Leggett & Platt Adjustable Base User manual

Adjustable Base
setup guide
Foldable Base
291-0081-B EDR15759 7/20
© 2020 Leggett & Platt, Inc. Adjustable Bed Group
CUSTOMER SERVICE toll free: [phone]

2
ALLOW FOR ENOUGH SPACE TO UNFOLD
BASE IN SETUP AREA.
NOTE
SETUP
READ ALL INSTRUCTIONS BEFORE USING.
ADJUSTABLE BASE IS HEAVY.
DUE TO RISK OF INJURY, TWO ADULTS
ARE REQUIRED TO HANDLE AND MOVE
ADJUSTABLE BASE.
WARNING
!
DO NOT DROP!
PINCH POINT WARNING!
TEAM
LIFT
STEP 1
Open the shipping carton. Carefully, lift adjustable base
out of shipping carton and place on clean surface.
STEP 2
Unfold base (FIGURE 1). Remove hardware box, leg box,
and protective plastic.
KEEP HANDS AND FINGERS CLEAR WHEN
UNFOLDING BASE.
WARNING
!
FIGURE 1
HARDWARE BOX
LEG BOX

3
STEP 3
Remove and dispose of plastic spacers from base frame
(FIGURE 2).
STEP 4
Cut all orange zip-ties (FIGURE 3). Set mattress
retainer (see FIGURE 3) aside. BE CAREFUL USING SHARP INSTRUMENTS. INJURY IS
POSSIBLE IF TOOLS ARE NOT USED PROPERLY.
CAUTION
!
FIGURE 2
MATTRESS RETAINER -
SECURED BY (2) ZIP-TIES
CHILDREN / PET CHOKING HAZARD!
REMOVE PLASTIC SPACERS FROM BASE FRAME.
WARNING
!
SETUP
FIGURE 3

4
SETUP
x1 - Mattress
Retainer
x2 - Center
Support
Brackets
x1 - Remote Control
(Varies according
to base type. Image
may not match actual
remote control.)
AAA Batteries*
(quantity &
type varies
according to
base type)
x1 - WRENCH
*Remote Control may have integral battery -
no battery install required
x4 - 3-Inch Carriage
Bolts and Nuts
REMOTE
x6 - Legs (leg type
may vary)
STEP 5
Verify contents; inspect for damage.

5
SETUP
STEP 6
A. Place a center support bracket over the mounting points on each side of base.
B. Insert carriage bolts through the square holes in the center support bracket.
Install nuts on carriage bolts (FIGURE 4). HAND TIGHTEN.
C. After all hardware is installed, tighten all nuts using provided wrench.
FIGURE 4
A
B
C

6
SETUP
STEP 7
Screw all legs into the threaded inserts (FIGURE 5). HAND TIGHTEN.
STEP 8
Extend power cord out head end of base. Remove protective covering
from power cord plug.
STEP 9
Rotate base over onto its legs.
FIGURE 5
HEAD
FOOT
If leg is
adjustable,
push pin in
to adjust leg
height.
HANDLE BASE BY FRAME ONLY. DO NOT
GRAB FABRIC.
DUE TO RISK OF INJURY, TWO ADULTS
ARE REQUIRED TO HANDLE AND MOVE
ADJUSTABLE BASE.
CAUTION WARNING
! !

7
SETUP
STEP 10
Install batteries in remote control, if applicable.
Plug power cord into power outlet. Note: An electrical
surge protection device is recommended (not included).
Operate remote control to test base functions.
See Remote Control User Guide for programming
instructions (FIGURE 6).
STEP 11
Lower base to at position.
STEP 12a (OPTIONAL)
Your base may be equipped with a Micro-Hook™ system to hold the mattress
in place (FIGURE 7), but a wire mattress retainer can still be used.
FIGURE 7
FIGURE 6
REMOTE USER GUIDE
MICRO-HOOK™
STRIPS

8
SETUP
STEP 13
Place mattress on base to complete assembly.
FIGURE 8
STEP 12b (OPTIONAL)
Insert the mattress retainer into the holes at the foot end of the base (FIGURE 8).
USB PORTS
Your base is equipped with USB ports on each side of the
base (at the head end). These USB ports are for charging
low-voltage devices such as cell phones and tablets
directly from the base.
USB ports are for charging convenience only. Remove
USB charging cord and/or power cord from USB charging
station before entering or exiting base. If an extended
charging period is needed, it is recommended to use the
wall outlet.
USE THE DEVICE MANUFACTURER RECOMMENDED
CHARGING CABLE TO CHARGE THE DEVICE. USING
UNAPPROVED CHARGING CABLES IS A FIRE
HAZARD.
WARNING
!
