Congratulations on your new LEGO® MINDSTORMS® NXT robotics tool set. You
now have the power to build and program robots that do what you want!

Your MINDSTORMS NXT set enables you to create thousands
of robotic inventions. Intelligent robots that can see, speak,
feel and move. Cool robots that guard your room and do your
chores. If you can dream it, you can build it!

Creating a MINDSTORMS robot is easy. Build the robot using
your LEGO elements. Program it using the easy-to-use soft-
ware and watch your robot come alive. For your rst robotic
adventure, try out the quick-build model that you can build
and program in less than 30 minutes.

Your MINDSTORMS NXT set features the latest in robotic technology: an
advanced 32-bit programmable microcontroller; icon-based drag-and-drop
programming software and interactive challenges; smart sensors and Inter-
active Servo Motors; wireless Bluetooth and USB connection. In fact, all the
smart technologies you need to create your dream robot.

You are now a part of the worldwide LEGO MINDSTORMS community. Log on
to MINDSTORMS.com and get more robotic challenges. Download programs,
sound effects and other cool stuff. Share your inventions and exchange tips
and tricks with other MINDSTORMS users.
www.MINDSTORMS.com is your new robotic hot spot.

In this User Guide you can learn more about the technology
and the many exciting features in your MINDSTORMS set.
Have fun building your own amazing robots!
The LEGO MINDSTORMS team.

Steven


 
 

  
  
  
  
  
  
  
  
  
  

  
  
  
  
  
  
  
  
  
  
  

  
  
  
  






Build a robot. You can nd building
instructions for this model (Quick Start
model) in this User Guide, in the soft-
ware or at www.MINDSTORMS.com. Or
you can use your imagination to build
your own unique robot.


Program your robot to do what you
want. Use the LEGO® MINDSTORMS® NXT
Software to create a program. Down-
load the program to the NXT by using
the USB cable or the wireless Bluetooth
connection.

Run the program and watch your robot
come to life.

Use the Quick Start kit to get your rst
MINDSTORMS experience. In the Quick
Start kit you will nd everything you
need to get off to a great start. It will
only take you a few minutes to create
your rst MINDSTORMS robot, test it,
and get a fun reaction.
The building instructions for your rst
robot starts on page 5 (opposite).
udsnit?


?
2
1x 1x1x 1x
2
1
1
1x 2x
New
Bag


3
1x 1x 1x 1x
4
2x
2
1
1:1


5
2x
2x
2x
6
2x1x
1
2
2x
1:1
1:1


7
2x12x2x
2x
1 2


9
2x4x2x
1:1
8
2x
2x2x
2x


10
4x 2x2x
11
1x
1x 1:1


13
2x 2x1x
12
2x4x


14
4x
15
2x 4x


17
1x2x 2x
1x 1x 1x
16
1x
2x 2x
1x 1x1x
1 3
2 4
1 3
2 4


18
1x
19
4x2x
2x


3x
35 cm
20




The NXT is an intelligent, computer-controlled
LEGO® brick and the brain of the MINDSTORMS® robot.


Enables the robot to feel and react to
its environment.

Enables the robot to detect colors and light.
Can also be used as a color lamp.





Enables the robot to see, measure
distance to an object, and react to
movement.

Ensure that the robot moves with precision.


To make your robot work correctly, the sensors and
motors should be connected to specic input and out-
put ports. Here are the standard port settings:
Input ports
Port 1: Touch Sensor
Port 2: Touch Sensor
Port 3: Color Sensor
Port 4: Ultrasonic Sensor
Output ports
Port A: Motor used for an extra function
Port B: Motor for movement
Port C: Motor for movement

Effects

  
   




To connect a motor to the NXT, use one of the black 6-wire
cables. Attach one end of the cable to the motor and the other to
one of the NXT’s output ports (A, B, or C).

To connect a sensor to the NXT, use one of the black 6-wire
cables. Attach one end of the cable to the sensor and the other
to one of the NXT’s input ports (1, 2, 3, or 4).

The USB port and wireless Bluetooth connection let you download and
upload data between your computer and the NXT. If your computer has
Bluetooth capability, you can download programs to the NXT without using
the USB cable. If your computer does not have Bluetooth capability, you
must use the USB cable or install a Bluetooth USB dongle on your computer.
NOTE: Read more about wireless Bluetooth communication on page 36.
Note that ALL of the black 6-wire
cables can be used in both input
and output ports, sensors and
motors. To work, sensors MUST be
attached to the input ports (1-4)
and motors MUST be attached to
the output ports (A-C).




 



Turn on the NXT.
Connect the PC and the NXT with the USB cable.
When the PC identies the NXT it will automatically nalize the
installation of the LEGO MINDSTORMS NXT Software.
The USB connection must be made by an adult or under
supervision of an adult.

Make sure that the LEGO MINDSTORMS NXT Software is installed before connecting your NXT to
your Macintosh (see page 47).
Turn on your NXT.
Connect the USB cable to the NXT.
Connect the USB cable to the Macintosh and you’re ready to go.
Make sure that the
LEGO® MINDSTORMS® NXT
Software is installed before
connecting your NXT to your PC
(see page 46).





The NXT is the brain of a MINDSTORMS® robot. It’s an intelligent,
computer-controlled LEGO® brick that lets a MINDSTORMS robot come
alive and perform different operations.
Please note that all text on the NXT display is in English.

The NXT has four input ports for attaching sen-
sors. The sensors need to be attached to port 1,
2, 3 or 4.

Connect a USB cable to the USB port and down-
load programs from your computer to the NXT (or
upload data from the robot to your computer).
You can also use the wireless Bluetooth connec-
tion for uploading and downloading.

When you connect your NXT to a computer with
a USB cable, a USB icon will be displayed. If you
disconnect the USB cable, the icon will disappear.

The Bluetooth icon shows the current status of
any wireless Bluetooth connections. If there is no
Bluetooth icon shown, Bluetooth is OFF.
Bluetooth is ON but your NXT is not visible to
other Bluetooth devices.
Bluetooth is ON and your NXT is visible to other
Bluetooth devices.
Bluetooth is ON and your NXT is connected to a
Bluetooth device.
USB connected and working ne.
USB connected but not working properly.

The NXT has three output ports for attaching
motors. To make the motor work, the motors
need to be attached to port A, B or C

