Leggett & Platt Platinum 2000 Series User manual

MODEL NO
RETAIN FOR FUTURE
REFERENCE
SERIAL NO:
P-2000
Platinum SeriesPlatinum Series
Platinum SeriesPlatinum Series
Platinum Series
20002000
20002000
2000
ADJUSTABLE BED
WITH WALLHUGGER® ACTION
•Introduction
•Installation
•Operation
•Trouble Shooting
• Warranty
Manual Part Number:
99300487
1-04

1
WARNINGS
WARNING! IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE USING THIS PRODUCT.
Your Adjustable Bed has been totally engineered to provide you with reliability of operation and the strength
you deserve. The manufacturer has given each bed a thorough inspection and testing prior to shipment.
The utmost in comfort and safety has been provided for you. This bed is for HOME use only. It is NOT
designed for hospital use and was not designed to meet hospital standards. Do not use bed with TENT
TYPE oxygen therapy equipment, or near explosive gases.
GROUNDING SAFETY
This Adjustable Bed has a grounded plug (two flat blades and one round pin) as a safety feature to reduce
the risk of electric shock. The plug will only fit into a grounded outlet one way. If this plug does not fit into your
outlet, contact a qualified electrician and have them install a properly grounded outlet. NEVER REMOVE
THE GROUNDING PIN OR ALTER THE PLUG IN ANY WAY. Unauthorized modifications could void the
electrical portion of your warranty. The use of adapters is not recommended unless the outlet is checked
by a qualified electrician to ensure the proper grounding of the adapter. Failure to use a properly grounded
outlet for this product will compromise this important grounding safety feature and may result in electrical
shock, electrical fire, or faulty operation of the product. FOR BEST RESULTS, YOUR BED SHOULD BE
PLUGGED INTO A SURGE PROTECTOR (not supplied with this adjustable bed).
WARNING!
Do not open control box, motors or hand controls (with the exception of the battery compartment). The
warranty is void if these units are tampered with. Any repair or replacement of adjustable bed parts must
be implemented by an authorized person.
IMPORTANT SAFETY FEATURE
This Adjustable Bed is equipped with a special locking caster for your safety. In order to prevent the movement
of this product, all four casters should be locked in position. This may be accomplished by pushing down
the safety latch on the caster. To resume mobility of the product, lift up on the safety latch. You are strongly
encouraged to place rubber caster cups or carpet squares under the casters in addition to locking them in
place if the product is positioned on a hard surface floor such as hardwood, tile or linoleum. Although your
casters are locked and will not roll, they may slide. Note: To avoid damage to flooring, casters must
be installed before operating the bed. Failure to attach casters my void warranty.

2
WARNINGS
The recommended weight restrictions on our adjustable beds are as follows:
WEIGHT RESTRICTIONS:
Twin 300
Full 375
Queen 425
Note: Exceeding the recommended weight restrictions could damage your adjustable bed
and void your warranty.
For best performance, consumers should enter and exit the adjustable bed with the bed in the flat or
down position.
A note to consumers with pacemakers: As with any product that produces a vibrating motion, it is
possible that some pacemakers may interpret this motion as a false sense of movement and/or exercise.
This may or may not affect your pacemaker. If you have any concerns, please consult your physician.
The bed will structurally support the recommended weights when distributed uniformly across the entire
bed. This product is not desighed to support or lift this amount of weight in the head or foot sections alone.
RADIIO FREQUENCY IS 310 MHz.
WARNING: The transmitter and the receiver of the wireless control system have been tested and comply
with FCC and DOC/MDC rules. Changes or modifications not expressly approved be the party responsible
for compliance could void user’s authority to operate the equipment.
DO NOT SIT ON THE HEAD OR FOOT SECTION WHILE IT IS IN THE RAISED POSITION.

