Leggett & Platt Falcon 2.0+ User manual

LPAdjustableBases.com
owners manual
Y-120 Falcon™2.0+

Advisory...................................................................................................................... 4
Acoustics.................................................................................................................... 6
Installation ................................................................................................................. 7
Remote Control Function............................................................................................ 11
Remote Control Programming ..................................................................................... 12
Power Down Operation ............................................................................................... 15
Troubleshooting ......................................................................................................... 18
Accessories ............................................................................................................... 19
Warranty ................................................................................................................... 20
CONTENTS
If adjustable base does not operate or if parts are missing, call:
[phone]

Falcon™ 2.0+ Owners Manual 290-0009-b
4
IMPORTANT INFORMATION
ELECTRICAL GROUNDING
This product is equipped with a polarized or
grounded electrical power cord. The power cord will
only fit into a grounded, electrical surge protection
device (not included) or a grounded electrical outlet.
WARRANTY WARNING
Do not open any control boxes, motors or remote
control devices (with the exception of the remote
control battery compartment). The product warranty
will be void if these components are tampered with.
Do not attempt to alter component wiring or adjust
or modify the structure of the product in any way or
the warranty will be void. Any repair or replacement
of base parts must be performed by authorized
personnel.
LUBRICATION
This product is designed to be maintenance free.
The lift motors are permanently lubricated and
sealed—no additional lubrication is required. Do not
apply lubricant to lift motor lead screws or any nylon
nuts or the base may inadvertently creep downward
from the elevated position.
PRODUCT RATINGS
The base lift motors are not designed for continuous
use. Reliable operation and full life expectancy will
be realized as long as the lift motors do not operate
any more than five (5) minutes over a thirty (30)
minute period, or approximately 15% duty cycle.
Note: Massage equipped bases are not designed for
continuous, extended massage operation. Massage
systems are rated for a maximum of 2 hours of
use within any 6 hour period. Any attempt to
circumvent or exceed product ratings will shorten
the life expectancy of the product and may void the
warranty.
The recommended weight restrictions for these
adjustable bases is 850 lb (385 kg) all sizes. The
base will structurally support the recommended
weight distributed evenly across the head and foot
sections. This product is not designed to support
or lift this amount in the head or foot sections
alone. Note: Exceeding the recommended weight
restrictions could damage the base and void the
warranty. Depending on the size and/or model of
mattress, the available weight capacity may be less.
For best performance, consumers should enter and
exit the adjustable base with the base in the flat
(horizontal) position. DO NOT SIT ON THE HEAD OR
FOOT SECTIONS WHILE IN THE RAISED POSITION.
Motors and electronics have been ETL tested to UL
(Underwriters Laboratories) standard UL962.
CFR 1633 approved for use with most mattresses.
Assembled in USA.
ADVISORY
READ THE FOLLOWING INFORMATION CAREFULLY BEFORE USING THIS PRODUCT
ELECTRICAL RATING
Electrical components are rated for 110/120
voltage, 60Hz, 3.9 amp.
FOR OPTIMUM ADJUSTABLE BASE
OPERATION, USE A GROUNDED, ELECTRICAL
SURGE PROTECTION DEVICE (NOT
INCLUDED). FAILURE TO USE A SURGE
PROTECTION DEVICE COULD COMPROMISE
SAFETY OR CAUSE PRODUCT MALFUNCTION.
READ ALL INSTRUCTIONS BEFORE USING

5
Falcon™ 2.0+ Owners Manual 290-0009-b
ADVISORY
READ THE FOLLOWING INFORMATION CAREFULLY BEFORE USING THIS PRODUCT
IMPORTANT INFORMATION
PACEMAKER WARNING
This product produces a vibrating sensation.
It is possible that individuals with heart-assist
pacemakers may experience a sensation similar to
exercise. Consult physician for complete information.
SMALL CHILDREN / PETS WARNING
After the base is unboxed, immediately dispose of
packaging material as it can smother small children
and pets. To avoid injury, children or pets should not
be allowed to play under or on the base. Children
should not operate this base without adult supervision.
HOSPITAL USE DISCLAIMER
This base is designed for in-home use only. It is
not approved for hospital use and does not comply
with hospital standards. Do not use this base with
tent type oxygen therapy equipment, or use near
explosive gases.
SERVICE REQUIREMENTS
Service technicians are not responsible for moving
furniture, removing headboards and footboards
or any items required to perform maintenance on
the base. In the event the technician is unable to
perform service due to lack of accessibility, the
service call will be billed to the purchaser and the
service will have to be rescheduled.
FCC COMPLIANCE
The equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when the equipment
is operated in a residential environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to radio
or television reception, which can be determined
by turning off the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
- Reorient or relocate the receiving antenna
- Increase the separation between the
equipment and receiver.
- Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
Radio Frequency = 433MHz.
