Ledj Aspect User manual

9W Red - LEDJ386
9W Green - LEDJ388
9W Light Blue - LEDJ390
9W Amber - LEDJ392
9W Cool White - LEDJ394
9W Warm White - LEDJ396
9W Deep Blue - LEDJ398
Order codes:
3W Red - LEDJ385
3W Green - LEDJ387
3W Light Blue - LEDJ389
3W Amber - LEDJ391
3W Cool White - LEDJ393
3W Warm White - LEDJ395
3W Deep Blue - LEDJ397
Aspect
Exterior Feature Lights
User Manual

www.prolight.co.uk Aspect Exterior Feature Lights User Manual 2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE YOUR INITIAL START-UP!
• Before your initial start-up, please make sure that there is no damage caused during transportation.
• Should there be any damage, consult your dealer and do not use the equipment.
• To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
• Please note that damages caused by user modications to this equipment are not subject to warranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and
the warranty becomes void. Incorrect operation may lead to danger e.g: short-circuit, burns and electric shocks etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and/or property.
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!
• Never let the power cable come into contact with other
cables. Handle the power cable and all mains voltage
connections with particular caution!
• Never remove warning or informative labels from the unit.
• Do not open the equipment and do not modify the unit.
• Do not connect this equipment to a dimmer pack.
• Do not switch the equipment on and off in short intervals,
as this will reduce the system’s life.
• Do not expose to ammable sources, liquids or gases.
• Always disconnect the power from the mains when
equipment is not in use or before cleaning! Only handle
the power-cable by the plug. Never pull out the plug by
pulling the power-cable.
• Make sure that the available mains supply voltage
is 240V AC, 50Hz.
• Make sure that the power cable is never crimped
or damaged. Check the equipment and the power
cable periodically.
• If the equipment is dropped or damaged, disconnect the
mains power supply immediately and have a qualied
engineer inspect the equipment before operating again.
• If your product fails to function correctly, stop use
immediately. Pack the unit securely (preferably in the
original packing material), and return it to your Prolight
dealer for service.
• Only use fuses of same type and rating.
• Repairs, servicing and power connection must only be
carried out by a qualied technician. THIS UNIT CONTAINS
NO USER SERVICEABLE PARTS.
• This lighting xture is for professional use only - it is not
designed for or suitable for household use. The product
must be installed by a qualied technician in accordance
with local territory regulations. The safety of the
installation is the responsibility of the installer. The xture
presents risks of severe injury or death due to re hazards,
electric shock and falls.
• Warning! Risk Group 2 LED product according to
EN 62471. Do not view the light output with optical
instruments or any device that may concentrate the beam.
• WARRANTY: One year from date of purchase.

www.prolight.co.uk Aspect Exterior Feature Lights User Manual 3
LEDJ 1m Exterior
Power cable
LEDJ 2m Exterior
Power cable
LEDJ 5m Exterior
Power cable
LEDJ 10m Exterior
Power cable
LEDJ 2m Exterior
UK Power cable
LEDJ 1.5m Exterior
Schuko Power cable
Order code:
LEDJ146
Order code:
LEDJ147
Order code:
LEDJ148
Order code:
LEDJ149
Order code:
LEDJ145
Order code:
LEDJ145A
Product overview & technical specications
This stylish, compact feature light has 3 x 1W/3W LEDs that produce a bright
beam of light to illuminate and highlight outdoor areas including gardens,
paths, foliage and forecourts. This IP65 rated xture comes in a die-cast alloy
housing and has IP rated power input/output trailing connections to allow
multiple units to be powered from a single cable run.
• 3 x 1W LEDs (3W Version)/
3 x 3W LEDs (9W Version)
• Beam angle: 35°
• IP rated 0.60m trailing power input
• IP rated 0.15m trailing power output
• Convection cooled
Aspect Exterior Feature Lights
Specications Aspect Exterior Feature Lights
3W Versions 9W Versions
Power consumption 4W 10W
Power supply 240V, 50Hz
Dimensions 110 x 85 x 89mm
Weight 0.5kg
Order codes LEDJ385 - 3W Red
LEDJ387 - 3W Green
LEDJ389 - 3W Light Blue
LEDJ391 - 3W Amber
LEDJ393 - 3W Cool White
LEDJ395 - 3W Warm White
LEDJ397 - 3W Deep Blue
LEDJ386 - 9W Red
LEDJ388 - 9W Green
LEDJ390 - 9W Light Blue
LEDJ392 - 9W Amber
LEDJ394 - 9W Cool White
LEDJ396 - 9W Warm White
LEDJ398 - 9W Deep Blue
0m 1m 2m 3m 4m 5m
35°
35° - Lux - 3W Versions
Red
Green
Light Blue
Amber
CW
WW
Deep Blue
35° - Lux - 9W Versions
Red
Green
Light Blue
Amber
CW
WW
Deep Blue
320
244
167
392
492
420
40
672
344
337
800
1020
952
84
80
61
41.8
98
123
105
10
168
86
84.3
200
254
238
21
35.6
27.1
18.6
43.6
54.7
46.7
4.44
74.7
38.2
37.4
88.9
113
106
9.33
20
15.3
10.4
24.5
30.8
26.3
2.5
42
21.5
21.1
50
63.5
59.5
5.25
12.8
9.76
6.68
15.7
19.7
16.8
1.6
26.9
13.8
13.5
32
40.6
38.1
3.36
IP65
01 - Bracket
02 - Bracket adjustment bolts
03 - IP rated 0.60m trailing power input
04 - IP rated 0.15m trailing power output
In the box: 1 x xture
& 1 x user manual
01 040302
89mm85mm
110mm

www.prolight.co.uk Aspect Exterior Feature Lights User Manual 4
Correct Disposal of this Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries
with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed of
with other household wastes at the end of its working life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please separate this from other
types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their
local government ofce, for details of where and how they can take this item for environmentally
safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product should not be mixed with other commercial wastes for disposal.
Technical specications
WEEE notice
Installation:
Installation must be completed by a qualied electrician in
accordance with all recognised local and national electrical and
construction regulations. Ensure the power is off during installation
and the power cannot unexpectedly reconnected. This xture is
IP65 rated - suitable for indoor and outdoor use, i.e. gardens,
entrances, garages, foliage and corridors. Not suitable for
immersion. Do not cover the light source or heat sink.
To avoid damage do not carry or let the xture hang by its wiring.
Suitable to be mounted on a stable solid surface e.g. concrete,
brick or wood. Connect to a suitable mains outlet using the
IP rated 0.60m power input trailing connection.