3
INSTALLATION
STEP 2
Insert casters into the caster sockets at the
bottom of each leg. If necessary, strike the
center of the caster lightly with a hammer.
NOTE: To avoid damage to flooring,
casters must be installed before
operating the bed. Failure to attach
casters may void warranty.
STEP 1
Remove and discard the packing materials from the bottom of the base unit. You will see the mattress
retainer bracket and headboard brackets attached to the side rail of the bed. Remove these items and
set aside for the moment. Remove bagged parts and the power cord from the underside of the bed.
HEADBOARD BRACKET
MATTRESS RETAINER BRACKET

4
INSTALLATION
STEP 3
Lift the base unit from the carton and, keeping the unit
top-side-down, place it on a raised surface such as the
mattress. Remove the four bolts at the foot end of the
bed and attach the mattress retainer..See Figure 1.
The mattress retainer must be used or the mattress will
slide off the end of the bed when the head is raised.
If this product is not going to be attached to a headboard, omit Step 4 and Step 6.
STEP 4
Attach the headboard brackets per instructions on Page 5. Brackets must be attached to allow a one inch
space between the mattress and headboard (FAILURE TO FOLLOW THESE GUIDELINES MAY CAUSE
THE HEADBOARD BRACKET TO INTERFERE WITH THE BASE FOAM WHEN THE HEAD SECTION
IS BEING ELEVATED. THIS WILL CAUSE DAMAGE TO THE BASE FOAM AND/OR BASE COVER).
Note: When attaching twins to a king size headboard, it is only necessary to prepare the outside brackets
for use, See Figure 2.
FOR TWIN FOR KING
STEP 5 WARNING: Power cord must not
interfere with any of the adjustable bed mechanisms.
Carefully turn the entire base assembly over so
that it is resting on its casters. Remove protective
covering from the base unit. Unpack the mattress
and place it on the base unit. Dispose of all plastic
packing material.
STEP 6 Attach the headboard to the brackets. WARNING:
To avoid potential injury, position the headboard with a
distance of 3 inches or less between the headboard and
the top of the mattress; See Figure 3.
STEP 7 Plug the adjustable bed power cord into
electrical outlet. You are strongly encouraged
to plug your unit in to a Surge Protector.
FIGURE 1
FIGURE 2
FIGURE 3

5
INSTALLATION
HEADBOARD BRACKET
ASSEMBLY INSTRUCTIONS
Assemble headboard brackets for full or queen size bedding as shown in Detail A. Headboard brackets
for twin size bedding do not require assembly.
DETAIL A
FULL SIZE
QUEEN SIZE
DETAIL B
Slide headboard bracket assembly between the metal frame and the wood trim panel. Position brackets
to allow a one inch space between the mattress and the headboard. Attach brackets to the frame as
indicated in Detail B.

OPERATION
P-2000 OPERATING INSTRUCTIONS
Head Massage Arrow Buttons:
Slowly increases or decreases
speed of the massager as long as
the appropriate button is pressed.
Massage Set Button:
Once desired settings of the
massagers and wave have been
activated, press this button to save
those settings for the Favorite
Massage Button.
Head Up/Down Rocker Switch:
Adjusts the head section of the bed
to the desired position.
Head Massage On/Off Button:
Turns massager on or off. When turned
on, the massage has an automatic shut
off timer of 30 minutes.
Wave Arrow Buttons:
Once one or both massagers are
activated, this button turns the wave
feature on or off.
Wave On/Off Button:
These buttons increase or decrease
the speed of the wave feature as
long as the appropriate button is
pressed.
Foot Massage Arrow Button:
Slowly increases or decreases
speed of the massager as long as
the appropriate button is pressed.
Foot Up/Down Rocker Switch:
Adjusts foot section of the bed to the
desired position.
Foot Massage On/Off Button:
Turns massager on or off. When
turned on, the massage has an
automatic shut off timer of 30
minutes.
6
Transmission Indicator Light:
Verifies a button is being pressed.
AUTO LEARN FEATURE: This feature is used to reprogram your remote, or to program a new remote.
Unplug the bed from the wall, then plug it back in. Press and hold the POS1 button and the Head Massage
ON/OFF buttons on the remote. The transmission light will flash slowly and then flash rapidly. Continue to
hold for 2 seconds and then release. The code for the new hand control has been learned.
REQUIRES FOUR (4) “AAA” BATTERIES
Flat Button:
Massagers will turn off and the
bed will move to the flat position.
Position Buttons: (see note below)
Automatically moves bed to the preset
position from any other setting. To stop
the bed while in motion, press and hold
any button until the bed stops.
Favorite Massage Button:
Press and hold this button to turn on
massager to the programmed setting.
FOR RADIO FREQUENCY AND FCC INFORMATION, SEE PAGE 2.
NOTE: The POS1, POS2 and POS3 buttons are not programmable. They are preset
and can not be changed.

