover mains supply and data input
lines at the distribution board level, by using respective primary (Type 1)
and secondary (Type 2) surge arrestors in compliance with EN61643-11/
IEC61643-1.
Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this document for details.
Warning
Ensure that all required surge protection measures are in place and
activated prior to luminaire installation. Also, disconnect luminaires
before operating high-power devices such as, for example, electrical
arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Post Mounted Luminaires
AFL100 series

1
Post Mounted Luminaires
IP66. IK08. Class I, II. Tasee table in on page 5
602
37
65
191.
5
653
37
65
191.
5
683
11
1
733
11
1
250
ø 89
250
ø 89
300
ø 89
300
ø 89
Tool required
Torx 20, 45 5 mm Allen key
ø 9 – 14 mm 1 = 2.5 mm2
Mounting height 3 – 8 m
Installation: horizontal, light output downwards
The photometric data was measured at an incline of 2.5°.
AFL110
AFL120
AFL130
480
37
65
191.5
200
ø 89
200
ø 89
561
111

2
Light Source
LED
Maintenance
Apart from cleaning the product’s exterior surfaces, no special maintenance work is required.
Do not use high-pressure cleaners.
In case of component failure due to abnormal circumstances or at end of life, replacement must be carried
out by a suitably qualied and trained professional.
Warning: Do not open luminaire while mains supply is switched on.
Caution: Risk of electric shock!
Important: To clean the glass panel, we recommend isopropanol 99% diluted 1:1 with distilled water.
Installation
The product must be installed and maintained by a suitably qualied professional in compliance
with latest building/construction and/or electrical regulations and relevant legislation.
Warning: Switch o mains electrical supply prior to installing and connecting the luminaire.
Caution: Risk of electric shock!
Notice: If the luminaire is modied by anybody other than the original manufacturer, then the warranty
will no longer be valid and shall become the full responsibility of the modifying person/organisation.
Claims based on defects attributable to improper installation and/or application, and the consequences
thereof, are excluded.
Attention: The luminaire is factory-sealed and does not need to be opened during installtion.
The installation on site must comply with local and/or national health and safety regulations.
Weight kg
for AFL110 max. 4.70
for AFL120 max. 6.95
for AFL130 max. 8.60
Windage area m2
for AFL110 max. 0.092
for AFL120 max. 0.146
for AFL130 max. 0.191

3
B
M
M
I
J
B
Post top and Side entry
Attachment Mcan be mounted vertically or horizontally. To change position loosen fasteners J,
rotate by 180° and refasten.
For vertical mounting, attachment can be set at 0° or 2.5° by loosening screws J. For horizontal
mounting, attachment can be set at 0°, 2.5°, 5°, 7.5°, 10°, 12.5°, and 15°.
Adaptor (to be ordered separately)
Using adaptor K, diameter can be reduced from 76 mm to 60 mm or 42 mm.
Attach adaptor Kwith the fasteners Lto M. See below for position. When using adapter K, standard
fasteners BM10x10 must be replaced with fasteners M10x20 supplied with the adapter.
Mounting Position
D = 60 mm
Mounting Position
D = 42 mm
L
B
K
M

4
1) Switch o mains electrical supply.
Installation Procedure
2) Pull the connecting cable through the pole. Place the luminaire on top of the pole and tighten
fasteners B, tightening to a torque of 10 Nm.
Side entry Post top
ø 40-60 x 100*
B
ø 76 x 100
B
* ø 60 x 100 adaptor Kis required

5
3) Trim mains cable Eto the desired length and connect the leads to their respective terminals at
the base of the pole:
a) ON/OFF (L = Phase, N = Neutral, = Earthing)
b) BASIC (L1 = Phase 1, L2 = Phase 2,N = Neutral, = Earthing)
c) DALI (L = Phase, N = Neutral, = Earthing, DA/DA = DALI control line)
4) Table of maximum temperature AFL110, AFL120 and AFL130.
AFL110 - 8 LED
Power Ta
8 W 50 °C
12 W 50 °C
16 W 50 °C
24 W 50 °C
AFL120
Power Ta
24 W 50 °C
36 W 50 °C
48 W 50 °C
72 W 45 °C
AFL130
Power Ta
48 W 50 °C
72 W 50 °C
96 W 50 °C
114 W 45 °C
AFL110 - 16 LED
Power Ta
16 W 50 °C
24 W 50 °C
32 W 50 °C
48 W 50 °C
EC
B