TROUBLE SHOOTING
ELECTRICAL
If the bed does not operate:
•Check the power cord to see that it is securely plugged into the electrical outlet.
•Check the outlet by plugging in a lamp or another electrical device.
•Replace batteries in the remote hand control.
•Perform the Auto Learn Feature outlined on your Remote Operation page.
•If bed still does not work, contact:
Leggett & Platt
Warranty Service Department
P.O. Box 140
Linwood, NC 27299
1-800-888-3078
FOR BEST RESULTS, YOUR BED SHOULD BE PLUGGED INTO A SURGE PROTECTOR.
NOISE CONCERNS
Because of the free fall safety design, the wheels of the lift arm should come into contact with the platform
boards slightly to place tension on the mechanism and reduce a potential noise problem.
The level of noise emitted in most cases is directly proportional to the acoustics of the room where the bed
is placed. Thus, when a bed is on a hardwood floor and the massagers are running, it will transmit the noise
and sound like a base drum. To minimize this noise, place a piece of carpet or a rubber caster cup under
each caster. (Rubber caster cups can be purchased at your local dealer or by calling Customer Service at
1-800-888-3071.)
When the bed is operated, there will be a harmonic hum from the lift motors. This is normal.
LUBRICATION
The lift motors are permanently lubricated. No additional lubrication will ever be required.
Do not apply lubricant to the lift motor lead screw or to the nylon nuts. Any lubrication to these parts may
cause your bed to creep down from the elevated position.
7
Please have your Model Number, Serial Number and Date Of Purchase available when
calling. If possible, please be in the same location as the bed before calling.

8
WARRANTY
LEGGETT & PLATT 20-YEAR LIMITED WARRANTY
Leggett & Platt, Incorporated (“L&P”) warrants this P-2000 Bed to the consumer who is the original purchaser
(the “Purchaser”), subject t o the terms and conditions set forth herein. This warranty begins on the “warranty
commencement date” which is the date of purchase for new, unused beds and the date of manufacture for
beds that have been used as floor or display models. [Thus, on a floor model bed, the warranty is a portion
of the limited 20-year warranty.]
FULL ONE-YEAR WARRANTY
This P-2000 Bed is warranted against defects in the workmanship or materials for a period of one year
from the warranty commencement date. Upon notice during the first year after the warranty Commencement
date, L&P will repair or replace at no cost to the Purchaser any defective P-2000 part, and L&P will pay all
authorized labor and transportation costs associated with the repair or replacement of any parts found to be
defective.
LIMITED FIVE-YEAR WARRANTY
During the second through the fifth years from the warranty commencement date, upon receipt of notice,
L&P will replace any P-2000 part found to be defective. This limited five year warranty shall not apply
unless the defective part is returned to L&P within ten (10) days of Purchaser’s receipt of the replacement
part. Purchaser shall pay all service and transportation costs related to the replacement of the defective
part.
LIMITED TWENTY-YEAR WARRANTY
Upon notice during the sixth through the twentieth years from the warranty commencement date, L&P will
replace, upon terms and conditions set forth in this paragraph, any P-2000 part found to be defective.
Purchaser shall pay 1/180 of the then current replacement cost of the defective part multiplied by the
number of months after five (5) years from the warranty commencement date, and L&P shall bear the
remainder of the cost of the replacement part. This twenty (20) year warranty shall not apply unless the
defective part is returned to L&P within ten (10) days of Purchaser’s receipt of the replacement part.
Purchaser shall pay all service and transportation costs related to the replacement of the defective part.
After the twentieth year, Purchaser shall bear the entire cost of repair and replacement of all parts and
materials, including labor and transportation.
ADDITIONAL TERMS AND CONDITIONS
This warranty does not apply; (a) to any damage caused by the Purchaser; (b) if there has been any repair
or replacement of P-2000 parts by an unauthorized person; (c) if the P-2000 has been mishandled (whether
in transit or by other means), subjected to physical or electrical abuse or misuse, or otherwise operated in
any manner inconsistent with the operation and maintenance procedures outlined in the Owner’s Manual
and this warranty; (d) to damage to mattresses, fabric, cables, electrical cords or items supplied by dealers.
[Contact the dealer for warranty information on these items.]; (e) if there has been any modification of the
P2000 without prior written consent by L&P; (f) to costs for unnecessary service calls, including costs for in
home service calls solely for the purpose of educating the consumer about the P-2000 or for finding a
satisfactory power connection; (g) if the recommened weight restrictions are not followed (300-Twin; 375-
Full; 425-Queen), the warranty will be void.

9
WARRANTY, Continued
The decision to repair or to replace defective parts under this warranty shall be made, or cause to be made,
by L&P at its option and in its sole discretion.
REPAIR OR REPLACEMENT SHALL BE THE SOLE REMEDY OF THE PURCHASER. THERE SHALL
BE NO LIABILITY ON THE PART OF L&P FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES OR FOR ANY OTHER DAMAGE, CLAIM, OR LOSS NOT EXPRESSLY
COVERED BY THE TERMS OF THIS WARRANTY.
This Limited Warranty does not include reimbursement for inconvenience, removal, installation, set up time,
loss of use, shipping, or any other costs or expenses. Leggett & Platt or its ServiceTechnicians shall not be
responsible for moving furniture, removing headboards and footboards or any other items in order to perform
service on your adjustable bed. It is the sole responsibility of the customer to provide adequate space and
accessibility to the Adjustable Bed. In the event that the technician is unable to perform service due to lack
of accessibility, the service call will be billed to the consumer and the service will have to be rescheduled.
THERE ARE NO UNDERSTANDINGS, TERMS, CONDITIONS OR WARRANTIES NOT FULLY
EXPRESSED HEREIN. L&P MAKES NO OTHER WARRANTY WHATEVER, EXPRESS OR IMPLIED,
AND ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE ARE DISCLAIMED BY L&P AND EXCLUDED FROM THIS AGREEMENT.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to every Purchaser.
This warranty gives the Purchaser specific legal rights, and the Purchaser may also have other rights, which
may vary from state to state. This warranty is valid in all 50 states and Puerto Rico.
All claims and correspondence under this warranty shall be made to:
Leggett & Platt, Incorporated
Warranty Service Department
P.O. Box 140
Linwood, NC 27299
1-800-888-3078
Repairs to or replacement of a P-2000 bed or its components under the terms of this Limited Warranty will
apply to the original warranty period and will not serve to extend such period.

For All Service Questions and Problems,
Call: 1-800-888-3078
Do not call your retail dealer or any other service person.
Manual Part Number:
99300487
1-04
MODEL NO:
Platinum SeriesPlatinum Series
Platinum SeriesPlatinum Series
Platinum Series
20002000
20002000
2000
ADJUSTABLE BED
WITH WALLHUGGER® ACTION
P-2000
This model number will be found on the decal which is attached to the
main frame rail under the headboard. Always mention the model
number when requesting repair parts.
WHEN ORDERING PARTS OR REQUESTING SERVICE
ASSISTANCE, PLEASE HAVE THE FOLLOWING
INFORMATION READY:
•THE PART DESCRIPTION
•THE MODEL NUMBER - LAB 6
•THE NAME OF THE ITEM - P2000
•THE SERIAL NUMBER- Also located on front cover
of this manual.
